Franke FTMY AH BK MATT F90 User manual

EN
USER MANUAL
FTMY AH BK MATT F90

EN
1. SAFETY INFORMATION
For your own safety and
correct operation of the
appliance, please read
this manual carefully be-
fore installation and oper-
ation. Always keep these
instructions together with
the appliance, even if it is
sold or transferred to third
parties. It is important that
users are familiar with all
the appliance's operating
and safety characteristics.
Connection of the wiring
must be performed by a
specialist technician.
• The manufacturer cannot be
held responsible for any dam-
age resulting from incorrect or
inadequate installation.
• The minimum safety distance
between the hob and the ex-
tractor hood is 650 mm (some
models can be installed at a
lower height; see the para-
graph on working dimensions
and installation).
• If the gas hob installation in-
structions specify a distance
greater than that indicated
above, this must be taken into
account.
• Check that the mains voltage
corresponds to that indicated
on the rating plate fixed to the
inside of the hood.
• The cut-out devices must be
installed in the fixed system
according to the wiring sys-
tem regulations.
• For Class I appliances, check
that the domestic power sup-
ply has a suitable earthing
connection.
• Connect the hood to the flue
with a pipe with a minimum
diameter of 120 mm. The
fume path must be as short as
possible.
• All the regulations regarding
air discharge must be com-
plied with.
• Do not connect the extractor
hood to exhaust ducts carry-
ing combustion fumes (boil-
ers, fireplaces, etc.).
• If the extractor is used in con-
junction with non-electrical
appliances (e.g. gas burning
appliances), a sufficient de-
gree of ventilation must be
guaranteed in the room in or-
der to prevent the backflow of
exhaust gas. When the
cooker hood is used in con-
junction with appliances sup-
plied with energy other than
electricity, the negative pres-
sure in the room must not ex-
ceed 0.04 mbar to prevent
fumes being drawn back into
the room by the cooker hood.
• The air must not be dis-
charged into a flue that is used
for exhausting fumes from ap-
pliances burning gas or other
fuels.
• The power cord, if damaged,
must be replaced by the man-
ufacturer or by a service tech-
nician.
• Connect the plug to a socket
complying with current regu-
3

lations, located in an access-
ible place.
• Regarding the technical and
safety measures to be adop-
ted for fume discharging it is
important to strictly follow the
regulations provided by the
local authorities.
WARNING: Before in-
stalling the hood, remove
the protective films.
• Use only screws and small
parts of a type suitable for the
hood.
WARNING: failure to in-
stall the screws or fixing
devices in accordance
with these instructions
may result in electrical
hazards.
• Do not look directly at the light
through optical devices (bin-
oculars, magnifying
glasses…).
• Do not flambé under the
hood; risk of fire.
• This appliance can be used
by children aged from 8 years
and above and by persons
with reduced physical, sens-
ory or mental capabilities or
lacking in experience and
knowledge if they have been
given supervision or instruc-
tion concerning use of the ap-
pliance in a safe way and if
they understand the hazards
involved. Children must not
play with the appliance.
Cleaning and maintenance
by the user must not be per-
formed by children, unless
they are supervised.
• Children should be super-
vised to ensure that they do
not play with the appliance.
• The appliance is not to be
used by persons (including
children) with reduced phys-
ical, sensory or mental cap-
abilities, or lacking in experi-
ence and knowledge, unless
they have been given super-
vision or instruction.
The accessible parts may
become hot when used
with cooking appliances.
• Clean and/or replace the fil-
ters after the time specified
(fire hazard). See the Main-
tenance and cleaning para-
graph.
• There must be adequate
ventilation of the room when
the hood is used at the same
time as appliances burning
gas or other fuels (not applic-
able to appliances that only
discharge the air back into the
room).
• The symbol on the product
or on its packaging indicates
that the product cannot be
disposed of as normal house-
hold waste. The product must
be taken to an appropriate
collection point for the recyc-
ling of electrical and elec-
tronic components. By ensur-
ing that this product is dis-
posed of correctly, you will
help prevent possible negat-
ive consequences for the en-
vironment and health that
might result from its improper
disposal. For more detailed
4

information about recycling
this product, please contact
your local town hall, the waste
disposal service or the store
where the product was pur-
chased.
WARNING: Before per-
forming any cleaning and/
or maintenance operation,
disconnect the plug from
the power socket.
Information on the purifier
WARNING: Switch off the
device to avoid contact
with the UV-C lamps.
• If the device is damaged, it
must not be used.
• The device contains UV-C
emitting lamps.
• The UV-C lamps must be re-
placed after 6000 hours of op-
eration. To replace them,
contact Technical Assist-
ance. The lamps must not be
replaced by the user.
• Using the device in a manner
not described in this docu-
ment, or damage to the case,
may result in the escape of
UV-C radiation.
• UV-C radiations can cause
damage to eyes and skin,
even in small doses.
• Do not insert small objects
through the ventilation open-
ings. They may damage the
fans and compromise the op-
eration of the device.
• Read the maintenance in-
structions before opening the
device.
• The device must be discon-
nected from the power supply
before replacing the UV-C
emitter.
2. USE
• The suction hood has been designed
exclusively for domestic use, to elim-
inate kitchen odours.
• Never use the hood for purposes
other than those for which it was de-
signed.
• Never leave high flames under the
hood when it is in operation.
• Adjust the intensity of the flame so
that it is directed onto the bottom of
the cooking pan, making sure it does
not wrap around the sides.
• Deep-fryers must be kept under con-
stant supervision when in use: the oil
may catch fire if it gets too hot.
3. CLEANING AND
MAINTENANCE
• The active carbon filter cannot be
washed or regenerated and must be
replaced after every 4 months of op-
eration or, more frequently, in case of
very intense use (W).
• The grease filters must be cleaned
every 2 months of operation or more
frequently in case of very intense use
and can be washed in a dishwasher
(Z).
5

