FrSky TD MX Receiver User manual

Version
1.0
Instruction Manual for FrSky TD MX Receiver
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
How to switch the S.Port/F.Port/FBUS (F.Port2)
Enter into the Set-Options, click the Telem.Port, and select S.Port/F.Port/FBUS (F.Port2).
How to switch SBUS channel mode
Enter into RX Settings, click [SBUS], then select SBUS-16 mode or SBUS-24 mode.
Note: When using redundancy function, ensure the same mode of primary and secondary receivers
How to enter into the Race mode (down to 4ms)
Enter into Model-RF system, select the Channel Range as CH1-CH8. Click [Switch Positions] and select a switch to
start the race mode.
LED state
Green LED
On
Flash
On
On
On
Off
Red LED
On
Flash
On
Off
Off
On
Status
Register
Register successfully
Bind
Bind successfully
Working normally
Failsafe
Blue LED
Off
Off
Off
Flash
Flash
Off
Version
1.0
Instruction Manual for FrSky TD MX Receiver
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
Introduction
Neither like other FrSky 2.4G receivers nor 900M receivers, the Tandem dual-band series receivers work simultane-
ously at both 900M and 2.4G frequencies that means it can give not only low latency signal control but long control
range with an enhanced level of high reliability and anti-interference performance.
The Tandem series receivers adopt the triple antenna design that can give the multi-directional coverage as wide
as possible for the remote signal. The 900M antenna comes with a newly designed small form factor, but it has the
equivalent high-performance as the original 900M antenna.
TD MX offers 4 PWM channels on a small board with lightweight, and it also has multiple ports onboard like SBUS
Out, SBUS In (Signal Redundancy), S.Port. With the FBUS protocol, the Tandem series receivers can open up the
possibility of seamlessly pairing with multiple telemetry devices (Neuron ESC, Advance Sensors, etc.) as well as
simplifying the builds setup. In addition, the data (Power & Signal related) under unusual status during the flight can
be recorded by Tandem receivers through the built-in black-box function.
Features
● Simultaneous working dual-band TD mode
● Triple antenna design for multi-directional coverage
● Black Box function
● 4ms Race Mode with Telemetry
● Long control range
● Over-The-Air (OTA) FW update
● 4 PWM channels
● S.Port (with the FBUS protocol)
● SBUS Out / SBUS In (Redundancy Func.)
Registration & Automatic binding
Follow the step below to finish the Registration & binding procedure:
1. For TANDEM X20 as an example,enter into the Model, select RF System, turn on the internal module, select
status [ON] and TD MODE(Type). You can select Internal / External antenna and the power as you need, then
select [Register].
2. Connect the battery to the receiver while holding the button on the receiver. The RED LED and GREEN LED on
the receiver will be on, indicating into the [Reg] status.
3. When it shows the Register ID, RX name and UID,click [Register]. The RED LED and GREEN LED on the
receiver will flash, and the transmitter displays [Registration OK ].
4. Turn off the receiver.
5. Move the cursor to select the any one of the 3 receivers [Bind].
6. Connect the battery to the receiver.
7. Select the RX, the GREEN will keep lit and the BLUE will flash. Then the transmitter displays [Bind successful].
Note: Once the receiver is registered, the button is not needed anymore in the binding process.
Button
RED GREEN BLUE
G C D V
2.4G
2.4G
900M
Specifications
● Frequency: 2.4GHz & 900MHz
● Dimension: 25*21*4mm (L*W*H)
● Weight: 7.1g
● Operating Voltage: 3.5-10V (Please ensure the supplied voltage exceed 3.5V during the use.)
● Compatibility: Tandem series transmitter & TD protocol capable RF module
● Triple 2.4G/900M Antenna
● – 2 External 2.4G antenna (IPEX1)
● – 1 Newly designed 900M antenna
It only matches with the Tandem series transmitters with dual-band transmitter module.
*
*
Overview
21mm
25mm
Button
GND
VIN
S.Port
TEST
SBUS OUT
SBUS IN
4
3
2
1
RED GREEN BLUE
G C D V
2.4G
2.4G
900M
900MHz Receiver Antenna

FCC STATEMENT
Product certificated FCC ID：XYFTDMR2409
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment generates uses and can radiate transmitter frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to transmitter
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to transmitter or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced transmitter/TV technician for help.
About OTA function
For TANDEM X20 as an example, go to the [File manager], and select the FW, press the enter button, select
[Flash RX by int.OTA].Power on the receiver, select the RX, go to the [ENTER], complete the flash process, the
transmitter will display [Success]. Wait for 3 seconds,the receiver works properly at the moment.
Note: Please do not do the binding operation in the near range while the firmware upgrading in progress.
Note: Update the firmware after the receiver getting registered (OTA).
Failsafe
Failsafe is a useful feature which is for a preset channel output position whenever control signal is lost for a period.
Follow the steps to set Failsafe for channels necessary:
Failsafe for receiver supporting TANDEM can be set via transmitter interface, which support no pulse, hold and
custom three modes for each channel.
For TANDEM X20 as an example, turn on the transmitter, go to: MODEL SETUP/Internal RF/Failsafe.
FrSky is continuously adding features and improvements to our products. To get the most from your product, please check
the download section of the FrSky website www.frsky-rc.com for the latest update firmware and manuals
