FoxESS A022KP1-E1-R User manual

FoxESS EV Charger
User Manual
Please read the product manual prior to installation to prevent improper operation.

Table of Contents
1. Notes on This Manual ................................................................................................1
1.1 Scope of Validity ............................................................................................... 1
1.2 Target Group .....................................................................................................1
1.3 Symbols Used .................................................................................................. 1
2. Safety ......................................................................................................................... 2
3. Packing List ................................................................................................................3
4. Introduction ................................................................................................................ 4
5. Technical Data ........................................................................................................... 5
6. Charger installation ....................................................................................................6
6.1 Product Handling ..............................................................................................6
6.2 Out of the box inspection ................................................................................. 6
6.3 Install ................................................................................................................ 6
7. APP download ........................................................................................................... 9
8. Operation ................................................................................................................. 10
8.1 Charger Status Indicators .............................................................................. 10
8.2 Charging mode and Operation .......................................................................11
9. Maintenance ............................................................................................................ 13
10. Decommissioning .................................................................................................. 14
10.1 Dismantling the charger ............................................................................... 14
10.2 Packaging .....................................................................................................14
10.3 Storage and Transportation ..........................................................................14

1
1. Notes on This Manual
1.1 Scope of Validity
This manual describes the assembly, installation, commissioning, maintenance and troubleshooting
of the following model(s) of Fox products:
A022KP1-E1-R
A022KP1-E1-B
A022KP1-E1-S
A022KP1-E2-R
A022KP1-E2-B
A022KP1-E2-S
A022KS1-E1-R
A022KS1-E1-B
A022KS1-E1-S
A022KS1-E2-R
A022KS1-E2-B
A022KS1-E2-S
Note: Please keep this manual where it will be accessible at all times.
1.2 Target Group
This manual is for qualified electricians. The tasks described in this manual only can be performed
by qualified electricians.
1.3 Symbols Used
The following types of safety instructions and general information appear in this document as
described below:
Danger!
“Danger” indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
Warning!
“Warning” indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
Caution!
“Caution” indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
Note!
“Note” provides important tips and guidance.

2
Symbols
Explanation
Symbol Explanation CE mark. The charger complies with the requirements of the
applicable CE guidelines.
Beware of hot surface. The charger can become hot during operation. Avoid contact
during operation.
Danger of high voltages.
Danger to life due to high voltages in the charger!
Danger.
Risk of electric shock!
Read the manual.
Product should not be disposed as household waste.
2. Safety
FoxESS EV chargers are designed and tested in accordance with international safety requirements.
However, certain safety precautions must be taken when installing and operating this. The installer
must read and follow all instructions, cautions and warnings in this installation manual.
-All operations including transport, installation, start-up and maintenance, must be carried out
by qualified, trained personnel.
-The electrical installation & maintenance of the charger shall be conducted by a licensed
electrician and shall comply with local wiring rules and regulations.
-Before installation, check the unit to ensure it is free of any transport or handling.Unauthorized
removal of necessary protections, improper use, incorrect installation and operation may lead
to serious safety and shock hazards or equipment damage.
-Do not install the equipment in adverse environmental conditions such as in close proximity to
flammable or explosive substances; in a corrosive or desert environment; where there is
exposure to extreme high or low temperatures; or where humidity is high.
-Do not use the equipment when the safety devices do not work or are disabled.
-Use personal protective equipment, including gloves and eye protection during the installation.
-Inform the manufacturer about non-standard installation conditions.
-Do not use the equipment if any operating anomalies are found. Avoid temporary repairs.
-All repairs should be carried out using only approved spare parts, which must be installed in
accordance with their intended use and by a licensed contractor or authorized FoxESS service
partner.
-Liabilities arising from commercial components are delegated to their respective manufacturers.

