Escene ES330-PEG User manual

www.escene.cn/en/ Escene Communication
1
ES330-PEG IP Phone
User Manual
E
Es sc ce en ne e C Co om mm mu un ni ic ca at ti io on n C Co o. . L Lt td d

www.escene.cn/en/ Escene Communication
2
Tables of Contents
1.Getting Started 4
1.1 About 4
1.2 Feature Highlights: 4
1.3 Technical Features 4
2.Connecting Your Phone 6
3.Phone overview 8
3.1 Understanding Buttons and Hardware 8
3.2 Understanding Phone Screen Features 10
4.Basic Call Handling 11
4.1 Placing a Call11
4.2 Answering a Call 12
4.3 Ending a Call12
4.4 Using Hold and Resume (Switch Calling Line) 13
4.5 Transferring Calls 13
4.6 Using Mute 14
4.7 Do Not Disturb 14
4.8 3-way Conference 14
4.9 Expansion Installation 14
4.10 Expansion Settings 15
4.11 Time & Date15
4.12 VOIP Call Forwarding 15
5.Advanced Call Handling 17
5.1 Using the phone book 17
5.2 Using Call Logs 18
6.Keypad Instruction 19
6.1 SIP Account Settings 19
6.2 Network Setting 19
6.3 Load default settings 20
6.4 Customizing Rings and Volume20
6.6 View status 20
6.7 Diagnose 20
7.Web Settings 22
Main Interface-Phone Status 22
7.1 Net Work 22
7.1.1 LAN Port 22
7.1.2 PC Port 25
7.1.3 Advanced 25
8 SIPAccount 27
8.1Basic 27
8.2 Call 28
8.3 Security 29
9 Phone Setting 29
9.1 Basic 29

www.escene.cn/en/ Escene Communication
3
9.1.1 Time Settings 30
9.1.2 Call 31
9.1.3 VoIP Call Forward 32
9.1.4 QoS 32
9.2 Advanced 33
9.2 Audio 33
9.3 Line Keys 35
9.4 Function Keys 36
9.5 Soft Key 36
9.6 Dial Plan 36
9.7 IP Strategy 37
10 Phone Book 38
10.1 Group38
10.2 Contact 38
10.3 LDAP 39
10.4 Ban List 40
11 Phone Maintenance 40
11.1 Basic 40
11.1.1 HTTP Upgrade 40
11.1.2 FTP Upgrade 41
11.1.3 TFTP Upgrade 42
11.1.4 Default Setting 42
11.1.5 Reboot 42
11.2 Advanced 43
11.2.1 Log 43
11.2.2 Auto Provision 43
12 Password 45
13 WEB Other Settings or Information - Appendix 45
13.1 WEB User 45
13.2 Multi-Language 45
13.3 Note Tips 45

