PRODUCT NO. BASE MODEL NO. MARKET BTU COOLING
FAC083K7A4 FAC083K7A USA 8000 BTU
Publication No.
5995364451
020124
-EN/SERVICE /KC
345
ROOM AIR CONDITIONER
Model No.
FAC083K7A4
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
WIRING DIAGRAM - # 309107703
OWNER’S GUIDE - # 309000825
ELECTROLUX HOME PRODUCTS, INC.
P.O.BOX 212378, AUGUSTA, GA 30917

01/02 2
Publication No. FAC083K7A4
5995364451
CABINET FRONT AND WRAPPER

# = Fast-moving Parts 3 01/02
* = Non-Illustrated Parts
FAC083K7A4 Publication No.
5995364451
CABINET FRONT AND WRAPPER
POS. NO PART NO DESCRIPTION
1 309643602 Cabinet
* 5303303691 Screw,truss head ,8-18AB x 0.375 ,cabinet/base,w/nibs
8 309640202 Louver Assy,horizontal ,Incl-7,8,9
7 309638001 * Link,vertical louver ,with handle
8 309639301 * Louver,horizontal
9 309342001 * Louver,vertical ,(6)
12 309343501 Filter-air,7.12 x 17.31 ,no frame
17 309640104 Front-cabinet,4 way ,complete assy
19 309342903 Dial Plate
19* 5303001775 Spacer,dial plate
20 309306811 Knob-control,rotary
25 309328603 Door-vent,fresh air
26 309638201 Handle vent door
26* 309330201 Detent-vent
38 309646301 Panel,cabinet front
43 309646401 Frame,cabinet front

01/02 4
Publication No. FAC083K7A4
5995364451
CONTROLS

# = Fast-moving Parts 5 01/02
* = Non-Illustrated Parts
FAC083K7A4 Publication No.
5995364451
CONTROLS
POS. NO PART NO DESCRIPTION
7 309643802 Box-control
8 # 5303323284 Switch,selector ,7 posn,3 speed
9 # 5304402838 Control,temperature
10 309643702 Bulkhead
10* 309111201 Grommet,wire protector
12 309101202 Clip,retainer ,temp sensor ,(2)
13 # 5304426450 Capacitor,250 V ,40+10 mfd
14 3015312 Screw,8-18AB x 0.500
15 309351901 Strap-capacitor
17 # 309343101 Cord-electric power,18 AWG ,115 V
18 5303007754 Screw,6-32 x 0.188
20 5304417582 Sleeve,temp sensor ,6 in.

01/02 6
Publication No. FAC083K7A4
5995364451
AIR HANDLING PARTS

# = Fast-moving Parts 7 01/02
* = Non-Illustrated Parts
FAC083K7A4 Publication No.
5995364451
AIR HANDLING PARTS
POS. NO PART NO DESCRIPTION
1 # 309624502 Fan Blade,with clamp
2 3202975 Screw,10-16AB x 0.72 ,square drive
3 309643901 Housing-fan,shroud
4 5304421913 Seal,top
4 5303303759 Seal,bottom
6 08007481 Nut,Keps ,motor mtg
8 # 309644302 Motor-fan
10 309643702 Bulkhead
11 # 309631701 Blower Wheel
12 309112101 Clamp-blower
15 309642901 Housing-blower,Extended
16 309100201 Clip,evap/bulkhead
20 309643002 Plate-blower housing,scroll plate

01/02 8
Publication No. FAC083K7A4
5995364451
COMPRESSOR PARTS

# = Fast-moving Parts 9 01/02
* = Non-Illustrated Parts
FAC083K7A4 Publication No.
5995364451
COMPRESSOR PARTS
POS. NO PART NO DESCRIPTION
1 # 309616918 Compressor
2 5303283877 Grommet,compressor mtg ,(3)
3 5308006948 Nut,compressor mtg ,(3)
6 3201668 Gasket,terminal cover
7 5304405245 Cover-terminal,compressor
8 # 5304402840 Overload Protector
9 3201670 Nut,terminal cover
10 # 5303317601 Start Assist Kit,compressor
11 # 309619313 Evaporator assy
12 # 5303307226 Condenser
13 # 309642801 Tray-evaporator
14 309644003 Base,compressor mtg ,with studs
16 # 5304409280 Capillary Tube,37 inch long
17 5304417516 Tube-process
19 5303002664 Washer,compressor mtg
19* 309112501 Washer,metallic

01/02 10
Publication No. FAC083K7A4
5995364451
WINDOW MOUNTING PARTS

# = Fast-moving Parts 11 01/02
* = Non-Illustrated Parts
FAC083K7A4 Publication No.
5995364451
POS. NO PART NO DESCRIPTION
1 5304407729 Seal-window frame,stuffer
2 5303211056 Bracket
4 309644901 Frame Extension Kit,accordian ,LH & RH ,incl.-4,14
4 5304414120 Extension-frame,LH ,w/accordian
5 08016226 Seal-top rail
14 3015312 Screw,8-18AB x 0.500
14 5304414121 Extension-frame,RH ,with accordian
15 309626504 Closure,accordian type ,window mount
16 5304417362 Rail,retainer ,top
17 3002803 Screw,wood, type 17 ,10-12 x 0.750
18 5303303691 Screw,truss head ,8-18AB x 0.375 ,cabinet/base,w/nibs
20 5304411997 Screw,8-18 x 0.750
22 5304403252 Rail,retainer ,bottom
23 3001806 Screw,23(T) ,10-32 x 0.310
24 5308002974 Screw,wood,type 17 ,8-15 x 0.500
WINDOW MOUNTING PARTS

01/02 12
Publication No. FAC083K7A4
5995364451
WIRING DIAGRAM
