FUJITSU Supercomputer
PRIMEHPC FX700
BMC User's Guide
C120-0091-03EN

WARNING indicates a hazardous (potentially dangerous) situation that could result in death or
serious personal injury if the product is not used properly.
CAU ION indicates a hazardous situation that could result in minor or moderate personal injury
and/or property damage, such as to the product itself or the user's property, if the product is not used
properly.
Preface
his document describes how to operate the BMC (Baseboard Management Controller) of FUJI SU
Supercomputer PRIMEHPC FX700.
he BMC provides functions to manage and control the equipment.
Organization and Contents of This Manual
his document consists of the following chapters and appendix.
Chapter
1 Environment and Settings for Using the Web GUI
his chapter describes the environment for operating the BMC over the Web.
Chapter
2 Basic Web GUI Operations and Behavior
his chapter describes the screen configuration and logging in and out on Web
screens for operating
the BMC.
Chapter
3 Web GUI Functions
his chapter shows Web GUI categories and screens, and describes their functions.
Chapter
4 Command Support (IPMI)
his chapter describes the requests (commands) received by the BMC, command functions, and
request/response data formats.
Appendix
A REMCS
his appendix describes REMCS settings.
Warning and Important Notice Symbols
his manual uses the following symbols to provide warnings and indicate useful information to the user, to
prevent personal injury and property damage.
Alert Symbols in the Text
An alert statement follows an alert symbol. An alert statement is indented on both ends to distinguish it from
regular text. Similarly, one line is inserted before and after the alert statement.
Preface
C120-0091-03ENi

Edition Date Changed Location (Change
Classification)(*1)
Description
01 February 27 2020 - Created
02 March 17 2020 Preface
Chapter 3
Added "Safety Radio and Harmonics (Europe)"
Added "CE Compliance" to "Regulations"
Updated "Table 3.28 Specifying SNMP Trap Setting
Information"
Changed order of display items on screens
03 June 25 2020 Chapter 2
Chapter 3
Updated remarks in "Logging In" in "2.1.1 Login"
Updated "Table
3.2 Display Items on the [FRU Information]
Screen" and "3.5.2 Firmware Update"
Revision istory
*1 he numbers/titles of the chapters/sections to which changes are made are those used in the latest
version. However, the numbers/titles of the chapters/sections with an asterisk are those used in the old
version.
Preface
C120-0091-03ENii

Safety, Radio, and Harmonics (North America)
Certified
Standard
Standard Number Safety Radio Harmonics
UL ANSI/UL 60950-1, 2nd Ed., 2014-10-14 ✓
FCC FCC Part-15 Subpart-B (2019) ✓
CSA CAN/CSA-C22.2 No. 60950-1-07, 2nd Ed., 2014-10 ✓
ICES ICES-003 Issue 6 (2017) ✓
his section describes the following:
-For Your Safety
-Compliance With Laws and Regulations in Each Country
-Regulations
-Manuals in his Series
-Notation
-Caution Labels
For Your Safety
How to Use This Manual
his manual contains important information required for using this product safely. Read the
FUJITSU
Supercomputer PRIMEHPC FX700 Operating Manual
(C120-0089EN), the
FUJITSU Supercomputer
PRIMEHPC FX700 Getting Starte Gui e
(C120-0093XA), the
FUJITSU Supercomputer PRIMEHPC
FX700 Safety an Regulatory Information
(C120-0092XA), the
FUJITSU Supercomputer PRIMEHPC
FX700 BMC User's Gui e
(C120-0091EN), and the
FUJITSU
Supercomputer PRIMEHPC FX700 Upgra e
an Maintenance Manual
(C120-0090EN) thoroughly before using this product. Before attempting to
operate this device, carefully read and understand each manual, paying particular attention to the safety
precautions.
Be sure to keep this manual in a safe and convenient location for quick reference.
Fujitsu makes every effort
to prevent injury to users and bystanders as well as property damage. Be sure to
use the product in accordance with the instructions in the manual.
Notes on This Product
his product is designed and manufactured for use in standard applications such as office work, personal
devices, and general industrial use. he product is not intended for special uses (nuclear-reactor control in
atomic energy facilities, aeronautic and space systems, air traffic control, operation control in mass transit
systems, life support, or
missile launch controls) where particularly high reliability requirements exist,
where the pertinent levels of safety are not guaranteed, or where a failure, an operational error, or some
other factor could be life-threatening or cause a physical injury (referred to below as "high-risk" use).
Customers considering the use of this product
for high-risk applications must have safety-assurance
measures in place beforehand. Moreover, they are requested to consult our sales representative before
embarking on such specialized use.
Compliance With Laws and Regulations in Each Country
he FX700 system complies with the laws and regulations listed below.
North America
Safety Precautions
C120-0091-03ENiii

Environmental Substances (North America)
Standard Number Energy-Saving Environmental
Substances
Recycling
Regulations on brominated flame retardants (Maine,
Washington, Oregon, and Vermont in the U.S.)
✓
Law on emission of perchloric acid compounds to the
environment (California)
✓
Proposition 65 (California) ✓
Prohibition of Certain oxic Substances Regulations
(SOR/2012-285)
✓
Export Related (North America)
Standard Number
IA A Dangerous Goods Regulations 58th Edition (2017)
(Regulations on transport of lithium, lithium-ion batteries, and electric double layer capacitors)
Foreign Exchange and Foreign rade Control Law of Japan
North American Free rade Agreement (NAF A)
FIPS 140 (Federal Information Processing Standardization 140)
U.S. federal standards that specify security requirements for cryptography modules
NIS SP800-171 (U.S.
security standards)
rade Adjustment Assistance ( AA)
Safety, Radio, and Harmonics (Europe)
Certified
Standard
Standard Number Safety Radio Harmonics
EN, IEC IEC 60950-1:2005 (2nd Ed.); Am1:2009+Am2:2013
EN 60950-1:2006 +A11:2009 +A1:2010+A12:2011+A2:
2013
✓
EN 62479 (2010)
EN 55035 (2017)
EN 55032 (2012); Class A
EN 55024 (2010)
EN 61000-4-2
(2009)
EN 61000-4-3
(2006), +A1, +A2
EN 61000-4-4
(2012)
EN 61000-4-5
(2014), +A1
EN 61000-4-6
(2014)
EN 61000-4-8
(2010)
EN 61000-4-11
(2004), +A1
EN 300 386 V2.1.1
(2016)
✓
Europe
Safety Precautions
C120-0091-03ENiv

Safety, Radio, and Harmonics (Europe) (continued)
Certified
Standard
Standard Number Safety Radio Harmonics
EN 61000-3-2 (2014)
EN 61000-3-3 (2013)
✓
Environmental Substances and Recycling Disposal (Europe)
Standard Number Energy-Saving Environmental
Substances
Recycling
ErP Directive (2009/125/EC) ✓✓ ✓
RoHS II (2011/65/EU) ✓
New chemical regulation (REACH: No. 1907/2006) ✓
Directive 2006/66/EC of the European Parliament and of
the Council of 6 September 2006 on batteries and
accumulators and waste batteries and accumulators and
repealing Directive 91/157/EEC
✓
Waste Electrical and Electronic Equipment Directive
(WEEE Directive)
✓
European Parliament and Council
Directive 94/62/EC of
20 December, 1994 on packaging and packaging waste
✓
Export Related (Europe)
Standard Number
IA A Dangerous Goods Regulations 58th Edition (2017)
(Regulations on transport of lithium, lithium-ion batteries, and electric double layer capacitors)
Foreign Exchange and Foreign rade Control Law of Japan
Customs law of each country
Export Administration Regulations (EAR)
Safety, Radio, and Harmonics (Japan)
Certified
Standard
Standard Number Safety Radio Harmonics
PSE Act on Product Safety of Electrical Appliances and
Materials
✓
VCCI VCCI (2016)/VCCI-CISPR 32 (2016) ✓
-JIS C 61000-3-2 (2019) ✓
Japan
Safety Precautions
C120-0091-03ENv

Energy-Saving, Environmental Substances, and Recycling Disposal (Japan)
Standard Number Energy-Saving Environmental
Substances
Recycling
Act on the Rational Use of Energy ✓
Law Concerning the Examination and Regulation of
Manufacture, etc. of Chemical Substances
✓
Act on Promotion of Procurement of Eco-Friendly Goods
and Services by the State and Other Entities (Act on
Promoting Green Procurement)
✓
Act on the Promotion of Effective Utilization of Resources
✓
Export Related (Japan)
Standard Number
IA A Dangerous Goods Regulations 58th Edition (2017)
(Regulations on transport of lithium, lithium-ion batteries, and electric double layer capacitors)
Fundamental notices of customs law
Safety, Radio, and Harmonics (South Korea)
Certified
Standard
Standard Number Safety Radio Harmonics
KCC K 60950-1 (2.0) (2011-12)
(PSU only)
✓
KN32 Class A
KN35
KN61000-4-2/3/4/5/6/8/11
✓
Recycling and Disposal (South Korea)
Standard Number Energy-Saving Environmental
Substances
Recycling
Display rules on package separation ✓
Export Related (South Korea)
Standard Number
IA A Dangerous Goods Regulations 58th Edition (2017)
(Regulations on transport of lithium, lithium-ion batteries, and electric double layer capacitors)
Foreign Exchange and Foreign rade Control Law of Japan
Export Administration Regulations (EAR)
South Korea
Safety Precautions
C120-0091-03ENvi

Safety, Radio, and Harmonics (Australia New Zealand)
Certified
Standard
Standard Number Safety Radio Harmonics
RCM IEC 60950-1:2005 (2nd Ed.); Amd1+ Amd2 with AU,NZ
deviation
✓
AS/NZS CISPR 32 (2013) ✓
Export Related (Australia New Zealand)
Standard Number
IA A Dangerous Goods Regulations 58th Edition (2017)
(Regulations on transport of lithium, lithium-ion batteries, and electric double layer capacitors)
Foreign Exchange and Foreign rade Control Law of Japan
Export Administration Regulations (EAR)
his equipment is Class A information technology equipment. Operation of this equipment in a
residential area may cause radio interference, in which case the user may be required to
correct the interference at the user's own expense.
VCCI-A
he system complies with the requirements of European regulations.
his product is a Class A product. Operation of this product in a residential area may cause radio
frequency interference,
in which case the user will be required to correct the interference at the user's own expense.
Australia New Zealand
Regulatory Compliance Statements
he applicable regulatory compliance statements provided for this product are as follows:
- Voluntary Control Council for Interference (VCCI) - Japan
Be sure to read the notices on this product before installing the product.
he notices on the product are shown below.
- VCCI Class A Notice
Regulations
his section describes the applicable regulations.
CE Compliance
Safety Precautions
C120-0091-03ENvii

his equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules, and meets all requirements of the Canadian Interference-
Causing Equipment Standard (ICES-003) for digital apparatus. hese regulations are designed to
provide reasonable protection against radio
interference when the equipment is operated in a
residential installation. his product generates, uses, and can radiate radio frequency energy and, if
not installed and used in strict accordance with the instructions, may cause harmful interference to
radio communications. However, there is no warranty that interference will not occur in the
conditions
at a particular installation. If the product causes harmful interference to radio or television reception
(which can be confirmed by switching the equipment on and off), the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving
antenna.
- Increase the distance between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit separate from that connected to the receiver.
- Consult a reseller or experienced radio/ V technician for support.
Fujitsu is not responsible for any radio or television interference caused by unauthorized modification
of this equipment or the substitution or attachment of connecting cables and equipment other than
those specified by Fujitsu. he user shall be responsible for correcting the interference caused by
such unauthorized modification, substitution, or attachment.
he use of shielded I/O cables is required when connecting the equipment to any optional
peripheral
or host device. Failure to use shielded I/O cables may violate FCC and ICES regulations.
Document Manual Code Description
FUJITSU Supercomputer
PRIMEHPC FX700 Operating Manual
C120-0089EN Contains information about how to install, set up, and
operate the device. (Provided online)
FUJITSU Supercomputer
PRIMEHPC FX700 Upgra e an
Maintenance Manual
C120-0090EN
Contains device upgrade procedures and replacement
procedures for faulty hardware. (Provided online)
FUJITSU Supercomputer
PRIMEHPC FX700 BMC User's
Gui e
C120-0091EN Contains information about the BMC (Baseboard
Management Controller), which manages the
condition of the device. (Provided online)
FUJITSU Supercomputer
PRIMEHPC FX700 Safety an
Regulatory Information
C120-0092XA Contains important safety information. (Provided
online and as print version)
FCC Class A Declaration of Conformity
he device may be marked with an FCC declaration, which would apply to the equipment covered in this
document unless otherwise specified herein. he declaration for other products will appear in the
accompanying documentation.
Manuals in This Series
he documentation can be found online.
For the Japanese market
https://www.fujitsu.com/jp/products/computing/servers/supercomputer/downloads/
For the global market
https://www.fujitsu.com/global/products/computing/servers/supercomputer/documents/
See the following table for an overview of the documentation.
Safety Precautions
C120-0091-03ENviii

Document Manual Code Description
FUJITSU Supercomputer
PRIMEHPC FX700 Getting Starte
Gui e
C120-0093XA Describes how to access the reference manuals and
other important information after unpacking the
equipment. (The manual is supplied with the product.)
Font or Symbol Meaning Example
AaBbCc123 Indicates
what is input by users and displayed on
screens.
his font is used to indicate command input examples.
# adduser jsmith
AaBbCc123 Indicates
the names of commands, files, and directories
output by the computer and displayed on screens.
his font is used to indicate command output examples
in boxes.
Shell> showinfo
・
・
M.2 Slot Device Status: PASS
Italics Indicates
the name of a referenced manual. See the
FUJITSU Supercomputer
PRIMEHPC FX700 BMC User's Gui e.
" " Indicates the title of a referenced chapter, section, or
subsection.
See "Chapter 4 Operation."
Never peel off the labels.
Storage of Accessories
Keep the accessories in a safe place because they are required for FX700 main unit operation.
Notation
his document uses the following fonts and symbols to indicate special meanings.
Caution Labels
Caution labels are affixed to this product.
Safety Precautions
C120-0091-03ENix

Main Unit (Top)
Trademarks
- Company names and product names are the trademarks or registered trademarks of their respective
owners.
- rademark indications ( M, (R)) are omitted for some system and product names in this document.
his document shall not be reproduced or copied without the permission of the publisher.
All Rights Reserved, Copyright FUJI SU LIMI ED 2020
Safety Precautions
C120-0091-03ENx

Ask a certified service engineer or our sales representative to perform the inspection and repair work
for this product and the optional products provided by Fujitsu. he work must not be done by the
customer under any circumstances. Otherwise, electric shock, injury, or fire may result.
Modifying this product or recycling and using a secondhand product may result in personal injury to
users and/or bystanders or damage to the product and/or other property.
Notes on Product Handling
Maintenance
Modifying or Recycling the Product
Disposal or Recycling of Products That ave Completed Their Life Cycle
Waste must be disposed of in a professional and responsible way in accordance with environmental
regulations. For details, please contact your nearest environmental authority or our sales representative.
andling Lithium Batteries
his product uses lithium batteries. Under no circumstances are customers to replace the batteries. he
work must not be done by the customer under any circumstances. Otherwise, a battery may burst or
explode.
Notes on Product Handling
C120-0091-03ENxi

Contents
Preface ……………………………………………………………………………………… i
Notes on Product Handling ……………………………………………………………… xi
Chapter 1 Environment and Settings for Using the Web GUI ……… 1
1.1 Operating Environment …………………………………………………………………… 1
1.1.1 OS …………………………………………………………………………………………… 1
1.1.2 Browser ……………………………………………………………………………………… 1
1.1.3 Language …………………………………………………………………………………… 1
1.2 Various Settings …………………………………………………………………………… 2
1.2.1 Browser Settings …………………………………………………………………………… 2
1.2.2 Network Settings …………………………………………………………………………… 2
Chapter 2 Basic Web GUI Operations and Behavior ………………… 3
2.1 Login and Logout ………………………………………………………………………… 3
2.1.1 Login ………………………………………………………………………………………… 3
2.1.2 Logout ………………………………………………………………………………………… 6
2.2 Description of Web GUI Screens ………………………………………………………… 7
Chapter 3 Web GUI Functions ………………………………………… 10
3.1 Server Status ……………………………………………………………………………… 11
3.1.1 FRU Information …………………………………………………………………………… 11
3.1.2 CMU Information …………………………………………………………………………… 13
3.2 System Event Logs ………………………………………………………………………… 15
3.3 Power Control ……………………………………………………………………………… 23
3.4 Configuration ……………………………………………………………………………… 25
3.4.1 Chassis Settings …………………………………………………………………………… 25
3.4.2 Services ……………………………………………………………………………………… 27
3.4.3 Network Settings …………………………………………………………………………… 32
3.4.4 ime Settings ……………………………………………………………………………… 34
3.4.5 SNMP rap Settings ……………………………………………………………………… 35
3.4.6 SSL Certificate Configuration ……………………………………………………………… 39
3.5 Maintenance ……………………………………………………………………………… 42
3.5.1 Maintenance ………………………………………………………………………………… 42
3.5.2 Firmware Update …………………………………………………………………………… 46
3.5.3 REMCS ……………………………………………………………………………………… 48
Contents
C120-0091-03ENxii

3.5.4 REMCS Detail Setup ……………………………………………………………………… 49
3.6 User ………………………………………………………………………………………… 50
3.6.1 Modify User ………………………………………………………………………………… 50
3.6.2 One ime Password ………………………………………………………………………… 52
Chapter 4 Command Support (IPMI) …………………………………… 54
4.1 Command Tables ………………………………………………………………………… 54
4.1.1 Get Chassis Status (NetFN:00h, CMD:01h) ……………………………………………… 54
4.1.2 Chassis Control (NetFN:00h, CMD:02h) ………………………………………………… 56
4.1.3 IPMI Standard Command able …………………………………………………………… 56
Appendix A REMCS ……………………………………………………… 58
A.1 REMCS Settings ………………………………………………………………………… 58
A.1.1 Preparing the Environment ………………………………………………………………… 58
A.1.2 Configuring REMCS ………………………………………………………………………… 59
A.2 REMCS Detail Setup ……………………………………………………………………… 72
A.2.1 REMCS FE Menu (Initial Screen) ………………………………………………………… 73
A.2.2 Detail Environment Settings ……………………………………………………………… 73
A.2.3 Selecting REMCS Center ………………………………………………………………… 76
A.2.4 Select Language …………………………………………………………………………… 77
A.2.5 Machine Name Display Change …………………………………………………………… 78
A.2.6 Deleting the Personal Information ………………………………………………………… 79
A.2.7 Display of SSL Certificate ………………………………………………………………… 80
A.2.8 Replace Connection Center List …………………………………………………………… 82
Contents
C120-0091-03ENxiii

Figure Table Contents
Figure Contents
Figure 2.1 Login Screen ……………………………………………………………………… 4
Figure 2.2 [Logout] Button …………………………………………………………………… 6
Figure 2.3 Screen Configuration and Size …………………………………………………… 7
Figure 2.4 Information Area …………………………………………………………………… 7
Figure 3.1 [FRU Information] Screen ………………………………………………………… 12
Figure 3.2 [CMU Information] Screen ………………………………………………………… 13
Figure 3.3 [System Event Logs] Screen ……………………………………………………… 16
Figure 3.4 Snapshot Collection Dialog Box ………………………………………………… 18
Figure 3.5 [Detail]
Dialog Box ………………………………………………………………… 22
Figure 3.6 [Power Control] Screen …………………………………………………………… 23
Figure 3.7 [Chassis Settings] Screen ………………………………………………………… 26
Figure 3.8 [Services] Screen ………………………………………………………………… 28
Figure 3.9 web Service Modification Dialog Box …………………………………………… 29
Figure 3.10 ssh Service Modification Dialog Box …………………………………………… 30
Figure 3.11 snmp Service Modification Dialog Box ………………………………………… 31
Figure 3.12 [Network Settings] Screen ……………………………………………………… 32
Figure 3.13 [Time Settings] Screen …………………………………………………………… 34
Figure 3.14 [SNMP Trap Settings] Screen …………………………………………………… 36
Figure 3.15 [Upload SSL] Tab on the [SSL Certificate Configuration] Screen …………… 40
Figure 3.16 [View SSL] Tab on the [SSL Certificate Configuration] Screen ……………… 41
Figure 3.17 [Maintenance] Screen …………………………………………………………… 43
Figure 3.18 [Firmware Update] Screen ……………………………………………………… 47
Figure 3.19 [REMCS]
Screen ………………………………………………………………… 49
Figure 3.20 [REMCS Detail] Screen ………………………………………………………… 50
Figure 3.21 [Modify User] Screen …………………………………………………………… 51
Figure 3.22 [One Time Password] Screen …………………………………………………… 53
Figure A.1 [Customer Information Registration Instructions] Screen ……………………… 60
Figure A.2 [Selecting REMCS Center] Screen ……………………………………………… 61
Figure A.3 [Initial Settings] Screen …………………………………………………………… 62
Figure A.4 [Internet Connection environment settings] Screen
…………………………… 63
Figure A.5 [Periodical Connection settings] Screen ………………………………………… 65
Figure A.6 [Customer Information] Screen ………………………………………………… 66
Figure A.7 [Customer Information Review] Screen ………………………………………… 68
Contents
C120-0091-03ENxiv

Figure A.8 [Information Transmit Agreement] Screen ……………………………………… 69
Figure A.9 [Registration result] Screen ……………………………………………………… 70
Figure A.10 [Connection check] Screen ……………………………………………………… 71
Figure A.11 [Result of connection check] Screen …………………………………………… 72
Figure A.12 REMCS FE Menu (Initial Screen) ……………………………………………… 73
Figure A.13 Detail Environment Settings …………………………………………………… 74
Figure A.14 Selecting REMCS Center ……………………………………………………… 77
Figure A.15 Select Language
(Japanese or English) ……………………………………… 78
Figure A.16 Select to Display Machine ID or Machine Unique Name …………………… 79
Figure A.17 Deleting the Personal Information ……………………………………………… 80
Figure A.18 Display of Certificate …………………………………………………………… 81
Figure A.19 Display When the SSL Certificate Does Not Exist …………………………… 82
Figure A.20 Replace Connection Center List ……………………………………………… 83
Contents
C120-0091-03ENxv

Table Contents
Table 2.1 Operation Items on the Login Screen …………………………………………… 4
Table 2.2 Display Items on the Login Screen ……………………………………………… 5
Table 2.3 Icons on the Screen ………………………………………………………………… 5
Table 2.4 [Logout] Button ……………………………………………………………………… 6
Table 2.5 Error Status Background and Text Colors ……………………………………… 9
Table 3.1 Web GUI Screens ………………………………………………………………… 10
Table 3.2 Display Items on
the [FRU Information] Screen ………………………………… 12
Table 3.3 Display Items on the [CMU Information] Screen ………………………………… 13
Table 3.4 Operation Items on the [System Event Logs] Screen …………………………… 17
Table 3.5 Specifying the Snapshot to Collect ……………………………………………… 18
Table 3.6 Specifying the Environment Log to Download …………………………………… 19
Table 3.7 Filter Conditions of the Event Type
Filter ………………………………………… 19
Table 3.8 Display Items in [Logs:] on the [System Event Logs] Screen ………………… 20
Table 3.9 Display Items in the [Detail] Dialog Box ………………………………………… 22
Table 3.10 Operation Item on the [Power Control] Screen ………………………………… 24
Table 3.11 Specifying Power Control and a Boot Mode …………………………………… 24
Table 3.12 Display Items on
the [Power Control] Screen ………………………………… 25
Table 3.13 Operation Items on the [Chassis Settings] Screen …………………………… 26
Table 3.14 Specifying the FX700 Main Unit Name and Altitude …………………………… 26
Table 3.15 Display Items on the [Chassis Settings] Screen ……………………………… 27
Table 3.16 Display Items on the [Services] Screen ………………………………………… 28
Table 3.17 Operation Items on the
[Services] Screen ……………………………………… 29
Table 3.18 Specifying the web Service ……………………………………………………… 30
Table 3.19 Specifying the ssh Service ……………………………………………………… 31
Table 3.20 Specifying the snmp Service …………………………………………………… 32
Table 3.21 Operation Items on the [Network Settings] Screen …………………………… 33
Table 3.22 Specifying Network Information ………………………………………………… 33
Table 3.23 Display Items on the [Network Settings] Screen ……………………………… 33
Table 3.24 Operation Items on the [Time Settings] Screen ………………………………… 34
Table 3.25 Specifying Date and Time Setting Information ………………………………… 34
Table 3.26 Display Items on the [Time Settings] Screen …………………………………… 35
Table 3.27 Operation Items on the [SNMP Trap Settings] Screen ………………………… 36
Table 3.28 Specifying SNMP Trap Setting Information …………………………………… 36
Table 3.29 Display
Items on the [SNMP Trap Settings] Screen …………………………… 39
Table 3.30 Operation Items on the [Upload SSL] Tab on the [SSL Certificate Configuration]
Screen ……………………………………………………………………………… 40
Table 3.31 Display Items on the [Upload SSL] Tab ………………………………………… 40
Contents
C120-0091-03ENxvi

