THRU-THE-WALL AIR CONDITIONERS
26” AND 27” SLEEVES. IDEAL for NEW CONSTRUCTION, RETROFITS and REMODELS.

• High efciency operation
saves on energy costs
• Residential/commercial
applications
• Heat pumps and electric heat
models
• Mounts ush with the exterior
wall for a neat appearance
• Ideal for thicker wall
installations, where side ns
don’t t
• A high efciency replacement
for 27" sleeves including
Fedders A and B*. Sleeve
measures 27" W x 16 3/4" H
• Easy-to-reach, top mount
controls
• Three-speed fan
• Efcient rotary compressor
• Easy-to-clean lter
• Auto restart
• Remote control
• 24 hour programmable timer
• Money Saver® setting saves money
by conserving energy
• Smart Fan auto-adjusts fan speed to
maintain desired temperature
• Auto-memory backup saves settings
should power be interrupted
Digital Control Features
Unit is shown installed in WSD sleeve (sold and shipped separately)
*Installation in Fedders B sleeve requires a bafe kit. See BAK accessory
under accessories.
Sleeve Dimensions
Friedrich
WSD Sleeve
Fedders
A Sleeve
Fedders
B Sleeve*
Height (inches) 16 3/4 16 3/4 16 3/4
Width (inches) 27 27 27
Depth (inches) 16 3/4 16 3/4 19 3/4
27” SLEEVE
Ideal for new construction, and as
a high efficiency replacement in
retrofits and remodels
Features
WALLMASTER® THRU-THE-WALL AIR CONDITIONERS
WallMaster®
COOLING HEATING
7,800-14,500 BTU/h 7,300-11,000 BTU/h
Up to 9.9 EER
QUALITY

Units are shown without USC sleeve (USC
sleeves sold and shipped separately)
• Rotary compressors
provide quiet, dependable
performance
• Six-way air ow control
• Stale air exhaust
• Auto restart
• Washable/reusable lter
• Seacoast protection
• 12 hour programmable timer
• Money Saver® setting saves money
by conserving energy
Digital Control Features
Features
Sleeve Dimensions
Friedrich
USC
Sleeve Amana
Carrier
(51S
Series)
Fedders/
Emerson/
Friedrich
WSD
Emerson/
Fedders
GE/
Hotpoint Whirlpool
White-
Westinghouse/
Frigidaire/
Carrier (52F
Series)
Height (inches) 15 1/2 15 5/8 16 7/8 16 3/4 15 3/4 15 5/8 16 1/2 15 1/4
Width (inches) 25 7/8 26 25 3/4 27 26 3/4 26 25 7/8 25 1/2
Depth (inches) 16 3/4 16 7/8 18 5/8 16 3/4 or
19 3/4
15 16 7/8 17 1/8
or 23
16, 17 1/2
or 22
UNI-FIT® THRU-THE-WALL AIR CONDITIONERS
26” SLEEVE
Universal fit for easy replacement in
existing 26” sleeves
Uni-Fit®
COOLING HEATING
8,000-13,000 BTU/h 3,850-11,200 BTU/h
Up to 9.6 EER

When should you
install a solid side
sleeve?
SOLID SIDE wall sleeve allows
for installation in thick exterior
walls where the installation of
room air units with side vents
would effect performance and
may even void the warranty.
ROOM AIR CONDITIONER
Blocked side vents restrict air
ow
FRIEDRICH THRU-THE-WALL
Solid-side sleeve (no side
vents) can be installed ush
with exterior wall.
Commercial & Residential Applications
THRU-THE-WALL
units mount ush with
exterior walls for a sleek
appearance, as well as
unobstructed window
views.
(Wallmaster WSD sleeve
shown with architectural
grille. Uni-t grille has
different appearance.)

