Installation Manual
FES20 Series ELECTRIC STRIKE
PRODUCT
FES20 Non Monitored Strike (not SCEC approved)
FES20M Monitored Strike (SCEC approved)
FES20M-L2 Monitored Strike Lipless (SCEC approved)
FES20M-R Monitored Strike with additional integrated Reed Door Position Switch (DPS) (not SCEC approved)
ACCESSORIES
MORTICE LOCK FACEPLATES EQUIPPED WITH A SET OF MONITORING MAGNETS
FES20-EL 15
FES20-EL 25
FES20-EL 50
FES20-EL 75
Australian Lock Company FES20MR-AUS
DORMA FES20MR-DOR
KABA FES20MR-KAB
Legge FES20MR-LEG
Lockwood FES20MR-LOC
Nova FES20MR-NOV
Other mortice lock types or cylindrical locks on request
WIRING
When installation of the strike and the mortice lock face plate is completed, connect the wiring according to list below:
Grey Grey Normally Open Contacts Door Position Switch
0.5A, 30VDC
Multi Voltage 11-30VDC 12 VDC – current 220 mA
Red (+) Black (-)
Black (Common) Yellow (NO-PTO); (NC-PTL) Green (NC- PTO); (NO-PTL)
Black (Common) Blue (NO) Orange (NC)
Black (Common) Red (NO) White (NC)
LSS Sensor Output
3 A, 125 VAC;
2 A, 30 VDC.
DSS Sensor Output
3 A, 125 VAC;
2 A, 30 VDC.
Anti-tamper Sensor Output
5 A, 125 VAC;
3 A, 250 VAC.
24 VDC – current 110 mA
DPS (Door Position Status)
Power Input
Wire output
LSS (Lock Status Sensor)
DSS(Door Status Sensor)
ATS (Anti – tamper Sensor)
Sensor Output
122
122
122
10
5
24
26
28.5
175.6
39.5
122
26
10
28.5
3
23
5
138
122
122
PRODUCT DIMENSIONS
The FES20M-R monitored Electric Strike is equipped with an integrated Reed Door Position Switch (DPS). This function requires a special
Mortice Lock Face Plate equipped with a set of magnets to operate in combination with the FES20M-R Electric Strike.
FSH is providing a range of face plates from 6 manufacturers (see above). Face plates from other manufacturers on request.
NOTE
FES20 Series Electric Strike factory setting is Power to Lock (PTL) .
The control circuit for the door strike is protected against reverse polarity connection. No additional diode protection required.
see new separate Manual for FES20M

Latch front face
cut thru
outline
TEMPLATE
Position this line to
your marking.1mm
clearance has been
added.
5 sizes of extension lips are available
5mm,15mm, 25mm, 50mm and 75mm
Depth of cut-out will vary dependent on width of door frame
Depth
Lipless
10mm Lip
Standard
15mm Lip
40mm
162mm
123.1mm
NOT TO SCALE 29.0
44.8
*These dimensions have a tolerance of +0.8mm/-0
176.0
Keeper
INSTALLATION
If frame is not prefabricated, use the enclosed stick-on template to prepare strike cut-out in frame.
Install strike as described in diagram.
POSITION OF DOOR LATCH
As drawn in the diagrams, there should be a 1mm gap between the door latch and the front face of the strike keeper, preventing the door from
creating back pressure on the strike keeper when the door is closed.

FIELD SELECTION
PROCEDURES TO CONVERT PTO (POWER TO OPEN) TO PTL (POWER TO LOCK)
Remove the rubber cap to expose the capstan wheel.
Slacken both of the capstan release screws two full revolutions,
DO NOT REMOVE.
Remove the sticker from the cover end opening hole.
The strike is now in the Power to Lock mode.
Tighten the two capstan releasing screws replace the rubber cap.
Replace the sticker after changing over locking function.
Insert the “tool pin” through the cover end opening hole
and push down the solenoid. Hold it in position and at the
same time insert the “tool” thru the cover plate opening
hole and turn the capstan wheel in the direction of the
keeper to the stop.

FIELD SELECTION
PROCEDURES TO CONVERT PTL (POWER TO LOCK) TO PTO (POWER TO OPEN)
Remove the rubber cap to expose the capstan wheel.
Slacken both of the capstan release screws two full revolutions,
DO NOT REMOVE.
Remove the sticker from the cover end opening hole.
The strike is now in the Power to Open mode.
Tighten the two capstan releasing screws and replace the rubber cap.
Replace the sticker after changing over locking function.
Insert the “tool pin” through the cover end opening hole
and push down the solenoid. Hold it in position and at the
same time insert the “tool” thru the cover plate opening
hole and turn the capstan wheel in the direction of the
release screw to the stop.
