FTP-627USL401/402
FTP-627USL401/402
Overview
The FTP-627 USL Series are 24V driven high-speed printers
with a ultra low prole auto cutter and long life.
The FTP-627 USL Series can be used for a variety of applica-
tions, such as POS terminals, ticket vending machines, label
printers, banking terminals, and measurement and medical
equipment.
HiGHLiGHTS
Ultra low prole
Height 108 mm, width 100 mm, depth 94 mm
High speed printing
It can print at 100 mm/s (800 dotlines/s) maximum by using
Fujitsu's unique head drive control.
Windows® 2000/XP, Linux and OPOS drivers
Auto Cutter
Long life and high reliable guilotine with dedicated motor.
Easy paper loading
Our lever platen release mechanism allows a
wide paper route, so 60 mm diameter paper can be easily
inserted.
Multifunctional die-cast frame
Wide operating temperature range, long continuous
printing, high ESD absorbtion and discharge of static
electricity vibration and shock resistant.
Barcodes
Prints standard, extended and 2-D types
RoHS compliant
■
■
•
•
•
•
•
•
•
•
24v drive, reCeiPT PriNTer MiCrO UNiT
2” HiGH SPeed THerMaL PriNTer
FTP-627USL401 platen/cutter closed
FTP-627USL401 platen/cutter open

2
FTP-627USL401/402
nParT NUMberS
* Interface board is the : FTP-627DSL601 (Serial/ USB), FTP-627DSL603 (USB), FTP-627DSL605 (Serial)
nSPeCiFiCaTiONS
Part Number Power
Printer mechanism with cutter and board FTP-627USL401 (USB interface) 5V / 24V
FTP-627USL402 (Serial interface) 5V / 24V
FTP-627USL410 (USB/Serial) 24V only
Length
Interface cables Serial (RS-232) FTP-628Y302 500mm
USB (V.1.1) FTP-629Y301 600mm
Power cables Logic FTP-629Y401 300mm
Head, motor FTP-629Y601 300mm
Part number FTP-627USL401/402
Printing method Thermal-line dot method
Dot structure 432 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 54 mm
Number of columns ANK 36 columns/line (maximum 12 x 24 dot font)
Paper width 58 mm
Paper diameter 60 mm
Paper thickness 60 to 90 µ m (some paper in this range may not be used because
of paper characteristics)
Printing Speed Maximum 100mm/sec. (800 dot line/sec.) at 24V, 25oC
Alphanumeric, kana: 159 types
International characters: 195 types
JIS Kanji (Kanji CG loaded board): about 6800 types
12 × 24 dots, (1.5 × 3.0 mm), 36 columns: ANK
24 × 24 dots, (3.0 × 3.0 mm), 18 columns: ANK
8 × 16 dots, (1.0 × 2.0 mm), 54 columns: ANK
16 × 16 dots, (2.0 × 2.0 mm), 27 columns: ANK
Barcodes UPC-A, UPC-E, JAN (EAN) 13, JAN (EAN) 8, Code 39, 1TF CODABAR
CODE128
QR, Maxi , PDF417
Printing mode Page mode, line mode
SpecicationsItem
Character types
Character, dimensions (W×H), number
of columns
Standard
Extended
2-D

3
FTP-627USL401/402
nSPeCiFiCaTiONS
*+5˚C to +40˚C printing density assurance range.
Item Specication
Iterface Conforms to USB/Serial
Power
supply
For print head 24 VDC average current, 0.5A (0.9A peak)
(print ratio: 12.5%, print speed 100mm/sec.)
For motor 24 VDC ±5%, 0.9 A maximum
For cutter 24 VDC ±5%, 1.1 A maximum
For logic 4.75 to 5.25VDC, 0.2 A maximum
Dimensions Mechanism and board 100 x 94 x 108 mm (WxDxH)
Weight Mechanism and board Approximately 310g
Life Head Pulse durability: 50 million pulses/dot (under our standard
conditions); Abrasion resistance: paper traveling distance
50km (print ratio: 12.5% or less).
Cutter 500,000 cuts (20 cuts/minute)
Platen 5,000 (open/close)
MTBF Mechanism 3,000 hours
Circuit board 500,000 hours
Operating
environment
Operating temperature* 0ºC to +50ºC
Operating humidity 20 to 85% RH (no condensation)
Storage temperature -20ºC to +60ºC (paper not included)
Storage humidity 5 to 95% RH (no condensation)
Detection
function
Head temperature detection Detected by thermistor
Paper out/mark detection Detected by photo-interruptor
Platen release Detected by sliding switch
Recommended thermal sensitive paper High sensitive paper TF50KS-E4 (Nippon paper)
Standard paper TF60KS-E (Nippon paper),
FTP-020PU001 (58mm)
PD105R (Oji paper)
FTP-020P0701 (58mm)
Medium life paper TF60KS-F1 (Nippon paper)
FTP-020P0102 (58mm)
PD170R (Oji paper)
P220VBB-1 (Mitsubishi paper)
Long life paper PD160R (Oji paper)
AFP-235 (Mitsubishi paper)
TP50KJ-R (Nippon paper)
HA220AA (Nippon paper)