USC Sleeve
Standard Grille
STANDARD GRILLE – Ships with USC sleeve
Expanded aluminum grille designed for use with USC
sleeve.
REPLACEMENT GRILLE – Ships with US/UE chassis
High-tech plastic for use on existing sleeves without any
grille.
IMPORTANT:
When installing into an existing sleeve, consult
Installation Section of your Installation/Operation Manual
to determine whether or not the grille needs to be
replaced and/or a bafe adapter should be used.
Installation Accessories (27” sleeve models only)
DK / Drain Kit
Installed at the back of the unit and allows
for attachment to permanent condensate
disposal system, if disposal is necessary
or desired.
SB / Sub Base
Used as a base for the unit when
it is desired to place the cord and
receptacle within the installation, or
simply as a base for the unit when
mounted low in the wall.
BAK / Bafe Adapter Kit
Necessary when installing in a sleeve
deeper than 16 3/4" deep, such as
Fedders B sleeve (19 3/4" deep).
IDK / Internal Drain Kit
New construction applications where
a condensate drain system has been
built into the wall interior.
16 3/4"
Fedders B
19 3/4”
IMPORTANT:
Operating the air
conditioner with incorrect
rear grille or without
Bafe Adapter Kit (on
19 3/4” deep sleeve) will
recirculate discharge air
and cause compressor
overload to trip.
CORRECT Vertical Louvers
INCORRECT Horizontal Louvers
WSD Sleeve
Standard Grille - Ships
with sleeve. Galvanized
steel weather panel also
ships with sleeve.
Model Height Width Depth
Depth
with
Front
Minimum
Extension
Into Room
Minimum
Extension
Outside
Thru-the-wall
Finished Hole
Height Width Max. Depth
WALLMASTER
WSD Sleeve 16 3/4" 27" 16 3/4" 23" 7 1/2" 9/16" 17 1/4" 27 1/4" 15 5/16"
Chassis 15 3/4" 26 1/2" 21" 22” – – – – –
UNI-FIT
USC Sleeve 15 1/2" 25 7/8" 16 3/4" 20 1/2" – 1/2" 15 3/4" 26 1/8" 16 1/4"
US Chassis 14 3/8" 24" 20 1/8" 3 3/4" – – – –
UE Chassis 14 3/8" 24 5/8" 19 5/8" 3 1/2" – – – –
IMPORTANT: Sleeves are sold and shipped separately to accommodate new construction and replacement requirements
Uni-Fit® 26” Sleeve Exterior Grilles
Sleeve/Chassis Dimensions
WallMaster® 27” Sleeve Exterior Grilles
Sleeve shown with
Replacement Grille
WSD Sleeve
Optional Architectural Grille- AG
IMPORTANT:
US chassis w/front fully installed into USC sleeve
extends into room 3 3/8”. UE chassis w/front fully
installed into USC sleeve extends into room 2 7/8”.
US= 3 3/8”, UE= 2 7/8”

Specifications  EnErgy Star® models
WALLMASTER HEAT PUMP
HEATING PERFORMANCE: Change-over from heat pump operation to resistance
operation on models indicated is automatic at a preset outside ambient temperature
of approximately 35°F.
Calculate the heat loss of the space to be heated. As long as the heat loss does
not exceed the resistance heating capacity rating of the unit, the heating perfor-
mance will be satisfactory.
Note: all models will produce condensate. If condensate disposal is desired, an
optional drain kit is available.
DEFROST CONTROL: Initiated at 20°F (outdoor coil temperature) and terminated
at 43°F (outdoor coil temperature). During defrost, the compressor stops and
the electric heat starts, then operates with the fan to maintain indoor comfort.
Below 43°F, the unit remains in electric heat mode. During electric heat mode,
the unit will achieve the following ratings: 11000/9100 BTU/h, 16.0/14.7 amps,
and 3550/2950 watts.
DEFROST DRAIN: Drain automatically opens at approximately 50°F to prevent
condensate from freezing inside drain pan.
WallMaster Heat Pump heating information (shown in red) indicates heat pump heating performance. WallMaster Electric Heat heating information (shown in red)
indicates electric heat strip performance. For WallMaster Heat Pump electric heating performance refer to corresponding WallMaster Electric Heat model.
Plug Face/ Circuit Rating
WallMaster
Model Number
Uni-Fit
Model Number
Circuit Rating
Breaker
or T-D Fuse
Plug Face
(NEMA#)
Power Cord
Length (ft.)
Wall
Outlet
Appearance
WS08C10, WS10C10,
WS12C10
US08C10, UE08C13
US10C10, US12C10 125V - 15A 5 - 15P 6
WS10C30, WS13C30,
WS15C30
US10C30, US12C30,
US14C30 250V - 15A 6 - 15P 4
WE10C33, WE13C33,
WE15C33, W Y09C33, WY12C33 UE10C33, UE12C33 250V - 20A 6 - 20P 4
Power cords are located on front left of WallMaster models and on front right of Uni-Fit models.
All models use
environmentally
friendly R-410A
refrigerant.
R-410A
Friedrich Air Conditioning Co. l P.O. Box 1540 l San Antonio, TX 78295-1540 l 800.541.6645 l fax [phone]
www.friedrich.com
TTW-10 (3-10) Printed in USA
Estar
Model
Cooling
Capacity Btu
Heating
Capacity Btu
Volts
Rated
Cooling
Amps
Cooling
Watts
Heating
Amps
Heating
Watts
Energy
Efciecy
Ratio
EER
Estimated
Yearly
Operating
Cost
Moisture
Removal
Pints/HR
Room
Side Air
Circulation
CFM Sleeve
Net
Weight
Lbs
WALLMASTER
Cool only

