PRIMERGY BX630 S2
Scalable Server-Blade
Service Supplement
Edition December 2007

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.vor
Copyright © 2007 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

BX630 S2 Service Supplement
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Documentation Overview . . . . . . . . . . . . . . . . . . . . 5
1.2 Notational Conventions . . . . . . . . . . . . . . . . . . . . . 7
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Important Notes . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Notes on Safety . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Environmental protection . . . . . . . . . . . . . . . . . . . 15
4 Replacement Routines . . . . . . . . . . . . . . . . . . . . . 17
4.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Replacing the control panel board . . . . . . . . . . . . . . 21
4.3 Replacing processors . . . . . . . . . . . . . . . . . . . . . 23
5 Diagnosis and Maintenance . . . . . . . . . . . . . . . . . . 33
5.1 Server Blade Diagnostic LEDs . . . . . . . . . . . . . . . . 33
5.2 Recovering the Server Blade BIOS . . . . . . . . . . . . . . 35
5.3 Spare Parts and Add-On Modules . . . . . . . . . . . . . . . 38
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.ivz

BX630 S2 Service Supplement 5
1 Preface
The PRIMERGY BX630 2 Scalable Server Blade is an AMD-based server blade
that can be operated in the PRIMERGY BX600 S2 basic unit. It can also be
operated in slots 1-3 and 5-9 of the BX600 S2 basic unit. The PRIMERGY
BX630 2 Scalable Server Blade can be installed as a dual-socket server blade
or in a multi-blade configuration as a quad-socket server blade.
1.1 Documentation Overview
Concept and target groups
This Service Supplement supplements the information contained in the
Operating Manual.
VATTENTION!
The activities described in this manual may only be performed by
specialist personnel with technical training.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
Service DVD
A service DVD is available for service partners of Fujitsu Siemens Computers.
This DVD contains the following manuals in PDF format:
– the “Safety” manual
– the “Ergonomics” manual
– the Operating Manual for PRIMERGY BX630 2
– the Options Guide for PRIMERGY BX630 2
– the documentation for the server blade models available for the
PRIMERGY BX600 S2/S3 basic unit
IThese PDF files can also be downloaded from the Internet free of
charge: At http://manuals.fujitsu-siemens.com you will find an overview
page showing the online documentation available on the Internet. You
can go to the PRIMERGY Server documentation by clicking on industry
standard servers.

6 Service Supplement BX630 S2
Documentation Overview Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k01
Information/Activity Manual
Features and technical data of the server blade Operating Manual
Installation and initial operation, such as:
– Connections to the basic unit
– Operation
– Configuring the server blade
– Firmware update (server blade BIOS and
BMC)
– Installing the server blade in the basic unit
BIOS setup
Troubleshooting
Installing/removing hot-plug components:
– Hard disk modules
Extensions and conversions
– Installing memory modules
– Adding processors
– Installing an optional I/O module
– Replacing the battery
– Upgrading to a quad-socket server blade
Options Guide
Replacement routines
– Replacing the control panel
– Exchanging the processor
Diagnostics
– Diagnostic LEDs
–BIOSrecovery
Spare parts list
Service Supplement
Detailed safety information Safety manual
Table 1: Overview of the BX630 2 server blade documentation

BX630 S2 Service Supplement 7
Preface Notational Conventions
1.2 Notational Conventions
The following notational conventions are used in this manual:
“quotation marks” indicate names of chapters and terms that need to be
emphasized.
Êindicates an activity that must be performed.
VCAUTION! indicates that, if you ignore the information given at this
point, your health, the correct functioning of your
system or the security of your data may be at risk.
Iindicates supplementary information, remarks and tips.
Table 2: Notational conventions

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k01

BX630 S2 Service Supplement 9
2Procedure
VATTENTION!
The activities described in this manual should only be performed by
engineers, service personnel or technical specialists.
ÊFirst of all please familiarize yourself with the safety instructions in the
chapter “Important Notes” on page 11ff.
ÊMake sure that all the manuals you need (see service DVD) are available,
printing out the PDF files if necessary. You will definitely need the operating
manuals of the server blade and of your BX600 S2 or BX600 S3 basic unit.
ÊShut down the server blade correctly, switch it off and remove it from the
basic unit as described in the chapter “Replacement Routines” on page 17f.
ÊReplace the defective component as described in the relevant chapter.
ÊClose the server blade.
ÊStart the server blade.1
ÊIf necessary, configure the operating system as required.1
1See Operating Manual.

