Fuji Electric PUM User manual

INP-TN5A1634-E 1
Instruction Manual
Type
Parameter loader for multi-loop
module-type temperature controller
(For version 2.2.0 or later)
PUM
 INP-TN5A1634a-E
International Sales Div
Sales Group
GateCityOhsaki,EastTower,11-2,Osaki1-chome,
Shinagawa-ku,Tokyo141-0032,Japan
http://www.fujielectric.com
Phone:81-3-5435-7280,7281Fax:81-3-5435-7425
http://www.fujielectric.com/products/instruments/
ThankyouverymuchforpurchasingFuji’smulti-loopmodule-typetemperaturecontroller.Pleasereadthisinstructionmanual
carefullybeforeusingtheinstrument.Makesurethatthisinstructionmanualwillbehandedovertothenaluserofthis
software(PUMparameterloader).
Note
Thecontentsofthismanualaresubjecttochangewithoutnotice.
Thismanualiscompliedwithpossiblecareforthepurposeofaccuracy,however,FujiElectricshallnotbeheldliableforany
damages,includingindirectdamage,causedbytypographicalerrors,absenceofinformationoruseofinformationinthis
manual.
Contents
1 Aboutthecopyrightofthissoftware................... 3
2 Outline................................................................. 3
3 Operatingenvironment........................................ 3
4 Installing/uninstallingthesoftware....................... 4
 Installation..................................................................... 4
 Uninstallation................................................................ 6
5 ConnectingyourPCtothemodule-typetemperaturecontroller .. 7
 ConnectionwithRS-232C............................................ 7
6 StartingthePUMparameterloader....................11
 Startupmode/Initialvaluesstartupmode................... 13
 Selectingmode/Fileselectionstartupmode.............. 17

Selectingmode/moduledatareceptionlaunchmode .... 19
7 Initialsetting....................................................... 23
8 Parametersetting.............................................. 25
 “PUMloader–PUMParametersSupport”screen..... 25
 Settingparameters..................................................... 29
 Favorite....................................................................... 31
 SwitchingbetweendisplayONandOFF.................... 35
 Relevantparameters.................................................. 37
 Onlinefunction............................................................ 39
 Modulecomposition.................................................... 41
 Checkingthetypecode.............................................. 43
 Displayingtrend.......................................................... 45
 Copyingparameters................................................... 47
 Copyandpaste........................................................... 51
 UnDo........................................................................... 52
 FunctionofStationNo.Change................................. 53
 FunctionofaddinganddeletingStationNo............... 55
 Insert........................................................................... 57
 CompareparametertoinitialData............................. 58
 Parameterlist.............................................................. 61
 Uploading(TransmissionfromPUMtoPC)............... 63
 Downloading(TransmissionfromPCtoPUM)........... 66
 Openingles............................................................... 69
 Savingthesettinginale........................................... 71
 ExitingthePUMparameterloader............................. 72
 Multilauncherfunction................................................ 73
9 Troubleshooting................................................. 74
10 TableofcorrespondingrevisionNo.toPUMparameterloader .. 76

2 INP-TN5A1634-E

INP-TN5A1634-E 3
1 About the copyright of this software
Thecopyrightofthissoftware(PUMparameterloader)belongstoFujiElectricCo.,Ltd.Reproductionofanyformordistribution
ofthissoftwarewithoutpermissionisprohibited.
2
Outline
Thissoftware(PUMparameterloader)isanauxiliarytoolforsettingparametersandtuningthemodule-typetemperature
controller.Thesettingconditionscanbeeditedandsavedwiththissoftware.Bysetting,editing,andsavingparametersonyour
PC,thesettingcanbecopiedformultiplemodule-typetemperaturecontrollers.ThePV,SV,andMVtrendcanalsobedisplayed
asanauxiliarytoolfortuningthemodule-typetemperaturecontrollers.
Unlessotherwisespecied,theparameterloaderformodule-typetemperaturecontrollers(PUM)isreferredtoas“PUM
parameterloader”or“thissoftware”inthismanual.
3
Operating environment
OS :WindowsXP,Windows7(Englishversion)
RAM :128Mbytesormorerecommended
Freeharddiskspace :500Mbytesormorerecommended
Displayresolution :1024×768pixelsorhigher
Excel :Microsoft®OfceExcel
Reader :AdobeReader
Note

•Windows®isaregisteredtrademarkofMicrosoftCorporation.

•Excel®isaregisteredtrademarkofMicrosoftCorporation.

•Adobe®andReader®areregisteredtrademarksofAdobeSystemsIncorporated.

4 INP-TN5A1634-E
4
Installing/uninstalling the software
ParameterloaderforPUMisinstalledtoPCandenabledtouse.WhenyoudeletetheparameterloaderforPUM,makesureto
conducttouninstallit.
Installation
InstalltheparameterloaderforPUMonyourPC.
1
 Openthe“PUMloader”folderwhichwasdownloadedanddoubleclick[PUMLoader-Installer- .exe]
 Note:Pleasereferto“PUMparameterloaderrevisionlist(P.75)”
2
 Click[Next]tocontinue.
■To stop installation, click [Cancel].
3
 Enteruserinformationasnecessary,andthenclick[Next>].

INP-TN5A1634-E 5
4
 Selecttheinstallationfolderandclick[Next>].
■To return previous procedure, click [<Back].
■To stop installation, click [Cancel].

Note
WhenyouuseWindows7,donotinstalltheparameterloaderto“C:¥ProgramFiles”Otherwise,parameterloaderforPUMmay
notbeoperatedproperly.
5
 Conrmtheinstallationandclick[Install].
■To return previous procedure, click [<Back].
■To stop installation, click [Cancel].

6 INP-TN5A1634-E
6
 Installationbegins.
■To stop installation, click [Cancel].
7
 Click[Finish].
Uninstallation
(1) WindowsXP
“Controlpanel(C)”→“ProgramAdd/Delete”fromthestartmenutouninstallthesoftware.
(2) Windows7
Select“Controlpanel(C)”→“Program”fromthestartmenutouninstallthesoftware.

INP-TN5A1634-E 7
5
Connecting your PC to the module-type temperature controller
ConnectyourPCtothemodule-typetemperaturecontrollerusingtheRS-232Cinterface.
Note

•Makethesetting,beingcarefulnottomakethestationNos.ofthemodule-typetemperaturecontrollersduplicate.Thestation
numberofthecontrolmodule(PUMA/B)ortheanalogmoduleisthestationnumbercongurationswitch+1,andthatoftheevent
module(PUME)isthestationnumbercongurationswitch+17.

•ConnectionviaRS-485communicationisnotsupported.

•Whenoperatingtheparametersoftheenhancedcommunicationmodule,connecttheloaderconnectingcabletotheloader
communicationportoftheenhancedcommunicationmodule.

•
Connection with RS-232C
Providetheoptionallyavailablecableforloaderconnection(RS-232C,Type:PUMZ*L01).ConnecttheRS-232Cport(D-sub9
pin)andtheloadercommunicationportonthefrontfaceofthemodule-typetemperaturecontrollerwiththeloaderconnecting
cable.
[When connecting the PUM parameter loader to a control module, an event module, and an
analog module]
<Connecting a single unit>
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
D-Sub 9 pin
PC
Master
Loader connecting cable
(RS-232C)
PUMZ*L01
RS-232C
Station number
configuration switch

8 INP-TN5A1634-E
<Connecting multiple units>
(1) Adjustthestationnumbercongurationswitchto“0”position.
* The station number conguration switch can be adjusted a
control/event/analog module in hexadecimal digits from 0
to F.
(2) Connectoneunitonlyrst,andthenselectonthetreestructureinthelefteldofthe"PUMparametersSupport"screen(on
P.25)"Controlmodule→1;Parameter→6;Communication→6;Master/Slave"settingconnectedmoduleto"Master".(See
"Parametersetting"onP.25fordetailsofthesetting.)
* The multiple module-type temperature controller set in (2) above functions as the master..
(3) Connectmultiplemodule-typetemperaturecontrollerstotheonesetasthemasterclockwise.
Note
Besuretoturnoffthepowerofthemodule-typetemperaturecontrollersbeforemakingconnections.
(4) Setthestationnumbercongurationswitchesoftheconnectedmodule-typetemperaturecontrollersas1,2,……,F(station
Nos.:2,3,……,16)consecutivelyfromleft.
* Control/Analog module : Station number conguration switch set value + 1 = Station No.
Event module : Station number conguration switch set value + 17 = Station No.
Note
Setthestationnumberofthecontrol/analogmoduleintherangeof“1”to“16”withoutnumberduplication.
(5)Followingtheprocedure“Parametersetting”(onP.25),checkthat“Controlmodule→1;Parameter→6;Communication→
6;Master/Slavesettingconnectedmoduleissetto“Slave”exceptfortherstone,whichissetto“Master.”
Note
Whenallthesettingsarecompleted,turnonthepoweragain.
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
Station number
configuration switch

