Data Sheet
FUJITSU Server PRIMERGY TX140 S1p Mono-Socket
Intel®Xeon®processor server
Expandable SME all-round server
Fujitsu Server PRIMERGY TX Tower Servers are ideal
for use in SMEs or branch ofces. They increase
operational efciency by providing rock solid,
record-breaking, energy efcient performance.
That performance is built on 20-years of
pioneering work in Green IT. As a customer, you
benet from a reduction in your organization’s
environmental impact and lower running costs.
The reliability is proven by testing the machines
through 5000 boot cycles – far more than other
vendors do. PRIMERGY TX servers are also easy
to manage via the PRIMERGY ServerView Suite,
reducing IT admin workload and costs. Plus, tower
to rack conversion kits are available for most TX
systems, ensuring investment protection.
PRIMERGY TX140 S1p
Fujitsu Server PRIMERGY TX140 S1p: the
expandable SME all-rounder. It is ideal for SME or
branch customers looking for a classic le, print,
mail, or database server, with high scalability,
and best availability through optional redundant
power supplies. As the company evolves, so too
does the TX140 S1p. Storing up to 12 TB of data,
the TX140 S1p can easily handle large les. At a
later stage, the TX140 S1p can be included in a
rack cabinet with dedicated storage systems. From
here, customers can fully take advantage of the
extensive connectivity options, Intel® Xeon® E3
series performance, and high serviceability via the
optional front service LAN port. The TX140 S1p: an
excellent long-term investment.

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 2 / 9 www.fujitsu.com/fts
Features & Benefits
Main Features Benefits
The Intel® Xeon® processor E3 family-based platform and Fujitsu’s
engineering capabilities give you excellent performance with low
energy consumption.
High performance and energy efciency
Up to 12 TB of storage possible Whatever you need you can store it: databases, pictures, large
les... storage - no problem!
2x 1Gigabit LAN as standard and 3.5-inch (max. 4) or 2.5-inch
(max. 8) hot-plug hard disks
High availability to keep your business going - non-stop!
Optional tower to rack conversion kit and extensive connectivity
options
The TX140 S1p grows as your company grows, making it an
excellent long-term investment
The onboard remote management controller (iRMC S3), and the
optional service LAN, makes it easier to service your TX140 S1p
High manageability and serviceability - saving you time
Halogen-free printed circuit board For environmentally friendly waste disposal

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 3 / 9 www.fujitsu.com/fts
Technical details
PRIMERGY TX140 S1p
Housing types Tower Tower Tower Tower
Storage drive architecture 3.5-inch 2.5-inch 3.5-inch 2.5-inch
Power supply Standard Standard Hot-plug Hot-plug
Mainboard
Mainboard type D3049
Chipset Intel® C202
Processor quantity and type 1 x Intel® Pentium® processor / Intel® Core™ i3 processor / Intel® Xeon® processor E3-1200v2 product family
Processor Intel® Core™ i3-3220 processor
(2C/4T, 3.30 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Pentium® processor G2120
(2C/2T, 3.10 GHz, TLC: 3 MB, Turbo: No, 1600 MHz, 55 W)
Intel® Xeon® processor E3-1220v2
(4C/4T, 3.10 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1230v2
(4C/8T, 3.30 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1240v2
(4C/8T, 3.40 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1265Lv2
(4C/8T, 2.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 45 W)
Intel® Xeon® processor E3-1270v2
(4C/8T, 3.50 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Intel® Xeon® processor E3-1280v2
(4C/8T, 3.60 GHz, TLC: 8 MB, Turbo: Yes, 1600 MHz, 69 W)
Memory slots 4
Memory slot type DIMM (DDR3) UDIMM
Memory capacity (min. - max.) 2 GB - 32 GB
Memory protection ECC
Memory options 4 GB (1 module(s) 4 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
8 GB (1 module(s) 8 GB) DDR3, unbuffered, ECC, 1600 MHz, PC3-12800, DIMM
Memory modules notes 1600 MHz memory modules
Interfaces
USB 2.0 ports 10
Graphics (15-pin) 1 x VGA
Serial connection 1 x serial RS-232-C, usable for iRMC or system or shared
LAN / Ethernet 2 x Gb/s Ethernet
Management LAN (RJ45) 1 x dedicated management LAN port for iRMC S3 (10/100/1000 Mbit/s)
Management LAN trafc can be switched to shared onboard Gbit LAN port
Onboard or integrated Controller
RAID controller Optionally integrated RAID 0/1 or RAID 5/6 controller for SAS base units (occupies one PCIe slot).
additional RAID controller options are described under Components RAID controller
SATA Controller Intel® C200, 2 ports used for accessible drives
4 port for internal SATA HDDs with RAID 0, 1, 10 for Windows and Linux;
LAN Controller Intel® 82574L + Intel® 82579LM onboard, 2 x 10/100/1000 Mbit/s Ethernet (TCP/IP acceleration), iSCSI and PXE-Boot
via LAN, WoL for Intel® 82574L only.
Remote Management Controller Integrated Remote Management Controller (iRMC S3, 32 MB attached memory incl. graphics controller)
IPMI 2.0 compatible
Trusted Platform Module (TPM) Inneon / 1.2 (option)