www.escene.cn/en/ Escene Communication
4
1.Getting Started
1.1 About
ES330-PEG is a small-screen-based IP PHONE in SayHi IP PHONE series, it has fashion and technological appearance, excellent
voice quality, and powerful features, and it is a new generation of intelligent phones to replace of the traditional desktop office terminals, It
accomplished the powerful telephony features by cooperating with the communications platform,. such as the call transfer, hotline,
three-party conference calling, speed dial, voice mail, Do Not Disturb, etc. This document updated and revised by Nolto Bilişim ve
Telekomünikasyon, Escene Turkey Distributor (www.nolto.com)
1.2 Feature Highlights:
⚫128*64 Pixel LCD with Support Chinese display
⚫HD Voice: HD Codec
⚫2 VoIP accounts
⚫Enterprise Phone Book
⚫12 programmable hard keys and support BLF
⚫Support 4 ESM32 expansion modules (128 keys).
⚫Support Plug and Play
⚫Support PoE andAC power adapter
⚫Support HTTP/TFTP/FTPAuto-provision/TR069 for upgrade software
1.3 Technical Features
Item
ES330-PEG
Screen
Grayscale LCD with background light
128*64-pixel, 4 display, 2.4 inch.
Line
3
Language
Multi-Language (e.g.CN/EN/Spain/Portugal/Poland/Turkey/French/Italy etc.)
Function Keys
4 Soft keys,2 Line keys (dual-color LED)
6 Navigation keys (arrow button, OK button, C button)
Volume adjust, Hands-free, Mute, Headset, Message,
Menu, Directory, Service, Hold, Redial, Conference, Transfer
VoIP Protocol
SIP 2.0
Network Protocol
HTTP, BOOTP, FTP, TFTP, IEEE 802.1Q, *IEEE 802.1X
Codec
G.723.1(5.3Kb/s,6.4Kb/s), G.729A/B(8Kb/s), G.711 A/U, G.722(64Kb/s)
QoS
TOS, Jiffer Buffer, VAD, CNG, G.168 (32ms)
Network
2×RJ45 10/100/1000M Ethernet Interfaces (LAN/PC)
IPAssignment: static IP, DHCP, PPPoE
PC port support Bridge and Router
DNS SRV, STUN, VPN(L2TP), VLAN/QoS
STUN, DTMF (In-band/RFC2833/SIP INFO)
Voice
HD Voice: HD Codec/Handset/Speaker (Full duplex)
Handle, Headset and Hands-free mode available
Support call center headsets and PC headsets

www.escene.cn/en/ Escene Communication
5
Separated 9 Level VolumeAdjustment
Call Processing
Line Status Indicator MultiAccount
Always Forward, Busy Forward, No-answer Forward
Hotline line (Immediately/Delay)
Call Waiting, Call Queuing, Line Switching
Call Forward, Call Transfer, Call Holding, Call Pickup, *Callback
One Key Dial, Redial
Phone directly speed dial, Call record direct dial
3-way conference, SMS
DnD, Blacklist
Voice mail, Voice Prompt, Voice Message
BLF, BLA, Speed dial
P2P(Peer-to-Peer)
PBX
Call Transfer, Call Pick-Up, Network-Meeting, DND, Call Waiting, Call Hold. Call Barring,
Call Back on Busy, Anonymous Call, Intercom, Paging
Security
Login the website by password
Login the LCD by password
Signaling encryption (RC4)
Media encryption (RC4)
VPN, 802.1X, VLAN QoS(802.1pq), *LLDP
TLS, MD5, AES, ROOT/USER Management
Application
LDAP (2): search someone in two LDAP server.
Enterprise phone directory, download with server, and it support 800 contacts
Public phone directory
XML Phonebook: Search /Input/ Out put
Private phone directory: input/output 300 contacts, every contact can save 3 numbers and
the size of number is 19 bytes.
Call History (600): every record is 200 with Miss Calls /Received Calls/Dialed Calls.
Voice Message, Voice Mail Box, Light of Message.
Ringing Update, Input, Del,
*we also support to order the other APP.
Power Supply
Power adapter:AC 100-240V input and DC 12V/1Aoutput
PoE (IEEE 802.af); USB (Standard DC 5V)
Specification
DSPG Chipset
Storage Temperature: 0℃~ 60℃
Operating Humidity: 10%~90%
Size: 287mm*214mm*90mm
Net weigh: 1.2kg
Certifications
CE、FCC、RoHS、Avaya、BroadSoft、Alcatel、Yeastar、Digium,
Note: “*” Sign means function has not been published yet.

www.nolto.com Escene Communication
6
2.Connecting Your Phone
Your system administrator will likely connect your new ES330-PEG IP PHONE to the corporate IP telephony network. If that is not the case,
refer to the graphic and table below to connect your phone.
1) Open the ES330-PEG IP PHONE box; carefully check the packing list, Packing List as follows:
Item
Counts
IP Phone
1
Handset
1
Handset Cord
1
Power adapter
1
RJ45 cable
1
CD
1
Quick Installation
1
Quick User Guide
1
Product certification
1
2) As shown in figure 2.1 and figure 2.2, Please plug Handset Cord into RJ11 interface (IP PHONE and Handset), RJ45 cable into the
LAN interface；IP PHONE will automatically start if IP PHONE with POE function.
3) The phone must work together with power adapter without POE support.
4) Connect your computer to PC interface of the phone with cable.
* More detailed description please refers to the 3. Phone overview-Understanding phone buttons and hardware.
Figure 2.1 Interfaces of SayHi ES330-PEG
Figure 2.2 Foot stand of SayHi ES330-PEG

