OWNER'S MANUAL
English
EN
Turf Boss 3-5 HP
The Turf Boss is designed for applications moving
high volumes of water, such as timer-operated
irrigation systems, commercial dewatering, resi-
dential water transfer, rainwater drainage, light
agricultural irrigation, sump drainage, and indus-
trial liquid transfer. A premium self-priming
sprinkler pump, the Turf Boss is approved for
indoor or outdoor operation through CSA and UL.
This product is covered by a limited warranty for a period of 1 year from the date of original purchase by the
consumer. For complete warranty information, refer to www.FranklinWater.com.
Specifications
Pumps
Pump Ends
Model HP Suction x
Discharge (in) Motor Enclosure Phase Volts
FTB3CI
3 2 x 2
ODP 1 230
FTB3CI-T 3 230/460
FTB3CI-E
TEFC
1 230
FTB3CI-TE 3230/460
FTB3CI-T5E 575
FTB5CI
5 2½ x 2
ODP 1 230
FTB5CI-T 3 230/460
FTB5CI-E
TEFC
1 230
FTB5CI-TE 3230/460
FTB5CI-T5E 575
Model HP Suction x
Discharge (in) NEMA Motor Frame Size Fitment
FTB3CI-PE 3 2 x 2 143-184JM 4.5 AK .875" Shaft
FTB5CI-PE 5 2½ x 2

SAFETY INSTRUCTIONS
Specifications
2
SAFETY INSTRUCTIONS
This equipment should be installed and serviced by technically qualified personnel who are familiar with
the correct selection and use of appropriate tools, equipment, and procedures. Failure to comply with
national and local electrical and plumbing codes and within Franklin Electric recommendations may result
in electrical shock or fire hazard, unsatisfactory performance, or equipment failure.
Know the product’s application, limitations, and potential hazards. Read and follow instructions carefully to
avoid injury and property damage. Do not disassemble or repair unit unless described in this manual.
Failure to follow installation or operation procedures and all applicable codes may result in the following
hazards:
Risk of death, personal injury, or property damage due to explosion, fire,
or electric shock.
• Do not use to pump flammable, combustible, or explosive fluids such as gasoline, fuel oil, kerosene, etc.
• Do not use in explosive atmospheres or hazardous locations as classified by the NEC, ANSI/NFPA70.
• Do not handle a pump or pump motor with wet hands or when standing on a wet or damp surface, or in water.
• When a pump is in its application, do not touch the motor, pipes, or water until the unit is unplugged or electrically disconnected.
• If the power disconnect is out of sight, lock it in the open position and tag it to prevent unexpected application of power.
• If the disconnect panel is not accessible, contact the electric company to stop service.
Risk of severe injury or death by electrical shock.
• To reduce risk of electrical shock, disconnect power before working on or around the system. More than one disconnect switch
may be required to de-energize the equipment before servicing.
• Wire pump system for correct voltage.
• Be certain that this pump is connected to a circuit equipped with a ground fault circuit interrupter (GFCI) device if required by
code.
• The pump includes a grounding connector. To reduce risk of electric shock, be certain that it is properly connected to ground.
• To avoid hazards when installing or servicing, install a double-pole disconnect near the pump installation.
• Use an appropriate discharge resistor to discharge the capacitor prior to working on the motor.
• Check local electrical and building codes before installation. The installation must be in accordance with their regulations as well
as the most recent National Electrical Code (NEC) and the Occupational Safety and Health Association (OSHA), or Canadian Elec-
trical Code (CEC).
• Employ a licensed electrician.
Risk of bodily injury, electric shock, or equipment damage.
• This equipment must not be used by children or persons with reduced physical, sensory or mental abilities, or lacking in experi-
ence and expertise, unless supervised or instructed. Children may not use the equipment, nor may they play with the unit or in
the immediate vicinity.
• Do not run the pump dry. If run dry, the surface temperature of the pump will rise to a high temperature that could cause skin
burns if touched and will cause serious damage to your pump.
• Equipment can start automatically. Lockout-Tagout before servicing equipment.
• The pump has been evaluated for use with water only. Pump should only be used with liquids compatible with pump component
materials.
• An inoperative or malfunctioning pump could lead to flooding, resulting in personal injury or property damage.
• Pump may become hot during operation. Allow pump to cool before servicing.
• Operation of this equipment requires detailed installation and operation instructions provided in this manual. Read entire manual
before starting installation and operation. End User should receive and retain manual for future use.
• Keep safety labels clean and in good condition.
• Keep work area clean, well-lit, and uncluttered.
• Wear safety glasses while installing or performing maintenance on the pump.

