Frico AREC4000 Series User manual

Original instructions
AREC4000
.... 26
FR
.... 22
EN

AREC4000
2
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the respective language pages.
EN
Les pages de présentation contiennent principalement des images. Consulter
la page correspondant à la langue souhaitée.
FR

B
A
1 m: 4 x M8
1,5 m: 4 x M8
2 m: 6 x M8
2,5 m: 6-8 x M8
803
851
851
296
53 90
218
ø29
ø29
ø20
71
56
218
ø29
ø29
Ref Metric
[mm]
Imperial
[in]
Product type
A 1067 42.68 AREC4010x
B 1577 63.08 AREC4015x
C 2067 82.68 AREC4020x
D 2579 103.16 AREC4025x
E 1020 40.80 AREC4010x
F 1520 60.80 AREC4015x
G 2020 80.80 AREC4020x
H 2520 100.80 AREC4025x
I 29 1.16
J 90 3.60
K 53 2.12
L218 8.72
M 296 11.84
N 851 34.04
O 803 32.12
P 851 34.04
Q 20 0.80
A / B / C / D
JK
M
I
I
Q
L
N
O
P
E / F / G / H
AREC4000
3
Metric
Imperial
1 m: 4 x M8
1.5 m: 4 x M8
2 m: 6 x M8
2.5 m: 6-8 x M8
3.3 ft: 4 x M8
4.9 ft: 4 x M8
6.6 ft: 6 x M8
8.2 ft: 6-8 x M8

Ref Metric
[mm]
Imperial
[in]
Product type
A 884 35.36 AREC4010x
B 851 34.04 AREC4010x
C 20 0.80 AREC4010x
D 29 1.16 AREC4010x
E 71 2.84 AREC4010x
F 56 2.24 AREC4010x
G218 8.72 AREC4010x
H1400 56.00 AREC4015x
I 851 34.04 AREC4015x
J 945 37.80 AREC4020x
K 851 34.04 AREC4020x
L119 8 47.92 AREC4025x
M 851 34.04 AREC4025x
AREC4000
4
Mounting on threaded bars outside the unit
AREC4015
AREC4010
Top view
884
851
71
56
218
1400
851
851
851
945
1198 1198
945
ø29
ø20
ø29
AREC4020
AREC4025
A
G
H
J
L L
J
IK
M
C
D
D
EF
B

AREC4000
5
Fig. 1b. Mounting on threaded bars outside the unit.
Mounting on threaded bars outside the unit
Fig. 1a: Mounting brackets on delivery.
AREC4020
AREC4025

Ref Metric
[mm]
Imperial
[in]
Product type
A 363 14.52 AREC4010x
B 340 13.60 AREC4010x
C 430 17.20 AREC4010x
D 20 0.80 AREC4010x
E 29 1.16 AREC4010x
F 56 2.24 AREC4010x
G 291 11.64 AREC4010x
H 484 19.36 AREC4010x
I218 8.72 AREC4010x
J 71 2.84 AREC4010x
K4 11 16.44 AREC4015x
L 754 30.16 AREC4015x
M 430 17.20 AREC4015x
N 56 2.24 AREC4015x
O 291 11.64 AREC4015x
P 994 39.76 AREC4015x
Q 368 14.72 AREC4020x
R 666 26.64 AREC4020x
S 430 17.20 AREC4020x
T 56 2.24 AREC4020x
U 291 11.64 AREC4020x
V742 29.68 AREC4020x
W 397 15.88 AREC4025x
X 723 28.92 AREC4025x
Y 340 13.60 AREC4025x
Z 430 17.20 AREC4025x
AA 56 2.24 AREC4025x
AB 292 11.68 AREC4025x
AC 828 33.12 AREC4025x
AD 339 13.56 AREC4025x
AREC4000
6
Mounting on threaded bars inside the unit
AREC4015
AREC4010
Top view
AREC4020
AREC4025
363 340
430
430 56
56
430
56
430
56
291
291 994
411
368
754
666 666
484 218
71
56
291
292 828 339 828
742742
397 723 340 723
ø29
ø20
ø29
A
G
K L
O P
Q R R
U V
W X X
AB AC ACAD
Y
V
H I
C
M
S
Z
AA F
F
N
T
J
B
D
E
E

