Fujitsu M3097G Installation and operation manual

50FH5043E>02
M3097G
IMAGE SCANNER
OEM MANUAL

Specification No.: 50FH5043E
REVISION RECORD
Date published Revised contents
The contents of this manual is subject to change
without prior notice.
All Rights Reserved,
Copyright ”1993, 1996 FUJITSU LIMITED
Edition
01 Apr., 1993
02 Feb., 1996 Gray scale added
i!!

This page is intentionally left blank.
!!ii

CONTENTS
page
CHAPTER 1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $1
1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $1
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $3
1.3 Part Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $4
1.3.1 Exterior view of image scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $4
1.3.2 Functions of each part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $5
CHAPTER 2 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $1
2.1 Function Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $1
2.2 Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $3
2.3 Optional Circuit Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $4
2.3.1 Image processing circuit ¬(IPC ¬) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $4
2.3.1.1 Dynamic threshold function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $4
2.3.1.2 Image processing function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $5
CHAPTER 3 CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $1
3.1 Outer Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $1
3.2 Circuit Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $3
3.3 Operator panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $4
CHAPTER 4 INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $1
4.1 Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $3
4.2 SCSI Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $6
4.2.1 System configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $6
4.2.2 Bus signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $7
4.2.3 Bus signal drive conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $8
4.3 Bus Phases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $9
4.3.1 BUS FREE phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $12
4.3.2 ARBITRATION phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $13
4.3.3 SELECTION phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $15
4.3.4 RESELECTION phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $16
4.3.5 INFORMATION TRANSFER phases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $17
iii

4.4 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $20
4.4.1 RESERVE UNIT command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $22
4.4.2 RELEASE UNIT command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $24
4.4.3 INQUIRY command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $25
4.4.4 REQUEST SENSE command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $29
4.4.5 SEND DIAGNOSTIC command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $34
4.4.6 TEST UNIT READY command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $36
4.4.7 SET WINDOW command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $37
4.4.8 SET SUBWINDOW command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $56
4.4.9 OBJECT POSITION command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $64
4.4.10 SEND command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $68
4.4.11 READ command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $73
4.4.12 MODE SELECT (6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $79
4.4.13 MODE SENSE (6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $84
4.5 Status: STATUS phase (target Æ initiator) . . . . . . . . . . . . . . . . . . . . . . . . 4 $88
4.6 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $89
4.6.1 ATN detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $89
4.6.2 Message types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $89
4.7 Command Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $97
4.7.1 Initial sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $97
4.7.2 Command sequence to read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $98
4.7.3 READ command sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $99
4.7.3.1 Single READ (without CMP II option: disconnect disabled) . . . . . . . . . . . 4 $99
4.7.3.2 Single READ (with CMP II option: disconnect disabled) . . . . . . . . . . . . . . 4 $100
4.7.3.3 Single READ (with CMP II option: disconnect enabled) . . . . . . . . . . . . . . 4 $101
4.7.3.4 Multiple READ (with CMP II option: disconnect disabled) . . . . . . . . . . . . 4 $102
4.7.3.5 Multiple READ (with CMP II option: disconnect enabled) . . . . . . . . . . . . 4 $103
4.8 Status Transition of Logical Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $105
4.9 Error Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $106
4.10 Items for Specifying Window and Subwindow . . . . . . . . . . . . . . . . . . . . . . . 4 $107
iv