WS08C10 7800 NA 115 7.1 788 NA NA 9.9 †1.2 250 WSD 93

WS10C10 9700 NA 115 10.0 1032 NA NA 9.4 $82 2.4 257 WSD 103

WS12C10 11900 NA 115 11.8 1266 NA NA 9.4 $101 3.3 295 WSD 112

WS10C30 9500/9200 NA 230/208 4.5/4.7 989/958 NA NA 9.6/9.6 $79 1.5 300 WSD 101

WS13C30 12600/12300 NA 230/208 6.3/6.7 1340/1309 NA NA 9.4/9.4 $107 3.6 290 WSD 109
WS15C30 14500/14500 NA 230/208 8.3/8.2 1706/1706 NA NA 8.5/8.5 $136 4.2 290 WSD 119
Heat Pumps

WY09C33 9300/9000 7300/7300 230/208 4.4/4.7 989/957 3.8/4.0 839/793 9.4/9.4 $79 2.1 250 WSD 103
WY12C33 12000/11800 9350/9200 230/208 6.1/6.4 1395/1372 4.8/5.1 1062/1010 8.6/8.6 $111 2.6 275 WSD 111
Cool with Electric Heat
WE10C33 9500/9200 11000/9100 230/208 4.5/4.7 989/958 16.0/14.7 3550/2950 9.6/9.6 $79 1.5 300 WSD 121
WE13C33 12600/12300 11000/9100 230/208 6.3/6.7 1340/1309 16.0/14.7 3550/2950 9.4/9.4 $107 3.6 290 WSD 107
WE15C33 14500/14500 11000/9100 230/208 8.3/8.8 1706/1706 16.0/14.7 3550/2950 8.5/8.5 $136 4.2 290 WSD 116
UNI-FIT
Cool Only

US08C10 8000 - 115 7.5 830 - - 9.6 $66 2.2 260 USC 73

US10C10 9800 - 115 9.6 1040 - - 9.4 $83 3.2 285 USC 78

US12C10 11500 - 115 11.2 1220 - - 9.4 $97 3.8 290 USC 80

US10C30 10000/9800 - 230/208 4.7/5.2 1060/1040 - - 9.4/9.4 $85 3.2 285 USC 78

US12C30 11500/11200 - 230/208 5.6/6.0 1220/1190 - - 9.4/9.4 $97 3.8 290 USC 80

US14C30 13000/12600 - 230/208 7.0/7.5 1530/1480 - - 9.4/9.4 $122 4.0 310 USC 87
Cool with Electric Heat
UE08C13 8000 3850 115 7.5 830 10.7 1230 9.6 $66 2.2 260 USC 73
UE10C33 10000/9800 11200/9200 230/208 4.7/5.2 1060/1040 15.3/14.0 3500/2900 9.4/9.4 $85 3.2 285 USC 78
UE12C33 11500/11200 11200/9200 230/208 5.6/6.0 1220/1190 15.3/14.0 3500/2900 9.4/9.4 $97 3.8 290 USC 80
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
As an EnErgy Star® partner, Friedrich Air Conditioning Co. has determined that the selected EnErgy Star® models
meet the EnErgy Star® guidelines for energy efciency.
Estimated yearly operating cost based on a 2007 national average electricity cost of 10.65 cents per kWh.
† The estimated yearly operating cost of this model was not available at the time the range was published.
