Fujitsu PRIMEQUEST 2800B3 User manual

System Configuration Guide
PRIMEQUEST 2800B3
PRIMEQUEST 2800B3
System Configuration Guide
Contents
1. Overview
2. Base Unit
3. System Board (SB)
4. CPU
5. Memory
6. I/O Unit
7. Disk Unit (DU)
8. HDD/SSD in Disk Unit
9. PSU for Base Unit, Power Cord for Base Unit
10. PCI Card
11. Rack Installation
12. Maximum Quantity of PCIe Cards
13. Available OS
Change Report
July 2017
FUJITSU Server PRIMEQUEST 1 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Front side
Rear side
1. Overview
I/O Unit (1GbE) or
I/O Unit (10GbE)
Power Supply Unit or Fan
Management Board
System Board
Disk Unit
FUJITSU Server PRIMEQUEST 2 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Part Number Legend:
Part Number:
MC-****** is a Build-to-Order (BTO) option to be assembled with a Base Unit
at Fujitsu factory.
MCX****** is an option to be shipped separately from a Base Unit
(Loose Delivery)
PQ2800E Spec
=
1. Overview
RAID
カード
RAID
カード
RAID
カード
RAID
カード
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN
port
I/O Unit #2
PCI Slot
LAN
port
I/O Unit #1
PCI Slot
LAN
Port
I/O Unit #3
PCI Slot
LAN
Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory Memory
Memory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
Model
PRIMEQUEST 2800B3
CPU
E7-8800 v4 series
Max CPU / Cores
8 / 192
Max Memory Slots
192
Max Memory Capacity
24TB (special release)
Max System Board
4
Reserved SB
No
Max Physical Partition
1
Dynamic Reconfiguration
No
SAS Drive Slots
8
(Internal)
Max SAS Drive Capacity
(Internal)
14.4TB
(with 1.8TB HDD per slot)
Max I/O Units
4
Max 1GbE ports on 4 x
I/O Units (Low Profile)
8
Max 10GbE ports on 4 x
I/O Units (Full Height)
Max PCI-Box
-
PCIe Slots
( Internal)
16
Input Voltage (AC)
200-240V
Highest Operating
Temperature
35 °C
FUJITSU Server PRIMEQUEST 3 / 28

System Configuration Guide
PRIMEQUEST 2800B3
PRIMEQUEST 2800B3 Base Unit
MCH3AC111B
- Rack mount type
- Min. 1 x System Board needs to be mounted. Max. 4 x SystemBoards can be mounted.
- Min. 1 x I/O Unit needs to be mounted. Max. 4 x I/O Units can be mounted.
- 1 x MMB is included.
- 4 x LAN ports per MMB
- Min. 3 x PSUs need to be mounted.
- Fan units need to be mounted in empty space of PSU/Fan bay where PSU is not mounted.
6 x PSUs and/or Fans need to be mounted in total.
- Power cords need to be ordered. The quantity is equal to the quantity of PSU.
- Rack space : 10U
System Board
2. Base Unit
RAID
カード
RAID
カード
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN
port
I/O Unit #2
PCI Slot
LAN
port
I/O Unit #1
PCISlot
LAN
Port
I/O Unit #3
PCI Slot
LAN
Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
The following options are NOT included in the Base Unit.
- System Board, CPU, Memory, I/O Unit, PSU and Power Cord
The following options are included in the Base Unit.
- 1x Management Board (MMB)
- 1x Rack Mount Kit
Supported100BASE-TX/ 10BASE-TMaintenannce port
Supported100BASE-TX/ 10BASE-TREMCS port
Supported
1000BASE-T/ 100BASE-TX/ 10BASE-T
User port
Automatic negotiation functionEthernet standardInterface
The Interfaces per Management Board (MMB)
FUJITSU Server PRIMEQUEST 4 / 28

System Configuration Guide
PRIMEQUEST 2800B3
System Board for 2800B3
MC-3HSB91B / MCX3HSB91B (LD)
- Min. 1 x SB needs to be mounted. Max. 4 x SB can be mounted per Base Unit.
- The System Board does not include a security chip called TPM.
- Neither CPU nor Memory is included. CPU and Memory need to be ordered separately.
Min. 1 x CPU and 1 x Memory need to be mounted on each SB.
- If 1 x CPU is mounted on a SB, min. 1 x Memory (2 x DIMMs) need to be mounted.
