Fuji Electric FSC-2 User manual

Instruction Manual
PORTABLE TYPE
ULTRASONIC FLOWMETER
TYPE:  FLOW TRANSMITTER FSC-2
DETECTOR FSS-1, FSD-1
INZ-TN2FSCd-E

INF-TN2FSC-E i
PREFACE
You are now a proud owner of Fuji’s ultrasonic owmeter.
Manufacturer : Fuji Electric Co., Ltd.
Type : Described in nameplate on main frame
Date of manufacture : Described in nameplate on main frame
Product nationality : Japan
Note) Windows 2000/XP/Vista/7, Excel, Bitmap are registered trade marks of Microsoft Corporation.
SD logo is a registered trademark.
Issued in Mar., 2013
Rev. 1st edition Apr., 2014
Rev. 2nd edition Nov., 2015
Rev. 3rd edition Jan., 2016
Rev. 4th edition Jun., 2016
This manual explains cautions in use, wiring, operation, installation, troubleshooting and maintenance, and op-
tions of the portable type ultrasonic owmeter. Please read through the manual before using the instrument.
Keep this manual available for reference by appropriate operation and maintenance personnel.
Notice
• It is prohibited to transfer a part or the whole of contents of the
manual without permission.
• Contents of the manual are subject to change without prior notice.
© Fuji Electric Co., Ltd. 2013
Option
The following options are available.
• Flow velocity prole measurement

ii INF-TN2FSC-E

  
  
 
 
 
  
  
 
 
 
 
 
 
 
  
 
 
  
  
 
 
 
 
  
 
 
 
 
 
 
 
 
 
 
 
 
 
  
 
 

INF-TN2FSC-E iii
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
 
  
  
 





 




 



 



 







iv INF-TN2FSC-E
 





 


 


  
  
 
 
 
 
  
  
 
 
  
  
 
 
 
 
 





INF-TN2FSC-E v
Be sure to observe the following precautions. They offer important information on safety.
Operating this device in a manner not specied may damage its protective construction.
● The degree of injuries or damages resulting from improper handling of this device is indicated
by different symbols.
CAUTION
Improper handling of this device may cause dangerous
situations that result in personal injury or property damage.
● The following symbols describe items to be observed.
The symbol indicates “prohibition”.
The symbol provokes “cautions”.
The symbol indicates “mandatory”
action to be taken.
Do not modify this device.
Be careful. It may result in fire.
Be sure to pull out the plug.


vi INF-TN2FSC-E

Do not touch the switch with a wet hand. Do not break or pull the power cord.
Do not put heavy items
on the power cord.
Do not modify or pull the
power cord.
Otherwise it may break
and result in electric
shock and fire.
Do not disassemble.
Do not disassemble this
device.
Otherwise it may result in an
accident.
Do not use electric parts soaked in water.
Replace electric parts or wires
soaked in water due to floods
or some other reasons with
new ones.
Otherwise it may result in
electric shock or fire.
Do not repair.
Do not use the flammable
gases or volatile agents
such as paint thinner near
the device.
Otherwise it may result
in explosion or fire.
Pull out the plug immediately in
case of an emergency.
In case of abnormal odor, smoke
or fire is perceived, pull the power
plug immediately.
Ask an authorized
serviceperson or your
dealer for repair.
Otherwise it may
result in electric
shock or fire.
Do not touch the switch
with a wet hand.
Otherwise it may result in
electric shock.
WARNING
Prohibition
Prohibition
Prohibition
Disassemble
is prohibited.
Unplug the power cord.
Install the power cord in a manner
that it can be immediately unplugged
when necessary.
Ground the device when using the
power adapter.
Check that the device is
properly grounded when using
the power adapter.
Ground the device with the
grounding conductor of the
power cable. The grounding
conductor needs to be
connected to earth to avoid an
electric shock.


INF-TN2FSC-E vii
CAUTION
Keep warning labels clean.
Ask an authorized waste disposal
specialist for disposal.
Do not splash water.
Prohibition
Prohibition
Be careful when carrying the device.
Inspect the power plug periodically.
Clean or replace the warning
labels so that they can always be
read correctly.
Otherwise it may result in an
accident.
Do not dispose the device
without proper authorization.
Otherwise it may cause
environmental pollution or result
in an accident.
Do not wash or splash water on
the electrical parts inside the
device.
Otherwise it may result in electric
shock.
When carrying the device,
exercise care to avoid physical
shock or vibration.
Otherwise it may cause failure.
For connecting the cable,
turn the power off.
For connecting cable to terminal
of the large size detector
(Type: FSSE), turn the power off.
Inspect the power plug once
every 6 months. Wipe the dust
off the plug and insert it securely.
Otherwise it may result in electric
shock or fire.
Match power capacity
with the device ratings.
Fire hazard
Be sure to connect the device to
the power soruce of proper
voltage and current rating.
Otherwise it may result in fire.
Use the power adapter, power cord, and
built-in battery that are dedicated for this device.
Prohibition
Use the power adapter, power
cord, lithium ion battery
dedicated for this device.
Otherwise it may break and
cause failure.
Use the device in
favorable environment.
Do not use the device in an
environment subjected to dust
or corrosive gases.
Keep the device away from
direct sunlight, wind and rain.
Otherwise it may cause failure.
Flow transmitter
• Ambient temperature:
–10 to +55°C (Without printer)
–10 to +45°C (Witt printer)
0 to +40°C (during buttery charge)
• Ambient humidity: 90% RH or less
• Altitude: up to 2000m
• Installation category: II (power adapter)
 I (main unit)
• Pollution degree:2
Detector:
• Ambient temperature: –20 to +60°C
• Ambient humidity:
Large/middle size detector; 100% RH or less
Others; 90% RH or less

viii INF-TN2FSC-E
CAUTION
Cause of machine malfunction. Cause of machine malfunction.
Prohibition Prohibition
Use in a place which is remote
from electrical devices (motor,
transformer, etc.) which generate
electromagnetic induction noise,
electrostatic noise, etc.
Fire or damage may result.
Do not use in a place which is
near cell phones, wireless
devices, etc., which may cause
the machine blunder.
Except the main unit (printer, power
adapters, etc.), it is not protectes
for dust or waterproof.
Avoid using the product in a place
where it will be exposed to water or
humidity.