AREC4000
7
1 m: 4 x M8
1,5 m: 4 x M8
2 m: 6 x M8
2,5 m: 6-8 x M8
Fig. 2. Mounting on threaded bars inside the unit.
Mounting on threaded bars inside the unit
Metric
Metric
Imperial
1 m: 4 x M8
1.5 m: 4 x M8
2 m: 6 x M8
2.5 m: 6-8 x M8
3.3 ft: 4 x M8
4.9 ft: 4 x M8
6.6 ft: 6 x M8
8.2 ft: 6-8 x M8

Fig. 3: Snap fixings
90°
AR
Service hatch
Fig. 4: SIRe inside the unit.
Fig. 5: Hoses are mounted via cable glands at knockouts to protect the hose and prevent air leakage.
AREC4000
8
1
2
AREC

Accessories
AREC4000
9
Accessory Product type Quantity Metric Imperial
PA34TR15 AREC4010/15 4 pcs L: 1 m L: 3.3 ft
PA34TR20 AREC4020 6 pcs L: 1 m L: 3.3 ft
PA34TR30 AREC4025 8 pcs L: 1 m L: 3.3 ft
PA34CB15 AREC4010/15 4 pcs
PA34CB20 AREC4020 6 pcs
PA34CB30 AREC4025 8 pcs
PA34VD15 AREC4010/15 4 pcs
PA34VD20 AREC4020 6 pcs
PA34VD30 AREC4025 8 pcs
FHDN2010 AREC4000W 2 pcs L: 1 m L: 3.3 ft
AR42XTT10 AREC4010 H: 130-210 mm H: 5.2-8.4 in
AR42XTT15 AREC4015 H: 130-210 mm H: 5.2-8.4 in
AR42XTT20 AREC4020 H: 130-210 mm H: 5.2-8.4 in
AR42XTT25 AREC4025 H: 130-210 mm H: 5.2-8.4 in
PA34CBPA34TR PA34VD FHDN20 AR42XTT
See separate manual.

Metric Imperial
SIReB
SIReAC
SIReAA
SIReRTX 70x33x23 mm 2.8x1.3x0.9 in
SIReUR 114x70x50 mm 4.6x2.8x2.0 in
SIReWTA
SIReCJ4
SIReCJ6
SIReCC603 3 m 9.8 ft
SIReCC605 5 m 16.4 ft
SIReCC610 10 m 32.8 ft
SIReCC615 15 m 49.2 ft
SIReCC640 40 m 131.2 ft
SIReCC403 3 m 9.8 ft
SIReCC405 5 m 16.4 ft
SIReCC410 10 m 32.8 ft
SIReCC415 15 m 49.2 ft
SIRe
C
C
SIReB
SIReAC/SIReAA
SIReRTX
SIReUR
SIReWTA
SIReCC
SIReCJ4/SIReCJ6
VKF15LF DN15
VKF15NF DN15
VKF20 DN20
VKF25 DN25
VKF32 DN32
SD230
BPV10
SDM24
ST23024
VOT15 DN15
VOT20 DN20
VOT25 DN25
VKF
SDM24 ST23024
SD230 BPV10
VKF
VLSP VLP
VOT
AREC4000
10

AREC4000A/W
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~ L
Trafo
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
4010WA
4025WA/4020WA/4015WA
208V1~
AREC4000
11

AREC4010/15E-208V
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~ L
Trafo
C2
C1
4010E
4015E 4010E/4015E
TS1
TS2
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
208V3~
NL
PAEC4010E/4015E
161121
2 x 10A FUSE
AREC4000
12

AREC4020/25E-208V
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~ L
Traf o
K2
K1
K2
K1
4025E/4020E 4020E/4025E
!
2 X 208V3~
TS2
TS1
TS3 TS4
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
208V3~
NL
PAEC/AREC 4020E/4025E
161123
AREC4000
13

AREC4010/15E-480V/600V
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~
L
Trafo
K2
K1
4010E
4015E 4010E/4015E
TS1
TS2
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
NL
PAEC/AREC 4010E/4015E
215222
600/480V - 230V Transformer
2 x 10A FUSE
600/480V3~
AREC4000
14

AREC4020/25E-480V/600V
H1 H2N
Id
SIRe B1EC
RoomC2 C1 Actuator 230V Supply 230V
PE L
N
Heating
L
N
~ L
Trafo
K2
K1
K2
K1
4025E/4020E 4020E/4025E
!
2 X 600/480V3~
TS2
TS1
TS3 TS4
Motor
protection 0-10V
GND
PWM
LN
Motor
Internal
sensor
MMMM
600/480V3~
NL
PAEC/AREC 4020E/4025E
215223
600/480V - 230V Transformer
2 x 10A FUSE
AREC4000
15