www.nolto.com Escene Communication
7

www.escene.cn/en/
Escene Communication
8
3.Phone overview
3.1 Understanding Buttons and Hardware
Figure 3.1 Buttons and Hardware of SayHi ES330-PEG (NOTE: 330 have three lines)
Num
Buttons
Description
1
Headset button: Toggles the headset on or off.
Red means the feature is enabled.
2
Mute button: Toggles the Mute feature on or off.
Red means the feature is enabled.
3
Messages button: Typically, auto-dials your voice message service.
Red means have unread voice mail.
4
SERVICE
Server button: Open or Close the Services menu.
5
DIRECTORIES
Directory button: Use it to access call logs and corporate directories.
6
MENU
Menu button: Allows you to scroll through menus.
7
Volume button: Controls the volume and other settings.
8
CONFERENCE
Conference button: Connect calling / called party to the conference
9
REDIAL
Redial button: To Redial the last number.
10
TRANSFER
Transfer button: Transfer redirects a connected.

www.escene.cn/en/
Escene Communication
9
11
HOLD
Hold button: Put a call on hold
12
0-9, *, #
Basic Call Handling: press “#”send out a call(default)
13
Speaker button
Speaker button: Toggles the speakerphone on or off.
Red, steady: Pick up and enter normal call.
14
Softkey
Each displays a softkey function, to activate a softkey, press the softkey button.
15
Line buttons
Select the phone line（Call orAnswer).
Different colors for different status:
1) Red, flashing: There is an incoming call.
2) Red, steady: Pick up and enter normal call.
3) Yellow-green, flashing: Holding call.
4) Yellow-green, steady: Active call.
16
Programmable
Buttons
Hotline number can be used to bind in order to achieve speed dial；Turn on BLF:
1) Red, steady: Remote line is busying.
2) Yellow-green, steady: Remote line is idle.
The order of the hot keys:
On the left top to bottom: 1, 2, 3, 4, 5, 6.
On the right top to bottom: 7, 8, 9, 10, 11, 12;
17
C
Back button: Return to the standby interface;
18
Navigation
button
“Up”: Adjust ring volume, operate with the “down”button
“Down”: Open ‘Missed Calls”list:
“Left”: Open “Received Calls”list.
“Right”: Open “Dialed Numbers”list
19
OK
OK button: To confirm the action;
20
Hands-free
speakerphone
Hands-free voice of the output
21
LCD screen
160*32 pixels, grayscale LCD with background light.
22
Light strip
Red flashing: There are incoming call.
Red, steady: Missed Calls, or phone busy;
23
Hands-free
microphone
Sounds input when hands-free
Figure 3.2 Interfaces of SayHi ES330-PEG (NOTE: 330 support expansion, that it has an EXT port)

www.escene.cn/en/
Escene Communication
10
Num
Hardware
functions
1
Footstand
Hold up phone
2
Footstand button
Press buttons at the same time to adjust the angle
3
Reserved for USB port
Enhanced scalability
4
Microphone port
Connect the Microphone
5
Power port
12VDC
6
Headset port
Support RJ9 interface connection
7
Handset port
Connect the Handset
8
EXT port
Expansion module interface
9
LAN port
Connect to a LAN interconnecting device
10
PC port
Connect to a local PC
3.2 Understanding Phone Screen Features
This is what your main phone screen might look like:
Figure 3.3 LCD for example is 330 (NOTE: 320 just only have two lines).
②

