CELSIUS W370 E85+
Your gateway to workstation power
DATA SHEET
Issue: November 2009
CELSIUS W370 E85+
The CELSIUS W series is the versatile all-round workstation for price-conscious
users. Offering entry workstation performance, the CELSIUS W370 is your choice
for business segments, such as CAD, digital content creation and nance. The ISV
certication process enables workstation users to run their preferred applications with
maximum system stability.
Good performance
Higher productivity.
State-of-the art processors, graphic cards and hard disk drives
Ergonomics
Quiet system for a pleasant working environment
Optimized thermal management, low-noise chassis and silent fans
Flexibility
Suitable for all application areas
Excellent exibility for all tasks
Leading workstation application certication
Maximum compatibility and performance with customer-preferred applications
Full support for ISV applications and easy integration into existing IT 
environments
Built to order
Free congurability for all product lines
Customer is given a system optimized for his requirements
CORE PERFORMANCE
4
PROFESSIONAL GRAPHICS
ISV CERTIFICATION
MULTI DISPLAY SUPPORT
INFORMATION DISPLAY
24/7 OPERATING MODE
QUIET RUNNING
TWINLOAD

Components
Processor Intel®Core™2 Quad processor Q9650 (Quad Core, 3.0 GHz, 12 MB, 1333 MHz)
Intel®Core™2 Quad processor Q9550 (Quad Core, 2.83 GHz, 12 MB, 1333 MHz)
Intel®Core™2 Quad processor Q9505 (Quad Core, 2.83 GHz, 6 MB, 1333 MHz)
Intel®Core™2 Quad processor Q9400 (Quad Core, 2.66 GHz, 6 MB, 1333 MHz)
Intel®Core™2 Quad processor Q8300 (Quad Core, 2.5 GHz, 4 MB, 1333 MHz)
Intel®Core™2 Duo processor E8600 (Dual Core, 3.33 GHz, 6 MB, 1333 MHz)
Intel®Core™2 Duo processor E8500 (Dual Core, 3.16 GHz, 6 MB, 1333 MHz)
Intel®Core™2 Duo processor E8400 (Dual Core, 3.0 GHz, 6 MB, 1333 MHz)
Intel®Core™2 Duo processor E7600 (Dual Core, 3.06 GHz, 3 MB, 1066 MHz)
Intel®Core™2 Duo processor E7500 (Dual Core, 2.93 GHz, 3 MB, 1066 MHz)
Intel®Core™2 Duo processor E7400 (Dual Core, 2.8 GHz, 3 MB, 1066 MHz)
Intel®Pentium®processor E6300 (Dual Core, 2.8 GHz, 2 MB, 1066 MHz)
Intel®Pentium®processor E5400 (Dual Core, 2.7 GHz, 2 MB, 800 MHz)
Intel®Pentium®processor E5300 (Dual Core, 2.6 GHz, 2 MB, 800 MHz)
Intel®Pentium®processor E5200 (Dual Core, 2.5 GHz, 2 MB, 800 MHz)
Intel®Celeron®processor E3200 (Dual Core, 2.4 GHz, 1 MB, 800 MHz)
Intel®Celeron®processor 450 (Single Core, 2.2 GHz, 512 KB, 800 MHz)
Memory modules 4 GB (1 module(s) 4 GB) DDR2, 800 MHz, PC2-6400, DIMM
2 GB (1 module(s) 2 GB) DDR2, 800 MHz, PC2-6400, DIMM
1 GB (1 module(s) 1 GB) DDR2, 800 MHz, PC2-6400, DIMM
Graphics add on cards (op-
tional)
Midrange 3D: NVIDIA® Quadro FX 1800, 768 MB, PCIe x16, DL-DVI-I, 2x DP
Midrange 3D: NVIDIA® Quadro FX 580, 512 MB, PCIe x16, DL-DVI-I, 2x DP
Midrange 3D: ATI FirePro™ V5700, 512 MB, PCIe x16, DL-DVI-I, 2x DP
Midrange 3D: ATI FireGL V5600, 512 MB, PCIe x16, 2x DL-DVI-I
Entry 3D: NVIDIA® Quadro FX 380, 256 MB, PCIe x16, 2x DL-DVI-I
Entry 3D: ATI FirePro™ V3700, 256 MB, PCIe x16, 2x DL-DVI-I
Multi monitor 2D: NVIDIA® Quadro NVS 450, 512 MB, PCIe x1, 4 x DP
Multi monitor 2D: NVIDIA® Quadro NVS 290, 256 MB, PCIe x1, 2 x SL DVI-I
Multi monitor 2D: 2nd NVIDIA® Quadro NVS 290 256MB, , PCIe x1, 2x DL-DVI-I
Professional 2D: NVIDIA® Quadro NVS 295, 256 MB, PCIe x16, 2x DP
Professional 2D: NVIDIA® Quadro NVS 290, 256 MB, PCIe x16, 2 x SL DVI-I
Professional 2D: DVI Extension Adapter, , PCIe x16,
Professional 2D: Dual DVI Adapter, , PCIe x16,
Hard disk drives (internal) SSD SATA, 256 GB, 2.5-inch
SSD SATA, 128 GB, 2.5-inch
SATA II, 10000 rpm, 300 GB, 2.5-inch, S.M.A.R.T.
SATA II, 10000 rpm, 150 GB, 2.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 1000 GB, 3.5-inch, S.M.A.R.T. business critical
SATA II, 7200 rpm, 1000 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 750 GB, 3.5-inch, S.M.A.R.T. business critical
SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T. business critical
SATA II, 7200 rpm, 500 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 320 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 250 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 160 GB, 3.5-inch, S.M.A.R.T.
SATA II, 7200 rpm, 160 GB, 2.5-inch, S.M.A.R.T.
Hard disk notes One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
2.5-inch drives will be mounted in the 3.5-inch bays
Drives (optional) 1.44 MB Floppy
Blu-ray Disc Triple Writer
DVD-ROM
DVD Super Multi
MultiCard Reader 20in1, 3,5-Inch