Type Output
[kW]
Airflow*1
[m3/h]
Sound
pressure*2
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
AREC4010A 0 2650 61 208V1~ 3.2 1021 50
AREC4015A 0 3400 62 208V1~ 4.3 1530 70
AREC4020A 0 4800 63 208V1~ 6.0 2021 93
Type Output
steps
[kW]
Airflow*1
[m3/h]
Sound
pressure*2
[dB(A)]
FLA (full load
amperage).*3
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
AREC4010E-208 4/10 2650 60 31 208V3~/27 1021 58
AREC4015E-208 5/15 3400 61 44 208V3~/40 1530 81
AREC4020E-208 7/20 4800 63 60 208V3~/54 2021 107
AREC4010E-480 4/12 2650 60 19 480V3~/15 1021 58
AREC4015E-480 6/18 3400 61 26 480V3~/22 1530 81
AREC4020E-480 8/24 4800 63 35 480V3~/29 2021 107
AREC4010E-600 4/12 2650 60 15 600V3~/12 1021 58
AREC4015E-600 6/18 3400 61 22 600V3~/18 1530 81
AREC4020E-600 8/24 4800 63 30 600V3~/24 2021 107
Type Output*4
[kW]
Airflow*1
[m3/h]
Sound
pressure*2
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Water
volume
[l]
Length
[mm]
Weight
[kg]
AREC4010W 14 2550 60 208V1~ 3.4 1.87 1021 57
AREC4015W 21 3300 61 208V1~ 4.5 2.96 1530 78
AREC4020W 30 4700 62 208V1~ 6.2 4.14 2021 105
3Electrical heat - AREC4000 E (IP20)
2Water heat - AREC4000 W (IP20)
1Ambient, no heat - AREC4000 A (IP20)
*1) Highest airflow of totally 5 fan steps.
*2) Sound pressure (LpA). Conditions: Distance to the unit 5 m. Directional factor: 2. Equivalent absorption
area: 200 m². At highest airflow.
*3) FLA: total amperage for motor and heat.
*4) Applicable at water temperature 80/60 °C, air temperature, in +18 °C.
Approved for 230V/1ph/60Hz and 208V/1ph/60Hz. Product performance for 208V/1ph/60Hz and
230V/1ph/60Hz will differ from stated data.
Metric chart
AREC4000
16

Type Output
[MBH]
Airflow*1
[cfm]
Sound
pressure*2
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Length
[in]
Weight
[lb]
AREC4010A 0 1550 61 208V1~ 3.2 40.2 110
AREC4015A 02000 62 208V1~ 4.3 60.2 154
AREC4020A 0 2850 63 208V1~ 6.0 79.6 205
Type Output
steps
[MBH]
Airflow*1
[cfm]
Sound
pressure*2
[dB(A)]
FLA (full load
amperage).*3
[A]
Voltage [V]
Amperage [A]
(heat)
Length
[in]
Weight
[lb]
AREC4010E-208 14/34 1550 60 31 208V3~/27 40.2 128
AREC4015E-208 17/51 2000 61 44 208V3~/40 60.2 179
AREC4020E-208 24/68 2850 63 60 208V3~/54 79.6 236
AREC4010E-480 14/41 1550 60 19 480V3~/15 40.2 128
AREC4015E-480 20/61 2000 61 26 480V3~/22 60.2 179
AREC4020E-480 27/82 2850 63 35 480V3~/29 79.6 236
AREC4010E-600 14/41 1550 60 15 600V3~/12 40.2 128
AREC4015E-600 20/61 2000 61 22 600V3~/18 60.2 179
AREC4020E-600 27/82 2850 63 30 600V3~/24 79.6 236
Type Output*4
[MBH]
Airflow*1
[cfm]
Sound
pressure*2
[dB(A)]
Voltage
motor
[V]
Amperage
motor
[A]
Water
volume
[US gal]
Length
[in]
Weight
[lb]
AREC4010W 48 1500 60 208V1~ 3.4 0.49 40.2 126
AREC4015W 72 1950 61 208V1~ 4.5 0.78 60.2 172
AREC4020W 102 2750 62 208V1~ 6.2 1.09 79.6 231
*1) Highest airflow of totally 5 fan steps.
*2) Sound pressure (LpA). Conditions: Distance to the unit 16 ft. Directional factor: 2. Equivalent absorption
area: 2150 sqft. At highest airflow.
*3) FLA: total amperage for motor and heat.
*4) Applicable at water temperature 176/140F, air temperature, in +64F.
Approved for 230V/1ph/60Hz and 208V/1ph/60Hz. Product performance for 208V/1ph/60Hz and
230V/1ph/60Hz will differ from stated data.
Imperial chart
3Electrical heat - AREC4000 E (IP20)
2Water heat - AREC4000 W (IP20)
1Ambient, no heat - AREC4000 A (IP20)
AREC4000
17