www.escene.cn/en/
Escene Communication
11
Num
Screen
Functions
1
Time and Date
Show current time and date.
2
Auto-answer
Enabled Auto-answer, displays “AA”
3
Missed calls
Show the number of missed calls.
4
Line status
Show the phone line status:
1) : Disconnect into network.
2) : Only Peer-to-Peer call.
3) : Network connected normal, but the line is not successfully
registered.
4) : Network is OK, and the line is available.
5) : Line is turned on DND.
5
Soft key labels
Each displays a soft key function (displayed on your phone screen), and the
function is different when menu changes.
4.Basic Call Handling
You can perform basic call-handling tasks using a range of features and services. Feature availability can vary; see your system
administrator for more information.
Note: The bold type of the following text and following a “button” in table signifies the phone's button (for example, Speaker button), and
the coming call can use Ans (Answer) signifies soft key.
4.1 Placing a Call
Here are some easy ways to place a call on SayHi IP Phone:
If you want to...
Then...
Place a call using the
handset
Pick up the handset
1) You can hear the dial tone.
2) The first line light is ；
3) Enter a number.
Place a call using a
Press Speaker,
③
④
⑤

www.escene.cn/en/
Escene Communication
12
speakerphone
or Programmable buttons
4) Press ‘#’button（default),
-or press ;
-or wait 5s (default), then it sends the
number automatically.
Place a call using a
headset
Put on your headset and active
Headset button, and then do as using
speakerphone
Redial
Press REDIAL button to dial the last number
-or press Navigation Button-Right > “Dialed number”, select a number, and
press
Dial from a call log
1) Press MENU or OK button >“Call history”, you can select “Missed calls”,
“Received calls”and “Dialed numbers”,
- or press Navigation button (in Standby interface) > select “Missed calls”
(down), “Received calls” (left)and “Dialed numbers” (right)).
2) Then press button.
Place a call while
Another call is active
1) Press Hold button or soft key ;
2) Press again the line one or the other line, you can enter another number.
3) Press ‘#’button (default).
-or press to send the number.
Tips
• You can dial on-hook, without a dial tone (pre-dial). To pre-dial, enter a number, and then go off-hook by lifting the handset or
pressing , Headset or Speaker button.
• If you make a mistake while dialing, press Cbutton to erase digits.
4.2 Answering a Call
You can answer a call by simply lifting the handset, or you can use other options if they are available on SayHi IP Phone.
If you want to...
Then...
Answer with a
handset
1) Your phone rings.
2) Line button of the ringing line is
Red and flashing, Light strip is
Red and flashing；
Pick up the handset
Answer with the
speakerphone
(Non-headset mode)
Press Speaker button
-or press the flashing Line button,
-or press
Answer with a
headset
Put on headset, press Headset button so that
the status light is Red , and then do as
using speakerphone
Switch from a
connected Call to
answer a ringing
call
1) Another Line button is Red and flashing, Light strip is Red and flashing.
2) Press the flashing Line button to answer (at this time, the original call will be hold.)
Auto-answer
1) Press MENU or OK button > “Function setting”> “Auto answer”.
2) Select “Enable”.
3) Your phone answers incoming calls automatically after a few rings.
4.3 Ending a Call
To end a call, hang up. Here are some more details.
If you want to...
Then...
Hang up while using the
Return the handset to its cradle,