INP-TN5A1634-E 9
Completed connections
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
St. No.
Set value of the St. No. configuration switch
ST1
0
ST2
1
ST16
F
Master Slave Slave
ST17
0
Slave
ST32
F
Slave
Control module + Analog I/O module
(Total max. 16 units)
Event I/O module
(Total max. 16 units)
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
LOADER
PUM-E
PWR
COM
Di1
Di2
Di3
Di4
Di5
Di6
Di7
Di8
Do1
Do2
Do3
Do4
Do5
Do6
Do7
Do8
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
LOADER
PUM-E
PWR
COM
Di1
Di2
Di3
Di4
Di5
Di6
Di7
Di8
Do1
Do2
Do3
Do4
Do5
Do6
Do7
Do8
[When connecting the PUM parameter loader to the enhanced communication module]
LOADER
PUM-C
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
PWR
BUS
RX1
TX1
RX2
TX2
D-sub 9 pins
PC
Master
Loader connecting cable
(RS-232C)
PUMZ*L01
RS-232C
St. No. configuration switch
Note
Whenyouoperateparametersofanenhancedcommunicationmodule,theloaderconnectingcableshouldbeconnectedto
theloadercommunicationportontheenhancedcommunicationmoduledirectly.
*FigureaboveshowsthecasethatMitsubishi'sprogramlesscommunication(PUMCM)isused

10 INP-TN5A1634-E
Note
Whenallthesettingsarecompleted,turnthepoweronagain.
<Completed connections>
St. No.
Set value of the St. No.
configuration switch
ST128
0 to 7 (Mitsubishi programless
communication)
0 to 99 (Profibus communication)
ST1
0
ST16
F
Master
ST2
1
Slave Slave
ST17
0
Slave
ST32
F
Slave
Enhanced
communication module
Control module + Analog I/O module
(Total max. 16 units)
Event I/O module
(Total max. 16 units)
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
PWR
BUS
RX1
TX1
RX2
TX2
LOADER
PUM-C
LOADER
PUM-A
PWR
COM
OUT1
OUT2
OUT3
OUT4
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
LOADER
PUM-E
PWR
COM
Di1
Di2
Di3
Di4
Di5
Di6
Di7
Di8
Do1
Do2
Do3
Do4
Do5
Do6
Do7
Do8
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
STATION
4
3
2
1
0
F
E
D
C
B
A
9
8
7
6
5
LOADER
PUM-E
PWR
COM
Di1
Di2
Di3
Di4
Di5
Di6
Di7
Di8
Do1
Do2
Do3
Do4
Do5
Do6
Do7
Do8
Note
Alwaysplacetheenhancedcommunicationmoduleontheleftofthecontrolmodulesetasthemaster.
*FigureaboveshowsthecasethatMitsubishi'sprogramlesscommunication(PUMCM)isused

INP-TN5A1634-E 11
6
Starting the PUM parameter loader
Whenyoulaunch“PUMloader”instartmenu,“moduletypeselection”isindicated.
1
 In“moduletypeselection”screen,selectthemoduletypeoftemperaturecontrollertobelaunchedandclick[OK].
 Ifyouclick[Cancel],parameterloaderforPUMisend.
(2)Click.
(1)Selectthemoduletypeoftemperaturecontroller
tobelaunched.
2
 “Startupmode”isindicated.
Screen of control/ event / analog module at start-up.
Initialvaluesstartupmode(P.13)
Moduledatareceptionlaunchmode(P.19)
Note)Moduleconnectiondesignationis
onlyforthefunctionofcontrol/event/
analogmodule
Fileselectionstartupmode(P.17)

12 INP-TN5A1634-E
Screen of enhanced communication module /ProBUS communication module, Mitsubishi program less
communication module, Ethernet communication module at start-up.
Initialvaluesstartupmode(P.13)
Moduledatareceptionlaunchmode(P.19)
Fileselectionstartupmode(P.17)
Note
In“moduletypeselection”screen,incaseyouselectthemoduletypeselectiondifferentfrommoduletypeoftemperature
controllerbeingconnected,communicationerrorwilloccuratuploadanddownload.Makesuretoselectpropermoduletype
selection.

INP-TN5A1634-E 13
Startup mode/Initial values startup mode
Selectthemoduletypeoftemperaturecontrollertobesetandconductthesetting.
MakesuretoconductthisfunctionunderasituationwherePUMisnotconnectedtoPC.
1
 In“Startupmode”screen,select“Initialvaluesstartupmode”andclick[OK].
Screen of control /event / analog module at start-up.
(2)Click
(1)Click.
Screen of enhanced communication module /ProBUS communication module at start-up.
(2)Click
(1)Click.

14 INP-TN5A1634-E
2
 Stationdenition.
Control / event / analog module.
Whenclickthe[setting]buttonofthestationNo.tobeset,“modelcodesetting”screenappears.Setthelast10digitsoftype
codeandclick[Check]button.
Whenregistrationiscompleted,typecodewillbeindicatedatAinmodelcodesettingandthenclick[OK].
SetthestationNo.1to16forcontrol/analogmodule,stationNo.17to32foreventmodule.

INP-TN5A1634-E 15
A
Enhanced communication module [Mitsubishi program less communication]
Whenyouselecttheenhancedcommunicationmodule[Mitsubishiprogramlesscommunication],screenofstation
denitionisnotindicatedandmodelcodesettingappears.Enhancedcommunicationmodule[Mitsubishiprogramless
communication]hasthexedmodelcode,thereforedonotchangethemodelcodesettingandjustclick[Check]buttonand
thenclick[OK]buttonaftermodelcodeappearsatAasshownFig.5.
A
Fig.5Modelcodesetting

16 INP-TN5A1634-E
ProBUS communication module [ProBUS communication]
WhenyouselectProBUScommunicationmodule[ProBUScommunication],screenofstationdenitionisnotindicated
andmodelcodesettingappears.ProBUScommunicationmodule[ProBUScommunication]hasthexedmodelcode,
thereforedonotchangethemodelcodesettingandjustclick[Check]buttonandthenclick[OK]buttonaftermodelcode
appearsatAasshownFig.6.
A
Fig.6Modecodesetting
Inaccordancewithaboveprocedures,PUMloaderwillbelaunchedwithparametervalueoffactorydefaultcorrespondingto
modelcode.

INP-TN5A1634-E 17
Selecting mode/File selection startup mode
Readtheparametersettinglestoredpreviouslyasfollows.
1
 Select“Fileselectionstartupmode”onthe“Startupmode”screen,andthenclick[OK].
The display screen of the control/event/analog module on start-up
(2)Click
(1)Click.
The display screen of the enhanced communication module on start-up
(2)Click
(1)Click.

18 INP-TN5A1634-E
2
 Onthe“Fileselectionstartupmode”screen,selecttheleortheparametersettingstoredpreviously,andthenclick[Open].
(2)Click.
(1)Select
The“PUMloader-PUMparametersSupport”screenappears(P.25).

INP-TN5A1634-E 19
Selecting mode/module data reception launch mode
Readtheparametersettingoftheconnectedmodule-typetemperaturecontrollersasfollows.
1
 Onthe“Startupmode”screen,select“Moduledatareceptionlaunchmode”andthenclick[OK].
The display screen of the control/event/analog module on start-up
(2)Click.
(1)Click.
The display screen of the enhanced communication module on start-up
(2)Click.
(1)Click.

20 INP-TN5A1634-E
2
 The“PUMloader-PUMParametersSupport”screenappears(P.25).
Checktheconnectedmodule-typetemperaturecontrollersautomatically,andthenreadthesetvalueout.
■To cancel reading
Pressthe[Esc]keyonthekeyboardtocancelreading.
Note

•Approximately20secondsarerequiredtoreadtheparametersettingspermodule-typetemperaturecontroller.Donot
performothercommunicationoperationswhilethesettingsareread.

•Donotturnoffthepowerofthemodule-typetemperaturecontrollerwhilethesettingsareread.

•Donotpullouttheloaderconnectioncablewhilethesettingsareread.