Output charts water AREC4000
*1) Recommended outlet air temperature for good comfort and optimized output.
*2) Nominal output at given supply and return water temperature.
Supply water temperature:80 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 80/60 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
AREC4010W max 2550 14.7 31 0.07 2.6 28.1 50 0.34 39.6
AREC4015W max 3300 18.9 35 0.09 1.6 39.4 53 0.48 29.5
AREC4020W max 4700 27.8 30 0.13 1.5 55.4 53 0.68 25.9
Supply water temperature: 60 °C
Room temperature: +18 °C
Outlet air temperature: +35 °C*1
Water temperature: 60/40 °C
Room temperature: +18 °C
Type Fan
position
Airflow
[m3/h]
Output
[kW]
Return
water temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
Output *2
[kW]
Outlet
air temp.
[°C]
Water
flow
[l/s]
Pressure
drop
[kPa]
AREC4010W max 2550 15.2 37 0.16 11. 2 16.3 37 0.20 15.8
AREC4015W max 3300 18.8 33 0.17 5.1 22.9 38 0.28 11. 8
AREC4020W max 4700 27.7 35 0.27 5.3 32.3 38 0.39 10.3
Metric chart
Imperial chart
*1) Recommended outlet air temperature for good comfort and optimized output.
*2) Nominal output at given supply and return water temperature.
Supply water temperature:176 °F
Room temperature: +64 °F
Outlet air temperature: +95 °F*1
Water temperature: 176/140 °F
Room temperature: +64 °F
Type Fan
position
Airflow
[cfm]
Output
[MBH]
Return
water temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
Output *2
[MBH]
Outlet
air temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
AREC4010W max 1500 50.2 88 68.5 2.6 95.9 122 326.2 39.6
AREC4015W max 1950 64.5 95 84.6 1.6 134.5 127 456.5 29.5
AREC4020W max 2750 94.9 86 127.5 1.5 189.1 127 643.0 25.9
Supply water temperature: 140 °F
Room temperature: +64 °F
Outlet air temperature: +95 °F*1
Water temperature: 140/104 °F
Room temperature: +64 °F
Type Fan
position
Airflow
[cfm]
Output
[MBH]
Return
water temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
Output *2
[MBH]
Outlet
air temp.
[°F]
Water
flow
[US gal/h]
Pressure
drop
[kPa]
AREC4010W max 1500 51.9 99 155.0 11. 2 55.6 99 187.4 15.8
AREC4015W max 1950 64.2 91 163.6 5.1 78.2 100 264.4 11. 8
AREC4020W max 2750 94.5 95 252.0 5.3 110.2 100 370.9 10.3
AREC4000
18

SIReB Basic
AREC4000 A / AREC4000 E
Wiring diagrams for SIReAC Competent and SIReAA Advanced, see manual for SIRe.
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
SIReCC6XX (max 50 m)
SIReCC6XX
(max 50 m)
SIReCC6XX
(max 50 m)
C
SIReUB1
SIReRTX
(optional)
L=2m
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReB1/B2/B1EC
(max 50 m / 164')
(max 50 m / 164')
L = 2 m / 6' 7"
(max 50 m / 164')
AREC4000
19

Wiring diagrams for SIReAC Competent and SIReAA Advanced, see manuals for SIRe.
SIReB Basic
AREC4000 W
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
C2
X5
C1
X4
ROOM
X3
Pot.
Unit ID ACTUATORSUPPLY
N L NL
PE
L
~
230V~
SIReCC6XX (max 50 m)
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReB1/B2/B1EC
SIReCC6XX
(max 50 m)
SIReCC6XX
(max 50 m)
C
SIReUB1
SIReRTX
(optional)
SD230
SD230
SD230
L=1,5m
L=2m
(max 50 m / 164')
(max 50 m / 164')
(max 50 m / 164')
L = 2 m / 6' 7"
L = 1.5 m / 4' 11"
AREC4000
20
