Frama SHELF LIBRARY User manual

- ASSEMBLY GUIDE -
SHELF LIBRARY AND SINGLE SHELF
Steel

INDEX
3
7
11
15
Rail
Shelf
Single shelf
Hanger shelf
21 Cabinet

- PARTS -
RAIL
Rail Screw
x4 for 1084 rail
x5 for 1852 rail
AB

The logo text should be on
the bottom side
1.
Place the first rail Aon the desired position on the wall and put the screw B
into the wall through the top hole. Depends on the wall type, pre-drilling and
wall plug (not included) maybe required.
Use the the top hole as an achor point and level the rail straight then mark the
screw hole with a pencil or a sharp tool on the wall.
Anchor point

2.
Finish mounting the first rail by putting the screws Binto the marked position.
Measure the distances for the second rail A, then mount the second rail by
repeating the same process on page 4.
40 cm shelf = 38.4 cm
60 cm shelf = 58.4 cm
80 cm shelf / Cabinet = 78.4 cm
Inner distance between the rails

3.
To extend the system, repeat the same process on page 4 and 5.

Bracket x2
Shelf x1
Bolt x4
Threaded
insert x2
Spacing
bolt x1
B
A
C
DE
- PARTS -
SHELF
Only A, B, Care required for this assembly.

Front Ba ck
1.
Start by inserting bracket ends Binto the holes on the shelf A.

2.
Place the shelf at a desired position in the rail, secure the bracket Bto the rail by
fastening the bolts Cto the threaded hole in the rail.

3.
Note that the back side of the shelf should be placed
against the rail not to the wall.

Bracket x2Shelf x1 BA
- PARTS -
SINGLE SHELF

1.
Start by inserting bracket ends Binto the holes on the shelf A.
Front B ack

2.
Make sure that the brackets are placed correct side.
Place the complete shelf against the wall, level it straight then mark screw holes
with a pencil or a sharp tool on the wall.
Front

3.
Put screws into the marked position on the wall, then hang the bracket on.
Depends on the wall type, pre-drilling and wall plug (not included) maybe
required.

- PARTS -
HANGER SHELF
Bracket x2
Shelf x1 Hanger x1
Bolt x4
Threaded
insert x2
C
AB
D
EHanger / Spacing
bolt x3
F
Only A, B, C, D, Fare required for this assembly.

1.
Start by screwing the hanger bolts Finto the hanger Bthough the shelf A.

Front Back
2.
Insert bracket ends Cinto the holes on the shelf A.

3.
Place the shelf at a desired position in the rail, secure the bracket Cto the rail by
fastening the bolts Dto the threaded hole in the rail.

4.
Note that the back side of the shelf should be placed
against the rail not to the wall.
