Freescale Semiconductor FRDM-STBC-SA9500 Reference guide

3-Axis Sensor Toolbox Development Board
Quick Reference Card
Get Started
FREESCALE FREEDOM PLATFORM
documentation under
Jump-Start Your Design
at freescale.com/
sensortoolbox
Download tools and
FRDM-STBC-SA9500
FRDM-
STBC-
SA9500
For more information, visit freescale.com/
sensortoolbox
Freescale and the Freescale logo are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. © 2015 Freescale Semiconductor, Inc. FRDMSTBCSA9500QRC REV 1 920-28959 REV A
FRDM-
STBC-
SA9500
FXLC95000CL motion-sensing platform integrates a 3-axis MEMS
accelerometer with a 32-bit MCU

Test points (18 places)
Learn more at freescale.com/sensortoolbox
Get to Know the FRDM-STBC-SA9500
FXLC95000CL motion-sensing platform integrating
a 3-axis MEMS accelerometer and a 32-bit MCU
24 LGA (3 mm x 5 mm x 1 mm)
INT_I – 3
GPIO12 – 5
GPIO7 – 6
GND – 7
5 – I2C_SDA1
2 – GPIO13
7 – GND
4 – VDD
2 – VDD
I2C_SDA0 – 9
I2C_SCL0 – 10
6 – GND
6 – I2C_SCL1
3 – RST_MCU
PDB_8 – 1
S_SSB_IO3 – 3
S_SPI_MOSI – 4
S_SPI_SDO – 5
S_SPI_CLK – 6
4 – RST_GPIO
GPIO6 – 8
1 – INT_0
3 – BKGD
Through hole pins (18 places)
On/Off switch
Verify package contents:
FRDM-STBC-SA9500
development board
Connect the FRDM-STBC-SA9500
development board to a Freescale
Freedom development board,
such as the FRDM-K22F (or any
Arduino R3 compatible board).
Refer to the Freescale Freedom
development board Quick Start
Guide for driver information.
Plug one end of a USB cable into
the SDA port on the assembly.
Plug the other end of the cable into
the USB port on the computer.
Download and install the
latest Sensor Toolbox software at:
freescale.com/sensortoolbox
Start the Sensor Toolbox software.
1
2
3
4
5
