Fujitsu DESKPOWER 5000 Series User manual

i
DESKPOWER 5000 Series User’s Manual
Fujitsuendeavourstoensurethattheinformationinthisdocumentiscorrect,butacceptsnoliability
foranyerrororomissioninthesame.AnyproceduresdescribedinthisdocumentforoperatingFujitsu
productsshould beread andunderstood bythe operatorbefore suchproducts areused. Toensure
that Fujitsu products function without risk to safety and health, such procedures should be strictly
observed by the operator. The development of Fujitsu products and services is continuous and
published information may not be up to date. Any particular issue of a product may contain facilities
not described herein. It is important to check the current position with Fujitsu. Specifications and
statementsastoperformanceinthisdocumentareFujitsuestimatesintendedforgeneralguidance.
Theymayrequireadjustmentinparticularcircumstancesandshouldthereforenotbetakenasformal
offers or commitments.
DESKPOWERisatrademarkofFujitsuLimited.ThefollowingareregisteredtrademarksofMicrosoft
Corporation:MS,MS-DOS,Windows®NT,Windows®98,WindowsMillennium,Window®2000and
Windows XP.
Intel and Pentium are registered trademarks of Intel Corporation in the U.S.
Celeron is a registered trademark of Intel Corporation in the U.S.
ATI and RADEON are registered trademarks of ATI Technologies, Inc.
Other product names are trademarks or registered trademarks of respective companies.
Other products are copyrighted by individual companies.
All Rights Reserved, Copyright ©FUJITSU LIMITED 2001
We have been authorized by Microsoft Corporation in the U.S. to use Windows screenshots in this
manual.
DECLARATION OF CONFORMITY
according to FCC Part 15 Class B
Thisdevicecomplies with Part15ClassB of theFCCRules. Operations aresubjecttothe following
two conditions:
(1) This device may not be allowed to cause harmful interference, (2) This device must accept any
interference received, including interference that may cause undesired operation.
Wesbite: www.fujitsu-pc-asia.com
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM1

ii
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions carefully. Save these instructions for future reference.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water.
5. Donotplacethisproductonanunstablecart,stand,ortable.Theproductmayfall,causingserious
damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure
reliable operation of the product and to protect it from overheating, these openings must not be
blockedorcovered.Theopeningsshouldneverbeblockedbyplacingtheproductonabed,sofa,
rug,orothersimilarsurface.Thisproductshouldneverbeplacednearoroveraradiatoror heat
register, or in a built-in installation unless proper ventilation is provided.
7. Thisproductshouldbeoperatedfromthetypeofpowerindicatedonthemarkinglabel.Ifyouare
not sure of the type of power available, consult your dealer or local power company.
8. Thisproductisequippedwitha3-wiregrounding-typeplug,aplughavingathird(grounding)pin.
Thiswillonlyplugintoagrounding-typepoweroutlet.Thisisasafetyfeature.Ifyouareunableto
inserttheplugintotheoutlet,contactyourelectriciantoreplaceyourobsoleteoutlet.Donotdefeat
the purpose of the grounding-type plug.
9. Do not allow anything to rest on the power cord. Do not locate this product where persons will
walk on the cord.
10. If an extension cord is used with this product, make sure that the total ampere rating of the
equipment plugged into the extension cord does not exceed the extension cord ampere rating.
Also, make sure that the total rating of all products plugged into the wall outlet does not exceed
15 amperes.
11. Neverpushobjectsofanykindintothisproductthroughcabinetslotsastheymaytouchdangerous
voltagepointsthatcouldresultinafireorelectricshock.Neverspillliquidofanykindontheproduct.
12. Donot attempt toservice this productyourself, as openingor removing coversmay expose you
to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM2

iii
13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. Iftheproductdoesnotoperatenormallywhentheoperatinginstructionsarefollowed.Adjust
onlythosecontrolsthatarecoveredbytheoperatinginstructionssinceimproperadjustment
of other controls may result in damage and will often require extensive work by a qualified
technician to restore the product to normal condition.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
14. CAUTION. When replacing the battery, be sure to install it with the polarities in the correct
position. There is a danger of explosion if the battery is replaced with an incorrect type or
is mistreated. Do not recharge, disassemble or dispose of in fire. Replace only with the
same or equivalent type recommeded by the manufacturer. Dispose of the used battery
according to the manufacturer’s instructions.
15. Useonlythepropertypeofpowersupplycordset(providedinyouraccessoriesbox)forthisunit.
Itshouldbeadetachabletype:ULlisted/CSAcertified,BS1363,ASTA,SS145certified,rated10A
250V minimum, VDE approved or its equivalent. Maximum length is 15 feet (4.6 meters).
16. NOTE:
Pleasetake extra precaution when connectingthe LAN cable; do notconnect the LAN cable
to the peripheral device’s connector, that might have excessive voltage.
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM3

