Frico PA1006 User manual

.... 7
SE .... 16 ES
.... 13
DE
.... 21
RU
.... 9
GB
.... 18
FR
.... 11
NO
PA1006
Original instructions

A
B
Front
Back
Side
650
70
167
25
70154
25
315
63
1,5 mm²
0,9m
PA1006
2
Dimensions

A
B
PA1006
3
Mounting and installation
Fig. 1: Mounting with bracket
Fig. 2: Bracket dimensions
Fig. 3:To open
PH2
PH2
PA1006
548
ø5
595
14.5
5
PA1006

PA1006
4
Minimum distance
Fig. 4 Minimum distance
Min 25 mm
Min 1,8 m
Min 25 mm
Min 50 mmMin 50 mm

Wiring diagrams PA1006
Internal
PA1008E03
PA1006
5
750W 750W
750W 750W
°C °C
M
L
N
12
b
1
2
0OFF
+ 1,5kW
+ 3kW
12
b
~
PA1006E03

PA1006
6
GB
*1) ∆t = temperature rise of passing air at maximum heat output and highest airflow.
*2) Sound power (LWA) measurements according to ISO 27327-2: 2014, Installation type E.
*3) Sound pressure (LpA). Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area:
200 m².
SE
*¹) ∆t = temperaturhöjning på genomgående luft vid maximal värmeeffekt och högt luftflöde.
*²) Ljudeffekt (LWA), mätningar enligt ISO 27327-2: 2014, Installationstyp E.
*3) Ljudtryck (LpA). Förutsättningar: Avstånd till aggregat 5 meter. Riktningsfaktor 2. Ekvivalent absorptionsarea: 200 m².
NO
*¹) ∆t = temperaturøkning på gjennomstrømmende luft ved maksimal varmeeffekt og høy luftmengde.
*²) Målinger av lydeffekt (LWA) i henhold til ISO 27327-2: 2014, Installasjon type E.
*3) Lydtrykk (LpA). Betingelser: Avstand til aggregat 5 meter. Retningsfaktor: 2. Ekvivalent absorpsjonsareal: 200 m².
DE
*¹) ∆t =Temperaturanstieg der vorbeiströmenden Luft bei max. Heizleistung und hohem Volumenstrom.
*²) Schallleistungsmessungen (LWA) gemäß ISO 27327-2: 2014, Installationstyp E.
*3) Schalldruck (LpA). Bedingungen: Abstand zum Gerät: 5 Meter. Richtungsfaktor: 2. Entsprechende Absorptionsfläche:
200 m².
ES
*¹) ∆t = incremento de la temperatura derivado del paso del aire a la potencia calorífica máxima y con un caudal de aire
alto.
*²) Mediciones de potencia acústica (LWA) de conformidad con ISO 27327-2: 2014, Instalación de tipo E.
*3) Presión acústica (LpA). Condiciones: 5 metros de distancia a la unidad. Factor direccional: 2. Área de absorción
equivalente: 200 m².
FR
*¹) ∆t = augmentation de température du débit d’air sous un débit et une puissance maximale.
*²) Mesures de la puissance acoustique (LWA) selon la norme ISO 27327-2 : 2014, Installation de type E.
*3) Pression acoustique (LpA). Conditions : Distance de l’appareil : 5 mètres. Facteur directionnel : 2. Surface d’absorption
: 200 m².
RU
*1) ∆t = подогрев потока при максимальной мощности и скорости.
*2) Мощность звука (LWA) измерена в соответствии с ISO 27327-2: 2014, Тип установки E.
*3) Звуковое давление (LpA). Условия: Расстояние до прибора 5м. Фактор направленности: 2. Эквивалентная площадь
звукопоглощения: 200 м2.
3Electrical heat - PA1006 (IP20)
Type Output
steps
[kW]
Airflow
[m³/h]
∆t*¹
[°C]
Sound
power*²
[dB(A)]
Sound
pressure*²
[dB(A)]
Voltage
[V]
Amperage
[A]
Length
[mm]
Weight
[kg]
PA1006E03 0/1,5/3 230 39 60 44 230V~ 12,8 650 5,3
CE compliant.
GB: Output steps
SE: Effektsteg
NO: Effekttrinn
DE: Abgabestufen
ES: Niveles de potencia
FR: Etages de puissance
RU: Ступени мощности
GB: Airflow
SE: Luftflöde
NO: Luftmengde
DE: Volumenstrom
ES: Caudal de aire
FR: Débit d’air
RU: Расход воздуха
GB: Sound power
SE: Ljudeffekt
NO: Lydeffekt
DE: Schallleistung
ES: Potencia acústica
FR: Puissance acoustique
RU: Мощность звука
GB: Sound pressure
SE: Ljudtryck
NO: Lydtrykk
DE: Schalldruck
ES: Presión acústica
FR: Pression acoustique
RU: Звуковое давление
GB: Voltage
SE: Spänning
NO: Spenning
DE: Spannung
ES: Tensión
FR: Tension
RU: Напряжение
GB: Amperage
SE: Ström
NO: Strøm
DE: Stromstärke
ES: Intensidad
FR: Intensité
RU: Ток
GB: Length
SE: Längd
NO: Lengde
DE: Länge
ES: Longitud
FR: Longueur
RU: Длина
GB: Weight
SE: Vikt
NO: Vekt
DE: Gewicht
ES: Peso
FR: Poids
RU: Вес

