Fujitsu FPC5D201DZ User manual

i
ESPRIMO D5200 User’s Manual
Fujitsuendeavourstoensurethattheinformationinthisdocumentiscorrect,butacceptsnoliability
foranyerror or omission.Anyprocedures described inthisdocument for operatingFujitsuproducts
shouldbereadandunderstoodbytheoperatorbeforesuchproductsareused.ToensurethatFujitsu
products function without risk to safety and health, such procedures should be strictly observed by
the operator. The development of Fujitsu products and services is continuous and published
informationmaynotbeuptodate.Anyparticularissueofaproductmaycontainfacilitiesnotdescribed
herein. It is important to check the current position with Fujitsu. Specifications and statements as to
performanceinthisdocumentareFujitsuestimatesintendedforgeneralguidance.Theymayrequire
adjustment in particular circumstances and should therefore not be taken as formal offers or
commitments.
ESPRIMO is a trademark of Fujitsu Limited. The following are registered trademarks of Microsoft
Corporation:MS,MS-DOS,Windows®NT,Windows®98,WindowsMillennium,Window®2000and
Windows XP.
Intel and Pentium are registered trademarks of Intel Corporation in the U.S.
Celeron is a registered trademark of Intel Corporation in the U.S.
Other product names are trademarks or registered trademarks of respective companies.
Other products are copyrighted by individual companies.
Allothertrademarksreferencedaretrademarksorregisteredtrademarksoftheirrespectiveowners,
whose protected rights are acknowledged.
Copyright ©Fujitsu PC Asia Pacific
Allrights,includingrightsoftranslation,reproductionbyprinting,copyingorsimilarmethods,inpart
or in whole, are reserved.
Offenders will be liable for damages.
Allrights,includingrightscreatedbypatentgrantorregistrationofautilitymodelordesign,arereserved.
Delivery subject to availability. Right of technical modification reserved.
DECLARATION OF CONFORMITY
According to FCC Part15
Responsible Party: Fujitsu Computer Systems Corporation
Address: 1250 East Arques Avenue, Sunnyvale, CA94085
Telephone Number: [phone]
Product Name: Personal Computer
Model Number: FPC5D201DZ
Conforms the following specifications:
FCC Part15, Subpart B, Class B Digital Device
This device complies with Part 15 of the FCC Rules. Operation are subject to the following two
conditions:(1)Thisdevicemustnotbeallowedtocauseharmfulinterference,and(2)thisdevicemust
accept any interference received, including interference that may cause undesired operation.
Website: www.pc-ap.fujitsu.com
D5200_0(INTRO) 12/7/06, 10:58 am1

ii
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions carefully. Save these instructions for future reference.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water.
5. Donotplacethisproductonanunstablecart,stand,ortable.Theproductmayfall,causingserious
damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure
reliable operation of the product and to protect it from overheating, these openings must not be
blockedorcovered.Theopeningsshouldneverbeblockedbyplacingtheproductonabed,sofa,
rug,orothersimilarsurface.Thisproductshouldneverbeplacednearoroveraradiator or heat
register, or in a built-in installation unless proper ventilation is provided.
7. Thisproductshouldbeoperatedfromthetypeofpowerindicatedonthemarkinglabel.Ifyouare
not sure of the type of power available, consult your dealer or local power company.
8. Thisproductisequippedwitha3-wiregrounding-typeplug,aplughavingathird(grounding)pin.
Thiswillonlyplugintoagrounding-typepoweroutlet.Thisisasafetyfeature.Ifyouareunableto
inserttheplugintotheoutlet,contactyourelectriciantoreplaceyourobsoleteoutlet.Donotdefeat
the purpose of the grounding-type plug.
9. Donotallow anything toreston the powercord.Do not placethisproduct where thepowercord
can easily be stepped on.
10. If an extension cord is used with this product, make sure that the total ampere rating of the
equipment plugged into the extension cord does not exceed the extension cord ampere rating.
Also, make sure that the total rating of all products plugged into the wall outlet does not exceed
15 amperes.
11. Neverpushobjectsofanykindintothisproductthroughcabinetslotsastheymaytouchdangerous
voltagepointsthatcouldresultinafireorelectricshock.Neverspillliquidofanykindontheproduct.
12. Donot attempt toservice this productyourself, as openingor removing coversmay expose you
to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
D5200_0(INTRO) 12/7/06, 10:58 am2