Interface add on cards/compo-
nents (optional)
WLAN III, 802.11g/Draft-n (Windows only)
WLAN II, 802.11g, 54Mbps (Windows only)
Parallel Interface
Modem adapter kit (EU)
Modem 56k incl. RJ11 modem cable
Gigabit Ethernet PCIe x1
FireWire PCI-Card IEEE1394
eSATA Interface
Dual serial card, PCI, EX-43092
Base unit CELSIUS W370 E85+
Mainboard
Mainboard type D2817
Formfactor BTX
Chipset Intel®Q45 Express, Intel®82801JO ICH10DO
Chipset notes Intel®vPro™ technology dependent on processor type
Processor socket LGA 775
Processor quantity maximum 1
Memory slots 4 DIMM (DDR2)
Supported capacity RAM (max.) 16 GB
Memory frequency 800 MHz
Memory notes In congurations with 4 GB and more the visible memory may be reduced to
approximately 3.5 GB or less (for 32-bit operating systems) and congurations with 8
GB the visible memory may be reduced to approximately 7.5 GB or less (depending on
system conguration).
LAN Built-in 10/100/1000 MBit/s Intel®82567LM
WLAN Optional (for Windows only)
Audio codec Realtek ALC663
Audio features 5.1 surround sound, High Denition Audio, Internal speaker supports audio playback
I/O Controller
Serial ATA total 6
thereof eSATA 1, optional
SATA RAID support 0, 1, 10, 5, 50
Interfaces
Audio: in (rear) 2
Audio: out (rear) 1
DVI 1 or 2, optional
eSATA 1, optional
Ethernet (RJ-45) 1
Front Audio: in 1
Front Audio: out 1
Internal speakers 1
Mouse / Keyboard (PS/2) 2
Parallel 1, optional
Serial (RS-232) 1, (9 pin)
USB front 2
USB internal 2
USB rear 8
USB 2.0 total 12
VGA 1
Drive bays
Drive bays total 8
3.5-inch internal bays 4
3.5-inch external bays 2

Drive bays
5.25-inch external bays 2
Slots
PCI-Express x16 1 x (312 mm) full height
PCI-Express x4 (mech. x8) 1 x (190 mm) full height
PCI-Express x1 1 x (300 mm) full height
PCI (32-bit / 33 MHz) 4
Graphics on board
Graphics brand name Intel®GMA 4500
Shared video memory 256 MB
Refresh rate 1024 x 768
(recommended / max.)
85 Hz /
Refresh rate 1280 x 1024
(recommended / max.)
85 Hz /
Refresh rate 1600 x 1200
(recommended / max.)
85 Hz /
TFT resolution (VGA) 1360 x 768 pixel
1440 x 900 pixel
1680 x 1050 pixel
1920 x 1200 pixel
TFT resolution (DVI) 1360 x 768 pixel
1440 x 900 pixel
1680 x 1050 pixel
1920 x 1200 pixel
Graphics notes Tested resolutions, depending on display type additional resolutions and frequencies
possible
Shared memory depending on main memory size
Resolution (color depth up to 32 Bit/pixel)
For TFT we recommend to using 60Hz.
Electrical values
Rated voltage range 100 - 240 V
Rated frequency range 50 - 60 Hz
Max. output of power supply 300 W
Noise for standard conguration (HDD, ODD, FDD)
Noise emission According to ISO9296 (LpAm at bystander position)
Idle mode 18 dB(A)
Ofce mode 18 dB(A)
Noise notes / description Noise emissions may vary depending on actual conguration
Dimensions / Weight / Environmental
Dimension (W x D x H) 203 x 426 x 442 mm
Operating position Vertical / horizontal
Weight 16 kg
Weight notes Weight may vary depending on actual conguration
Operating ambient temperature 15 - 35°C
Compliance
Product CELSIUS W370 E85+
Model MTB-D2817
Germany GS
Europe CE
USA/Canada FCC Class B
CSA
Global RoHS (Restriction of hazardous substances)
Medical certication
IEC60601-1-2 in combination with medical kit
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx

Security
Physical security Kensington Lock support
Eye for padlock
Seal option
Intrusion switch
Optional: Integrated cabinet lock
System security Write protect option for the Flash EPROM
Embedded security (TPM 1.2) - Inneon
Disable / Hide TPM option
User security Hard disk password
User and supervisor BIOS password
Optional: Access protection via internal SmartCard reader
Optional: SmartCase Logon+
Operating system
Operating system optional
preinstalled
Microsoft®Windows®7 Professional 64-bit
Microsoft®Windows®7 Professional 32-bit
Microsoft®Windows®7 Home Premium
Microsoft® Windows Vista®Business 64-bit
Microsoft® Windows Vista®Business 32-bit
Operating system compatible Microsoft®Windows®XP Professional x64 Edition
Microsoft®Windows®XP Professional
Linux
Operating system notes RedHat / Novell certication pending
For some congurations third party drivers are currently not available or conguration
restrictions may apply.
Additional Software
Additional software (optional) Drivers & Utilities DVD (DUDVD) Windows® 7 & Vista & XP
Recovery DVD
TwinLoad
Windows®XP downgrade pack
Additional software (included as a
CD/DVD)
Norton Internet Security (incl. Firewall)
Manageability
Manageability features Intel®vPro™ technology
iAMT Intel®Active Manageability Technology v5.0 (not activated, not set up, for Windows
XP Professional and Windows Vista Business only)
Manageability type DeskView 10
Manageability link http://ts.fujitsu.com/manageability
Input device / components
Optical USB tilt wheel mouse
Input devices (optional) Optical USB/PS2 tilt wheel mouse
Space Explorer USB
Space Navigator USB
Space Pilot USB
Warranty
Service level (depending on country)
Maintenance and Support Services - the perfect extension
Recommended Service 5x9, Response Time: Next Business Day
Service Weblink http://ts.fujitsu.com/Supportservice
Information about environmental care, policies, programs and our Environmental Guideline FSC 03230:
http://ts.fujitsu.com/aboutus
Take back and Recycling information:
http://ts.fujitsu.com/recycling

All rights reserved, including intellectual property rights. Changes to technical data reserved.
Delivery subject to availability. Any liability that the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of
which by third parties for their own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions November 2009
Published by
Fujitsu Technology Solutions
http://ts.fujitsu.com