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 4 / 9 www.fujitsu.com/fts
Slots
PCI-Express 3.0 x16 1 x
PCI-Express 2.0 x1 (mech. x4) 1 x
PCI-Express 2.0 x4 (mech. x8) 1 x
PCI-slots 1 x PCI 32/33 MHz, 1x long, 5V
Slot Notes In SAS conguration 1x PCI-Express occupied by modular RAID controller.
In congurations with Intel® Core™ i3 or Intel® Pentium® processors slots are operated with PCI-Express 2.0.
Drive bays
Storage drive bays 3.5-inch or 2.5-inch hot-plug SAS/SATA
Accessible drive bays 3 x 5.25/1.6-inch
Notes accessible drives all possible options described in relevant system congurator
Drive bays (Base unit specic)
Storage drive bays Max 4 x 3.5-inch Max 8 x 2.5-inch
Accessible drive bays 3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD 3 x 5.25/1.6-inch for 1 x backup drive + 1 x ODD
General system information
Number of fans 1
Fan conguration 1 standard fan
Fan notes non redundant / non hot-plug
Operating panel
Operating buttons On/off switch
NMI button
Reset button
Status LEDs System status (orange / yellow)
Identication (blue)
Hard disks access (green)
Power (orange / green)
At system rear side:
System status (orange / yellow)
Identication (blue)
LAN connection (green)
LAN speed (green / yellow)
CSS (yellow)
BIOS
BIOS features ROM based setup utility
Recovery BIOS
BIOS settings save and restore
Local BIOS update from USB device
Online update tools for main Windows and Linux versions
Local and remote update via ServerView Update Manager
Remote PXE boot support
Remote iSCSI boot support

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 5 / 9 www.fujitsu.com/fts
Operating Systems and Virtualization Software
Certied or supported operating
systems and virtualization software
Microsoft® Hyper-V Server R2 2012
Microsoft® Windows Server® 2012 R2 Datacenter
Microsoft® Windows Server® 2012 R2 Standard
Microsoft® Windows Server® 2012 R2 Essentials
Microsoft® Windows Server® 2012 R2 Foundation
Microsoft® Windows Storage Server 2012 R2 Standard
Microsoft® Hyper-V Server 2012
Microsoft® Windows Server® 2012 Datacenter
Microsoft® Windows Server® 2012 Standard
Microsoft® Windows Server® 2012 Essentials
Microsoft® Windows Server® 2012 Foundation
Microsoft® Windows Storage Server 2012 Standard
Microsoft® Hyper-V™ Server 2008 R2
Microsoft® Windows Server® 2008 R2 Datacenter
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows Server® 2008 R2 Foundation
Microsoft® Windows® Web Server 2008 R2
Microsoft® Windows® Small Business Server 2011 Premium Add-On
Microsoft® Windows® Small Business Server Standard 2011
Microsoft® Windows® Server 2008 Datacenter
Microsoft® Windows® Server 2008 Enterprise
Microsoft® Windows® Server 2008 Standard
Microsoft® Windows® Web Server 2008
Novell® SUSE Linux Enterprise Server 11
Novell® SUSE Linux Enterprise Server 10
Red Hat® Enterprise Linux 6
Red Hat® Enterprise Linux 5
Operating system release link http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Operating system notes Support of other Linux derivatives on demand
Red Hat® certication starting with version 5.8 / 6.4.
Server Management
Standard ServerView Suite - Deploy
SV Installation Manager
SV Scripting Toolkit
SV Deployment Manager (30-day trial version)
ServerView Suite - Control
SV Operations Manager incl. PDA and ASR & R
(Prefailure and Analysis; Automatic Server Recovery and Restart)
SV Performance Management
SV Power Management
SV RAID Manager
ServerView Suite - Maintain
SV Remote Management (iRMC)
SV Update Management (BIOS, Firmware, Windows Drives and SV Agents)
SV Asset Management
SV Online Diagnostics
ServerView Suite - Integrate
SV Integration packs e.g. for Microsoft System Center, Nagios, HP, SIM, HP NNM, IBM Tivoli, Altiris
Deployment Solutions and others