Table 3.32 Display Items on the [View SSL] Tab on the [SSL Certificate Configuration] Screen
……………………………………………………………………………………… 41
Table 3.33 Operation Items on the [Maintenance] Screen ………………………………… 43
Table 3.34 Operations in [Power Control] …………………………………………………… 44
Table 3.35 Display Items in [CMU Maintenance] on the [Maintenance] Screen ………… 45
Table 3.36 Display Items in [PSU Maintenance]
on the [Maintenance] Screen ………… 45
Table 3.37 Display Items in [FANU Maintenance] on the [Maintenance] Screen ……… 46
Table 3.38 Operation Items on the [Firmware Update] Screen …………………………… 47
Table 3.39 Display Items on the [Firmware Update] Screen ……………………………… 48
Table 3.40 Operation Items on the [Modify User] Screen ………………………………… 51
Table 3.41 Changing
Registered User Information ([Modify User] Screen) ……………… 51
Table 3.42 Display Items on the [Modify User] Screen …………………………………… 52
Table 3.43 Operation Items on the [One Time Password] Screen ………………………… 53
Table 3.44 Issuing a Short Password ………………………………………………………… 53
Table 4.1 Get Chassis Status Format ………………………………………………………… 55
Table 4.2 Chassis Control Format …………………………………………………………… 56
Table 4.3 Chassis
Device Commands ……………………………………………………… 56
Table A.1 For Internet Connection …………………………………………………………… 59
Table A.2 Information Specified on the [Internet(Mail Only) connection environment settings]
Screen ……………………………………………………………………………… 63
Table A.3 Information Specified on the [Periodical Connection settings] Screen ……… 65
Table A.4 Information Specified on the [Customer Information] Screen ………………… 66
Table A.5 Information Specified on the
[Connection check] Screen ……………………… 71
Table A.6 Information Specified on the [Environment settings] Screen ………………… 74
Contents
C120-0091-03ENxvii

Chapter 1 Environment and Settings for
Using the Web GUI
his chapter describes the environment for operating the BMC over the Web.
1.1 Operating Environment
his section outlines the Web GUI operating environment of the BMC.
1.1.1 OS
he supported OS is Windows 8.1 or later.
1.1.2 Browser
he supported browser is Microsoft Internet Explorer 11 or later. he supported protocols are http and
https.
1.1.3 Language
Web GUI screens: English
REMCS screens: English and Japanese
Since the following areas appear in the browser, their display language depends on the language settings
in the OS:
- Dialog box titles
- Buttons for file selection fields
Chapter 1 Environment and Settings for Using the Web GUI
C120-0091-03EN
1.1 Operating Environment
1

1.2 Various Settings
his section describes settings for using the Web GUI of the BMC.
1.2.1 Browser Settings
- o use JavaScript, enable JavaScript in the browser.
- o use browser pop-ups, disable the pop-up blocker in the browser.
- o use cookie-based authentication, enable [Override automatic cookie handling].
- Uncheck to disable [Display intranet sites in Compatibility View].
1.2.2 Network Settings
[Energy Efficient Ethernet] must be disabled in the settings.
Chapter 1 Environment and Settings for Using the Web GUI
C120-0091-03EN
1.2 Various Settings
2