4
FTP-627USL401/402
Name Functions Remarks Note
CN1 +24V power supply connector Connection for +24V power supply
CN2 RS-232C Connection for serial interface *2
CN3 USB I/F connector Connection for USB interface *2
CN4 - -
CN5 Cutter connector Connection for paper cutter
CN6 Operation panel connector Connection for operation panel *1
CN7 Near end sensor connector Connection for near end switch
CN8 - -
CN9 Logic power connector Connection for +5V power Supply *1
CN10 Head/motor connector Connection for thermal head & paper feed motor 2-inch, 24 pin
niNTerFaCe, COMMaNd, OPTiONS
nFUNCTiON OF iNTerFaCe bOard
metI metI
.1 noitcnuftnirptseT .8 tcetedelbuortrettuC
.2 noitcetedtuorepaP .9 noitcnufgnivasrewoprotoM
.3 noitceteddneraenrepaP .01 noitcnufnoitcetedkraM
.4 noitcetedneponetalP .11 noitcetedytilamronbanoitarepoUCM
.5 noitcetedytilamronbaerutarepmetdaehlamrehT .21 noitcetorpecneuqesFFO/NOrewoP
.6 noitcetedesuftuo-wolB .31 noitcetorptnerruc-revorotoM
.7 noitcetedytilamronbaegatlovdaeH .41 remiterawdraH
Connectors on Control Board
Note: *1: Option
*2: Depends on P/N

5
FTP-627USL401/402
Note: 1. The cable size and FPC are not included in this drawing.
2. Do not mount anything in the shaded area except the printer.
3. Connect to the body with 2 screws at 2 hooks.
ndiMeNSiONS
1. Printer mechanism
Unit: mm
FTP-627 Unit Paper ø60 *2
2-screw holes *3
(Cross section)
Hook depth 6 *3
86 (paper presenting area)
86 (paper presenting area) Paper

6
FTP-627USL401/402
Command Contents
HT Moves print position to the next tab.
LF Line feed.
FF Feeds forms (new page).
ESC FF Data printing in page printing mode.
ECS RS Sets reverse printing.
ESC US Resets reverse printing.
ESC SP+n Character spacing setting.
ESC ! + n Sets print mode.
ESC $+n1+n2 Absolute position spacing.
ESC % + n External registration character specication/cancellation.
ESC & +y+c1+c2+x+d1to dn External registration character denition.
ESC *+m+n1+n2+d1+dN Sets bit image mode.
ESC - +n Undeline setting.
ESC 2 Sets 1/6 inch line feed length.
ESC 3+n Sets the line feed length.
ESC ? + n External registration character deletion.
ESC @ Printer initialization.
ESC A+n Sets the space between the line.
ESC C+n Sets the page length by character line.
ESC D+d1+dN +NUL Sets the tab position.
ESC E+n Highlighted printing specication/cancellation
ESC J+n Feeds paper in forward direction and prints.
ESC K+n Reverse paper feed.
ESC L Page printing mode selection.
ESC Q+n+!+j Frame overlay function.
ESC R+n Selects international character.
ESC S Line printing mode.
ESC T+n Print direction setting (only page mode).
ESC V+n Right Rotation 90° specication / cancellation.
nCOMMaNdS

