1 | For your safety Franke Kaffeemaschinen AG
4
1 FOR YOUR SAFETY
WARNING
Risk of fatal injury from electrocution
Damaged power cords, lines or plug connections can lead to electrocution.
a) Do not connect any damaged power cords, lines or plug connections to
the power supply.
b) Replace damaged power cables, lines or plug connections.
If the power cord is permanently attached, contact the service techni-
cian. If the power cord is not permanently attached, order and use a new,
original power cord.
c) Ensure that the machine and the power cord are not near any hot sur-
faces such as gas or electric stoves or ovens.
d) Ensure that the power cord is not pinched and does not chafe on sharp
edges.
CAUTION
Irritation from cleaners
Cleaning tablets, milk system cleaning agent, and descaler can lead to irrita-
tions.
a) Observe the hazard warnings on the label of the respective cleaner.
b) Avoid contact with your eyes and skin.
c) Wash your hands after coming into contact with cleaner.
d) Cleaners must not find their way into drinks.

Franke Kaffeemaschinen AG For your safety | 1
5
CAUTION
Spoiled milk
Spoiled milk could represent a health hazard.
a) Use only fresh, refrigerated milk.
b) Observe the storage conditions for milk.
c) Observe the shelf life of the milk used.
CAUTION
Germs in unpasteurized milk
Germs in unpasteurized milk could pose a health hazard.
a) Do not use any unpasteurized milk.
b) Only use pasteurized or long-life milk.
Do you have any questions that are not addressed in these instructions?
Please do not hesitate to contact your local customer service partner, Franke
Customer Service, or Franke Kaffeemaschinen AG in Aarburg.

1 | For your safety Franke Kaffeemaschinen AG
6
NOTICE
Spoiled milk
Insufficient cooling or hygiene can cause milk to spoil.
a) Only use pre-cooled milk (2,0 − 5,0 °C).
b) Only store milk in the cooling unit when the cooling unit is in operation.
When the cooling unit is not in operation, e.g. overnight, store the milk in
a refrigerator.
c) Clean the machine and cooling unit once a day.
d) Only touch the suction hose, the inside of the milk container, and the milk
lid after sanitizing your hands, or wear disposable gloves.
e) Place the container lid with the suction hose only on a clean surface.
NOTICE
Damage to the machine
Connection lines could be damaged by tensile load.
Incoming moisture could cause damage.
An unsuitable location could lead to damage.
a) Never pull on the connection lines.
b) Lay the connection lines in such a way that they do not form tripping haz-
ards.
c) Do not use jets of water or steam for cleaning.
d) Do not expose the machine to the elements, such as rain, frost or direct
sunlight.
e) Place the machine only on a level, stable subsurface.

Franke Kaffeemaschinen AG Instructions | 2
7
2 INSTRUCTIONS
2.1 Installation
Installation may only be performed by a Franke-authorized specialist.
Tasks
– Unpack the device
– Check that there is the required free space
– Check the electrical power connection
– Connect connection lines and connection hoses
– Mount the device
– Connect the power supply
– Switch on the device
– Put the device into operation with the coffee machine
2.2 Intended use
– The cooling unit is used exclusively to keep milk cool for the preparation
of coffee drinks with a Franke coffee machine.
– Only use pre-cooled milk.
– Remove the milk when the cooling unit is not in use. Store the milk in a
suitable cooling unit.
– Use only the recommended cleaners. Other cleaners may leave residues
in the milk system.
– The cooling unit is intended exclusively for operation indoors.
– Please also observe the Declaration of Conformity delivered with the de-
vice.

2 | Instructions Franke Kaffeemaschinen AG
8
2.3 Non-authorized use
– Children under the age of 8 years are not permitted
to use the device.
– Children or persons who are challenged with respect
to physical, sensory or mental abilities must not use
the device except under supervision, nor should they
play with the device.
– Alcoholic or explosive substances must not be used or stored in the ma-
chine.
– Do not use the machine:
– If you are not familiar with its functions.
– If the machine, power cord or connection lines are damaged.
– If the machine has not been cleaned or filled as specified.
2.4 Function
The cooling unit has the following functions:
– Keeping the milk cool
– Displaying the milk temperature
– Preventing unauthorized access via a lockable door
2.5 Operation and maintenance
Regular cleaning is a prerequisite for the pure and safe enjoyment of milk
drinks. You can find more detailed information on operating, configuring,
cleaning and caring for your cooling unit in the operating instructions supplied
with your coffee machine.

Franke Kaffeemaschinen AG Instructions | 2
9
Cleaning
Clean the milk system daily or when prompted by the coffee machine. Clean
the device and device parts with warm water and a mild cleaner. Dry the de-
vice and device parts when cleaning is complete.
Clean daily:
• Interior chamber, inner side of the door and lip seal
• Milk container
• Intake hose
2.6 Malfunctions
Error messages will appear on the coffee machine's display in the case of
malfunctions. The error messages contain information regarding the cause
and resolution of the malfunction.
2.7 Transport, storage, decommissioning
– Clean the device
– Secure the device against accidents and do not set it up in an inclined
position
– Use suitable packaging for transport and storage
– Comply with the ambient conditions provided in the technical data

2 | Instructions Franke Kaffeemaschinen AG
10
2.8 Disposal
– Observe the information on the label when disposing of any unused
cleaning agent.
– The tetrafluorethane refrigerant (R134a) used requires no special means
of disposal.
The machine complies with European Directive 2012/19/EU regarding Waste
Electrical and Electronic Equipment (WEEE) and must not be disposed of with
household waste.
Dispose of electronic parts separately.
Dispose of plastic parts in accordance with their marking.

Franke Kaffeemaschinen AG Technical data - UC05 | 3
11
3 TECHNICAL DATA - UC05
Device type FCS4071
Milk container 5 Ltr
Cooling temperature 2,0 − 5,0 °C
Ambient conditions Humidity: max. 80%
Ambient temperature: 10 – 32 °C
Refrigerant R134a/40 g
Climate class N/4 temperate climate
suitable for temperature of 16 – 32
°C
Noise emission <70dB(A)
Weight Approx. 27 kg
Dimensions (width/height/depth) 320 mm/238 mm/646 mm
Power cord 1800 mm
Electrical connection data
Type Country
UC05
(FCS4071)
CH, EU,
GB
Voltage 220–240V
Frequency 50–60Hz
Power rating 90W
Current consumption 1.0A
Connection 1L N PE
UC05
(FCS4071)
JP Voltage 100V
Frequency 50–60Hz
Power rating 81W
Current consumption 1.5A
Connection 1L N PE
