Fujitsu ASYG07-14KGTF User manual

AIR CONDITIONER
3-unit multi-split type
SERVICE MANUAL
INDOOR
AUXG07–18KVLA ARXG07–14KSLAP
ARXG18KSLAP
ARXG07–14KLLAP
ARXG18KLLAP
ASYG07–14KGTB
ASYG07–14KGTE
ASYG07–14KGTF
ASYG18KMTB
ASYG18KMTE
ASYG07–14KMTB
ASYG07–14KMCC
ASYG07–14KMCE
ASYG07–14KMCF
ASYG07–14KETA
ASYG07–14KETE
ASYG07–14KETF
ASYG07–14KETA-B
ASYG07–14KETE-B
ASYG07–14KETF-B
OUTDOOR
ABYG18KRTA AGYG09–14KVCA AOYG18KBTA3
AOYG24KBTA3
SR_MU003EF_14
2023.03.17

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
FGLair™ is trademark of FUJITSU GENERAL LIMITED in the United States, other countries or both.
“AIRSTAGE Mobile” is a trademark of FUJITSU GENERAL LIMITED.
Android and Google Play are trademarks of Google LLC.
App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under
license.
Copyright © 2020, 2023 Fujitsu General Limited. All rights reserved.

CONTENTS
1. GENERAL INFORMATION
2. TECHNICAL DATA AND PARTS LIST
3. TROUBLESHOOTING
4. CONTROL AND FUNCTIONS
5. FILED WORKING

1. GENERAL INFORMATION
2023.03.17
SR_CH01_MU003EF_07

CONTENTS
1. GENERAL INFORMATION
1. Specifications..............................................................................................01-1
1-1. Indoor unit ......................................................................................................................01-1
1-2. Outdoor unit..................................................................................................................01-21
2. Dimensions................................................................................................01-23
2-1. Compact cassette type .................................................................................................01-23
2-2. Mini duct type ...............................................................................................................01-25
2-3. Slim duct type ...............................................................................................................01-28
2-4. Wall mounted type........................................................................................................01-31
2-5. Ceiling type...................................................................................................................01-45
2-6. Floor type .....................................................................................................................01-47
2-7. Outdoor unit..................................................................................................................01-49

1. Specifications
1-1. Indoor unit
¢Compact cassette type
Model name AUXG07KVLA AUXG09KVLA AUXG12KVLA AUXG14KVLA
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 18 23 28
Running current A 0.15 0.19 0.22
Fan
Airflow rate
Cooling
HIGH
m3/h
540 610 680
MED 490 530 580
LOW 440 470 490
QUIET 390 410 410
Heating
HIGH 540 610 790
MED 490 530 680
LOW 440 470 580
QUIET 390 410 450
Type × Qty Turbo fan × 1
Motor output W 54
Sound pressure level*
Cooling
HIGH
dB (A)
33 37 38
MED 31 34 35
LOW 29 31 32
QUIET 27 28 29
Heating
HIGH 34 37 43
MED 32 34 38
LOW 29 31 34
QUIET 27 29 30
Sound power level Cooling dB (A) 46 49 50
Heating 47 49 55
Heat exchanger type
Dimensions (H × W × D) mm Main 1: 210 × 1,310 × 13.3
Main 2: 210 × 1,250 × 13.3
Fin pitch mm 1.2
Rows × Stages Main 1: 1 × 10
Main 2: 1 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net mm 245 × 570 × 570
Gross 265 × 730 × 625
Weight Net kg 15
Gross 19
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Cassette grille
(Grid type: Option)
Model name UTG-UFYF-W
Material Polystyrene
Color White
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × W × D)
Net mm 49 × 620 × 620
Gross 120 × 765 × 755
Weight Net kg 2.3
Gross 4.5
NOTES:
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-1. Indoor unit - (01-1) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name AUXG18KVLA
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 5.0
Input power W 39
Running current A 0.30
Fan
Airflow rate
Cooling
HIGH
m3/h
680
MED 580
LOW 490
QUIET 410
Heating
HIGH 790
MED 680
LOW 580
QUIET 450
Type × Qty Turbo fan × 1
Motor output W 54
Sound pressure level*
Cooling
HIGH
dB (A)
38
MED 35
LOW 32
QUIET 29
Heating
HIGH 43
MED 38
LOW 34
QUIET 30
Sound power level Cooling dB (A) 50
Heating 55
Heat exchanger type
Dimensions
(H × W × D) mm
Main 1: 210 × 1,310 × 13.3
Main 2: 210 × 1,250 × 13.3
Fin pitch 1.2
Rows × Stages Main 1: 1 × 10
Main 2: 1 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net mm 245 × 570 × 570
Gross 265 × 730 × 625
Weight Net kg 15
Gross 19
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Drain hose Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Cassette grille
(Grid type: Option)
Model name UTG-UFYF-W
Material Polystyrene
Color White
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × W × D)
Net mm 49 × 620 × 620
Gross 120 × 765 × 755
Weight Net kg 2.3
Gross 4.5
NOTES:
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-1. Indoor unit - (01-2) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