INSTALLATION
Typical Installation
3
INSTALLATION
Typical Installation
Pump Location
• Install the pump in a clean, dry, and ventilated location shielded from direct sun and precipitation.
• Provide adequate room for future servicing, protection from freezing temperatures, flooding, and
equipment drainage.
• Bolt unit down evenly on a good foundation, preferably concrete, to prevent unnecessary stresses
from pump movement.
• Install as close as possible to water source to minimize suction piping length.
1 Check Valve 3 Discharge 5 Suction Line
2 Gate Valve 4 Pump 6 Strainer
12
3
4
5
6

INSTALLATION
Piping Instructions
4
Piping Instructions
• Properly support all suction and discharge piping to avoid strain on the pump.
• Piping should match the pump inlet and outlet connection sizes.
• For long runs, increase connections by one pipe size.
• Use pipe thread sealant.
• Avoid the use of unions on the suction line if possible. All suction line connections must be airtight.
• Do not over-tighten piping connections.
Suction Line
Suction Lift Applications
NOTE: The total suction lift should not exceed 25 feet.
1. Install a new, clean pipe or hose.
• Make sure piping rises vertically or is sloped continually upward from the water source to the
pump inlet connection.
• Check that there are no high spots that cannot be evacuated of air during the priming process.
2. Install a strainer at the end of the suction line.
• Ensure the strainer remains well submerged at all times.
Discharge Line
1. Tighten the discharge pipe, using an opposing pipe wrench on the pump discharge.
2. Install a check valve.
• All discharge piping must have a pressure rating capable of withstanding the incoming inlet
pressure plus the pump’s maximum shut-off head pressure.
IMPORTANT: Do not operate the pump under a no-flow/shut-off head condition.
Electrical Connections
1. An electrician should be employed to do the wiring.
2. Provide a separate circuit from the distribution panel to the pump unit, properly protected with a
fuse or circuit breaker.
3. Install a proper fused disconnect switch in the line. Make sure the correct gauge of cable is used to
carry the load.
IMPORTANT: Undersized wire between the motor and the power source will adversely limit the
starting and load carrying abilities of the motor.
4. Wire the motor according to the motor nameplate to achieve clockwise rotation when viewed from
the motor end.
• Very long leads will require a larger cable.
• If needed, remove motor end compartment for viewing.
5. Make sure the insulated green or bare ground wire is securely connected to the green ground termi-
nal screw on the motor terminal board.
Risk of severe injury or death by electrical shock.
• To reduce risk of electrical shock, disconnect power before working on or around the system.