iii
13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. Iftheproductdoesnotoperatenormallywhentheoperatinginstructionsarefollowed.Adjust
onlythosecontrolsthatarecoveredbytheoperatinginstructionssinceimproperadjustment
of other controls may result in damage and will often require extensive work by a qualified
technician to restore the product to normal condition.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
14. Useonlythepropertypeofpowersupplycordset(providedinyouraccessoriesbox)forthisunit.
It should be a detachable type: UL listed/CSA certified, BS1363, ASTA, SS145 certified, rated
10A 250V minimum, VDE approved or its equivalent. Maximum length is 15 feet (4.6 meters).
15. If your computer includes a modem, the cable used with the modem should be manufactured
with a minimum wire size of 26 American wire gauge (AWG) and certified as the law in your
respective country. For detailed information, please contact Fujitsu or the store where you
purchased these products.
Please take extra precaution when connecting the LAN and do not connect the cables to the
peripheraldevice ’sconnector, that mighthave excessivevoltage.
16. CAUTION.
IftheCD/DVDdriveisnotoperatedcorrectlyaccordingtotheinstructionsorprocedures
specified in the operating manual, it may emit a laser beam. Disassembling the CD/
DVDdrivemaycauseyoutobeexposedtoaharmfullaserbeam.Soneverdisassemble
it. The CD/DVD drive may emit a Class 3A or Class 3B laser beam when its cover is
detached.
The CD/DVD drive may emit a Class 3A or Class 3B laser beam when its cover is
detached.Donotlookatthelaserbeam directlyorthrough anopticaldevice.Also,be
careful not to be exposed to the laser beam.
Safety of Laser Products
The CD/DVD drive installed on your computer uses a laser.
Class 1 Laser Products
TheCD/DVDdrivecomplieswiththeprovisionspertinenttoclass1laserproducts,inSubchapter
JoftheFederalRegulationDHHS21CFRoftheUnitedStatesDepartmentofHealthandHuman
Services.Also,itcomplieswiththeinternationalstandardIEC60825-1,theCENELECstandard
EN 60825-1 and the Japanese standard JIS C6802, which govern Class 1 laser products.
17. CAUTION.
Donottouchtheon-boardbattery.Riskofelectricshock,burnandfire.Donotreplacethe
on-boardbattery.Riskofexplosionifbatteryisreplacedbyincorrecttype.Pleasecontact
Fujitsu or the store where you purchased this products.
D5200_0(INTRO) 12/7/06, 10:58 am3

iv
Before Reading this Manual
Thissection describes safety precautions and convention used in this manual. Be sure to read this.
For Safe Operation
This manual contains important information for using the ESPRIMO personal computer.
ReadthismanualthoroughlybeforeusingyourPC.Inparticular,“SafetyPrecautions”inthismanual
must be read and understood.
Fujitsu,aparticipantintheU.S.EnvironmentalProtectionAgency’s(EPA)EnergyStart
Program, warrants that the computer meets the Energy Start specifications.
Using this Product for High-Safety Applications
Thisproductisforoffice,personal,home,ordinaryindustryandothergeneraluse.Itisnotdesigned
and manufactured for use in high-safety applications.
Do not use this product for such applications without taking measures to satisfy the high-safety
requirements.
High-safetyapplicationsrequireextremelyhighlevelofsafety,andinvolveserioushazardstolife
and health if the required safety is not assured. High-safety applications include the following.
●Nuclearreactioncontrolinnuclearfacilities,automaticaviationcontrol,airtrafficcontrol,mass-
transportation control, life-supporting medical equipment, and missile launch control.
Thecomputer includes limited-lifedevices (such asaCRT, anLCD,and a harddisk), and ifthey
are used continuously for an extended period of time, it may become necessary to replace them
earlierthanexpected.Thecomponentscomewithone-yearwarranty(warrantyperiodsmayvary
depending on the type of contract).
●Besidestheusefullife,thebrightnessoftheLCDmonitordecreaseswiththetimeforwhichitis
used.
Backing Up the Data
Thecustomerisresponsibleformaintainingtheintegrityofdata(includingthebasicandapplication
software)storedorinstalledontheproduct.Wedonotwarranttheintegrityofdatastoredorinstalled
onthepersonalcomputerthecustomersentforrepair.Takeappropriatemeasuressuchasmaking
a backup.
Weassumenoresponsibilityforlossofdataandanydirectorincidentaldamageduetoanycause
other than those specified in the warranty.
This computer is designed for use within the country. If you are using it abroad, please do so at
your own responsibility.
Thisequipmentmaybeadverselyaffectedbythemomentary drop ofthesuppliedvoltagedueto
lightning. Use of an uninterrupted AC power supply is recommended for measures against the
momentary drop of the supplied voltage.
(This message is based on the Japan Electronics and Information Technology Industries
Association’s guidelines for measures against momentary voltage drop in PCs.)
SincethisequipmentcontainsspecialmaterialscontrolledbytheForeignExchangeandForeign
Trade Control Law. Authorization under the law may be required to export this equipment.
D5200_0(INTRO) 12/7/06, 10:58 am4

v
Microsoft Service Pack
MicrosoftCorp.offersServicePacktoprovidetheusersofMicrosoft®Windows®withmorestable
system operation (http://www.microsoft.com/).
ThelatestversionoftheServicePackhelpsyouconfigurethemoststablesystemusingMicrosoft®
Windows®provided at that time by Microsoft Corp.
We recommend you to use the latest version.
Insomeenvironments,however,theServicePackmaycauseunexpectedfailure.ReadReadme.txt
for the Service Pack before use.
Again, we recommend you to make a system backup in case of failed installation.
Components of this product (motherboard, CD-ROM, hard disk, and floppy disk drive) contain
traces of heavy metals (lead and chrome) and chemical (antimony).
Software License Agreement
FujitsuLimited(“Fujitsu”)grantsyoualicensetousethesoftwareproducts(“Software”)installed
onor includedwith yourcomputer, providedthat youagree toall termsand conditionsin “Useof
the Software” below.
By using the Software, you accept this License Agreement, so read the terms and conditions in
“Use of the Software” carefully before using the Software. If separate license agreements or
equivalent documents are included with some of the Software, a higher priority will be given to
them than to this License Agreement.
Use of the software
1. Use of and copyright on the Software
You may use the Software solely on your computer. You are granted a license to use the
Softwarebypurchasingthecomputer,butthecopyrightontheSoftwareremainstheproperty
of Fujitsu or its developer.
2. Backup copy
You may make one (1) copy of the Software solely for backup purposes.
3. Incorporating the Software into other software
If the Software is designed to be used as an add-on to other software, you may incorporate
the whole or part of the Software into other software in accordance with the manual
accompanying the Software.
4. Reproduction
(1) You may reproduce the Software solely for the purposes defined in Clauses 2 and 3
above.
Unlessotherwiseexpresslystatedinthisuser’sguideorotherdocumentation,youmay
not reproduce the software into which the Software has been incorporated for any
purposes other than backup purposes.
If the Software is copy-protected, it shall not be reproduced.
(2) WhenyoureproducetheSoftwareundertheconditionsin(1)above,youmaynotmodify,
delete or conceal the copyright statement on the Software.
5. Transfer to a third party
You may transfer the Software (including all media and documentation accompanying your
computer, as well as its backup copy) to a third party, provided that you transfer the whole
Softwarealong with thecomputeron which theSoftware is installed.Youmay not,however,
transfer any media included with your computer separately from the computer.
D5200_0(INTRO) 12/7/06, 10:58 am5

vi
6. Modification and reverse engineering
You may not modify the Software or reverse engineer the Software by decompiling or
disassembling.
shall the third party or developer warrant the Software.
7. High level of safety
TheSoftwareisdesignedforgeneraluse,i.e.,forofficeuse,personaluseandhomeuse,but
not designed or manufactured for the use with a system that requires a high level of safety.
You may not use the Software with any system that requires a high level of safety, without
takingpropermeasurestosecuresafetyforthesystem.Theterm“systemsthatrequireahigh
levelofsafety,”whichincludebutnotlimitedtothefollowing,referstosystemsthatrequirean
extremely high level of safety and may directly affect human lives and bodies if safety is not
secured.
Nuclear energy control systems, flight control systems, air traffic control systems, mass
transportationoperationandcontrolsystems,life-supportsystems,andmissilelaunchersin
military facilities.
Keep the accompanying CD-ROMs in a safe place.
TheCD-ROMsareneededtoreturnthesoftwareinstalledonyourcomputertoitsinitialstate(state
at the time of purchase).
Temperature and humidity condition
Thecomputershouldbeusedandstoredunderthefollowingtemperatureandhumidityconditions:
10 to 35°C/20 to 80 %RH (during operation) or -10 to 60°C/20 to 80 %RH (during storage) (no
condensation during operation/storage).
D5200_0(INTRO) 12/7/06, 10:58 am6

vii
Conventions Used in this Manual
Introduction
This manual tells you how to put your PC into operation and how to operate it in daily use.
Dependingontheconfigurationlevelchosensomeofthehardwarecomponents described may not
be available on your PC. Please observe the notes on your operating system.
You can incorporate operable drives (for example DAT drive) as well as other boards.
Dependingontheconfigurationselected,theoperatingsystemispreinstalledonyourharddisk(e.g.
Windows XP).
YourPChasanumberof security features to ensurethatnounauthorisedpersonscanaccess your
data,forexample,youcanactivateascreensaverwithpasswordprotection.Thesecurityfunctions
in the BIOS Setup also allow you to protect your data by means of passwords.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
Indicates information which is important for your health or for preventing
physical damage.
Indicatesimportantinformationwhichisrequiredtousethesystemproperly.
Text which follows this symbol describes activities that must be performed in the order shown.
Text in this typeface indicates screen outputs.
"Quotation marks" indicate names of chapters or terms.
CAUTION
D5200_0(INTRO) 12/7/06, 10:58 am7

viii
Important Notes
Inthischapteryouwillfindinformationregardingsafetywhichisessentialtotakenoteofwhenworking
with your PC. The manufacturer's notes contain helpful information on your PC.
Safety
CAUTION
During installation and before operating the device, please observe the instructions on
environmental conditions in the chapter entitled "Technical data" as well as the instructions in
the chapter "Preparing for Use".
Please check whether the device is correctly set for the local power supply (see "Preparing for
Use" chapter).
ThemainswitchandtheON/OFFswitchdonotdisconnectthesystemunitfromthemainsvoltage.
To completely disconnect the mains voltage, remove the power plug from the grounded mains
outlet.
Caution: components in the system can get very hot.
Manufacturer’s notes
Keepthis operating manual together with your device. If you pass on the device to third parties,
you should include this manual.
Energy saving
When the PC is delivered, some energy-saving functions are already set
If you are not using your PC, switch it off.
In the BIOS Setup you may set further energy-saving functions for the PC.
Depending on the operating system, you can set additional power-management features.
Energy saving under Windows XP
The Screen Saver tab allows you to set energy-saving functions for your screen. Select the
followingiteminthemenu:Start→Settings→ControlPanel →Display→DisplayProperties→
Screen Saver →Energy saving features of monitor.
With the default setting Control Panel →Power Options →Advanced additional power
management features of Windows XP are available.
D5200_0(INTRO) 12/7/06, 10:58 am8

ix
FCC Class B Compliance Statement
Thefollowingstatementappliestotheproductscoveredinthismanual,unlessotherwisespecified
herein. The statement for other products will appear in the accompanying documentation.
NOTE:
Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora"ClassB"digitaldevice,
pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian Interference-
Causing Equipment Regulations. These limits are designed to provide reasonable protection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiate radio frequency energy and, if not installed and used in strict accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause
harmful interference to radio or television reception, which can be determined by turning the
equipmentoffand on, theuseris encouraged to trytocorrect the interferencebyone or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Fujitsu is not responsible for any radio or television interference caused by unauthorised
modifications of this equipment or the substitution or attachment of connecting cables and
equipment other than those specified by Fujitsu. The correction of interference caused by such
unauthorised modification, substitution or attachment will be the responsibility of the user.
TheuseofshieldedI/Ocablesisrequiredwhenconnectingthisequipmenttoanyandalloptional
peripheral or host devices. Failure to do so may violate FCC rules.
D5200_0(INTRO) 12/7/06, 10:58 am9

x
Transporting the PC
CAUTION
Transport all parts separately in their original packaging or in a packaging which protects them
from knocks and jolts, to the new site. Do not unpack them until all transportation manoeuvres
are completed.
Never drop the monitor!
Cleaning the PC
CAUTION
Turn off all power and equipment switches and remove the power plug from the mains supply.
Do not clean any interior parts yourself, leave this job to a service technician.
Do not use any cleaning agents that contain abrasives or may corrode plastic.
Ensure that no liquid enters the system.
Ensure that the ventilation areas of the system unit and the monitor are free.
Cleaning the system unit and the monitor
Wipethesystemunitandmonitorcasing withadrycloth.Ifparticularlydirty,useacloththat has
been moistened in mild domestic detergent and then carefully wrung out.
D5200_0(INTRO) 12/7/06, 10:58 am10

xi
Disposal and recycling
Disposal of the PC unit
DisposalofthePCunit(includingaccessoriesexcepttheLCDunit)iscontrolledbytheWasteDisposal
and Public Cleaning Law.
To institutional and corporate customers
Personalcomputersmustbedisposedoffasindustrialwaste.Institutionalandcorporatecustomers
are obliged to entrust an authorized industrial-waste disposer.
To individual customers
Personal computers should be disposed off as general waste. Individual customers are advised to
follow the disposal rules and regulations set forth by the local municipality.
Disposal of the LCD unit
The fluorescent tubes in the LCD contain mercury.
Disposal of the LCD unit is controlled by the Waste Disposal and Public Cleaning Law.
To institutional and corporate customers
LCDunitsmustbedisposedoffasindustrialwaste.Institutionalandcorporatecustomersareobliged
to entrust an authorized industrial-waste disposer.
To individual customers
LCD units should be disposed off as general waste. Individual customers are advised to follow the
disposal rules and regulations set forth by the local municipality.
Disposal of batteries
The wireless keyboard and mouse use dry batteries. These batteries may explode when inflamed.
Disposal of the batteries is controlled by the Waste Disposal and Public Cleaning Law.
To institutional and corporate customers
Dry batteries must be disposed off as industrial waste. Institutional and corporate customers are
advised to entrust an authorized industrial-waste disposer.
To individual customers
Drybatteriesshouldbedisposedoffasgeneralwaste.Individualcustomersareadvisedtofollowthe
disposal rules and regulations set forth by the local municipality.
Reference to products
In this manual, the product names are referred to as follows:
This manual includes information on other operating systems.
Product name Description used in the manual
Microsoft®Windows®XP Professional Edition
Microsoft®Windows®XP Home Edition Windows*
Windows
XP
Windows XP
Professional
Windows XP
Home Edition
D5200_0(INTRO) 12/7/06, 10:58 am11

xii
WARNING
• Before mounting or dismounting an optional unit in/from your PC, switch off
the PC and all connected units. Unplug all power cords from respective outlets
to prevent electric shock and unplug all data communication cables from the
respective outlets.
Warning and Caution Labels
Your PC bears the warning and caution labels as shown below.
The warning and caution labels must not be removed or damaged.
Top of the PC main unit
Inside the PC main unit
D5200_0(INTRO) 27/7/06, 10:02 am12

xiii
Before Reading This Manual
Chapter 1Preparing for Use
This chapter provides the names and functions of individual parts.
Chapter 2Operation
Thissectiondescribesthelocationofinstallationandinstallationofthecomputer.
Chapter 3Troubleshooting and Tips
This chapter provides the basic information on the PC and operation.
Chapter 4System Expansion
Thischapterprovidesbasicinformationonhowtohandletheperipheralsinstalled
(or can be installed) on the PC.
OrganizationofThisManual
D5200_0(INTRO) 12/7/06, 10:58 am13

xiv
Contents
CHAPTER 1 Preparing for Use
Preparing for Use..............................................................................1
Unpacking and Checking the Delivery ............................................................. 1
Steps for Initial Setup ....................................................................................... 1
Setting Up the PC ............................................................................................ 2
Installing the Feet............................................................................................. 2
Connect the Monitor, Mouse and Keyboard ..................................................... 6
Initial Switch-on: Software will be Installed....................................................... 7
Connecting External Devices ...........................................................................8
CHAPTER 2 Operation
Operation.........................................................................................11
Switching On the PC ......................................................................................11
Switching Off the PC ......................................................................................11
Front Panels of the Main Unit of the Personal Computer ............................... 12
Back Panel of the Main Unit of the Personal Computer ................................. 14
Keyboard ........................................................................................................ 16
Folppy Disks ................................................................................................... 18
Settings in BIOS Setup .................................................................................. 18
Anti-theft Protection and Lead-sealing ........................................................... 19
How to Lock the Main Unit of the Personal Computer From Behind .............. 19
CHAPTER 3 Troubleshooting andTips
Troubleshooting andTips ..............................................................20
Installing New Software.................................................................................. 20
Power-on Indicator Remains Unlit after you have Switched on your Device .. 20
No Mouse Pointer Displayed on the Screen................................................... 22
The Floppy Disk Cannot be Read or Written.................................................. 22
Time and/or Date is not Correct .....................................................................23
Error Messages on the Screen ...................................................................... 23
Restoring the Hard Disk Contents ................................................................. 23
Tips ................................................................................................................ 23
CHAPTER 4 System Expansion
System Expansion..........................................................................24
Information about Boards ............................................................................... 24
Before Connecting Peripheral Devices........................................................... 25
Removing the Main Unit Cover ...................................................................... 27
Installing Memory ........................................................................................... 28
Installing the Expansion Card ........................................................................ 33
Electrical Data ................................................................................................ 37
D5200_0(INTRO) 12/7/06, 10:58 am14