¢Mini duct type
Model name ARXG07KSLAP ARXG09KSLAP ARXG12KSLAP ARXG14KSLAP
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power Fan
HIGH
W
33 40 47 72
MED 23 23 26 44
LOW 20 20 22 30
QUIET 18 18 18 18
Running current A 0.29 0.33 0.38 0.58
Fan
Airflow rate
Cooling
HIGH
m3/h
550 600 650 800
MED 440 450 490 640
LOW 390 400 430 530
QUIET 360 360 360 360
Heating
HIGH 550 600 650 800
MED 440 450 490 640
LOW 390 400 430 530
QUIET 360 360 360 360
Type × Qty Sirocco fan × 2
Motor output W 75
Recommended static pressure Pa 0 to 30 0 to 50
Sound pressure level*
Cooling
HIGH
dB (A)
29 29 31 35
MED 26 26 27 30
LOW 24 24 25 27
QUIET 23 23 23 23
Heating
HIGH 29 29 31 35
MED 26 26 27 30
LOW 24 24 25 27
QUIET 23 23 23 23
Sound power level Cooling dB (A) 52 54 55 60
Heating 53 56 57 62
Heat exchanger type
Dimensions (H × W × D) mm 336 × 490 × 26.6
Fin pitch mm 1.3
Rows × Stages 2 × 16
Pipe type Copper tube
Fin type Aluminum
Enclosure Material Steel sheet
Color —
Dimensions
(H × W × D)
Net mm 198 × 700 × 450
Gross 250 × 930 × 580
Weight Net kg 15.5
Gross 19.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material Hard PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range Cooling °C 18 to 32 %RH 80 or less
Heating °C 16 to 30
NOTES:
• Values mentioned in the table are based on the following conditions:
– Static pressure: 07-12 models: 10 Pa, 14 model: 15 Pa
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-1. Indoor unit - (01-3) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ARXG18KSLAP
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 5.0
Input power Fan
HIGH
W
63
MED 38
LOW 22
QUIET 19
Running current A 0.49
Fan
Airflow rate
Cooling
HIGH
m3/h
940
MED 750
LOW 540
QUIET 480
Heating
HIGH 940
MED 750
LOW 540
QUIET 480
Type × Qty Sirocco fan × 3
Motor output W 80
Recommended static pressure Pa 0 to 50
Sound pressure level*
Cooling
HIGH
dB (A)
33
MED 29
LOW 26
QUIET 23
Heating
HIGH 33
MED 29
LOW 26
QUIET 23
Sound power level Cooling dB (A) 58
Heating 59
Heat exchanger type
Dimensions (H × W × D) mm 336 × 690 × 26.6
Fin pitch 1.30
Rows × Stages 2 × 16
Pipe type Copper tube
Fin type Aluminum
Enclosure Material Steel sheet
Color ―
Dimensions
(H × W × D)
Net mm 198 × 900 × 450
Gross 250 × 1,130 × 580
Weight Net kg 18.5
Gross 23.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø12.7 (Ø1/2)
Method Flare
Drain hose Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range Cooling °C 18 to 32 %RH 80 or less
Heating °C 16 to 30
NOTES:
• Values mentioned in the table are based on the following conditions:
– Static pressure: 15 Pa
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-1. Indoor unit - (01-4) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