iv
Before reading this manual
This section describes safety precautions and convention used in this manual. Be sure to read this.
For Safe Operation
This manual contains important information for using the DESKPOWER personal computer.
ReadthismanualthoroughlybeforeusingyourPC.Inparticular,“SafetyPrecautions”inthismanual
must be read and understood.
This manual including “Safety Precautions” must be readily available at all times.
ThisequipmentiscompliantwiththePCindustrystandard(PC-11-1988)oftheJapanElectronics
and Information Technology Industries Association.
Note
ThisproductisaClassBInformationTechnologyEquipmentandconformstothestandardsetby
the Voluntary Control Council for Interference by Technology Equipment (VCCI).This product is
designed to be used in a domestic environment, however, it may cause radio interference when
used in the vicinity of a radio or television receiver.
Make sure that you read the manual when using this product.
Fujitsu, as a member of the International Energy Star Program, recognizes that
this equipment is compliant with the standard of the International Energy Star
Program.
The International Energy Star Program is a worldwide program for promoting
energy saving for computers and other office equipment. The program aims at
promoting the development and use of products equipped with the functions that can effectively
reduce energy consumption and uses a voluntary system that allows enterprises to join at their
owndiscretion.Thetargetproductsareofficeequipmentincludingcomputers,displays,printers,
facsimiles,andcopyingmachines.Thestandardsforindividualtypesofequipmentandthemark
( ) prepared by the Program are used commonly among member countries.
Caution
ThisequipmentisclassBinformationtechnologyequipmentbasedonthestandardoftheVoluntary
Control Council for Interference by Information Technology Equipment (VCCI). Although the
equipmentisintendedforuseinresidentialenvironments,itmaycreateinterferenceifplacednear
radio or television.
Handle the equipment in accordance with the manual.
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM4

v
Using this Product for High-Safety Applications
Thisproductisforoffice,personal,home,ordinaryindustryandothergeneraluse.Itisnotdesigned
and manufactured for use in high-safety applications.
Do not use this product for such applications without taking measures to satisfy the high-safety
requirements.
High-safetyapplicationsrequireextremelyhighlevelofsafety,andinvolveserioushazardstolife
and health if the required safety is not assured. High-safety applications include the following.
●Nuclearreactioncontrolinnuclearfacilities,automaticaviationcontrol,airtrafficcontrol,mass-
transportation control, life-supporting medical equipment, and missile launch control.
Someparts(includingtheCRTdisplay,LCD,orharddiskdrive)usedonthisproducthavealimited
life. When used continuously for a prolonged period, these parts will need earlier replacement.
Backing Up the Data
Thecustomerisresponsibleformaintainingtheintegrityofdata(includingthebasicandapplication
software)storedorinstalledontheproduct.Wedonotwarranttheintegrityofdatastoredorinstalled
onthepersonalcomputerthecustomersentforrepair.Takeappropriatemeasuressuchasmaking
a backup.
Weassumenoresponsibilityforlossofdataandanydirectorincidentaldamageduetoanycause
other than those specified in the warranty.
This computer is designed for use within the country. If you are using it abroad, please do so on
your own responsibility.
Thisequipment may beadverselyaffectedbythemomentarydropof the suppliedvoltagedueto
lightning. Use of an AC uninterruptible power supply is recommended for measures against the
momentary drop of the supplied voltage.
(This message is based on the Japan Electronics and Information Technology Industries
Association’s guidelines for measures against momentary voltage drop in PCs.)
SincethisequipmentcontainsspecialmaterialscontrolledbytheForeignExchangeandForeign
Trade Control Law. Authorization under the law may be required to export this equipment.
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM5

vi
Microsoft Service Pack
MicrosoftCorp.offersServicePacktoprovidetheusersofMicrosoft®Windows®withmorestable
system operation (http://www.microsoft.com/).
ThelatestversionoftheServicePackhelpsyouconfigurethemoststablesystemusingMicrosoft®
Windows®provided at that time by Microsoft Corp.
We recommend you to use the latest version.
In some environments, however, the Service Pack may cause unexpected failure. Read
Readme.txt for the Service Pack before use.
Again, we recommend you to make a system backup in case of failed installation.
Components of this product (motherboard, CD-ROM, hard disk, and floppy disk drive) contain
traces of heavy metals (lead and chrome) and chemical (antimony).
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM6

