Fujitsu PRIMERGY RX200 S6 User manual

Options Guide - English
PRIMERGY RX200 S6 Server
Options Guide
Edition November 2011

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected]ujitsu.com.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2010 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
– The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
– No part of this manual may be reproduced in any form without the prior written permission
of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

RX200 S6 Options Guide
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the product
is used in a hot environment. The customer shall bear the cost of replacing
replaceable components which have exceeded their operating life. Note that
these are only guidelines, and do not constitute a guarantee of trouble-free
operation during the maintenance support period.
High safety use
This product has been designed and manufactured for general uses such as
general office use, personal use, domestic use and normal industrial use. It has
not been designed or manufactured for uses which demand an extremely high
level of safety and carry a direct and serious risk to life or body if such safety
cannot be ensured.

Options Guide RX200 S6
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance control
in weapons systems (hereafter, "high safety use"). Customers should not use
this product for high safety use unless measures are in place for ensuring the
level of safety demanded of such use. Please consult the sales staff of Fujitsu if
intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://primeserver.fujitsu.com/primergy/harddisk/

RX200 S6 Options Guide
Only for the Japanese market:
IAlthough described in this manual, some sections do not apply to the
Japanese market. These options and routines include:
– CSS (Customer Self Service)

Options Guide RX200 S6

RX200 S6 Options Guide
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 9
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10
1.3 Expansions and conversions . . . . . . . . . . . . . . . . . 12
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 14
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 17
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1 Pulling the server out of the rack . . . . . . . . . . . . . . . 26
4.2 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 27
4.3 Removing the air duct . . . . . . . . . . . . . . . . . . . . . 29
5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.1 Memory modules . . . . . . . . . . . . . . . . . . . . . . . . 32
5.2 Expanding the main memory . . . . . . . . . . . . . . . . . 33
6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.1 Installing a second processor . . . . . . . . . . . . . . . . . 36
6.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . 39
6.3 Replacing the heat sink . . . . . . . . . . . . . . . . . . . . 42
7 Accessible drive . . . . . . . . . . . . . . . . . . . . . . . . 43

Contents
7.1 Installing a SATA DVD drive . . . . . . . . . . . . . . . . . . . 44
8 HDD modules . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.1 Installing additional HDD cage . . . . . . . . . . . . . . . . . 48
9 Expansion cards and iBBU . . . . . . . . . . . . . . . . . . . 55
9.1 Installing an expansion card . . . . . . . . . . . . . . . . . . 56
9.2 Installing a modular RAID controller . . . . . . . . . . . . . . 61
9.3 Installing an iBBU . . . . . . . . . . . . . . . . . . . . . . . . 62
10 Further options . . . . . . . . . . . . . . . . . . . . . . . . . 69
10.1 Trusted Platform Module (TPM) . . . . . . . . . . . . . . . . . 69
10.2 USB Flash Module (UFM) . . . . . . . . . . . . . . . . . . . . 71
11 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
11.1 Installing the air duct . . . . . . . . . . . . . . . . . . . . . . 73
11.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 76
12 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
12.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Options Guide RX200 S6

RX200 S6 Options Guide 9
1 Preface
The PRIMERGY RX200 S6 rack server is a universal and high-performance
platform designed for a whole range of application areas in data center and
server farm concepts. The ultra-compact rack server is ideal for web services
and solutions such as caching, gateway and firewall applications. Other
application areas include front-end solutions (tier 1) in modern multi-tier
configurations, and e-mail service and appliance solutions.
The PRIMERGY RX200 S6 offers a balanced architecture that incorporates
next generation main memory (DDR3) and I/O technologies (PCIe Gen2). The
backplane is already provided for SAS 2.0 and 6 Gbit/s SAS and the chipset
prepared for the next generation of 6-core processors. High performance,
scalability, impressive reliability and excellent extension options are combined
in a powerful design.
The Cool-safe™ cooling concept with improved air flow cooling technology
(honeycomb design) ensures the highest possible performance of the
processors at work; at the same time, the system is extremely reliable thanks to
the reduced heat dissipation.
The highly compact server occupies just one height unit (HU) in the rack.
1.1 Concept and target groups
This Options Guide shows you how to extend and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
technical specialists.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.