¢Slim duct type
Model name ARXG07KLLAP ARXG09KLLAP ARXG12KLLAP ARXG14KLLAP
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 33 49 58 76
Running current A 0.33 0.30 0.35 0.51
Fan
Airflow rate
Cooling
HIGH
m3/h
550 600 650 800
MED 490 550 600 700
LOW 470 500 550 600
QUIET 440 450 480 480
Heating
HIGH 550 600 650 800
MED 490 550 600 700
LOW 470 500 550 600
QUIET 440 450 480 480
Type × Qty Sirocco fan × 2
Motor output W 80 81
Recommended static pressure Pa 0 to 90
Sound pressure level*
Cooling
HIGH
dB (A)
28 28 29 32
MED 26 27 28 30
LOW 25 26 27 28
QUIET 24 25 26 26
Heating
HIGH 28 28 29 32
MED 26 26 28 30
LOW 25 25 27 28
QUIET 24 24 24 25
Sound power level Cooling dB (A) 57 58 60
Heating 57 58 60
Heat exchanger type
Dimensions (H × W × D) mm 294 × 500 × 26.6 294 × 500 × 39.9
Fin pitch mm 1.3
Rows × Stages 2 × 14 3 × 14
Pipe type Copper tube
Fin type Aluminum
Enclosure Material Steel sheet
Color —
Dimensions
(H × W × D)
Net mm 198 × 700 × 620
Gross 276 × 968 × 772
Weight Net kg 16 17
Gross 21 22
Connection
pipe
Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
NOTES:
• Values mentioned in the table are based on the following conditions:
– Static pressure: 25 Pa
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-1. Indoor unit - (01-5) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ARXG18KLLAP
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 5.0
Input power W 73
Running current A 0.44
Fan
Airflow rate
Cooling
HIGH
m3/h
940
MED 880
LOW 820
QUIET 750
Heating
HIGH 940
MED 880
LOW 820
QUIET 750
Type × Qty Sirocco fan × 3
Motor output W 81
Recommended static pressure Pa 0 to 90
Sound pressure level*
Cooling
HIGH
dB (A)
32
MED 30
LOW 29
QUIET 27
Heating
HIGH 32
MED 30
LOW 29
QUIET 27
Sound power level Cooling dB (A) 58
Heating 58
Heat exchanger type
Dimensions (H × W × D) mm 294 × 700 × 39.9
Fin pitch mm 1.3
Rows × Stages 3 × 14
Pipe type Copper tube
Fin type Aluminum
Enclosure Material Steel sheet
Color —
Dimensions
(H × W × D)
Net mm 198 × 900 × 620
Gross 276 × 1,168 × 772
Weight Net kg 20
Gross 26
Connection
pipe
Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø12.70 (Ø1/2)
Method Flare
Drain hose Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
NOTES:
• Values mentioned in the table are based on the following conditions:
– Static pressure: 25 Pa
• The protective function might work when using it outside the operation range.
• *: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-1. Indoor unit - (01-6) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