1
Chapter1-PreparingforUse
CAUTION
Please take note of the safety information in the "Important notes" chapter.
■Unpacking and Checking the Delivery
It is recommended not to throw away the original packaging material! It may be required for
reshipment at some later date.
●Unpack all the individual parts.
●Check the delivery for damage incurred during transportation.
●Check whether the delivery agrees with the details in the delivery note.
Should you discover that the delivery does not correspond to the delivery note, notify your local
sales outlet immediately.
■Steps for Initial Setup
First-timesetup includes theconnection ofthe monitor, mouseand keyboard to the systemunit
and the setup of the supplied software.
External devices
Ifyouhave received otherdevicesin addition toyourPC(e.g. a printerora modem), do
not connect these until after the initial installation.
Drives and boards
Ifyou havereceived drivesor boardswith your PC, please do not install them until after
first-time setup. How to install drives and boards is described in the chapter "System
expansions".
Perform the following steps in the prescribed order:
1. Decide where you are going to use the PC, and then set it up.
2. Connect the monitor, mouse and keyboard to the PC.
3. Check the rated voltage of the PC and connect it to the mains.
4. Switch on the PC and follow the instructions on the screen.
D5200_1(01-10) 12/7/06, 10:58 am1

2
■Setting Up the PC
CAUTION
When installing your PC, give consideration to the recommendations and safety notes.
SetupthePConlyinitscorrectorientation.Thepointstoobserveareillustratedonthefollowing
pages.
DonotexposethePCtoextremeenvironmentalconditionsandprotectitfromdust,humidityand
heat.
WheninstallingthePC,providesufficientclearancearoundthePC,asindicatedinthe“Technical
data”chapter to ensure adequate ventilation. In order to avoid overheating, do not cover the
ventilation area of the monitor or the PC.
Do not place several system units one above the other.
ThePC can beused eitherhorizontally or vertically.We recommend thatyou placeyour equipment
on a surface with good anti-slip qualities. In view of the multitude of different finishes and varnishes
used on furniture, it is possible that the rubber / plastic feet of the devices will mark the surface they
stand on.
■Installing the Feet


POINT
The cables of the keyboard and the mouse can be collected through the slot of the foot.
The slot
for
passing
through
the cable
D5200_1(01-10) 12/7/06, 10:58 am2

3
Vertical positioning
Whenthispersonalcomputerisverticallyinstalledawayfromawall,installthefeetwiththefollowing
steps.
1 Align the feet to the width of the main unit of the personal computer.
2 Install the feet on the main unit of the personal computer.
Secure them in the screw holes on the back of the feet with screws.
D5200_1(01-10) 12/7/06, 10:58 am3

4
Horizontal positioning
1 Disassemble the foot.
2 Place the main unit of the personal computer on the disassembled foot.
D5200_1(01-10) 12/7/06, 10:58 am4

5


POINT
Forverticalinstallation,themainunitofthepersonalcomputercanbeinstalledbyfitting the
fiverubbersattachedtothefourcornersandcenterofthemainunitofthepersonalcomputers.
Wheninstalling rubbers, securethem inthe positions wherethe footdoes not touchwhen it
isverticallyinstalled.Wipedustoffthelocationwhererubbersforthemainunitofthepersonal
computer are installed.
Whenmoving themain unitof thepersonal computerafter therubbers havebeen installed,
do not drag the rubbers.
D5200_1(01-10) 12/7/06, 10:58 am5

6
■Connect the Monitor, Mouse and Keyboard
The ports for monitor, mouse and keyboard are on the rear and on the front of the system unit.
PS/2 keyboard port / purple PS/2 mouse port / green
Monitor port / blue
USB port / black
Connecting the keyboard
Connecting standard keyboard
Use the supplied keyboard cable only.
●Plug the round keyboard cable connector into the port marked with this symbol on the
system unit.
Connecting the mouse
Connecting a PS/2 mouse
●Connect the PS/2 mouse to the PS/2 mouse port on the system unit.
Connecting USB mouse
●Connect the USB mouse to the USB port on the system unit.
D5200_1(01-10) 12/7/06, 10:59 am6