3
3. Packing List
Object
Name
Qty
A
Charger
1
B
Mounting backplane
1
C
Mounting bracket
1
D
RFID card
2
E
Expansion tube
4
F
Expansion screw
4
G
Screw
5
H
Tubular terminal
5

4
4. Introduction
Socket version
Plug version
Plug version
Emergency stop button
Stop switch in Plug and
Charge mode
Credit card area
Charging socket
Status
indicator
light
Side cover
Leakage
protection
switch
COM
IN
Emergency stop button
Leakage
protection
switch
Stop switch in Plug and
Charge mode
Credit card area
Side cover
IN
COM
Status
indicator
light
Charging socket

5
5. Technical Data
Model
A022K
General
Name
AC Charger
Input
Input line
3P+N+PE
Rated voltage
400Vac，±20%
Rated current
32A
Rated frequency
50/60Hz
Output
Output voltage
400Vac，±20%
Maximum output current
32A
Rated power
22kW
Interaction method
Charging connection method
With cable/socket
Card reader
Mifare ISO/IEC 14443 A
Start-up mode
Plug and Charge/RFID Card/APP
Communication method
Bluetooth
Yes
WiFi
Yes
Using environment
Installation method
Wall mounting/column mounting
Working temperature
-30°C ~50°C
Working humidity
5%-95% no condensation
Altitude
≤2000m
Size and weight
Size
480*275*180 mm
Weight
6.5kg(socket),8.8kg(plug)
Safety
Waterproof rating
IP65
Anti-collision grade
IK08
Type A RCD
6mA DC
Protection function
Over-current protection, grounding protection,
lightning protection, over-voltage protection,
under-frequency protection, over temperature
protection
Certification
CE/UKCA
Certification standard
EN/IEC 61851-1: 2019, EN/IEC 61851-21-2: 2018

6
6. Charger installation
6.1 Product Handling
To ensure safety, the following points should be paid attention to:
-All accessories are placed separately during transport or handling.
-Avoid violent shock and impact, and take it lightly.
-Avoid inversion.
6.2 Out of the box inspection
-Open the charging pile packaging, please check the random attachment according to the
attachment list.
-Check the charging pile for damage in transport. If damage or missing parts are found, do not
boot up and inform the carrier and dealer. Determine if this machine is the model that you want
to purchase.
Note: Please keep the packing boxes and packaging materials for future handling.
6.3 Install
•Pre-installation preparation
The following tools are required for the installation:
Cross screwdriver, special plum screwdriver, stripping pliers, pressing pliers.
•Installation precautions
Please strictly follow the wiring requirements and correct access. Please confirm that all
fasteners are locked to secure the charging pile.
•Installation placement environment and location
-The area where the charger must be placed must be well ventilated, far away from water,
combustible gas and corrosive agent.
-Ensure that the ground or installation platform can withstand the weight of the charger.
-If the charger is disassembled and used at low temperature, there may be water droplets
condensation phenomenon, be sure to wait for the charger inside and outside completely dry.
After dryness can be installed and use, otherwise there is a danger of electric shock.
-Please place the charger near the mains input to disconnect the mains input switch and cut off
the power supply in an emergency.
Note: The actual installation needs to comply with local installation requirements and local safety
regulations.
Ensure that the wall or column is vertical or positive 15 ° before installation.
Vertical Front Tilt Back Tilt Flat

7
•Wall-mounted installation method:
1. Open the package and mark 4 holes in the wall (φ 8 * 50mm).
2. Fit into the expansion tube.
3. Attach the mounting backplane with screws to the mounting wall.
4. Attach the bracket to the charger.
5. Hang the charger into the mounting back plate and screw it.
6. Installation completed.
Note: Installation wall angle 90°±15，thickness > 50mm
①
②
③
④
⑤
⑥

8
•Floor type / Vertical installation method:
1. Drill holes on the cement floor，four holes with diameter φ 10mm deep 50mm screws and one
φ 60mm through duct hole.
2. Install and fix the anchor screws.
3. The input line runs through the column hole through the bottom of the column.
4. Install the backplane is fixed to the landing column with screws.
5. Attach the bracket to the charger.
6. Hang the charger into the mounting back plate and screw it well.
7. Installation completed.
Note: The angle of cement ground 90°±15
①
②
⑦
③
④
⑤
⑥

9
Electrical Connection
Step 1: Peel five L1, L2, L3, N and PE copper 16mm with wire stripping pliers, and press L1, L2, L3,
N, PE and tube terminals with terminal pliers.
Step 2: Loosen the screw nut and puncture the hole.
Step 3: Open the side cover, load the cable (13-18mm) and tighten the gram head.
Step 4: Unscrew the terminal screws. Link L.N.PE line lock the terminal screw, lock the side cover.
Note：choose7~9 AWG five core wire
①
②
③
④
7. APP download
Users can scan the QR code (Android and IOS ) in the quick installation manual, or go to the App
Store and Google Play to search for FoxSwitch.