Max. 12 x Memory (24 x DIMMs) per CPU can be mounted.
- If 2 x CPUs are mounted on a SB, min. 2 x Memory (4 x DIMMs) need to be mounted.
Max. 24 x Memory (48 x DIMMs) can be mounted.
TPM module V1.2
MC-6HTP11 / MCX6HTP11(LD)
- Available except for China
TPM module V2.0
MC-6HTP21 / MCX6HTP21(LD)
- Available except for China
CPU
3. System Board
RAID
カード
RAID
カード
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlot
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
FUJITSU Server PRIMEQUEST 5 / 28

System Configuration Guide
PRIMEQUEST 2800B3
CPU Module Xeon E7-8894v4
2.4GHz / 60MB LLC / 24 cores
MC-3BEJ21B / MCX3BEJ21B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8893v4
3.2GHz / 60MB LLC / 4 cores
MC-3BED11B / MCX3BED11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8891v4
2.8GHz / 60MB LLC / 10cores
MC-3BEG11B / MCX3BEG11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8890v4
2.2GHz / 60MB LLC / 24cores
MC-3BEA11B / MCX3BEA11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8880v4
2.2GHz / 55MB LLC / 22 cores
MC-3BEE11B / MCX3BEE11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8870v4
2.1GHz / 50MB LLC / 20 cores
MC-3BEF11B / MCX3BEF11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8867v4
2.4GHz / 45MB LLC / 18 cores
MC-3BEC11B / MCX3BEC11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8860v4
2.2GHz / 45MB LLC / 18 cores
MC-3BEB11B / MCX3BEB11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
CPU Module Xeon E7-8855v4
2.1GHz / 35MB LLC / 14 cores
MC-3BEK11B / MCX3BEK11B (LD)
- Max. 2 x CPUs per System Board. Min. 1 x CPU per System Board
Memory
4. CPU
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlot
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
CPU mounting condition:
- The same kind of CPUs need to be mounted in a Base Unit.
FUJITSU Server PRIMEQUEST 6 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Memory Expansion Board
MC-3HMB31B / MCX3HMB31B (LD)
- 1 x Memory Expansion Board can be mounted per CPU.
- 1 x Memory Expansion Board has 12 DIMM slots.
* Conditions to mount Memory Expansion Boaｒd depend on
the number of DIMM to be mounted and a Memory Mode.
For details, please refer to "Memory Mounting".
16GB memory (8GB DDR4 DIMM x 2)
MC-3CD521B / MCX3CD521B (LD)
- Min. 1 x Memory (2 x DIMMs) needs to be mounted per CPU.
Max. 12 x Memory (24 x DIMMs) can be mounted per CPU.
- 2 x 8GB 2400MHz RDIMMs
32GB memory (16GB DDR4 DIMM x 2) Single Rank x4
MC-3CD621B / MCX3CD621B (LD)
- Min. 1 x Memory (2 x DIMMs) needs to be mounted per CPU.
Max. 12 x Memory (24 x DIMMs) can be mounted per CPU.
- 2 x 16GB 2400MHz RDIMMs
32GB memory (16GB DDR4 DIMM x 2) Dual Rank x4
MC-3CD631B / MCX3CD631B (LD)
- Min. 1 x Memory (2 x DIMMs) needs to be mounted per CPU.
Max. 12 x Memory (24 x DIMMs) can be mounted per CPU.
- 2 x 16GB 2400MHz RDIMMs
* long lead time option
64GB memory (32GB DDR4 DIMM x 2)
MC-3CD731B / MCX3CD731B (LD)
- Min 1 x Memory (2 x DIMMs) needs to be mounted per CPU.
Max 12 x Memory (24 x DIMMs) can be mounted per CPU.
- 2 x 32GB 2400MHz RDIMM
128GB memory (64GB DDR4 DIMM x 2)
MC-3CD811B / MCX3CD811B (LD)
- Min. 1 x Memory (2 x DIMMs) needs to be mounted per CPU.
Max. 12 x Memory (24 x DIMMs) can be mounted per CPU.
- 2 x 64GB 2133MHz LRDIMMs
256GB memory (128GB DDR4 LRDIMM x 2)
MC-3CD911B / MCX3CD911B (LD)
- Min. 1 x Memory (2 x DIMMs) needs to be mounted per CPU.
Max. 12 x Memory (24 x DIMMs) can be mounted per CPU.
- 2 x 128GB 2400MHz LRDIMMs
* long lead time option
Memory Mode
5. Memory
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlot
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
At least one option needs to be mounted.
RAID
card
RAID
card
FUJITSU Server PRIMEQUEST 7 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Memory Mode
Memory Mode Setting (Normal)
MC-0PMM1
Memory Mode Setting (Mirror)
MC-0PMM3
Memory Mode Setting (Spare)
MC-0PMM4
Memory Mounting Condition
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlot
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
card
RAID
card
Option
FUJITSU Server PRIMEQUEST 8 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Memory Mounting Condition
1. Memory and Memory Expansion Board
(1) Memory for PRIMEQUEST is composed of 2 x DIMMs.
(2) 6 sets (12 x DIMMs) can be mounted per CPU on System Board and 6 sets (12 x DIMMs) can be mounted on Memory Expansion Board.
(3) Combination of Memory Mode, number of Memory and necessity of Memory Expansion Board is shown below.
Please order Memory Expansion Board referring the following chart.
Combination of Memory Mode, number of Memory and Memory Expansion Board
1 (2)
2 (4) or more
1 (2) or 2 (4)
3 (6) or more
1 (2), 2 (4) or 3 (6)
4 (8) or more
2. Memory Mounting Conditions
(1) Mixture of different type of Memory is not allowed in a single Base Unit.
The exception is a combination of 16GB Memory (2 x 8GB RDIMM) and 32GB Memory (2 x 16GB RDIMM), which is allowed to mix in a single Base Unit.
(2) Unit of memory expansion: 1 set (2 x DIMMs) for Normal Mode, 2 sets (4 x DIMMs) for Mirror Mode and 3 sets (6 x DIMMs) for Spare Mode.
Memory Mounting (1) or Memory Mounting (2)
In case none of the 2 conditions below is applicable, please see "Memory Mounting (1)".
In case any of the 2 conditions below is applicable, please see "Memory Mounting (2)".
The conditions are:
- In a single Base Unit, total 4 x System Boards (SBs) are mounted.
- Address Range Mirror is enabled.
Memory Expansion Board
Normal Mode
Mirror Mode
Spare Mode
Memory Mode
Quantity of Memory (Quantity of DIMM)
Not Necessary
Necessary
Not Necessary
Necessary
Not Necessary
Necessary
Memory slots on
Memory Expansion
Board
CPU #0
System Board
Memory Expansion Board
DIMM #0C0
DIMM #0C1
DIMM #0C2
DIMM #0C3
DIMM #0C4
DIMM #0C5
DIMM #0D0
DIMM #0D1
DIMM #0D2
DIMM #0D3
DIMM #0D4
DIMM #0D5
DIMM #0A0
DIMM #0A1
DIMM #0A2
DIMM #0A3
DIMM #0A4
DIMM #0A5
DIMM #0B0
DIMM #0B1
DIMM #0B2
DIMM #0B3
DIMM #0B4
DIMM #0B5
Slots directly on System Board
CPU #1
Memory Expansion Board
DIMM #1C0
DIMM #1C1
DIMM #1C2
DIMM #1C3
DIMM #1C4
DIMM #1C5
DIMM #1D0
DIMM #1D1
DIMM #1D2
DIMM #1D3
DIMM #1D4
DIMM #1D5
DIMM #1A0
DIMM #1A1
DIMM #1A2
DIMM #1A3
DIMM #1A4
DIMM #1A5
DIMM #1B0
DIMM #1B1
DIMM #1B2
DIMM #1B3
DIMM #1B4
DIMM #1B5
Slots directly on System Board
FUJITSU Server PRIMEQUEST 9 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Memory Mounting (1)
DIMM mounting order on System Board
The Memory needs to be mounted from a small number in accordance with the chart below.
2 x CPUs per System Board
CPU#0 CPU#1
0A0 0A3 0B0 0B3 0C0 0C3 0D0 0D3 1A0 1A3 1B0 1B3 1C0 1C3 1D0 1D3
0A1 0A4 0B1 0B4 0C1 0C4 0D1 0D4 1A1 1A4 1B1 1B4 1C1 1C4 1D1 1D4
0A2 0A5 0B2 0B5 0C2 0C5 0D2 0D5 1A2 1A5 1B2 1B5 1C2 1C5 1D2 1D5
1144226611553377
8 8 12 12 10 10 14 14 9 9 13 13 11 11 15 15
16 16 20 20 18 18 22 22 17 17 21 21 19 19 23 23
1111222211113333
4444666655557777
888810 10 10 10 999911 11 11 11
1144226611553377
1144226611553377
1144226611553377
DIMM slots on Memory Expansion Board
Mixed DIMM mounting condition on System Board
In case different type of DIMMs are mounted on the System Board, the DIMMs need to
be mounted in accordance with the following rule.
The same type of DIMMs with the same Product ID need to be mounted in the slots
with the same symbol.
2 x CPUs per System Board
CPU#0 CPU#1
0A0 0A3 0B0 0B3 0C0 0C3 0D0 0D3 1A0 1A3 1B0 1B3 1C0 1C3 1D0 1D3
0A1 0A4 0B1 0B4 0C1 0C4 0D1 0D4 1A1 1A4 1B1 1B4 1C1 1C4 1D1 1D4
0A2 0A5 0B2 0B5 0C2 0C5 0D2 0D5 1A2 1A5 1B2 1B5 1C2 1C5 1D2 1D5
□□○○△△☆☆■■●●▲▲★★
□□○○△△☆☆■■●●▲▲★★
□□○○△△☆☆■■●●▲▲★★
□□□□△△△△■■■■▲▲▲▲
□□□□△△△△■■■■▲▲▲▲
□□□□△△△△■■■■▲▲▲▲
□□○○△△☆☆■■●●▲▲★★
□□○○△△☆☆■■●●▲▲★★
□□○○△△☆☆■■●●▲▲★★
DIMM slots on Memory Expansion Board
Normal
Mirror
Spare
Normal
Mirror
Spare
FUJITSU Server PRIMEQUEST 10 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Memory Mounting (2)
DIMM mounting order on System Board
The memory needs to be mounted from a small number in accordance with the chart below.
2 x CPUs per System Board
CPU#0 CPU#1
0A0 0A3 0B0 0B3 0C0 0C3 0D0 0D3 1A0 1A3 1B0 1B3 1C0 1C3 1D0 1D3
0A1 0A4 0B1 0B4 0C1 0C4 0D1 0D4 1A1 1A4 1B1 1B4 1C1 1C4 1D1 1D4
0A2 0A5 0B2 0B5 0C2 0C5 0D2 0D5 1A2 1A5 1B2 1B5 1C2 1C5 1D2 1D5
Normal 1122112211221122
3344334433443344
5566556655665566
Mirror 1111111111111111
2222222222222222
3333333333333333
Spare 1122112211221122
1122112211221122
1122112211221122
DIMM slots on Memory Expansion Board
DIMM mixed mounting condition on System Board
In case different type of DIMMs are mounted on the System Board, the DIMMs need to
be mounted in accordance with the following rule.
The same type of DIMMs with the same Product ID need to be mounted in the slots
with the same symbol.
2 x CPUs per System Board
CPU#0 CPU#1
0A0 0A3 0B0 0B3 0C0 0C3 0D0 0D3 1A0 1A3 1B0 1B3 1C0 1C3 1D0 1D3
0A1 0A4 0B1 0B4 0C1 0C4 0D1 0D4 1A1 1A4 1B1 1B4 1C1 1C4 1D1 1D4
0A2 0A5 0B2 0B5 0C2 0C5 0D2 0D5 1A2 1A5 1B2 1B5 1C2 1C5 1D2 1D5
Normal
□□○○□□○○□□○○□□○○
□□○○□□○○□□○○□□○○
□□○○□□○○□□○○□□○○
Mirror
□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□
□□□□□□□□□□□□□□□□
Spare
□□○○□□○○□□○○□□○○
□□○○□□○○□□○○□□○○
□□○○□□○○□□○○□□○○
DIMM slots on Memory Expansion Board
FUJITSU Server PRIMEQUEST 11 / 28

System Configuration Guide
PRIMEQUEST 2800B3
I/O Unit (1GbE)
MC-3HUX31B / MCX3HUX31B (LD)
- Min. 1 x I/O Unit needs to be mounted.
- Max. 4 x I/O Units can be mounted.
- 2 x LAN ports for 1GbE per I/O unit.
- 4 x PCIe slots (Low Profile) per I/O Unit.
- PCIe slots in I/O Unit are not hot pluggable.
I/O Unit (10GbE)
MC-3HUX41B / MCX3HUX41B (LD)
- Min. 1 x I/O Unit needs to be mounted.
- Max. 4 x I/O Units can be mounted.
- 2 x LAN ports for 10GbE per I/O unit.
- 3 x PCIe slots (1 x Low Profile, 2 x Full Height) per I/O Unit.
- PCIe slots in I/O unit are not hot pluggable.
Disk Unit
6. I/O Unit
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN
port
I/O Unit #2
PCI Slot
LAN
port
I/O Unit #1
PCISlot
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
Min. 1 x I/O Unit needs to be mounted for either 1GbE or 10GbE.
FUJITSU Server PRIMEQUEST 12 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Disk Unit
MC-5HDU21B / MCX5HDU21B (LD)
- Max. 2 x Disk Unit per Base Unit
- Min. 1 x RAID Controller cards per Disk Unit needs to be mounted.
- Max. 2 x RAID Controller cards per Disk Unit can be mounted.
- Max. 4 x HDD/SSD can be mounted in case 1 x RAID Controller card is
mounted.
- Max. 2 x HDD/SSD can be mounted per RAID Controller card in case
2 x RAID Controller cards are mounted.
SAS RAID Controller Card
MC-0JSR51 / MCX0JSR51 (LD)
- 1 x RAID Controller can connect max. 4 x disk drives such as
HDD and SSD.
- 1 x Flash Backup Unit can be mounted.
- Data transfer speed: SAS 12Gbps. Cache memory: 2GB
- RAID 0/1/1E/5/6/10 and hot spare supported
RAID Advanced Software Options
MC-0KLA31 / MCX0KLA31 (LD)
- License Activation Key for MegaRAID
CacheCade 2.0
Flash Back-up Unit
MC-0JFB31 / MCX0JFB31 (LD)
- Flash Backup Unit for RAID Controller
with cache memory
Internal HDD in Disk Unit
7. Disk Unit
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlots
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
FUJITSU Server PRIMEQUEST 13 / 28

System Configuration Guide
PRIMEQUEST 2800B3
8. Internal HDD in Disk Unit
300GB Internal Hard Disk Drive (15,000rpm)
MC-5DS751 / MCX5DS751 (LD)
- 12Gbps, hot plug, 512n format
300GB Internal Hard Disk Drive (10,000rpm)
MC-5DS761 / MCX5DS761 (LD)
- 12Gbps, hot plug, 512n format
600GB Inetrnal Hard Disk Drive (15,000rpm)
MC-5DS931 / MCX5DS931 (LD)
- 12Gbps, hot plug, 512n format
600GB Internal Hard Disk Drive (10,000rpm)
MC-5DS951 / MCX5DS951 (LD)
- 12Gbps, hot plug, 512n format
900GB Internal Hard Disk Drive (10,000rpm)
MC-5DSA41 / MCX5DSA41 (LD)
- 12Gbps, hot plug, 512n format
1.2TB Internal Hard Disk Drive (10,000rpm)
MC-5DSB31 / MCX5DSB31 (LD)
- 12Gbps, hot plug, 512n format
1.8TB Internal Hard Disk Drive (10,000rpm)
MC-5DSC11 / MCX5DSC11 (LD)
- 12Gbps, hot plug, 512e format
Internal SSD in Disk Unit
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlots
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
CARD
RAID
card
SAS RAID Controller Card is neccesary to mount internal HDD.
FUJITSU Server PRIMEQUEST 14 / 28

System Configuration Guide
PRIMEQUEST 2800B3
8. Internal SSD in Disk Unit
400GB Internal SAS SSD
MC-5DK861 / MCX5DK861 (LD)
- 12Gbps, MLC, hot plug, DWPD: 10 times
800GB Internal SAS SSD
MC-5DK941 / MCX5DK941 (LD)
- 12Gbps, MLC, hot plug, DWPD: 10 times
1.6TB Internal SAS SSD
MC-5DKA41 / MCX5DKA41 (LD)
- 12Gbps, MLC, hot plug, DWPD: 10 times
PSU for Base Unit
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlots
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
CARD
RAID
card
SAS RAID Controller Card is neccesary to mount internal SSD.
FUJITSU Server PRIMEQUEST 15 / 28

System Configuration Guide
PRIMEQUEST 2800B3
9. PSU for Base Unit
200V High Efficiency PSU
MC-5HPS41 / MCX5HPS41 (LD)
- Min 3 - Max. 6 units per Base Unit
- 80PLUS® Platinum certified
200V Normal PSU
MC-5HPS61 / MCX5HPS61 (LD)
- Min 3 - Max. 6 units per Base Unit
- 80PLUS® Sliver certified
Fan unit
MC-5HFA41 / MCX5HFA41 (LD)
- Fan unit x 1
Power Cords for Base Unit
PSU Fan Power cord
Not redundant 33 3 3
AC 200V redundant (*1)
4 (3＋1) 4 2 4
Dual redundant (*2) 6 (3×2) 6 0
6
(*1) Single power feed configuration will help to supply power even in the event of PSU failure.
(*2) Dual power feed configuration will help to supply power even in the event of one Power feed failure or PSU failure.
Single
Required quantity
Input voltage
Power feed
Redundancy
# of PSU
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlots
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
Total number of PSUs and Fans to be mounted needs to be six.
Fans need to be mounted for PSU slots for cooling if they are unoccupied.
FUJITSU Server PRIMEQUEST 16 / 28

System Configuration Guide
PRIMEQUEST 2800B3
9. Power Cords for Base Unit for APAC and Americas
200V IEC Power Cord (3m)
MC-0HCA83
- IEC60320 C20, 3m
- Power Cord x 1
- 1 x piece per PSU
200V IEC Power Cord (1m)
MC-0HCA81
- IEC60320 C20, 1m
- Power Cord x 1
- 1 x piece per PSU
PCI Card
MMB #0 PSU/
FAN #0
PSU/
FAN #1
PSU/
FAN #2
PSU/
FAN #3
PSU/
FAN #4
PSU/
FAN #5
I/O Unit #0
PCI Slot
LAN port
I/O Unit #2
PCI Slot
LAN port
I/O Unit #1
PCISlots
LAN Port
I/O Unit #3
PCI Slot
LAN Port
Disk Unit #0
HDD
RAID
Card
Disk Unit #1
HDD
RAID
Card
SB #2
CPUCPU
Memory
Memory
SB #1
CPUCPU
SB #3
CPUCPU
Memory MemoryMemory Memory
SB #0
CPUCPU
Memory
Memory
RAID
Card
RAID
Card
The same quantity of Power Cords need to be ordered as that of PSU.
FUJITSU Server PRIMEQUEST 17 / 28

System Configuration Guide
PRIMEQUEST 2800B3
9. Power Cords for Base Unit for EMEA & India
you need one cable for each PSU
S26361-F3151-E301 T26139-Y3850-E10
Power Cord 16A No powercord as
IEC320 C19->C20, 3.5m order option
No mix of different power cords is possible.
S26361-F3151-E100 S26361-F3151-E200 S26361-F3151-E500 S26361-F3151-E10
Power cord 16A Power cord 16A Power cord Power Cord 16A
IEC320 C19->CEE 7/7 IEC320 C19->16A CEE Blue IEC320 C19 -> US NEMA L6-20p IEC320 C19->C20 1 m
PCI Card
Base Unit Power Cords
End
FUJITSU Server PRIMEQUEST 18 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Single Channel 8Gbps Fibre Channel Card
MC-0JFC31 / MCX0JFC31 (LD)
- LPe1250, Low Profile
Single Channel 8Gbps Fibre Channel Card
MC-0JFC91 / MCX0JFC91 ( LD)
-LPe1250, Full Height
Dual Channel 8Gbps Fibre Channel Card
MC-0JFC41 / MCX0JFC41 (LD)
- LPe12002, Low Profile
Dual Channel 8Gbps Fibre Channel Card
MC-0JFCA1 / MCX0JFCA1 (LD)
- LPe12002, Full Height
Single Channel 16Gbps Fibre Channel Card
MC-0JFC71 / MCX0JFC71 (LD)
- LPe16000, Low Profile
Single Channel 16Gbps Fibre Channel Card
MC-0JFC72
- LPe16000, Full Height
Dual Channel Fibre Channel Card (16Gbps)
MC-0JFC81 / MCX0JFC81 (LD)
- LPe16002, Low Profile
Dual Channel Fibre Channel Card (16Gbps)
MC-0JFC82
- LPe16002, Full Height
Single Channel 8Gbps Fiber Channel Card
MC-0JFC51 / MCX0JFC51 (LD)
- QLE2560, Low Profile
Single Channel 8Gbps Fiber Channel Card
MC-0JFC52
- QLE2560, Full Height
Dual Channel 8Gbps Fiber Channel Card
MC-0JFC61 / MCX0JFC61 (LD)
- QLE2562, Low Profile
Dual Channel 8Gbps Fiber Channel Card
MC-0JFC62
- QLE2562, Full Height
Single Channel 16Gbps Fiber Channel Card
MC-0JFCB1 / MCX0JFCB1 (LD)
- QLE2670, Low Profile
Single Channel 16Gbps Fiber Channel Card
MC-0JFCB2
- QLE2670, Full Height
Dual Channel 16Gbps Fiber Channel Card
MC-0JFCC1 / MCX0JFCC1 (LD)
- QLE2672, Low Profile
Dual Channel 16Gbps Fiber Channel Card
MC-0JFCC2
- QLE2672, Full Height
next page
10. PCI Card
Base Unit
SB
I/O Unit
PCI slot
LAN port
Per Base Unit:
Max. 16 x PCI Cards can be mounted in 4 x I/O Units (1GbE) .
-Per I/O Unit (1GbE) : Max. 4 x PCI cards can be mounted.
-Per I/O Unit (10GbE) : Max. 3 x PCI cards can be mounted.
FUJITSU Server PRIMEQUEST 19 / 28

System Configuration Guide
PRIMEQUEST 2800B3
Dual Channel 1000BASE-T Card
MC-0JGEA1 / MCX0JGEA1 (LD)
- Eth Ctrl 2x 1GbE [Intel® Ethernet Controller I350] Low Profile
Dual Channel 1000BASE-T Card
MC-0JGEA2
- Eth Ctrl 2x 1GbE [Intel® Ethernet Controller I350] Full Height
Quad Channel 1000BASE-T Card
MC-0JGEB1 / MCX0JGEB1 (LD)
- Eth Ctrl 4x 1GbE [Intel® Ethernet Controller I350] Low Profile
Quad Channel 1000BASE-T Card
MC-0JGEB2
- Eth Ctrl 4x 1GbE [Intel® Ethernet Controller I350] Full Height
Dual Channel 10G BASE-T Card
MC-0JXE31 / MCX0JXE31(LD)
- Eth Ctrl 10GBase-T (RJ45) – Intel Twinville based, Low Profile
Dual Channel 10G BASE-T Card
MC-0JXE32
- Eth Ctrl 10GBase-T (RJ45) – Intel Twinville based, Full Height
Dual Channel 10G BASE Card
MC-0JXE41 / MCX0JXE41(LD)
- Eth Ctrl 2x 10Gb SFP+ - SR/DA, PCIe x8, D2755 – Intel Niantic based, Low Profile
Dual Channel 10G BASE Card
MC-0JXE42 / MCX0JXE42
- Eth Ctrl 2x 10Gb SFP+ - SR/DA, PCIe x8, D2755 – Intel Niantic based, Full Height
Dual Channel 10G BASE Card
MC-0JXE61 / MCX0JXE61(LD)
- LAN Ctrl 10Gb 2 Channels based on OCe14102-NX with Low Profile bracket
Dual Channel 10G BASE Card
MC-0JXE62
- LAN Ctrl 10Gb 2 Channels based on OCe14102-NX with Full Height bracket
Dual Channel 10G BASE Card
MC-0JXE71 / MCX0JXE71(LD)
- LAN Ctrl 10Gb 2 Channels based on OCe14102-NT with Low Profile bracket
Dual Channel 10G BASE Card
MC-0JXE72
- LAN Ctrl 10Gb 2 Channels based on OCe14102-NT with Full Height bracket
next page
10. PCI Card
Per Base Unit:
Max. 16 x PCI Cards can be mounted in 4 x I/O Units (1GbE) .
-Per I/O Unit (1GbE) : Max. 4 x PCI cards can be mounted.
-Per I/O Unit (10GbE) : Max. 3 x PCI cards can be mounted.
FUJITSU Server PRIMEQUEST 20 / 28