APPENDIX A PAPER SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $1
A.1 Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $2
A.2 Paper Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $3
A.2.1 Paper type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $3
A.2.2 Ream weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $3
A.2.3 Paper quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $3
A.2.4 ADF document feeder capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $4
A.3 Paper Limitations (for ADF Reading Only) . . . . . . . . . . . . . . . . . . . . . . . . . . A $5
A.3.1 Areas that must not be perforated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $5
A.3.2 Reverse unprintable areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $6
A.4 Grounding Color Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $7
A.5 Job Separation Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $8
A.5.1 Shape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $8
A.5.2 Paper conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $8
APPENDIX B ADF SCANNING SPEED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B $1
APPENDIX C DROP>OUT COLOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C $1
C.1 Print Density Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C $1
C.2 Drop>out Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C $2
APPENDIX D DIFFERENCES BETWEEN THE M3097G AND
M3096G IMAGE SCANNERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $1
D.0 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $1
D.1 Enhanced Functions and Functional Differences . . . . . . . . . . . . . . . . . . . . D $2
D.1.1 Functions added . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $3
D.1.1.1 Paper size detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $3
D.1.1.2 Job separation sheet detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $5
D.1.1.3 Error diffusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $8
D.1.1.4 Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $8
D.1.1.5 Gamma correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $8
D.1.1.6 Dynamic threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $9
D.1.1.7 Lamp timer function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $10
D.1.1.8 Added sense code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $10
D.2 Supplement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $11
D.2.1 Unified terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $11
D.2.2 Corrections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $11
v

D.2.3 Notes on compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $12
D.2.3.1 Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $12
D.2.3.2 Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $13
D.2.3.3 Threshold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $13
D.2.3.4 Downloaded dither pattern and Brightness . . . . . . . . . . . . . . . . . . . . . . . . . D $13
D.2.3.5 Simplified DTC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $14
vi

FIGURES
page
1.1 M3097G outer view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $2
1.2 M3097G part names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 $4
3.1 Outer dimensions of M3097G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $2
3.2 Function block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $3
3.3 M3097G operator panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $4
4.1 Pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $5
4.2 Phase sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $10
A.1 Paper size specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $2
A.2 Areas that must not be perforated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $5
A.3 Reverse unprintable areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $6
A.4 Grounding color area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A $7
C.1 Spectrum band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C $2
D.1.1 Command sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $3
vii

TABLES
page
2.1 Function specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $1
2.2 Physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $3
2.3 Image processing function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 $5
3.1 Lamp functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 $4
4.1 SCSI physical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $4
4.2 Bus phases vs. signal drive sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $8
4.3 Method of driving the interface signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $9
4.4 Signal delay times definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $10
4.5 INFORMATION TRANSFER phase type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $17
4.6 Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 $21
D.1.1 Added functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $2
D.1.2 Functional differences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D $2
viii

CHAPTER 1 GENERAL
1.1 General
1.2 Features
1.3 Part Names and Functions
1.1 General
M3097G image scanners produce excellent electronic images from documents using
the high quality optical image scanning technology and output to the host system.
The M3097G can scan a single page (including a page of a book) of a double>letter
size (17 in.¥11 in.) or A3 size (420 mm¥297mm) in maximum on the standard flat>
bed. The M3097G has an Automatic Document Feeder (ADF) that can
accommodate up to 100 pages.
The M3097G outputs only binary data on the Small Computer System Interface
(SCSI).
Figure 1.1 shows outer view of this scanner.
1 $1

Figure 1.1 M3097G outer view
1 $2

1.2 Features
(1) Fast reading
This scanner can read data about twice as fast as the M3096G.
For flatbed reading: 1.3 seconds (A4, 200 dpi) (M3096G: 2.3 seconds)
For ADF reading: 36 pages per minute (A4, 200 dpi) (M3096G: 18 pages per
minute)
(2) Large>capacity document feeder
Up to 100 pages (A4, 55>kg continuous forms) can be loaded into the document
feeder. (M3096G: Up to 50 pages)
(3) High>quality image
This scanner uses a compact optical system that provides sharper focus.
Furthermore, the use of new LSI chips produces finer images.
(4) New image processing
The standard version of this scanner has error diffusion function. Dithering or error
diffusion can be applied to those areas judged to be photographs by automatic
separation (image processing ¬option).
(5) Compact
This scanner is small and light. (Its size is almost the same as that of the M3096G)
1 $3