10
8. Operation
8.1 Charger Status Indicators
LED Indicator description
Definition
Green Flashing
Device available
Blue Steady
EV connected，User not authorized
Blue Flashing
Authorized, Wait for charging
Blue marquee light
Charging
Blue Flashing
Charging suspension
Green Steady
Charging Finish, Wait for unplug
Yellow Steady
Charging Locking
Red Steady
Device Fault

11
8.2 Charging mode and Operation
Users can set three charging modes through the charging mode setting interface of the APP:
controlled, locked, plug and charge.
A. Plug and charge mode
Charging will start automatically after EV plugged in. If you want to stop the charging, just press the
stop button on the side of the charger.
•Start Charging:
1. Set the charger to the Plug and Charge mode
2. Insert the charging plug into the EV
3. Charging session started
•Stop Charging:
Press the stop button on the side of the charger.
B. The controlled mode
Initiate or cease charging by using APP or by swiping RFID card on this mode. You can also use
APP for Reservations.
The controlled mode with RFID card
•Start Charging:
1. Set the charger to the Controlled mode
2. Insert the charging plug into the EV
3. Click to Start the Charge on the APP
4. Waiting for authorizing
5. Charging session started

12
•Stop Charging:
1. Swipe card
2. Charging session end
The controlled mode with APP
•Start Charging:
1. Set the charger to the Controlled mode
2. Insert the charging plug into the EV
3. Click to Start the Charge on the APP
4. Waiting for authorizing
5. Charging session started
•Stop Charging:
1. Click to Stop the Charge on the APP
2. Charging session end
C. The locked mode
On this mode, the charger is locked and cannot be used.

13
9. Maintenance
Troubleshoot by Alarm information on APP or LCD display.
If fault occurs, users can check the fault information on the APP or by blinks of the LED indicator
light.
No.
Fault code on app
Solution
1
Electronic lock fault
Set the electronic lock status to the correct
position.
Or seek help from us.
2
Emergency stop fault
Reset the emergency stop button.
Or seek help from us.
3
Abnormal CP voltage
seek help from us.
4
Abnormal AC output contactor
seek help from us.
5
Over current
Reduce output current.
Or seek help from us.
6
Over voltage
Wait for the grid voltage to return to normal.
Or seek help from us.
7
Undervoltage
Wait for the grid voltage to return to normal.
Or seek help from us.
8
Electric leakage
seek help from us.
9
Reverse connection of lin N
Correctly connect P and N lines.
Or seek help from us.
10
Abnormal frequency
Wait for the grid frequency to return to normal.
Or seek help from us.
11
Over temperature of charging
interface
Wait for the temperature of charging interface to
return to normal.
Or seek help from us.

14
10. Decommissioning
10.1 Dismantling the charger
-Disconnect the charger from AC Input and AC output.
-Disconnect communication and optional connection wirings. Remove the charger from the
bracket.
-Remove the bracket if necessary.
10.2 Packaging
If possible, please pack the charger with the original packaging. If it is no longer available, you can
also use an equivalent box that meets the following requirements.
-Suitable for loads more than 30 kg
-Contains a handle
-Can be fully closed
10.3 Storage and Transportation
Store the charger in dry place where ambient temperatures are always between -40°C - +
70°C.Take care of the charger during the storage and transportation; keep less than 4 cartons in
one stack. When the charger or other related components need to be disposed of, please ensure it
is carried out according to local waste handling regulations. Please be sure to deliver any charger
that needs to be disposed from sites that are appropriate for the disposal in accordance with local
regulations.

V1.0
The copyright of this manual belongs to FOXESS CO., LTD. Any corporation
or individual should not plagiarize, partially or fully copy (including software, etc.), and no
reproduction or distribution of it in any form or by any means is permitted. All rights reserved.
Add: No.939, Jinhai Third Road, New Airport Industry Area, Longwan District, Wenzhou,
Zhejiang, China
Tel: [phone]
WWW.FOX-ESS.COM.