• Clean the hood using a damp cloth
and a neutral liquid detergent.
• For external and internal cleaning of
the hood avoid alcoholic or silicone
products.
If the product or one of its parts is made
of stainless steel, use specific non-ab-
rasive products for cleaning and follow
the lines of the satin finish during clean-
ing.
4. PURIFIER CLEANING
AND MAINTENANCE
• Do not use abrasive products or ma-
terials.
• Avoid products containing alcohol or
silicone.
• Clean the grids with a brush.
• Clean the grids every 2 months of op-
eration or more frequently in case of
very intensive use of the product.
For more thorough cleaning, contact
the technical assistance.
The technical information is situated in
the rating plate on the internal side of
the appliance.
6

5. CONTROLS
Key Key Press Functions LED
AShort Turns off the motor. Off
BShort Turns the motor on at the first speed. LEDs A+B are on.
Long press with all
loads off (motor and
lights)
The Filter saturation alarm and the expended lamp alarm are re-
set.LEDs A + C + D
flash once.
CShort Turns the motor on at the second speed. LEDs A + C are on.
Long 24h Function
It activates/deactivates the motor in 24h Air Exchange mode. This
function sets the motor to the first speed which allows suction with
an interval of 10 minutes on and 50 minutes off.
Cannot be activated if the Intensive or Delay modes are active.
It is deactivated by pressing the same key or by switching off the
motor.
Active function:
LEDs A + B are on
and LED C flashes.
Long press with all
loads off (motor and
lights)
Activates/Deactivates the Activated Carbon Filters alarm.Alarm activated:
LEDs A + B flash
twice.
Alarm deactivated:
LEDs A + B flash
once.
- Signals the saturated Metal Grease Filters alarm and the need to
wash them. The alarm is activated after 99 hours of effective hood
operation.
The LED flashes.
- Signals the Activated Carbon Odour Filter saturation alarm. The
alarm is activated after 200 hours of effective hood operation. LED C flashes.
DShort Turns the motor on at the third speed. LEDs A + D are on.
Long Turns the motor on at the Intensive speed.
This speed is timed for 6 minutes. At the end of this time, the sys-
tem automatically returns to the previously selected speed. If activ-
ated with the motor off, once the time has passed it switches to OFF
mode.
It is deactivated by pressing the same key or by switching off the
motor.
LED A is on and
LED D flashes.
EShort Switches the lights on/off at maximum intensity. On/Off
Long Delay Function
Activates/Deactivates the Delay function, the automatic delayed
shut-down of the motor and lighting system after 30 minutes.
Cannot be activated if the Intensive or 24H function is active.
It is deactivated by pressing the same key or by switching off the
motor.
LEDs A + B or C or
D flash.
FShort Manual mode
Turns on/off the UV-C lamp and ventilation at minimum speed.
After 24 hours, the lamp and ventilation are turned off automatically.
On/Off.
GShort Day mode
Turns on/off the UV-C lamp and ventilation at maximum speed.
After 2 hours, the lamp and ventilation are turned off automatically.
On/Off.
7

HShort Night mode
Turns on/off the UV-C lamp and ventilation at minimum speed.
The automatic operating mode starts with a 24-hour work cycle in
which the device remains on for 5 hours and off for the next 19
hours.
After 7 days the night mode will be turned off automatically.
On/Off.
Warning:
The simultaneous flashing of LEDs F + G + H indicates damage to the UV-C lamps.
The simultaneous flashing of LEDs G + H indicates that it is necessary to replace the UV-C lamps.
The UV-C lamps must be replaced after 6000 hours of operation.
To replace them, contact Technical Assistance.
Warning:
If the following functions are present: Manual mode + Day mode are active and
the hood is turned on, the purifier turns off.
If the hood is on at any speed and the purifier is turned on, the hood turns off.
If the Night Mode function is active and the hood motor is turned on, the purifier turns
off. If the hood is turned off, the purifier turns on with the previously set function.
6. LIGHTING
• Please contact the Service Depart-
ment to change it ("Please contact
the service department to purchase
it").
• Lamps in risk group 1 under IEC/
EN62471 at a distance of 20cm and
in exempt from risk group under IEC/
EN62471 at a distance of 30cm.
8

Franke UK Ltd.
MIOC, Suite 1, Styal Road
Manchester
M22 5WB
www.franke.com/gb/en/hs.html