www.escene.cn/en/
Escene Communication
13
Handset
-or press End
Hang up while using the
Speakerphone
Press Speaker button that is Red ,
-or press Line button for the appropriate line,
-or press End
Hang up while using the
Headset
Press Handset button, （Do not keep the headset mode),
-or press End (keep the headset mode)
Hang up one call, but preserve
another call on the other line
Press End,
-or refer to the above three methods
4.4 Using Hold and Resume (Switch Calling Line)
You can hold and resume calls. You can take a call in one line at any time, and the other lines would be hold. As a result of that, you can
switch different calling line on our phone.
If you want to...
Then...
Put a call on hold
Press HOLD button,
-or press soft key
Hold a line and switch to another
line
Press another Line button for the appropriate line
Resume a call on current line
Press Line button,
Release a call on different line
Select the line want to release hold, press the line, so recovery;
Tips
•Engaging the Hold feature typically generates music or a beeping tone.
•A held call is indicated by the Yellow green and flashing Line button.
4.5 Transferring Calls
Transfer redirects a connected call. The target is the number to which you want to transfer the call.
If you want to...
Then...
Talk to the transfer
recipient before
transferring a call
(consult transfer)
1) Press TRANSFER button or press XFER.
2) Enter number.
3) press “#” （default),
-or press then transfer the call,
-or wait five seconds(default)then transfer the call
Transferred to idle lines or
other numbers without
talking to the transfer
recipient
(Blind transfer)
1) Press TRANSFER button or XFER.
2) Press ;
3) Enter number.
4) Press “#” （default)
-or press , then transfer the call.
-or wait five seconds(default)then transfer the call
Blind transfer to the
held line
1) Press TRANSFER button or press XFER.
2) Press the Line button of held line

www.escene.cn/en/
Escene Communication
14
4.6 Using Mute
With Mute enabled, you can hear other parties on a call, but they cannot hear you. You can use mute in conjunction with the handset,
speakerphone, or a headset。
If you want to...
Then...
Toggle Mute on
Press Mute button, then the button is Red
Toggle Mute off
Press Mute button, then the button lights off
4.7 Do Not Disturb
You can use the Do Not Disturb (DND) feature to block incoming calls on your phone with a busy tone（Can also be set to their voice mail
or other extension numbers, etc.).
If you want to...
Then...
Enable global DND
1) Press ;
2) All enabled line on the phone would changes to status.
Enable DND on a single
line
Press MENU or OK button > “Function setting”> “DND”> (select line) “Enable”
Disable DND
Global DND enabled, press to disable global DND.
Line DND enabled, press twice ,
-or press MENU or OK button > “Function setting”> “DND”> (select line) “Disable”
4.8 3-way Conference
You can establish a three-party conference, during the conversation three phone parties can communicate with each other.
If you want to...
Then...
Invite the transfer recipient
into a conference in a
transferring
1) When the transfer recipient answers the call, press CONFERCENCE button or
"CONF" on your phone.
2) Then the held one, transfer recipient and you will be into a conference, and the
LCD will display status.
Invite the third party into a
conference in an active call
1) Press CONFERENCE button or "CONF" in an active call.
2) Enter the third-party number.
3) After connected the third party, press CONFERENCE button or "CONF" again
establish a conference
withheld line
1) when one phone line is holding on and the other line is busy.
2) Press CONFERENCE button,
-or Press "CONF" Soft key
3) press the held line's programmable button, the 3-way Conference will establish.
4.9 Expansion Installation
Expansion support list. Pls make sure your model is support or not.

www.escene.cn/en/
Escene Communication
15
If you want to...
Then...
Expansion installation
1) Press MENU or OK button > “Function setting”> “expansion installation”,
2) if you want to install expansion, please according to tips to do, after you install,
press "finish".
4.10 Expansion Settings
If you want to...
Then...
Expansion setting
1) Press MENU or OK button > “Function setting” > “expansion installation”,
2) choose which you want to set “expansion”
3)choose which you want to set “programmable keys “
4)you can set:
Mode: Speed Dial、Asterisk BLF、Speed Dial Prefix、BLA、DTMF
Account: choose account which you want to set
Name: give it a name which you want
Number: set your expansion number
4.11 Time & Date
If you want to...
Then...
Time & Date
1) Press MENU or OK button > “Function setting”> “time & date”,
2)you can select:
SNTP: select “enable” to set parameter: time 、server 、daylight
SIP server: select “enable” to set parameter: root can modify date.
manual Settings: select “enable” to set parameter: date and time
4.12 VOIP Call Forwarding
If you want to...
Then...
Unconditional transfer
1) Press MENU or OK button > “Function setting”> “VoIP call forwarding”.
2)select “unconditional transfer”, select enable.
3)input number which you want to transfer, when have a call in, it will
unconditional transfer.

