Fujitsu IP Pathfinder S User manual

Fujitsu IP Path󲥬nder S
English Guidance Service
User Guide
Thank you for your purchase of the Fujitsu communication system.
This user guide is intended for users of its telephones and system administrators, and the
user guide explains the functions and operation of the Fujitsu communication system.
The user guide also provides important information on using this product safely.
Before using this product, read this user guide thoroughly.
Keep this user guide handy in a safe and convenient location for quick reference during use
of the product.
Fujitsu makes every effort to prevent users and bystanders from being injured and to prevent
property damage. To ensure no harm to you and bystanders, and no damage to the equipment
itself, be sure to use the product in accordance with the instructions in this user guide.

This Product is designed, developed and manufactured as contemplated for general use,
including without limitation, general of󲥬ce use, personal use, household use, and ordinary
industrial use, but is not designed, developed and manufactured as contemplated for use
accompanying fatal risks or dangers that, unless extremely high safety is secured, could
lead directly to death, personal injury, severe physical damage or other loss (hereinafter
"High Safety Required Use"), including without limitation, nuclear reaction control in
nuclear facility, aircraft flight control, air traffic control, mass transport control,
medical life support system, missile launch control in weapon system. You shall not use
this Product without securing the suf󲥬cient safety required for the High Safety Required
Use. If you wish to use this Product for High Safety Required Use, please consult with our
sales representatives in charge before such use.
CAUTION
This is a Class A product.
In a domestic environment this product may cause radio interference, in which case the
user may be required to take corrective actions. VCCI-A
● This telephone system is designed for use in Japan only and cannot be used in any
other country.
● The speci󲥬cations and information provided herein are for informational purposes
only and are not a warranty of actual performance, whether expressed or implied.
the specifications and information are subject to change without notice. Actual
performance may vary based on individual con󲥬gurations, use of collateral equipment,
or other factors.
● This telephone complies with certi󲥬cation of technical standard conformance.
This user guide prohibits copying, and transcribing the content of the description of
this user guide without the permission of the publisher.
All Rights Reserved,Copyright© Fujitsu 2010
2

IMPORTANTNOTETOUSERS
●Aboutthisuserguide
The user guide also provides important information on using this product safely.
Before using this product, read this manual thoroughly.
Especially, please use this product after you read "IMPORTANT NOTE TO USERS" described in
user guide, and you understood. Moreover, please keep this book importantly.
We will explain some of telephone function on this user guide. Please see the IP Path󲥬nder S
family's user guide ( ※ ) in detail.
※ IP Path󲥬nder S family's user guide : ES200 series ISS, CS100, CM50, MS16,
IP Path󲥬nder RM10S GSM series, IP Path󲥬nder S
●ConventionsforAlertSignals
This user guide uses the following conventions to alert users to potential injury to
themselves or bystanders and to potential property damage.
「 DANGER」 indicates a hazardous situation likely to result
in serious personal injury if the user does not perform the
procedure correctly.
DANGER
「 WARNING」 indicates a hazardous situation could result in
serious personal injury if the user does not perform the
procedure correctly.
WARNING
「 CAUTION」 indicates a hazardous situation could result in
minor or moderate personal injury if the user does not perform
the procedure correctly. This alert signal also indicates that
damages to the product or other property, may occur if the
user does not perform the procedure correctly.
CAUTION
●SafetyPrecautions
Follow the safety precautions given below when using the telephone, and the AC adapter (these
components are hereafter collectively referred to as the equipment). Improper handling of the
equipment or failure to observe the precautions may expose users and bystanders to harm, lead
to property damage, and may harm the environment and lead to injury and/or economic loss to
third parties.
DANGER
（1） Uses
・Use the dedicated AC plug of the equipment. Otherwise, a fire,
  NNootteessoonntthheeAACC electric shock, or product failure may occur.
aaddaapptteerr
The dedicated AC plug
：FC164H12（The dedicated AC plug of FC780BM）
3

IMPORTANTNOTETOUSERS
（1） Uses
 NNootteessoonnrreeaassoonnaabbllyy
 ffoorreesseeeeaabblleeiinnccoorrrreecctt
uusseess
 PPrroohhii bbiittiioonn aaggaaiinnsstt
 dd ii ss aa ss ss ee mm bb ll yy  aa nn dd
mmooddiiccaattiioonn
 NN oo tt ee ss  oo nn  tt hh ee
ccoonnnneeccttiioonnddeevviiccee
  NNootteessoonntthheeccaabblleess
WARNING
・Do not spill liquid on the equipment, and do not immerse the
equipment in any liquid. Otherwise, a fire, electric shock, or
product failure may occur.
・Do not place the equipment near vases, 󲥭owerpots, glass, toiletries,
containers of chemicals or liquids, and small metal objects. If
liquid from a container were to spill onto the equipment, or if a
foreign object were to get inside the equipment, a 󲥬re, electric
shock, or product failure may occur.
・Be careful to not expose the equipment to insecticide or hair
spray or cleaning spray (one including in󲥭ammable) etc. Otherwise,
a 󲥬re, electric shock, or product failure may occur.
・Ensure that no foreign object such as clips and staples gets
through openings and inside the equipment. Otherwise, a fire,
electric shock, or product failure may occur.
・Do not place the equipment in a location that is not stable, such
as on a wobbly stand, or in a location that is at an incline.
Otherwise, the equipment may be drop off or fall over because of a
problem with balance, which may cause an injury or product failure.
・Placing the AC adapter or the equipment in a microwave oven or
high-pressure container could cause it to generate excessive heat,
explode, or ignite, or a product failure.
・Do not disassemble or modify the equipment. Do not overhaul or
rebuild a used product for the purpose of reusing it. Otherwise, a
󲥬re, electric shock, or product failure may occur.
・Do not use a modi󲥬ed device in the equipment. Otherwise, a 󲥬re,
electric shock, or product failure may occur.
・Do not damage, break, or modify the cable. Otherwise, a fire,
electric shock, or product failure may occur.
・Ensure that no heavy or flammable object rests on the cable.
Otherwise, they may become damaged, which may result in a fire,
electric shock, or product failure.
・Do not place the cable near a heater. Otherwise, the coating of
the cord may melt, which may result in a 󲥬re, electric shock, or
product failure.
・Do not bend the cable. Otherwise, they may become damaged, which
may result in a 󲥬re, electric shock, or product failure.
4

IMPORTANTNOTETOUSERS
（2） Maintenanceandinspection
 RR ee ss tt rr ii cc tt ii oo nn  aa nn dd
pp rr oo hh ii bb ii tt ii oo nn
cc oo nn cc ee rr nn ii nn gg
ii nn ss pp ee cc tt ii oo nn ss
(( mm aa ii nn tt ee nn aa nn cc ee
ppeerrssoonnnneell))
・If inspection of the inside of the equipment or repair work is
required, ask the shop where you purchased the equipment to carry
out the work. Such work may result in an electric shock, injury, or
product failure.
・If the equipment is emitting smoke or an abnormal odor, contact the
shop where you purchased the equipment after taking the following
action. For the telephone, remove the AC adapter and cable to turn
off the telephone. For the connection device, use the power switch
to turn off the system.
CAUTION
（1） Uses
 NN oo tt ee ss  oo nn  tt hh ee
oo pp ee rr aa tt ii nn gg
eenvnviirroonnmmeenntt
・Do not place the equipment in a location where it is hot or
exposed to direct sunlight. Otherwise, the inside of the equipment
becomes hotter, which may cause a 󲥬re or product failure.
・Do not place the equipment in a location that is extremely hot or
cold or in a location that has large 󲥭uctuations in temperature.
Otherwise, a 󲥬re, electric shock, or product failure may occur.(Use
the equipment at a temperature ranging from 0℃ to 40℃ .)
・Do not set up or use the equipment in wet locations, such as in a
bathroom and near a humidi󲥬er. (Use the equipment in an environment
where the humidity ranges from 20% to 80%.)
・Do not place the equipment in a location where oil may splash on
it, such as near a cookstove, or in a wet or dusty location.
Otherwise, a product failure may occur.
・Do not place the equipment on an object that tends to accumulate
static electricity, such as rugs and carpets. Otherwise, a 󲥬re,
electric shock, or product failure may occur.
・Do not place the equipment in a location where the equipment is
exposed to harmful gases, such as sulfur gas and the exhaust gas
from automobiles. Otherwise, a fire, electric shock, or product
failure may occur.
・Do not place the equipment in a location where the equipment is
exposed to air from a nearby sea. Otherwise, a 󲥬re, electric shock,
or product failure may occur.
5

IMPORTANTNOTETOUSERS
 NNootteessoonnrreeaassoonnaabbllyy
 ffoorreesseeeeaabblleeiinnccoorrrreecctt
uusseess
・Ensure that no object rests on the equipment. The object may drop
off the equipment or fall over, which may cause a 󲥬re, electric
shock, injury, or product failure.
・Do not place the equipment near an unstable object that is likely
to fall over easily. Such an object may drop off or fall over,
which may cause a 󲥬re, electric shock, injury, or product failure.
・When mounting the equipment on a wall, be careful to make sure that
the equipment cannot fall off. Otherwise, a 󲥬re, electric shock,
injury, or product failure may occur.
・Do not place the equipment in a location that is exposed to
frequent vibrations or impacts. Otherwise, the equipment may drop
off or fall down, which may cause a 󲥬re, electric shock, injury, or
product failure.
・Do not set up the equipment in a passageway. Otherwise, people may
trip over the equipment, which may result in an injury or product
failure.
（2） Maintenanceandinspection
II nn ss pp ee cc tt ii oo nn  aa nn dd
cclleeaanniinngg
（3） Disposal
   NNootteessoonnddiissppoossaallooff
tthheepprroodduucctt
・If drops of water are found on the equipment, wipe them up with a
dry cloth. Drops of water left on the equipment may cause a 󲥬re,
electric shock, or product failure.
・If the equipment is dirty, clean the equipment by wiping it with a
soft dry cloth. Avoid using organic solvents, such as benzine and
thinner. Otherwise, the equipment may corrode or melt, which may
result in a 󲥬re, electric shock, or product failure.
・Please use " 富士通事業系 IT 製品リサイクルサービス " when this
product is abandoned and recycled from the customer of the
corporation and the enterprise. Please see the following Web site
in detail.
http://jp.fujitsu.com/about/csr/eco/products/recycle/recycleindex.html
・This equipment is products that registers or can maintain peculiar
data to the customer. When this equipment is abandoned to evade
unexpected damage etc. of the out󲥭ow of data in equipment etc. (Or,
it transfers and return it), it is necessary to delete the data
that registers or is maintained in equipment. Please contact the
purchased shop in detail.
6

CONTENTS
IMPORTANT NOTE TO USERS............................... 3
1 BEFORE USES
BASIC PACKAGE.......................................... 8
DIGITAL TELEPHONE CONTROLS AND INDICATORS.............. 9
CONTROL OF TONE / VOLUME / DISPLAY CONTRAST........... 11
CLEAR FACEPLATE....................................... 12
2 OPERATIONS
MAKING A CALL......................................... 13
ANSWERING A CALL...................................... 14
HOLDING CALLS / TRANSFER CALLS........................ 15
ABBREVIATED DIALING................................... 16
NOT PROGRAMMED ONE-TOUCH DIALING...................... 17
ABBREVIATED DIALING................................... 17
SYSTEM ABBREVIATED DIALING............................ 17
ABBREVIATED DIALING DISPLAY........................... 17
USEFUL OPERATIONS..................................... 18
EXTENSION CAMP-ON ................................ 18
THREE-WAY CONFERENCE ............................. 18
GROUP PICK-UP .................................... 18
3 LOCAL TELEPHONE DIRECTORY
TO REGISTER A DIRECTORY DATA.......................... 19
TO MAKE A CALL USING THE LOCAL TELEPHONE DIRECTORY.... 20
TO CORRECT A DIRECTORY DATA ............................. 21
TO DELETE A DIRECTORY DATA............................ 22
METHOD OF INPUTTING THE CHARACTERS.................... 23
4 CALL LOG
OUTGOING CALL LOG AND INCOMING CALL LOG............... 24
ABOUT OUTGOING CALL LOG............................... 25
ABOUT INCOMING CALL LOG............................... 26
7

1BEFOREUSES
BASIC PACKAGE
■Digitaltelephone
D-station50series
■Attachment
Warranty Cable Safetyprecautions
InsertsheetforIPPathnserS InsertsheetforotherPBX Clearfaceplate
family
● Besides the above attachment, a modular connector with screw terminal is attached.
● Please contact the purchased shop if there is an insuf󲥬cient one in the set or if there are an erratum
and an omission of a word in this book.
■Environmentalcondition
Temperature（ ℃） Humidity（％ RH）
Operating 0 ～＋ 40 20 ～ 80（ not dewfall）
Storage － 20 ～＋ 60 5 ～ 90（ not dewfall）
8

1BEFOREUSES
DIGITAL TELEPHONE CONTROLS AND INDICATORS
＜FC782D ＞
■Face Ringer LED Programmable Line / Feature Buttons
All buttons can be used to automatically dial
either an extension or others.
Dial Buttons
RG TONE
DIR
Press this key to change the ringing
tone.
Local telephone directory can be
operated.
Use these keys to change the ringing
tone volume, speaker volume, handset
volume, display co ntrast, an d
retrieval of telephone book.
Function Buttons
FLASH
ICM
ABBD Dial
REDIAL
DEL
TRANSFER
MUTE
REG
HOLD
CHR
SPEAKER
Press this key to terminate a call
without replacing the handset.
Press this key for extension call
and answering.
Press this key for abbreviated
dialing.
Press this key to redial number.
Press this key to clear the local
telephone directory's data.
Press this key to transfer a call to
another telephone.
Press this key to turn off the
microphone.
Press this key to register the local
telephone directory's data.
Press this key to hold an outside or
extension call. Press the ICM or the
LINE button to resume call.
Press this key to switch th e
character input mode.
Press this key to dial without
lifting handset. Only FC782D can
use the handsfree by pressing this
button.
Handset Microphone（only FC782D）
■Bottom
Recording jack Line code Handset code
※The insert sheet is option (the available accessory).
【The insert sheet of the available accessory】
・FC780TC41 : For FC781A, Ten pieces
・FC780TC42 : For FC781B, Ten pieces
・FC780TC43 : For FC782B/D/PA/PB, Ten pieces
9

1BEFOREUSES
DIGITAL TELEPHONE CONTROLS AND INDICATORS
＜FC782PAandFC782PB ＞
■Face
Please see ＜FC782D ＞ .
FC782PA
FC782PA : DP/PB switch
FC782PB : P/MP switch DP/PB Please set up the following switch
switch pursuant to analog network's contract
for the power outage.
(default：DP )
■Bottom
◆ DP：Analog sending signal 20pps
◆ PB：Analog sending signal PB
FC782PB
P/MP Please set up the following switch
switch pursuant to INS network's contract
Recording jack for the power outage.
Line code
Handset code (default：MP )
◆ MP: Point to Multi Point
always-on / call-by-call
◆ P: Point to Point
FC782PA/PB'sbehaveinpoweroutage
■ FC782PA and FC782PB
・During the power outage, functions (display, extension to extension calls, etc.) other than making calls
and answering calls cannot be used.
・About FC782PA/PB's behave in the power outage during the call.
【When the power is lost】
If the power is lost during the call, the call will be broken. After a few seconds, you can hear the
dial tone of the analog / INS network.
【When the power is restored from the power outage】
If the power is restored during the call, the call will be disconnected.
After several tens of seconds, you can hear the internal dial tone.
・The call waiting service etc. of the analog/INS network cannot be used during power outage.
■ Only FC782PB
・Please set up following switch pursuant to INS network's contract for the power outage.
◆ MP : Point to Multi Point always-on / call-by-call (default)
◆ P : Point to Point
P/MP swicth's con󲥬guration becomes effective if you reactivate the telephone after you change it during
power recovery.
P/MP switch's con󲥬guration doesn't become effective if you change it during power outage, or after you
reactivate the telephone.
・The line length from DSU to FC782PB (via PBX) is 300 metre ( φ 0.5 cable). One INS network line can
connect only one FC782PB.
10