vii
Conventions Used in This Manual
Warning messages
Thismanualusesvarioussigns.Thesesignsurgetheusertousetheequipmentsafelysoastoprevent
personalinjuryand/orpropertydamage.Thefollowingarealertsignalsandexplanations.Thesigns
should be understood before proceeding to subsequent portions of this manual.
This indicates a hazardous situation that could result in death or severe
injury if the user does not perform the procedure correctly.
This indicates a hazardous situation that could result in personal injury or
property damage if the user does not perform the procedure correctly.
Inadditiontotheabovesigns,thefollowingsymbolsareusedtoprovidedetailedinformationconcerning
personal injury and/or property damage:
The symbol marked with [ ] indicates a warning or caution item. An
explanation of an alert is presented in or beside the symbol.
The symbol marked with [ ] indicates what must not be done (prohibited
action). The meaning of a direction is presented in or beside the symbol.
Thesymbolmarkedwith[●]indicateswhatmustbeobserved.Themeaning
of a direction is presented in or beside the symbol.
Symbols used in the text
Symbol Meaning
Thestatementprovidedwiththissymbolexplainscautionsonuseorwhat
must not be done. Be sure to read this first!
The statement provided with this symbol explains what is required to
operate hardware or software correctly. Be sure to read this first!
This symbol indicates the page or manual to refer to.
Representation of keys and their operation method
Key names used in this manual are not exactly represented with the characters appearing on the
keyboard but are represented with characters needed for explanation as follows:
Example: [Ctrl] key, [Enter] key, [→] key...
Two or more keys that must be pressed simultaneously are represented by combining them with a
“+” sign as follows:
Example: [Ctrl] + [F3] keys, [Shift] + [↑] keys...
WARNING
CAUTION
Point
Important
→
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM7

viii
Command entry (keying in)
In this manual, a command entry is represented as follows:
diskcopy a: a:
↑↑
• Where character spacing is provided as shown by [↑], press the [Space] key once.
Commands,anexample of whichisgivenabove in lowercase,canalsobe entered inuppercase.
• [CD-ROM drive] indicates the name of the CD-ROM drive being used. Enter the drive name in
accordance with your PC environment.
[CD-ROM drive]:\setup.exe
Screenshot example and illustrations
Thescreenshotsandillustrationsgiveninthismanualareexamples.Thescreenshotsandfilenames
maybedifferentfromthoseactuallyshownonyourPCandtheillustrationsmaybedifferentfromthe
actual appearance. For the explanatory purpose, illustration used in this manual may omit cables
connected on the actual PC.
Representation of continuous operation
Continuous operation steps are represented in this manual by combining them with a “•••• ” sign as
shown below:
Example: Sequential operation of clicking the [Start] button, pointing [Program], then clicking
[Accessories]
↓
Click the [Start] button →[Program]→[Accessories].
Representation for BIOS Setup
When the BIOS Setup procedure is explained in this manual, a menu, submenu, and item may be
represented by combining them with a hyphen as shown below:
Example: Set the [Serial Port 1] in [Advanced] to [Disable].
↓
[Advanced] - [Serial Port 1]: Disable
Floppy disk and CD-ROM drives
UsersofamodelwithoutafloppyorCD-ROMdriveshoulduseaseparatelyavailabledriveforoperation
with a necessary drive.
For operation of peripheral devices, refer to the relevant manuals.
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM8

ix
Reference to products
In this manual, the product names are referred to as follows:
This manual includes information on other operating systems.
Product name Description used in the manual
Microsoft®Windows®XP Professional
Microsoft®Windows®XP Home Edition
Microsoft®Windows®2000 Professional
Microsoft®Windows NT®Workstation Operating System Version 4.0
Microsoft®Windows®Millennium Edition
Microsoft®Windows®98 operating system SECOND EDITION
Microsoft®MS-DOS®operating system
Note: Descriptions such as Windows XP/2000/NT/Me/98 are used.
Windows*
Windows
XP
Windows XP
Professional
Windows XP
Home Edition
Windows 2000
Windows NT
Windows Me
Windows 98
MS-DOS
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM9

x
Recycling
Disposal of the PC unit
DisposalofthePCunit(includingaccessoriesexcepttheLCDunit)iscontrolledbytheWasteDisposal
and Public Cleaning Law.
●To institutional and corporate customers
Personalcomputersmustbedisposedofasindustrialwaste.Institutionalandcorporatecustomers
are obliged to entrust an authorized industrial-waste disposer.
●To individual customers
Personalcomputersshouldbedisposedofasgeneralwaste.Individualcustomersareadvisedto
follow the disposal rules and regulations set forth by the local municipality.
Disposal of the LCD unit
The fluorescent tubes in the LCD contain mercury.
Disposal of the LCD unit is controlled by the Waste Disposal and Public Cleaning Law.
●To institutional and corporate customers
LCDunitsmustbedisposedofasindustrialwaste.Institutionalandcorporatecustomersareobliged
to entrust an authorized industrial-waste disposer.
●To individual customers
LCDunitsshouldbedisposedofasgeneralwaste.Individualcustomersareadvisedtofollowthe
disposal rules and regulations set forth by the local municipality.
Disposal of batteries
The wireless keyboard and mouse use dry batteries. These batteries may explode when plunged
into the flames.
Disposal of the batteries is controlled by the Waste Disposal and Public Cleaning Law.
●To institutional and corporate customers
Dry batteries must be disposed of as industrial waste. Institutional and corporate customers are
advised to entrust an authorized industrial-waste disposer.
●To individual customers
Dry batteries should be disposed of as general waste. Individual customers are advised to follow
the disposal rules and regulations set forth by the local municipality.
CHAPTER 0 Bennett (INTRO) 6/7/02, 3:49 PM10