¢Wall mounted type
Model name ASYG07KGTB ASYG09KGTB ASYG12KGTB ASYG14KGTB
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.29
Fan
Airflow rate
Cooling
HIGH
m3/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 270 270 270 280
Heating
HIGH 720 750 770 800
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 30 49
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level Cooling dB (A) 54 55 56 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D) mm Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch mm Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 215
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 12.5 13.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-7) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG07KGTE ASYG09KGTE ASYG12KGTE ASYG14KGTE
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.29
Fan
Airflow rate
Cooling
HIGH
m3/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 270 270 270 280
Heating
HIGH 720 750 770 800
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 30 49
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level Cooling dB (A) 54 55 56 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D) mm Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch mm Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 215
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 12.5 13.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-8) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG07KGTF ASYG09KGTF ASYG12KGTF ASYG14KGTF
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.29
Fan
Airflow rate
Cooling
HIGH
m3/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 270 270 270 280
Heating
HIGH 720 750 770 800
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 30 49
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level Cooling dB (A) 54 55 56 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D) mm Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch mm Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 215
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 12.5 13.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [AIRSTAGE Mobile])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®.
1-1. Indoor unit - (01-9) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG18KMTB
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 5.0
Input power W 37.5
Running current A 0.35
Fan
Airflow rate
Cooling
HIGH
m3/h
980
MED 810
LOW 640
QUIET 510
Heating
HIGH 1,020
MED 850
LOW 640
QUIET 510
Type × Qty Crossflow fan × 1
Motor output W 59
Sound pressure level*1
Cooling
HIGH
dB (A)
45
MED 40
LOW 35
QUIET 29
Heating
HIGH 46
MED 40
LOW 35
QUIET 29
Sound power level Cooling dB (A) 60
Heating 61
Heat exchanger type
Dimensions (H × W × D) mm
Main 1: 210 × 798 × 26.6
Main 2: 135 × 798 × 20.0
Sub 1: 84 × 798 × 13.3
Sub 2: 84 × 798 × 13.3
Fin pitch mm
Main 1: 1.2
Main 2: 1.1
Sub 1: 1.4
Sub 2: 1.4
Rows × Stages
Main 1: 2 × 10
Main 2: 2 × 8
Sub 1: 1 × 4
Sub 2: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 280 × 980 × 240
Gross 322 × 1,078 × 346
Weight Net kg 12.5
Gross 18
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4) Gas Ø12.7 (Ø1/2)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.8 to Ø16.7 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-10) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG18KMTE
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 5.0
Input power W 37.5
Running current A 0.35
Fan
Airflow rate
Cooling
HIGH
m3/h
980
MED 810
LOW 640
QUIET 510
Heating
HIGH 1,020
MED 850
LOW 640
QUIET 510
Type × Qty Crossflow fan × 1
Motor output W 59
Sound pressure level*1
Cooling
HIGH
dB (A)
45
MED 40
LOW 35
QUIET 29
Heating
HIGH 46
MED 40
LOW 35
QUIET 29
Sound power level Cooling dB (A) 60
Heating 61
Heat exchanger type
Dimensions (H × W × D) mm
Main 1: 210 × 798 × 26.6
Main 2: 135 × 798 × 20.0
Sub 1: 84 × 798 × 13.3
Sub 2: 84 × 798 × 13.3
Fin pitch mm
Main 1: 1.2
Main 2: 1.1
Sub 1: 1.4
Sub 2: 1.4
Rows × Stages
Main 1: 2 × 10
Main 2: 2 × 8
Sub 1: 1 × 4
Sub 2: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 280 × 980 × 240
Gross 322 × 1,078 × 346
Weight Net kg 12.5
Gross 18
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4) Gas Ø12.7 (Ø1/2)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.8 to Ø16.7 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-11) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG07KMTB ASYG09KMTB ASYG12KMTB ASYG14KMTB
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.30
Fan
Airflow rate
Cooling
HIGH
m3/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 270 270 270 280
Heating
HIGH 720 750 770 800
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 30 49
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level Cooling dB (A) 54 55 55 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D) mm Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch mm Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 222
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 12.5 13.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-12) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG07KMCC ASYG09KMCC ASYG12KMCC ASYG14KMCC
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.30
Fan
Airflow rate
Cooling
HIGH
m3/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 320 320 320 310
Heating
HIGH 720 750 780 820
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 27
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level Cooling dB (A) 54 55 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D)
mm
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 222
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 12.5 13.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-13) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Model name ASYG07KMCE ASYG09KMCE ASYG12KMCE ASYG14KMCE
Power supply 1Ø 230 V~ 50 Hz
Available voltage range 198—264 V
Capacity kW class 2.0 2.5 3.5 4.0
Input power W 23 27 27 33
Running current A 0.20 0.24 0.24 0.30
Fan
Airflow rate
Cooling
HIGH
m3/h
650 700 700 770
MED 540 560 560 600
LOW 430 430 430 450
QUIET 320 320 320 310
Heating
HIGH 720 750 780 820
MED 580 610 640 660
LOW 460 470 520 520
QUIET 330 330 330 340
Type × Qty Crossflow fan × 1
Motor output W 27
Sound pressure level*1
Cooling
HIGH
dB (A)
38 40 40 43
MED 33 34 35 36
LOW 29 29 30 30
QUIET 21 21 21 21
Heating
HIGH 41 42 42 44
MED 35 36 38 39
LOW 31 31 33 33
QUIET 22 22 22 24
Sound power level Cooling dB (A) 54 55 57
Heating 56 57 58 59
Heat exchanger type
Dimensions (H × W × D)
mm
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Main 1: 210 × 670 × 26.6
Main 2: 112 × 670 × 20.0
Sub: 84 × 670 × 13.3
Fin pitch Main 1: 1.2
Main 2: 1.1
Main 1: 1.2
Main 2: 1.1
Sub: 1.4
Rows × Stages Main 1: 2 × 10
Main 2: 2 × 7
Main 1: 2 × 10
Main 2: 2 × 7
Sub: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 222
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 12.5 13.0
Connection pipe Size Liquid mm (in) Ø6.35 (Ø1/4)
Gas Ø9.52 (Ø3/8)
Method Flare
Drain hose Material PP + HDPE
Tip diameter mm Ø13.8 (I.D.), Ø15.0 to Ø16.8 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Option: Wired, Mobile app*2 [FGLair™])
NOTES:
• The protective function might work when using it outside the operation range.
• *1: Sound pressure level:
– These are the measured values in the manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *2: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-14) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION
