ACCESSORIES: REAR CONTROLS
DIGI POWER REAR CONTROL KITS
*Specify camera type.
**FMM-3C for use on HA42x and HA25x
MS-11D Manual Focus/Servo Zoom
For use with RM/ZM type lenses.
SS-13D Servo Focus/Servo Zoom
For use with RM/ZM type lenses.
SS-11 Servo Focus/Servo Zoom
Not available on HA42x, HA36x and A36.
SS-11D Servo Focus/Servo Zoom
For use with RM/ZM type lenses.
MS-11 Manual Focus/Servo Zoom
MM-11 Manual Focus/Manual Zoom
Not available on HA42x, HA36x and A36.
*FMM-8 for use with S16x7.3
A. CFC-990
Flex Cable
B. FMM-6B/FMM-8*
Focus Manual
Module
C. ZMM-6
Zoom Manual
Module
D. SRD-92B
Zoom Demand
E. FSM-30B
Focus Servo
Module
F. MCA-7
Mounting Clamp
G. FSD-11
Focus Demand
H. CZH-14
Zoom Handle
I. CFH-3
Focus Handle
HA18x5.5BE RM/RD*/ZD**
Zoom Ratio / Format
Focal Length
Extender
Maximum Relative
Aperture
Maximum Photometric
Aperture T-No.
Angular Field of View
16:9 Aspect Ratio
M.O.D. from Image Plane
M.O.D. from Front of Lens
Object Dimensions at M.O.D.
Filter Size
Dia f x Length (w/o Hood
Weight (w/o Hood)
Options
Features
18X / 2/3”
5.5 to 100 mm
(2X) 11 to 200 mm
1:1.8 (5.5 ~ 62 mm)
1:2.9 (100)
1:1.9 (5.5 ~ 62 mm)
1:3.1 (100)
5.5 mm 82 ° 10’ x 52 ° 13’
100 mm 5 ° 29’ x 3 ° 05’
(2X) 11 mm 47 ° 06’ x 27 ° 32’
200 mm 2 ° 45’ x 1 ° 33’
0.69 m
0.4 m
5.5 mm 800 x 450 mm
100 mm 44 x 25 mm
(2X) 11 mm 395 x 222 mm
200 mm 22 x 12 mm
M127 x 0.75mm (In Hood Mounting Only)
f 95 x 240.5
1.97 kg / 2.04 kg* / 2.10 kg**
16 Bit Encoders (ZD Only) / Quick Frame
Inner Focus / Zoom Limit / Quick Zoom / Virtual Serial
Com / PC / Macro / 16 Bit Encoders (RM/RD)