10 Options Guide RX200 S6
Preface
1.2 Documentation overview
More information on your PRIMERGY RX200 S6 can be found in the following
documents:
– "Quick Start Hardware - PRIMERGY RX200 S6" leaflet
"はじめにお読みください -PRIMERGY RX200 S6" for the Japanese market
(only included as a printed copy)
– "Quick Start Software - Quick Installation Guide" DVD booklet
(only included with the ServerView Suite as a printed copy) except for the
Japanese market
– "Safety notes and other important information" manual
"安全上の注意およびその他の重要情報 " for the Japanese market
– "Warranty" manual
"保証書 " for the Japanese market
– "ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual and "Service Desk" leaflet
"サポート＆サービス " for the Japanese market
– "PRIMERGY RX200 S6 Server Operating Manual"
– "PRIMERGY RX200 S6 Server Options Guide"
– "System Board D3031 for PRIMERGY RX200 S6 Technical Manual"
– "D3031 BIOS Setup Utility for RX200 S6" manual

RX200 S6 Options Guide 11
Preface
IPRIMERGY manuals are available in PDF format on the
ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the
ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289 (the
order number for the Japanese market: please refer to the configurator
of the server http://primeserver.fujitsu.com/primergy/system.html).
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL (for EMEA market):
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.
For the Japanese market please use the URL:
http://primeserver.fujitsu.com/primergy/manual.html.
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

12 Options Guide RX200 S6
Preface
1.3 Expansions and conversions
Main memory
The system board offers 12 slots for memory modules. 6 memory slots can be
used in mono processor configurations.
Second processor
The system board can be upgraded with a second processor. Only processors
of the same type may be used on the system board. The second processor must
have the same clock frequency as the first.
Accessible drive
In the version with a maximum of six HDD modules, a 5.25 inch bay is available
for a DVD drive (SATA interface) with a height of 0.5 inches.
HDD modules
The server can accommodate two further HDD modules instead of the DVD
drive. To do this, you must install a conversion kit consisting of an additional
HDD cage and a HDD backplane for up to 8 HDD modules.
IThe conversion kit is only available for the EMEA market.
Expansion cards in the PCI Express slots
The system board offers two slots with a PCI Express x8 interface and one slot
with a PCI Express x4 interface (exclusively for modular RAID controllers):
Expansion cards can only be installed using three-slot riser cards. The riser
cards provide three slots at a right angle to the system board (two slots for PCIe
controllers and one slot for a RAID controller).
Intelligent Battery Backup Unit
You can add an iBBU (intelligent Battery Backup Unit) to the optional modular
RAID controller to ensure data integrity in the event of a power failure.

RX200 S6 Options Guide 13
Preface
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the BIOS system (for more information, refer to the
“D3031 BIOS Setup Utility for RX200 S6" manual).
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.
USB Flash Module (UFM)
The server can be equipped with a USB Flash Module (UFM).
This module can be used as optional memory for software (e.g. VMware) or as
a software dongle.

14 Options Guide RX200 S6
Preface
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

RX200 S6 Options Guide 15
2Procedure
VCAUTION!
●The actions described in this manual shall be performed by technical
specialists. A technical specialist is a person who is trained to install
the server including hardware and software.
●Repairs to the device that do not relate to CSS failures shall be
performed by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
ÊFirst of all, carefully read the safety instructions in the chapter "Safety
instructions" on page 17.
ÊMake sure that all necessary manuals (see the section "Documentation
overview" on page 10) are available; print the PDF files if required. Most
importantly, you will need the Operating Manual for the server and the
Technical Manual for the system board.
ÊShut the server down correctly, switch it off, disconnect the power cords and
open the server as described in the chapter "Preparation" on page 25.
ÊCarry out the expansion or upgrade of your server as described in the
pertinent chapter.
IInstallation and removal of the hot-plug components are described in
the Operating Manual.
ÊClose the server, connect it to the power outlet, and switch it on as described
in the chapter "Completion" on page 73.
ÊStart the operating system and make the appropriate configuration if
necessary (see the Operating Manual).
IFor the latest information on optional products provided for the RX200 S6
see the configurator of the server:
https://sp.ts.fujitsu.com/dmsp/docs/cnfgrx200s6.pdf
(for the EMEA market)
http://primeserver.fujitsu.com/primergy/system.html
(for the Japanese market)

16Options Guide RX200 S6

RX200 S6 Options Guide 17
3 Safety instructions
IThe following safety instructions are also provided in the manual "Safety
Notes and Regulations".
This device meets the relevant safety regulations for IT equipment. If you have
any questions about whether you can install the server in the intended
environment, please contact your sales outlet or our customer service team.
VCAUTION!
●The actions described in this manual shall be performed by technical
specialists. A technical specialist is a person who is trained to install
the server including hardware and software.
●Repairs to the device that do not relate to CSS failures shall be
performed by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
●Before installing/removing internal options to/from the server, turn off
the server, all peripheral devices, and any other connected devices.
Also unplug all power cords from the power outlet. Failure to do so
can cause electric shock.

18 Options Guide RX200 S6
Safety instructions
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the device.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.
Installation and operation
VCAUTION!
●This unit should not be operated in ambient temperatures above
35 °C.
●If the unit is integrated into an installation that draws power from an
industrial power supply network with an IEC309 connector, the power
supply's fuse protection must comply with the requirements for non-
industrial power supply networks for type A connectors.
●The unit automatically adjusts itself to a mains voltage in a range of
100V - 127V / 200V - 240V. Ensure that the local mains voltage lies
within these limits.
●This device must only be connected to properly grounded power
outlets or insulated sockets of the rack's internal power supply with
tested and approved power cords.
●Ensure that the device is connected to a properly grounded power
outlet close to the device.

RX200 S6 Options Guide 19
Safety instructions
VCAUTION!
●Ensure that the power sockets on the device and the properly
grounded power outlets are freely accessible.
●The On/Off button or the main power switch (if present) does not
isolate the device from the mains power supply. To disconnect it
completely from the mains power supply, unplug all network power
plugs from the properly grounded power outlets.
●Always connect the server and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
the server is still running but a peripheral device (e.g. memory
subsystem) fails during a power outage.
●Data cables must be adequately shielded.
●Ethernet cabling has to comply with EN 50173 and EN 50174-1/2
standards or ISO/IEC 11801 standard respectively. The minimum
requirement is a Category 5 shielded cable for 10/100 Ethernet, or a
Category 5e cable for Gigabit Ethernet.
●Route the cables in such a way that they do not create a potential
hazard (make sure no-one can trip over them) and that they cannot
be damaged. When connecting the server, refer to the relevant
instructions in this manual.
●Never connect or disconnect data transmission lines during a storm
(risk of lightning hazard).
●Make sure that no objects (e.g. jewelry, paperclips etc.) or liquids can
get inside the server (risk of electric shock, short circuit).
●In emergencies (e.g. damaged casing, controls or cables, penetration
of liquids or foreign bodies), switch off the server immediately, remove
all power plugs and contact your sales outlet or customer service
team.

20 Options Guide RX200 S6
Safety instructions
VCAUTION!
●Proper operation of the system (in accordance with IEC 60950-1/2
resp. EN 60950-1/2) is only ensured if the casing is completely
assembled and the rear covers for the installation slots have been
fitted (electric shock, cooling, fire protection, interference
suppression).
●Only install system expansions that satisfy the requirements and
rules governing safety and electromagnetic compatibility and those
relating to telecommunication terminals. If you install other
expansions, they may damage the system or violate the safety
regulations. Information on which system expansions are approved
for installation can be obtained from our customer service center or
your sales outlet.
●The components marked with a warning notice (e.g. lightning symbol)
may only be opened, removed or exchanged by authorized, qualified
personnel. Exception: CSS components can be replaced.
●The warranty is void if the server is damaged during installation or
replacement of system expansions.
●Only set screen resolutions and refresh rates that are specified in the
operating manual for the monitor. Otherwise, you may damage your
monitor. If you are in any doubt, contact your sales outlet or customer
service center.
●Before installing/removing internal options to/from the server, turn off
the server, all peripheral devices, and any other connected devices.
Also unplug all power cords from the outlet. Failure to do so can
cause electric shock.
●Do not damage or modify internal cables or devices. Doing so may
cause a device failure, fire, or electric shock.
●Devices inside the server remain hot after shutdown. Wait for a while
after shutdown before installing or removing internal options.
●The circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Before handling them, first
touch a metal part of the server to discharge static electricity from
your body.
●Do not touch the circuitry on boards or soldered parts. Hold the
metallic areas or the edges of the circuit boards.
