Fixing Instructions for;
D20161N, D20195N Model A Wash Hand Basin
D20162N Model B Wash Hand Basin
D20163N Model WB18 Wash Hand Basin
1. Place the wash basin upside down ensuring
that the polished surface is protected from
possible damage. Fit the apron support inside
the turndown of the wash basin surround
ensuring that both slotted and circular hoples
are aligned. Note - the rear apron return should
be level with the basin upstand so that it fits
flush to the wall.
Fix together using the four screws, washers
and nuts supplied. When the screws are fitted
in the front corners it is advisable to hold the
nut in position using a pair of pliers. The screw
can then be tightened using a screwdriver. Do
not fully tighten all the screws until satisfied
that the apron is in the correct and final
position.
2. Once assembled mark the desired posi-
tion on the wall. The recommended height for
adult use is 850 - 900mm. Mark the fixing hole
positions - two in the upstand and four in the
apron returns.
3. Drill the fixing positions and fit wall plugs to
suit the screws to be used (no plugs or screws
are supplied)
4. Fit the waste (and chain stay if required
- D20161N only) to the wash basin (waste
packs are only supplied as an extra and are not
automatically supplied unless requested at the
time of order)
Note:
D20161N is fitted with a 32mm waste outlet
and chain stay (no overflow).
D20162N & D20163N are both fitted with a
32mm waste and overflow.
5. Fix the wash basin to the wall by the two
fixing holes in the upstand. Once supported
on the wall securely screw fix through the
apron support returns, using the appropriate
screwdriver.
6. Fit the taps, Taps are only supplied at the
time of order as extras and are not supplied as
standard.
7. Connect the taps to the mains water
services and the waste to the drainage system
as necessary.
8.Remove the plastic coating, where
applicable.
See diagrams overleaf

Fixing Instructions for;
D20161N, D20162N, D20163N Wash Hand Basin
Illustration showing how the wash
basin fits onto the apron support.
Note: The model shown is the
D20161N but not the same fixing
procedures are required for the other
models
Model D20161N is the only model not fitted with an overflow. However a chain stay
is supplied for fitting into the small hole directly behind the bowl. (see above).