7
FTP-627USL401/402
Command Contents
ESC W+X1+X2+1+Y2+dX1+dX2+dX1+dY2 Page printing mode printing area setting.
ESC X+m+n Setting the turning time of the motor excitation.
ESC Y+01h+ESC+x+a+m+d~ Program download.
ESCY+n1+n2 Relative position setting.
ESC a+n Positional alignment.
ESC c+1+n Sets internal processing.
ESC c+5+n Panel switch enable/disable setting.
ESC d+n Printing and n-line feeding.
ESC i Full cut
ESC m Partial cut
ECS s+n Sets printing speed.
ECS t+n Character code table selection.
ESC {+n Sets/resets upside down printing.
ESC DEL+n Flash memory delete.
FS !+n Kanji printing mode collective specication.
FS & Kanji printing mode specication.
FS_+n Kanji underline specication/cancellation.
FS *+ m+n1+n2+d1 to dn High speed collective image printing specied.
FS . Kanji printing mode cancellation.
FS 2+c1+c2+d1 to dn External character denition.
FS 9+n Sets the detection functions.
FS C+n Kanji code system selection.
FS E+n Correction of impressed energy.
FS S+n+n1+n2 Kanji spacing setting.
FS W+n Kanji double height adn width printing specication/cancellation.
FS r+n*1 Parameter transmission.
GS ! + n Character size specication.
Commands continued

8
FTP-627USL401/402
Command Contents
GS $ + n1 + n2 Vertical absolute position specication in page printing mode.
GS & +m + x + y1 + y2 + d1 to dn Registered bit image denition.
GS' + m + n Registered bit image printing.
GS *+x+y1+y2 +d1+dn Registered bit image denition.
GS/ +m Registered bit image printing.
GS < Line feeds to the next mark.
GS A+m+n Sets the line feed length after mark detection.
GS B+m Angle setting of bar code.
GS E+n Sets print quality.
GS H+n HRI character printing position selection.
GS L+n1+n2 Left margin position setting.
GS M+n Printer ID demand.
GS W + n1 + n2 Printing area width setting.
GS Y +n1 + n2 Vertical relative position specication in page printing mode (vertical
direction of characters).
GS e+n+m Sets bar code width.
GS f + n HRI character font selection.
GS h+n Sets bar code height.
y) GS k+m +d1to dk + NUL Bar code printing.
x) GS k+m+n+ d1 to dn
GS k+m+k1+k2+k3+k4+{[p1][d(1,1)] ~ Print of 2Dcode (QR).
[d(1,i)} ~ {[pi][d(i,1)]~[d(i,j)} [00]16
GS k+m+k1+k2+k3+k4+k5+d1~dn Print of 2 Dcode (maxi).
GS k+m+k1+k2+k3+k4+k5+k6+d1~dn Print of 2 Dcode (PDF417).
GS w+n Sets bar code length.
GS C+C+n1+n2+m+fn+b+d1~dn Customize printer.
Commands continued
*1: These commands are valid with FTP-627DSL600 series.

9
FTP-627USL401/402
Japan
Fujitsu Component Limited
Gotanda-Chuo Building
3-5, Higashigotanda 2-chome, Shinagawa-ku
Tokyo 141 8630, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web: www.fcl.fujitsu.com
North and South America
Fujitsu Components America, Inc.
250 E. Caribbean Drive
Sunnyvale, CA 94089 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web: http://us.fujitsu.com/components/
Europe
Fujitsu Components Europe B.V.
Diamantlaan 25
2132 WV Hoofddorp
Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web: emea.fujitsu.com/components/
Asia Pacic
Fujitsu Components Asia Ltd.
102E Pasir Panjang Road
#01-01 Citilink Warehouse Complex
Singapore 118529
Tel: [phone]
Fax: [phone]
Email: [email protected]
Web: http://www.fujitsu.com/sg/services/micro/components/
Fujitsu Components International Headquarter Ofces
©2009 Fujitsu Components America, Inc. All rights reserved. All trademarks or registered trademarks are the property of their respective
owners.
Fujitsu Components America or its afliates do not warrant that the content of datasheet is error free. In a continuing effort to improve our
products Fujitsu Components America, Inc. or its afliates reserve the right to change specications/datasheets without prior notice.
Rev. February 26, 2009.
