FSH FCL0001 User manual

FCL0001 Cabinet Lock
Installation Instructions
The cabinet lock is designed to fit into cabinets and lockers with swing or sliding doors. The
lock is interchangeable between the POWER TO LOCK (see FIG 1) and POWER TO OPEN
(see FIG 2), two kinds of operation modes.
Striker installation:
SIDE ENTRY OF STRIKER (see FIG 3) Use the 10mm distance indicated in Figure 4 to set
the distance from the interior side of the door to the
first screw hole of the lock.
FRONT ENTRY OF STRIKER (See FIG 3) Use the 37mm distance indicated in Figure 4 to set
the distance from the backside of the lock to the
mounting face of the striker.
Power input 12 VDC or 24 VDC supply:
Note: There is no polarity on power input.
RED
BLUE
YELLOW
BLACK
12 VDC / 190 mA 24 VDC / 90 mA
RED
BLUE
YELLOW
BLACK
Figure 1: PTL Figure 2: PTO
Interchange between PTL and PTO:
1 Remove four screws from bottom
2 Remove the bottom case
3 Replace the wire in opposite side
4 Turn the bottom case 180ohorizontally
5 Replace the bottom case
6 Replace the four screws.
Striker insert
from left Striker insert
from right
FIG 4
Striker insert from front
10 10
Striker can enter lock from
any of three sides, and also
sliding from the side.
FIG 3
SIDE ENTRY SIDE ENTRY SLIDE ENTRY
FRONT ENTRY
Figure 3 Figure 4

15.5
22 22 15.5
60
72.7
28.5
40
31
4.5
18
￠
3.8CSK-4HOLES
Min 20Min 20
FIT STRIKER SECOND
15.5 15.5
2
FIT DOOR LOCK FIRST
1
SLIDING DOORS
2
1
SWING DOORS
FIT DOOR LOCK FIRST
FIT STRIKER SECOND
V1.0 2008