OPERATION
Electrical Connections
5
6. For 3-phase motors, install a separate manual thermal overload switch or a magnetic starter with
proper size heater elements.
• Failure to provide proper overload protection to the motor will void any warranty.
OPERATION
1. Prime the pump.
• Remove priming plug.
• Pour water into the priming port.
• Fill the pump and suction line with water.
• Rotate motor shaft to let air in casing escape.
• Refill at the priming port and replace priming plug.
2. If installing a 3-phase motor, check pump rotation by turning on power for a second.
• The impeller must rotate in a counterclockwise direction while facing the pump from the front of
the casing.
• If direction is wrong, interchange any two of three wires either at the motor or starter.
3. Start the pump.
4. Gradually open the discharge valve to the halfway point.
• If the pump does not deliver water within seconds, stop the motor and prime pump again.
• Several starting attempts may be necessary to expel all air from the pump and suction lines.
5. Once the pump is fully functioning, completely open the discharge valve and a system outlet.
Risk of severe injury or death by electrical shock, high temperatures,
or pressurized fluids.
• To reduce risk of electrical shock, disconnect power before working on or around the system.
• Do not continuously run pump against closed discharge. Release all system pressure before working on any com-
ponent.
Risk of damage to pump or other equipment.
• Do not let the unit run dry (without liquid). It is designed to be cooled by pumping fluid. The seal may be dam-
aged and the motor may fail if the pump is allowed to run dry.

MAINTENANCE
Draining the Pump
6
MAINTENANCE
NOTE: For replacement parts, consult the catalog available on www.FranklinWater.com.
• Check the pump periodically for loose or rubbing parts.
• Service immediately if any unusual noise, leaks, or vibrations develop.
• Drain the pump should it be subjected to freezing temperatures.
Draining the Pump
Drain all piping and water tanks exposed to freezing conditions.
1. Remove the pipe plug from bottom of pump case.
2. Allow the water to drain.
3. Install the pipe plug to the pump case.
Disassembly
1. Shut down system and lock out power.
2. Allow pump components to adequately cool.
3. Drain the pump. Refer to “Draining the Pump” on page 6.
Pump Shaft Disassembly
1. Unbolt and remove the casing, laying aside the case gasket.
2. Take the diffuser and square ring off the volute.
3. Remove impeller and shaft key:
IMPORTANT: Beware of breaking the back side of the impeller.
• Remove the impeller bolt and washer.
• Pry the impeller from the shaft. For corroded assemblies, flip the pump vertically and apply a
penetrating oil to the impeller.
• Remove the shaft key.
4. Spray the shaft sleeve with WD-40 and remove the rotating portion of the mechanical seal.
5. Unbolt the motor adapter from the motor and remove.
IMPORTANT: Be sure not to damage the stationary part of the mechanical seal.
6. Gently tap the stationary part of the mechanical seal from the motor adapter using a flat-blade
screwdriver and rubber mallet.
7. If necessary, remove the shaft sleeve and slinger.
• Clean the shaft sleeve with 000 steel wool and WD-40.
8. Inspect disassembled components. Replace the worn parts with new during reassembly.
Risk of severe injury or death by electrical shock.
• To reduce risk of electrical shock, disconnect power before working on or around the system.

MAINTENANCE
Reassembly
7
Pump Check Valve Disassembly
1. Unbolt and remove the check valve from the volute.
2. Loosen the nut and set aside.
3. Pull the bolt and set aside the flat washer, top weight, flapper, and bottom weight.
NOTE: The top weight is heavier, and sits on the pump side of the check valve.
4. Inspect disassembled components. Replace the worn parts with new during reassembly.
Reassembly
Pump Check Valve Reassembly
1. Insert the flapper bolt through bottom weight and flapper.
2. Add the top weight and flat washer to the bolt.
3. Screw on the nut.
• Torque to 65 in-lbs.
4. Bolt the check valve assembly to the volute.
• Torque to 20 ft-lbs.
Pump Shaft Assembly
1. Slide water slinger onto motor shaft.
2. Install the shaft sleeve onto motor shaft.
• Apply Loctite 7649 primer to motor shaft and inside of shaft sleeve.
• Apply a ring of green Loctite 648 retaining compound around the inside leading edge of the
shaft sleeve and a line along the motor shaft.
• Rotate the sleeve at least two times before fully seating the sleeve against shaft shoulder.
• Wipe off excess lubricant.
• Let stand 3 minutes.
3. Insert a new stationary portion of the mechanical seal into the motor adapter.
• Ensure the bracket socket is clean before installation.
• Lubricate seal and socket with P-80 lubricant to ease installation.
• Do not contaminate the seal face.
4. Bolt the motor adapter to the motor.
• Use Blue Loctite 243 on bolts.
• Torque to 20 ft-lbs.
IMPORTANT: Be sure not to damage the stationary part of the mechanical seal.
5. Install the rotating portion of the mechanical seal onto the shaft sleeve so that the rotating ring sits
against the stationary ceramic seal face.
• Lubricate seal with P-80 lubricant to ease installation.
• Do not contaminate the seal face.
NOTE: If there is a retainer on the seal spring, discard it.
6. Install the shaft key and impeller
• Slide the shaft key onto the shaft.
• Install the impeller with its washer and bolt onto the shaft.
• Use Red Loctite 271 on the impeller bolt.
• Torque the impeller bolt to 20 ft-lbs.
7. Ensure the impeller eye is perpendicular to the adapter flange.
8. Ensure the impeller spins freely.