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k02

BX630 S2 Service Supplement 11
3 Important Notes
This chapter provides safety instructions which you must observe when
handling your system.
3.1 Notes on Safety
IThe following safety instructions can also be found in the manual entitled
“Safety”.
This device complies with the relevant safety regulations for IT equipment,
including electronic office machines for use in an office environment.
If you have any questions, contact your sales outlet or the Fujitsu Siemens
Computers customer service center.
VATTENTION!
The activities described in this manual should only be performed by
engineers, service personnel or technical specialists. Equipment repairs
should only be performed by qualified staff! Any failure to observe the
guidelines in this manual could endanger the user (through electric
shock, fire hazards) or damage the equipment. Please note that any
unauthorized opening of the device will result in the invalidation of the
warranty and exclusion from all liability.
Before setting up
VATTENTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see
Operating Manual).
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Before operating the device, wait until it is absolutely dry and has
reached approximately the same temperature as the installation site.
Any failure to observe the guidelines in this manual could damage the
equipment.

12 Service Supplement BX630 S2
Notes on Safety Important Notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k03
VATTENTION!
●Transport the device only in its original packaging or in packaging
which protects it from knocks and jolts.
Installation and operation
VATTENTION!
●Read the notes on installation and operation in the Operating Manual
of the PRIMERGY BX600 S2 or BX600 S3 basic unit.
●When installing the server blade in the basic unit, beware of the
energy hazard at the midplane conctacts. A short-circuit on these
contacts may damage the system.
●Data cables must be adequately shielded to avoid interference.
●For the LAN wiring, the requirements according to standards EN
50173 and EN 50174-1/2 apply. The minimum requirement is the use
of a protected LAN line of category 5 for 10/100 Mbps Ethernet,
and/or of category 5e for Gigabit Ethernet. The requirements of the
specification ISO/IEC 11801 must also be taken into account.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the Operating Manual.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
●Be careful to ensure that no objects (e.g. jewelry, paper clips etc.) or
liquids get inside the device (electric shock, short circuit).
●In emergencies (e.g. damaged casing, elements, or cables,
penetration of liquids or foreign bodies), switch off the device immedi-
ately, unplug it from the grounded power outlet, and contact your
customer service centre.
●Proper operation of the device (in accordance with IEC60950/EN
60950) is only ensured if the casing is completely assembled and the
rear covers for the installation openings are in place (electric shock,
cooling, fire protection, interference suppression).

BX630 S2 Service Supplement 13
Important Notes Notes on Safety
VATTENTION!
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and telecommunica-
tions terminal equipment.
If you install other extensions, you may damage the system or violate
these safety regulations.
Information on which system extensions are suitable can be obtained
from the customer service center or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
may only be opened, removed, or exchanged by authorized, qualified
personnel, with the exception of the hot-plug/hot-swap components.
●If you cause a defect on the device by installing or exchanging system
extensions, the warranty will be invalidated.
●You may only set the resolutions and refresh rates specified in the
operating manual for your monitor.
Otherwise, you may damage the monitor. If you are in any doubt,
contact your sales outlet or customer service center.
Batteries
VATTENTION!
●Incorrect replacement of batteries can lead to risk of explosion. The
batteries must be replaced with an identical battery or with a battery
type recommended by the manufacturer.
●Do not throw batteries into the trash can. Please dispose of them in
accordance with local regulations for special refuse.
●When replacing the lithium battery in the relevant components,
always follow the instructions in this manual.
●All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). The marking also contains the chemical
symbol of the heavy metal that classifies the battery as a pollutant:
Cd Cadmium
Hg Mercury
Pb Lead