1.3 Part Names and Functions
This section shows the exterior view of image scanner. This section also provides
names of each part and describes their functions.
1.3.1 Exterior view of image scanner
The image scanner can read a document of A3 or double>letter size at maximum.
Figure 1.2 M3097G part names
a a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a a
Document cover
a a a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a a a
Automatic document
feeder (ADF)
a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a
Document
holding pad
a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a
Document
bed
a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a
Power switch
a a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a a
Operator panel
a a a a a a a a a a a a
a
a a a a a a a a a a
a
a
a a a a a a a a a a
a
a a a a a a a a a a a a
Stacker
a a a a a a a a a a a a a a
a
a a a a a a a a a a a a
a
a
a a a a a a a a a a a a
a
a a a a a a a a a a a a a a
Extension
a a a a a a a a a a a a a
a
a a a a a a a a a a a
a
a
a a a a a a a a a a a
a
a
a a a a a a a a a a a
a
a a a a a a a a a a a a a
Extension
a a a a a a a a a a a a a a a a a a a a a a a
a a a a a a a a a a a a a a a a a a a a a a a
a a a a a a a a a a a a a a a a a a a a a a a
a a a a a a a a a a a a a a a a a a a a a a a
ADF paper chute
a a a a a a a a a a a a a a a
a a a a a a a a a a a a a a a
a a a a a a a a a a a a a a a
a a a a a a a a a a a a a a a
ADF lever
a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a
Power inlet
a a a a a a a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a a a a a
a
a
a a a a a a a a a a a a a a a a a a a a a a a a
a
a a a a a a a a a a a a a a a a a a a a a a a a a a
Interface connectors
1 $4

1.3.2 Functions of each part
Document cover: Closed over and holds a document to be read.
Document bed: A document to be read is placed on the bed also
called Flatbed (FB).
Document holding pad: Presses a document to the document bed.
Automatic document feeder (ADF):
Automatically feeds documents to the reading
position.
Stacker: Stacks the read documents.
Extension: Keeps the stacked documents from overhanging.
Power switch: Turns the power on or off.
Operator panel: Used to control image scanner operations. See the
next section for details of the functions.
ADF paper chute: Holds the documents to be fed by the automatic
document feeder.
ADF lever: Opens or closes the automatic document feeder to
remove documents jammed in the feeder.
Power inlet: To be connected to an AC power outlet with the
power cable.
Interface connectors: To be connected to the host system with interface
cables.
1 $5

This page is intentionally left blank.
1 $6

CHAPTER 2 SPECIFICATIONS
2.1 Function Specifications
2.2 Physical Specifications
2.3 Optional Circuit Feature
2.1 Function Specifications
Table 2.1 Function specifications (1/2)
Technology
Item
Resolution
Gray scale
Scanning speed
SCSI>II
Document size
Light source
Flatbed+ ADF (automatic document feeder)
Interface
256 steps
CCD image sensor
Flatbed
No. Specification
1
2
3
Operating method
ADF
MAX 297 ¥ 432 mm
MAX 297 ¥ 432 mm
MIN 105 ¥ 148 mm
4 Green fluorescent lamp
5 ADF capacity MAX 100 (55 kg/continuous forms, A4 paper)
6 Horizontal scanning 400 dpi
Vertical scanning 400, 300, 240, 200 dpi
7
8
9 A4/200 dpi: 1.3 s
A3/400 dpi: 3.7 s
Output resolution Standard10
If the image
processing ¬
option is
installed
400, 300, 240, 200 dpi
(For horizontal scanning and vertical
scanning)
50 dpi to 1600 dpi
(Horizontal scanning and vertical
scanning are independent.)
2 $1

Table 2.1 Functional specifications (2/2)
No. Item Specification
11
12
13
Binarization and
halftone function
Compression
Image memory
Standard
processing II
option
installed
Standard
CMP II option
installed
Standard
CMP II option
installed
Fixed binarization (Line art)
Dither (Halftone)
Error diffusion (Halftone)
Automatic separation
Image emphasis
Outline extraction
Mirror image
Reverse image
Simplified dynamic threshold
Dynamic threshold
Smoothing
Filtering
Noise removing
Non
MH, MR, or MMR
Non
4 MB
2 $2