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 6 / 9 www.fujitsu.com/fts
Server Management
Option ServerView Suite - Deploy
SV Deployment Manager (full version)
ServerView Suite - Maintain
iRMC Advanced Pack incl. Advanced Video Redirection (AVR) and Remote Storage
ServerView Suite - Integrate
SV Integration pack for Fujitsu ManageNow® solution
Server Management notes Regarding Operating System dependencies and product details for ServerView Suite Software Products see dedicated
Product Data sheets.
Dimensions / Weight
Floor-stand (W x D x H) 205 x 584 x 444 mm
Rack (W x D x H) 482 x 570 x 220 mm
Dimension notes Floorstand Width 306 mm with tilt protection; depth measured excludes handles on redundant PSU. Rack depth
excludes handles of redundant PSU and rack front.
Height Unit Rack 5 U
Weight 21-28 kg
Weight notes Actual weight may vary depending on conguration
Rack integration kit Rack integration kit as option
Environmental
Operating ambient temperature 10 - 35 °C
Operating relative humidity 10 - 85 % (non condensing)
Operating environment FTS 04230 – Guideline for Data Center (installation specication)
Operating environment Link http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe
Sound pressure (LpAm) SATA: 25 dB(A) idle mode/ 25 dB(A) operation mode; SAS: 31 dB(A) idle mode/ 33 dB(A) operation mode
Sound power (LWAd; 1B = 10dB) SATA: 4.2 B idle mode/ 4.2 B operation mode ; SAS: 4.9 B idle mode/ 5.1 B operation mode
Noise notes Noise emissions and operation modes depend on system conguration.
Electrical values
Power supply conguration 1x standard, 1x hot-plug or 2x redundant hot-plug
Max. output of single power supply 450 W
Standard power supply output 300 W (90% efciency)
Hot-plug power supply output 450 W (94% efciency)
Hot-plug power supply redundancy Yes
Rated voltage range 100 V - 240 V
Rated frequency range 47 Hz - 63 Hz
Rated current max. 6 A / 3 A (100 V / 240 V)
Active power (max. conguration) 216 W
Active power note To estimate the power consumption of different congurations use the Power Calculator of the System Architect:
http://congurator.ts.fujitsu.com/public/
Apparent power (max. conguration) 247 VA
Heat emission 777.6 kJ/h (737.0 BTU/h)
Power Supply Notes The active power and apparent power values may change according to conguration.
Compliance
Germany GS
Europe CE Class A *
USA/Canada CSA us
ULc/us
FCC Class A
Global CB
RoHS (Restriction of hazardous substances)
WEEE (Waste electrical and electronical equipment)
ENERGY STAR®
Japan VCCI
Russia GOST-R

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 7 / 9 www.fujitsu.com/fts
Components
Storage drives SSD SATA, 6 Gb/s, 200 GB, MLC, hot-plug, 2.5-inch, enterprise
SSD SATA, 6 Gb/s, 100 GB, MLC, hot-plug, 2.5-inch, enterprise
HDD SATA, 320 GB, 5400 rpm, non hot plug, 2.5-inch, economic
HDD SATA, 6 Gb/s, 500 GB, 7200 rpm, hot-plug, 3.5-inch, economic
HDD SATA, 6 Gb/s, 500 GB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 500 GB, 7200 rpm, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 250 GB, 7200 rpm, hot-plug, 3.5-inch, economic
HDD SATA, 6 Gb/s, 250 GB, 7200 rpm, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 3 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 2 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7200 rpm, hot-plug, 2.5-inch, business critical
HDD SAS, 6 Gb/s, 900 GB, 10000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 600 GB, 15000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 6 Gb/s, 600 GB, 10000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 500 GB, 7200 rpm, hot-plug, 2.5-inch, business critical
HDD SAS, 6 Gb/s, 450 GB, 15000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 6 Gb/s, 450 GB, 10000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 300 GB, 15000 rpm, hot-plug, 3.5-inch, enterprise
HDD SAS, 6 Gb/s, 300 GB, 15000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 300 GB, 10000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 146 GB, 15000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 4 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 3 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 2 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 1 TB, 7200 rpm, hot-plug, 3.5-inch, business critical
HDD SAS, 6 Gb/s, 1 TB, 7200 rpm, hot-plug, 2.5-inch, business critical
Backup Drives DDS Gen6, 80 GB, 6 MB/s, half height, USB 2.0
LTO3HH Ultrium, 400 GB, 60 MB/s, half height, SAS 3Gb/s
LTO4HH Ultrium, 800 GB, 120 MB/s, half height, SAS 6Gb/s
LTO5HH Ultrium, 1500 GB, 140 MB/s, half height, SAS 6Gb/s
LTO6HH Ultrium, 2500 GB, 160 MB/s, half height, SAS 6Gb/s
RDX Drive, 320 GB, 500 GB, 1 TB , 25 MB/s, half height, USB 3.0
Compliance
South Korea KC
China CCC
Australia/New Zealand C-Tick
Taiwan BSMI
Compliance notes * Warning:
This is a class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
Compliance link http://globalsp.ts.fujitsu.com/sites/certicates
Global
Compliance link http://globalsp.ts.fujitsu.
com/sites/certicates
http://globalsp.ts.fujitsu.
com/sites/certicates
http://globalsp.ts.fujitsu.
com/sites/certicates
http://globalsp.ts.fujitsu.
com/sites/certicates