www.escene.cn/en/
Escene Communication
16
Busy transfer
1) Press MENU or OK button > “Function setting”> “VoIP call forwarding”.
2)select “busy transfer”, select enable.
3) input number which you want to transfer, when have a call-in
conversation, it will transfer.
No answer transfers
1) Press MENU or OK button > “Function setting”> “VoIP call forwarding”.
2)select “no answer transfer”, select enable.
3) input number which you want to transfer, when have a call in but you
don’t have time to answer, it will transfer.

www.escene.cn/en/
Escene Communication
17
5.Advanced Call Handling
5.1 Using the phone book
You can store a large number of contacts in your phone's directory. You can add, edit, delete, dial, or search for a contact in this directory.
However, it only can configure the phone book on web page in ES330-PEG. For details, you can refer to 7. Web Settings.
If you want to…
Then…
Add Contacts
1) Press Phone Book,
-or press MENU button > “Phone book”> “Personal phone book>View All”,
-or press OK button > “Phone book”> “Personal phone book>View All”.
2) Select “Add contact”, press OK button.
3) Use the navigation keys to select content, press OK button to set and modify:
-Name: set the name of contact,
-NO.1-3: you can set up 3 contacts’numbers,
-Group: the contacts be divided into different user’s groups
4) Press Save soft key to complete
Add group
1) Press DIR soft key,
-or press MENU button > “Phone book”> “Personal phone book>View All”,
-or press OK button > “Phone book”> “Personal phone book>View All”.
2) Select the “add group”then press OK button.
3) Use the navigation keys to select content, press OK button to set and modify:
-Group name: name of the group
4) Press Save soft key to complete
Modify group
1) Press DIR soft key,
-or press MENU button > “Phone book”> “Personal phone book>View All”,
-or press OK button > “Phone book”> “Personal phone book>View All”.
2) Select the “Modify group”then press OK button.
3) Select the group you want to modify, press the OK button to set and modify, press
Save to save the change
Delete group
1) Press DIR soft key,
-or press MENU button > “Phone book”> “Personal phone book>View All”,
-or press OK button > “Phone book”> “Personal phone book>View All”.
2) Select the “Delete group”or OK button.
3) Select a group you want to delete, press OK button
View/Edit Contacts
1) Press DIR soft key,
-or press MENU button > “Phone book”> “Personal phone book”,
-or press OK button > “Phone book”> “Personal phone book”.
2) Select “ViewALL”,
-or select a contact who are belong to different group.
3) Select the contact, press the OK button or Enter (to edit the contact’s information,
press OK button)

www.escene.cn/en/
Escene Communication
18
LDAP
1) 1) Press DIR soft key,
-or press MENU button > “Phone book”
-or press OK button > “Phone book”
2)Select “LDAP”, press the OK button.
3)Select “Search name->name”, then input the name, and press OK or Del.
4)Select “Search number->Number”, then input the number, and press OK or Del.
Pay attention: before you use LDAP function, you need to configure LDAP rule
in the web configure page.
Call from phone book
1) Press DIR soft key,
-or press MENU button > “Phone book”> “Personal phone book”,
-or press OK button > “Phone book”> “Personal phone book”.
2) Select “ViewALL”,
-or select a contact who are belong to different group.
3) Select a contact, then press Dial,
(If there are multiple numbers of one contact, press Dial to enter the interface of “call
options”, select the one you want to call and press Dial)
5.2 Using Call Logs
Your phone maintains records of your missed, placed, and received calls.
If you want to…
Then…
View your call logs
1) Press MENU button > “Call history”> “Missed Calls”, “Received Calls”, or “Dialed
numbers”
2) Use the navigation keys to view the call record information.
Dial from a call log
Please refer to the previous part 4. Basic call handing –Placing a call.
Tips: Each call log store up to 20 entries on ES330-PEG IP phone.

