Friedrich ZoneAire PH14B Guide




FRIEDRICH






Service & Parts Manual - 2012


PortableAirConditioner
Models PH14B






















































Portable Air Conditioner-2012 Svc-Parts (01/2012)
Important points on service , and flow chart
for
inspecting and repairing the unit ...............2
Troubleshooting .............................................2
Appearance and unit dimensional...................3
Operatio n .................................................... 4-5
Technica l specifications.............................. 6
Refrigerator system and schematic wiring
diagrams ........................................................ 7
Exploded view and Parts Lists ....................8 -10

98081402 00

Only a qualified professional should perform any repair service(s).
When replacing any electrical components they should be OEM factory components.
Be sure that any electrical components are properly wired and secured.
POWER
BREAKER/FUSE
TRIPPED
SUPPLY CORD NOT
PLUGGED IN OR IS
LOOSE IN POWER
RECEPTACLE
REPLACE SUPPLY
CORD IF RESETTING
DOES NOT CORRECT
UNIT'S POWER CORD
TRIPPED
3 MINUTE TIME DELAY
ISACTIVATED
ELECTRICAL
COMPONENT
COMPR20ISED
RE-TEST UNIT
TROUBLESHOOTING
THE SEALED SYSTEM
COMPONENTS
TEMPERATURE
SETTING IS NOT
BELOW ROOM
TEMPERATURE
SET TEMPERATURE SETTING
ABOVE (HEATING MODE) OR
BELOW (COOLING MODE)
ROOM TEMPERATURE
REPAIR OR REPLACED ALL
COMPROMISED SEALED
SYSTEM COMPONENTS
WEIGH IN UNIT'S SPECIFIC
REFRIGERANT CHARGE
TROUBLESHOOT
ELECTRICAL
COMPONENTSAND
REPAIR OR REPLACE
PLUG IN SECURELY
THE SUPPLY CORD
RESET SUPPLY
CORD'S LCDI
WAIT FOR THREE
MINUTES
FLOW CHART FOR TROUBLESHOOTING OF THE UNIT
---2---

Conditioned Supply
Air Louvers
Continuous Drain
Pump Outlet
Static Water
Drain Outlet
Return Air Grille
Room Air Filter
Outside Air Inlet
Exhaust Air Outlet
Power Supply Cord
Wheel Casters
19.50 inches
33.6 inches
15.5 inches
---3---

less than 80 F.
60 F
unit
60 F - 90 F.
75 degrees F
unit
turn unit ON
Timer Setting
exhaust hoses
two
air exchange hoses left vented to the outside
area will provide some cooling.
Timer (12 Hour Timer - 1 setting On or Off)
to the outside.
80 F
---4---

OFF
3 feet
---5---

inches
PH14B
19.5 x 33.6 x 15.5
3.8 pints/H
207
115/60
115/60volts/hz
volts/hz
volts/hz
inches .086 OD x .039 ID x 27.5 in
115/60
115/60
27.5 ounces
80
oz
lbs
volts/hz
140 sq ft - 204 sq ft
115/60
ft
P
---6---

---7---

Accessory Items
---8---

PARTS LIST PH14B
NO PART# PARTS NAME QUANTITY
1 67904000 BASEPAN 1
2 67904001 CASTERS (WHEELS) 4
3 67904002 DRAIN PLUG 1
4 67900404 DRAIN BUCKET COVER-B 1
5 67904100 MICRO SWITCH 3
7 67900405 FLOAT 1
8 67900406 FLOAT 1
9 67904300 PUMP FAN MOTOR 1
10 67900409 PUMP FAN WHEEL 1
11 67900410 PUMP HOUSING 1
19 67904301 4-WAY REVERSING VALVE ASS'Y 1
26 67904017 CONDENSER BLOWER HOUSING 1
27 67904018 CONDENSER BLOWER WHEEL 1
28 67904020 CONDENSER SHROUD 1
29 67904302 CONDENSER MOTOR 1
30 67904303 TERMINAL BLOCK 1
31 67904067 CAPACITOR (55uF/300V)(FOR COMPRESSOR (12) 1
32 67904021 CAPACITOR (9uF/250V)(FOR FAN MOTOR (29) 1
33 67904033 CONTROL BOARD HOUSING 1
34 67904305 CONTROL BOARD 1
35 67904031 COVER 1
36 67904023 TOP PLATE FOR EVAPORTATOR ASSLY 1
38 67904027 EVAPORATOR MOTOR 1
39 67904025 EVAPORATOR BLOWER HOUSING 1
41 67904028 EVAPORATOR SHROUD 1
42 67904304 EVAPORATOR BLOWER WHEEL 1
43 67904030 CAPACITOR (8uF/250V)(FOR FAN MOTOR (38) 1
44 67904078 POWER SUPPLY CORD COMPLETE 1
45 67904036 FRONT PANEL 1
46 67904306 REAR PANEL 1
47 67904039 AIR FILTER 1
48 67904037 HANDLE 2
49 67904040 SUPPLY AIR LOUVER CONNECTOR 1
50 67904041 SUPPLY AIR LOUVERS 5
---9---

PARTS LIST PH14B
NO PART# PARTS NAME QUANTITY
51 67904307 PC DISPLAY BOARD 1
52 67904046 DISPLAY BOARD MOUNTING PLATE 1
53 67904308 DISPLAY BOARD OVERLAY 1
54 67904042 COVER 1
55 67904043 DISCHARGE GRILLE 1
59 67904310 INDOOR AIR SENSOR 1
60 67904175 FIXTURE SUPPORT 1
61 67904311 FREEZE PROTECTION SENSOR 1
62 67904034 FIXTURE SUPPORT 1
63 67904053 EXHAUST & INTAKE HOUSES 2
64 67904054 EXHAUST & INTAKE AIRE HOSE CONNECTOR 4
65 67904055 FIXTURE 2
66 67904056 COVER 2
68 67904058 EXHAUST & INTAKE FIXTURE PLATE 1
69 67904059 EXTENSION FILLER PLATE 1
70 67904309 REMOTE CONTROL ASS'Y 1
71 67904312 CONNECTOR 1
72 67904313 DRAIN PIPE 1
75 67904101 DRAIN PUMP 1
76 67904102 QUICK CONNECTOR 1
77 67904107 FIXTURE 1
78 67904103 PUSH BUTTON SWITCH 1
---10---