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 8 / 9 www.fujitsu.com/fts
Optical drives Blu-ray Disc™ Triple Writer, (6x BD-ROM
; 8x DVD; 24x CD), slimline, SATA I
DVD-ROM, (16xDVD; 48xCD), half height, SATA I
DVD Super Multi, (16xDVD, 8xDVD+RW 6xDVD-RW, 12xDVD-RAM; 48xCD, 32xCD-RW), half height, SATA I
SCSI / SAS Controller SAS Ctrl. 6 Gbit/s 8 ports ext. PCIe Gen2 x8
RAID Controller RAID 5/6 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 5/6 512MB (D2616), 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache, Optional BBU (based on LSI SAS2108)
RAID 5/6 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 1GB (D3116C), 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU (based on LSI SAS2208)
RAID 5/6 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 1GB (D3116), 8 ports int.
RAID level: 0, 1, 10, 5, 50, 6, 60, 1 GB, Optional FBU (based on LSI SAS2208)
RAID 0/1 Ctrl., SAS/SATA 6 Gbit/s, Fujitsu RAID Ctrl SAS 6G 0/1 (D2607), 8 ports int.
RAID level: 0, 1, 10, No BBU support
Integrated RAID 0/1 Ctrl., SAS/SATA 3 Gbit/s, 4 ports int.
RAID level: 0, 1, 1E, No BBU support (based on LSI 1064e)
Communication, Network Ethernet Ctrl. 1 x 1 Gbit/s PCIe x1 ( Intel® )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe x8 ( Fujitsu )
Ethernet Ctrl. 2 x 10 Gbit/s PCIe x8 ( Intel® )
Ethernet Ctrl. 2 x 1 Gbit/s PCIe x4 ( Fujitsu )
Ethernet Ctrl. 4 x 1 Gbit/s PCIe x4 ( Fujitsu )
Graphics add on cards NVIDIA® Quadro® NVS 300, PCIe x1, 2x DVI/VGA
Warranty
Standard Warranty 1 year
Service level Onsite Service (depending on country)
Warranty Terms & Conditions http://support.ts.fujitsu.com/warranty/Index.asp?LNG=COM
Maintenance and Support Services - the perfect extension
Support Pack Options Globally available in major business areas:
9x5, Next Business Day Onsite Response Time
9x5, 4h Onsite Response Time
24x7, 4h Onsite Response Time
Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEA please contact your local Fujitsu partner.
Service Lifecycle 5 years after end of product life
Service Weblink http://www.fujitsu.com/fts/services

Data Sheet FUJITSU Server PRIMERGY TX140 S1p Mono-Socket Intel®Xeon®processor server
Page 9 / 9 www.fujitsu.com/fts
Contact
FUJITSU LIMITED
Website: www.fujitsu.com
2014-01-16 CE-EN
Fujitsu OPTIMIZATION Services
In addition to Fujitsu PRIMERGY TX140 S1p,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Fujitsu Portfolio
Build on industry standards, Fujitsu offers a full
portfolio of IT hardware and software products,
services, solutions and cloud offering, ranging
from clients to datacenter solutions and
includes the broad stack of Business Solutions,
as well as the full stack of Cloud offering. This
allows customers to leverage from alternative
sourcing and delivery models to increase
their business agility and to improve their IT
operation’s reliability.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu PRIMERGY TX140
S1p, please contact your Fujitsu sales
representative or Fujitsu Business partner, or
visit our website.
www.fujitsu.com/fts
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment.
Using our global know-how, we aim to
contribute to the creation of a sustainable
environment for future generations through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see http://www.fujitsu.
com/fts/resources/navigation/terms-of-use.
html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner.
More information
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see http://www.fujitsu.com/fts/resources/navigation/terms-of-use.html
Copyright © Fujitsu Technology Solutions
