Friedrich C24YF User manual

Ductless Split Systems
Ceiling Cassette Heat/Cool - C24YF
Features
• Auto-swing louvers (up/down)
• Auto-restart, auto-changeover
• Washable air filters
• Low-ambient operation
• Fresh air intake
• Two branch ducts for adjoining rooms
• Condensate pump– 31" lift
Wired Remote
• Seven-day programmable on/off timer
controls up to 16 units– individually or
by zones
• Self-diagnostics
PURCHASER P.O. # DATE
PROJECT LOCATION
ENGINEER ARCHITECT
SUBMITTED BY FOR APPROVAL FOR REFERENCE
ITEM PLAN DESIGNATION QUANTITY COOLING BTU/H VOLTAGE FRIEDRICH MODEL
91/4"
• Low profile– 9 1/4" above ceiling
Ductless_Ceiling_Cassette_C24YF_Submittal_08
PERFORMANCE RATINGS
SYSTEM MODEL NO. C24YF
INDOOR MODEL MC24Y3F
OUTDOOR MODEL MR24UY3F
Capacity Cooling BTU/h 22200
Capacity Heating @47°F BTU/h 24200
Capacity Heating @17°F BTU/h 20100
HSPF 8.5
SEER 15.0
Moisture Removal Pts/h 6.4
Airflow (Low, Med, High) CFM 436/536/618
Sound Rating - Indoor dB-A 38/43/45
Sound Rating - Outdoor dB-A 53
Operating Range COOL (HEAT) °F 0 to 115
(14-75)
ELECTRICAL DATA
Power Source 230/208-60-1
Min. Ampacity A 15.5
Cooling Watts W 2100
Max. TD Fuse/Breaker A 20
REFRIGERATION SYSTEM
Refrigerant R410A
Compressor Type Inverter (Twin Rotary)
Connections Flare
Liquid Line O.D. in 3/8
Suction Line O.D. in 5/8
Factory Precharge ft 50
Max. Line Length ft 165
Max. Height Difference ft 66
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in 32 5/8x 9 5/8x 32 5/8
Net Weight lbs 75
Shipping Weight lbs 97
OUTDOOR UNIT
W x H x D in 35 3/8x 32 5/8x 13
Net Weight lbs 141
Shipping Weight lbs 154