GB
9
Assembly and operating instructions
General Instructions
Read these instructions carefully before
installation and use. Keep this manual
for future reference.
The guarantee is only valid if the units
are used in the manner intended by
the manufacturer and in accordance
with the mounting and operating
instructions.
Application area
PA1006 is a compact door heater
which heats the incoming air and
gives increased comfort on the inside.
When wall mounted, the unit acts as a
stationary fan heater.
Protection class: IP20
Operation
Air is drawn in at the top/rear of
the unit and blown out downwards/
outwards.
Applies to door heater 0.6 m
The hot air heats the air that enters
through the opening/door and provides
good comfort.
Installation
The unit is installed horizontally with
the supply air grille facing downwards.
Position as close to the opening as
possible for the best effect.
The unit can be angled using the
enclosed bracket, which is used for
both wall and ceiling mounting. When
mounted on the wall it is possible to
angle the heater up to 30° to give even
heat distribution in the room.
For minimum measurements, see
diagram 4.
1.Fit the bracket on the wall or on the
ceiling.
2.Guide the unit onto the bracket
through the opening at the rear or on
top.
3.The unit is secured by guiding the slot
in the bracket over the screw (PH2)
inside the unit and then tightening
the screw from outside of the unit.
See diagram 1 och 2.
Electrical installation
The unit is designed for permanent
installation and is connected via cable
(1,5 mm², 0,9 m) without plug, at the
rear of the unit. 16 A fuse protection is
required for 3 kW.
The installation, which should be
preceded by an omnipolar switch with
a contact separation of at least 3 mm,
should only be wired by a competent
electrician and in accordance with the
latest edition of IEE wiring regulations.
Output
[kW]
Voltage
[V]
Minimum area
[mm²]
3 230V~ 2,5
Start-up (E)
When the unit is used for the first time
or after a long period of disuse, smoke
or odour may result from dust or dirt
that has collected on the element. This
is completely normal and disappears
after a short time.
Regulation
Unit 0.6 m features an integrated fan
and heat selector.
Positions – regulation
Unit 0,6 m
3 kW
Off
High speed 1,5 kW
High speed 3 kW
Service, repairs and maintenance
For all service, repair and maintenance
first carry out the following:
1.Disconnect the power supply.
2.Loosen the screws on the intake grille
and remove grille. See A, fig. 3.
3.Lift the front. See B, fig. 3.

GB
10
Maintenance
Since fan motors and other components
are maintenance free, no maintenance
other than regular cleaning is necessary.
The frequency of cleaning can vary
depending on local conditions, but
undertake cleaning at least twice a year.
Inlet and exhaust grilles and impeller
can be vacuum cleaned or wiped using a
dry cloth. Use a brush when vacuuming
to prevent damaging sensitive parts.
Avoid the use of strong alkaline or
acidic cleaning agents.
Overheating
The air curtain unit is equipped with an
overheat protector. If this is deployed
due to overheating, reset as follows:
1.Disconnect the electricity using the
omnipolar switch.
2.Allow the electrical coil to cool.
3.Determine the cause of overheating
and rectify the fault.
Once the power has been disconnected
the unit can be started again.
Troubleshooting
If the fans are not blowing enough,
check the following:
1.Operating power supply to the unit;
check fuses, circuit-breaker, time
switch that starts and stops the unit.
2.That the intake grille is not dirty.
If there is no heat, check the following:
1. That the heat demand exists;
check thermostat settings and actual
temperature.
2. That the overheat protection for the
motors has not been deployed
If the fault cannot be rectified, please
contact a qualified service technician.
Residual current circuit breaker (E)
When the installation is protected
by means of a residual current
circuit breaker, which trips when
the appliance is connected, this may
be due to moisture in the heating
element. When an appliance containing
a heater element has not been used
for a long period or stored in a damp
environment, moisture can enter the
element.
This should not be seen as a fault, but
is simply rectified by connecting the
appliance to the mains supply via a
socket without a safety cut-out, so that
the moisture can be eliminated from
the element. The drying time can vary
from a few hours to a few days. As a
preventive measure, the unit should
occasionally be run for a short time
when it is not being used for extended
periods of time.
Safety
• Forallinstallationsofelectrically
heated products should a residual
current circuit breaker 300 mA for
fire protection be used.
• Keeptheareasaroundtheairintake
and exhaust grilles free from possible
obstructions!
• Duringoperationthesurfacesofthe
unit are hot!
• Theunitmustnotbefullyorpartially
covered with clothing, or similar
materials, as overheating can result
in a fire risk!
• Thisappliancecanbeusedby
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance shall
not be made by children without
supervision.

Art.no.206171, 2013-04-15 LP/HH/SÄ
Main office
Frico AB Tel: [phone]
Box 102
SE-433 22 Partille [email protected]
Sweden www.frico.se
For latest updated information and information
about your local contact: www.frico.se