14 Service Supplement BX630 S2
Electrostatic-Sensitive Devices Important Notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k03
Modules with electrostatic-sensitive devices
Modules with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When handling modules with ESDs, it is essential that you observe the following
guidelines:
●You must always discharge static build-up, e.g. by touching a grounded
object, before working with such components.
●Any devices or tools that are used must be free of electrostatic charge.
●Always hold components with ESDs at the edges.
●Do not touch any connectors or conduction paths on an ESD.
●Wear a suitable grounding cable that connects you to the external chassis of
the basic unit.
●Place all the components on a pad which is free of electrostatic charge.
IFor a detailed description of how to handle ESD components, see the
relevant European and international standards (EN 61340-5-1,
ANSI/ESD S20.20).

BX630 S2 Service Supplement 15
Important Notes Electrostatic-Sensitive Devices
3.2 Environmental protection
Environmentally-friendly product design and development
This product has been designed in accordance with the Fujitsu Siemens
Computers standard for “environmentally friendly product design and devel-
opment”. This means that key factors such as durability, selection and labeling
of materials, emissions, packaging, ease of dismantling and recycling have
been taken into account.
This saves resources and thus reduces the harm done to the environment.
Energy-saving information
Devices that do not need to be constantly switched on should be switched off
until they are needed as well as during long breaks and after completion of work.
Packaging information
Do not throw away the packaging. You may need it later for transporting the
system. If possible, the equipment should only be transported in its original
packaging.
Information on handling consumables
Please dispose of printer consumables and batteries in accordance with the
applicable national regulations.
In accordance with EU directives, batteries must not be disposed of with
unsorted domestic waste. They can be returned free of charge to the manufac-
turer, dealer or an authorized agent for recycling or disposal.
All batteries containing pollutants are marked with a symbol (a crossed-out
garbage can). They are also marked with the chemical symbol for the heavy
metal that causes them to be categorized as containing pollutants:
Cd Cadmium
Hg Mercury
Pb Lead
Labels on plastic casing parts
Please avoid sticking your own labels on plastic parts wherever possible, since
this makes it difficult to recycle them.

16 Service Supplement BX630 S2
Electrostatic-Sensitive Devices Important Notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k03
Returns, recycling and disposal
Details regarding the return and recycling of devices and consumables within
Europe can also be found in the “Returning used devices” manual, via your local
Fujitsu Siemens Computers branch or from our recycling center in Paderborn:
Fujitsu Siemens Computers
Recycling Center
D-33106 Paderborn
Tel. [phone]
Fax [phone]
The device must not be disposed of with domestic waste. This
device is labeled in compliance with European directive
2002/96/EC on waste electrical and electronic equipment (WEEE).
This directive sets the framework for returning and recycling used
equipment and is valid across the EU. When returning your used
device, please use the return and collection systems available to
you. Further information can be found at
www.fujitsu-siemens.com/recycling.

BX630 S2 Service Supplement 17
4 Replacement Routines
VATTENTION!
When working with systems and boards, make sure you observe the
safety information in the chapter “Important Notes” on page 11ff.
4.1 Preparation
If you want to replace components which are not hot-pluggable, you must
remove the server blade from the basic unit and open it.
ÊExit all applications and shut down the server blade correctly.
ÊPress the On/Off button on the server blade control panel.

18 Service Supplement BX630 S2
Preparation Replacement Routines
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k04
Removing the server blade from the basic unit
Figure 2: Disengaging the server blade
ÊPress the two touch points (1) to unlock
the handles.
ÊOpen out the two handles (2) simulta-
neously to disengage the server blade.
1
2
2
1

BX630 S2 Service Supplement 19
Replacement Routines Preparation
Figure 3: Removing the server blade from the basic unit
ÊPull the server blade out of the
basic unit.

20 Service Supplement BX630 S2
Preparation Replacement Routines
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX630_S2\Service-Supplement\2007-11\BX630S2_suppl.en\BX630S2_suppl_en.k04
Removing the housing cover
Figure 4: Removing the housing cover
ÊUndo the two knurled screws (1).
ÊPush the housing cover as far as possible in the direction of the arrow (2).
ÊTake off the housing cover.
The server blade components are now freely accessible.
11
2