2.2 Physical Specifications
Table 2.2 Physical specifications
ItemNo.
Power
requirements
Voltage (VAC) 100 to 120, 220 to 240 VAC ±10%
SinglePhase
Frequency 50/60 Hz +2% -4%
Power consumption (VA) 150 or less
Temperature
(∞C)
Operating 5 to 35
Nonoperating -20 to +60
Relative
humidity (%)
Vibration (G)
Dimensions
(mm)
Height
Width
Depth
173
Weight (kg)
1
Specification
696
497
2 25
3
4
5 Surge current (A) 30 or less
6 Momentary power failure 100% 0.5 Hz
7 Leakage current (mA) 1 or less
8 Dielectric strength AC 1 KV or more for one minute or more
(between FG and AG lines)
AC line noise9 Voltage 1.2 KV pulse duration 5 os
10
11 Operating 20 to 80 (no condensation)
Nonoperating 8 to 95 (no condensation)
Operating 0.2
Nonoperating 0.4
12
Indication (%) Operating 5
Nonoperating 10
13
ESD (KV) 8 or more14
Acoustic
noise (dBA)
Operating 53 or less (ISO DIS 9296)
Nonoperating 40 or less (ISO DIS 9296)
15
2 $3

2.3 Optional Circuit Feature
The following option is provided for this scanner:
fImage processing circuit ¬(M3097E0191)
For the details, refer to Subsection 2.3.1.
fCMP II (M3097G0196)
2.3.1 Image processing circuit ¬(IPC ¬)
This option has the dynamic threshold function and image processing function.
2.3.1.1 Dynamic threshold function
The main purpose of this function is to read handwritten characters.
Handwritten character recognition preprocessing invalues specifying required
values for threshold curve setting, smoothing mode, and filtering mode.
Noise removal reduces noise often found in images after dynamic threshold
processing.
Threshold curve setting, smoothing mode, filtering mode, and noise removal are all
dynamic threshold circuit (DTC) functions.
(1) Threshold curve setting
The contrast level of the dynamic threshold circuit can be changed with setting 3
bits (8 levels).
(2) Smoothing mode
The convex portion of the segment is removed and the concave portion is filled up to
smooth the segment.
(3) Filtering mode
(a) Ball>point pen mode
This mode is used when this scanner is used as the input device of OCR system.
When using writing materials caused inter>ommission, e.g. ball>point pen, the
density of the omission portion is increased according to the density of
surrounding portion to get the picture does not have inter>omission.
(b) Normal mode
This mode is used when using writing materials other than above.
(4) Noise removal
Among black>dots in the binary picture code, the black>dot for the noise is changed
to white>dot.
2 $4

2.3.1.2 Image processing function
Table 2.3 Image processing function
No. Function name Details function
1 Automatic separation
Line>drawing/Photo
( )
automatic separation
Recognizes the photo area and Line>drawing
area in one scanning automatically, and outputs
data with applying dither processing or error
diffusion for the photo and the binarizing for the
line>drawing.
2 Outline extraction Extracts the outline of the Line>drawing such as
a thick character.
3 Image emphasis Emphasizes the black>white contrast to raise the
contrast.
4 Overlay (*1) Overlays the pattern on the scanned data and
make the overlayed black data to white data.
5 Reverse image
(White/black conversion)
Converts white into black and black into white
of read data (binary data).
6 Mirror image Turns over the both sides of read data.
7 Simplified dynamic
threshold
Changes the slice level of the binarizing
according to the density of the document.
8 Zooming Magnifies or reduces the image data in the range
between 25% and 400% with 1% step.
9 Subwindow 4 Subwindow can be specified on Main window.
The functions above are all image processing circuit (IPC) functions.
*1 M3097G does not support overlay function.
2 $5