MAINTENANCE
Troubleshooting
For technical assistance, parts, or repair, please contact:
106505101 Rev. 002 08/22 Copyright © 2022, Franklin Electric, Co., Inc. All rights reserved.
800.348.2420 |franklinwater.com
9. Place the square ring and diffuser on the volute.
10. Reposition the case gasket and bolt the volute to the motor adapter.
• Use Blue Loctite 243 on bolts.
• Torque to 20 ft-lbs.
Troubleshooting
Problem Probable Causes Corrective Action
Motor Fails to Start or
Not Running
Motor thermal protector tripped Correct cause for high amperage, such as low voltage or excessive
pumping.
Open circuit breaker or blown fuse Check electric wiring and motor for short circuits and correct.
Impeller binding Remove pump case and check for debris.
Motor improperly wired Check complete suction line and all fittings for air leaks and verify
foot valve has adequate submergence.
Defective motor Take to an authorized motor shop for repair or replacement.
Little or no discharge
Pump is not primed: air or gases in
pumpage Check suction line and foot valve for leaks. Make sure that water level has not dropped to uncover suction inlet. Prime pump.
Discharge or suction plugged or valve
closed Clear obstructions from suction and discharge lines.
Incorrect rotation (3-Phase only) Interchange any two of three wires either at the motor or starter.
Low voltage or phase loss Correct incoming power to match motor nameplate requirements.
Impeller worn or plugged Clean or replace impeller.
System head too high Reduce system head (back-pressure on pump) or resize pump.
Excessive suction lift or losses, or NPSHA
too low for the pump Locate pump closer to the water source, increase pipe size or resize pump.
Low pump capacity or
pressure
Valves in suction or discharge lines par-
tially closed Open valves to reduce possible restrictions.
Suction or discharge line partially
plugged Clear obstructions from discharge line.
Wrong pump rotation Correct to proper rotation.
Excessive power
consumption
Impeller binding Remove pump case and check for debris.
Discharge head too low creating exces-
sive flow rate Close down discharge valve to increase pressure and throttle back flow rate.
Fluid viscosity: specific gravity too high Modify fluid properties or resize pump.
Excessive noise and
vibration
Impeller binding Remove pump case and check for debris.
Pump is not primed: air or gases in
pumpage Check complete suction line and all fittings for air leaks and verify foot valve has adequate submergence.
Discharge or suction plugged or valve
closed Clear obstructions from suction and discharge lines.
Impeller worn or plugged Clean or replace impeller.
Excessive suction lift or losses. NPSHA
too low for the pump Locate pump closer to the water source, increase pipe size or resize pump.
Discharge head too low, creating exces-
sive flow rate Close down discharge valve to increase pressure and throttle back flow rate.
Worn bearing Check bearing for damage and replace if necessary.
Pump, motor, or piping loose Verify all connections and mountings are secure and piping sup-
ported.
Water leakage at pump
shaft Defective seal assembly Replace seal.