www.nolto.com Escene Communication
19
6.Keypad Instruction
SayHi series IP phones are can be configured in two ways. The first you can use the phone keypad where you can settings for you IP
phones, the other you can log in to User Options web pages where you can settings for you IP phones.
Use phone keypad to set. Press MENU or OK button to the main menu, Use the navigation keys to select menu, press OK button to
confirm menu selections, press to delete input information.
6.1 SIP Account Settings
ES330-PEG IP PHONE make calls based on sip accounts, ES330-PEG IP phones can support 2 or 3 independent SIP account, each
account can be configured to different SIP server.
If you want to…
Then...
Create a SIP account
1) Select “System setting”> “Advanced setting”.
2) Enter the password required（The default is empty).
3) Select “SIP”> “Account sip”.
4) Select one of the accounts you want to set, you can configure the following
parameters
-Enable account*: Select Enable
-Display Name: The name displayed on the screen
-User Name*: the account matched with the SIP server. （extension number) ,
-Authen usr: TheAuthenticated users matched with the SIP server. （The default
With the same account)
-user pwd*: the user password matched with the SIP server
-Description: description of this account,
-SIP1*: the primary SIP server, by default all calls through the server,
-SIP2: the secondary SIP, When the primary server is unavailable, use the SIP
server
-Refresh time: Registration refresh interval, the minimum value is 20 The default
value is 3600.
5) Set up the above parameters, select “Submit changes”to saves settings, Complete
the account creation.
* Note: the parameters with the * mark must be set.
Disable sip account
1) Select “System setting”> “Advanced setting”.
2) Enter the password required（The default is empty).
3) Select “SIP”> “Account sip”.
4) Select “Enable account”> “Disable”.
5) Select “Submit changes”to saves settings
6.2 Network Setting
If you want to …
Then…
network setting
1) Choose “System setting”> “Advanced setting”.
2) Enter the password required（The default is empty).
3) Choose “Network”, you can configure the following parameters:
-Type: static IP or DHCP
-IP: enter IP address, note: Do not duplicate the IP address with other devices on
the network

www.nolto.com Escene Communication
20
-Mask: enter appropriate subnet mask
-GW: enter appropriate gateway
-DNS1: enter IP address of the primary DNS server
-DNS2: enter IP address of the secondary DNS server
-Web port: the default Web port is 80,if you change it(for example change it to
88),you must use IP and Web port to login the web page (for example
http://192.168.0.200:88).It will take effect on next reboot.
-Telnet port: the default Telnet port is 23,if you change it(for example change it to
2003),you must use IP and Telnet port to login the manage page (for example telnet
192.168.0.200:2003).It will take effect on next reboot.
6.3 Load default settings
If you want to...
Then...
Load default settings
1) Choose “System settings”> “Advanced settings”.
2) Enter the password required（The default is empty).
3) Choose “load default settings”, and press ’OK’, then go
back and press “Reboot”the phone.
6.4 Customizing Rings and Volume
If you want to…
Then…
Change the ring tone
1) Choose “System setting”> “Phone setting”> “Ring type”.
2) It will auto ringing. Press navigation to choose ring tone.
3)Press OK to set the ring tone,
Press soft key to cancel
Adjust the volume
level
1) Choose “System setting”> “Phone setting”> “Volume setting”.
2) You can adjust the volume level of following types
-Ring volume: Phone call ring volume,
-Handset volume: Handle output volume,
-Handset mic volume: Handle input volume,
-Speaker volume: Hands-free speaker output volume,
-Speaker mic volume: Hands-free input volume,
-Headset volume: Headphone output volume,
-Headset mic volume: Headset microphone input volume
6.6 View status
If you want to see the phone status,Press MENU button > “view status” ,or press OK button > “view status”, you can see the detail
information of the phone.
If you want to ......
Then......
Network
You can see the network detail information of the phone
Lines
You can see the SIP account
software
It include phone Mode software version kernel version
Upgrade date Running time
Expansion
Can check the expansion, if your phone support this
feature.
6.7 Diagnose
If you want to check the phone hardware function,Press MENU button > “diagnose”,or press OK button > “diagnose”, you can check
the phone item as below.
