Fujitsu PRIMERGY RX600 S3 Owner's manual

PRIMERGY
PRIMERGY RX600 S3 SAS Server
Service Supplement
Joachim Pichol
Fujitsu Siemens Computers GmbH Paderborn
33094 Paderborn
e-mail: email: [email protected]
Tel.: [phone]
Fax: 0 700 / 372 000 01
Sprachen: En
Edition February 2007

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.vor
Copyright © 2007 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

Service Supplement RX600 S3 SAS
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . 5
1.2 Notational conventions . . . . . . . . . . . . . . . . . . . . . 7
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Environmental protection . . . . . . . . . . . . . . . . . . . 17
4 Replacement routines . . . . . . . . . . . . . . . . . . . . . 21
4.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.2 Opening/closing the server . . . . . . . . . . . . . . . . . . 22
4.3 Removing/inserting the processor cover . . . . . . . . . . . 24
4.4 Replacing the LocalView module . . . . . . . . . . . . . . . 27
4.5 Replacing the BMC board . . . . . . . . . . . . . . . . . . . 29
4.6 Replacing the control panel . . . . . . . . . . . . . . . . . . 31
4.7 Replacing the control panel board . . . . . . . . . . . . . . 32
4.8 Replacing the chassis ID module . . . . . . . . . . . . . . . 33
4.9 Replacing the SAS backplane . . . . . . . . . . . . . . . . . 35
4.10 Replacing RoMB components . . . . . . . . . . . . . . . . . 38
4.11 Replacing the system board . . . . . . . . . . . . . . . . . . 39
4.12 Replacing the power backplane . . . . . . . . . . . . . . . . 42
5 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.1 Control panel board . . . . . . . . . . . . . . . . . . . . . . 43

Service Supplement RX600 S3 SAS
Contents
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.ivz
5.2 Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.3 BMC board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.4 SAS backplane . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.5 Power backplane . . . . . . . . . . . . . . . . . . . . . . . . 48
6 Cable connections . . . . . . . . . . . . . . . . . . . . . . . . 49
6.1 Cable overview . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.2 Cable plans . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Service Supplement RX600 S3 SAS 5
1 Preface
The PRIMERGY RX600 S3 SAS server is an Intel-based server for mid-size
applications in server farms. It is suitable for front-end services as well as for use
as an application, e-mail, or Internet server.
The server is used exclusively as a rack model. It offers a whole host of config-
uration options but only uses four height units (HU) in the 19-inch rack.
1.1 Documentation overview
Concept and target groups
This Service Supplement supplements the information contained in the
Operating Manual, the Options Guide and the Technical Manual for the system
board.
VATTENTION!
The activities described in this manual should only be performed by
specialist personnel with technical training.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
Service DVD
A service DVD is available for service partners of Fujitsu Siemens Computers.
This DVD contains the following manuals in PDF format:
– the Operating Manual for PRIMERGY RX600 S3 SAS
– the Options Guide for PRIMERGY RX600 S3 SAS
– the Technical Manual for the system board D2630
– the “D2630 BIOS Setup Utility” manual
– the “Ergonomics” manual
– the “Safety notes and other important information” manual
IThese PDF files can also be downloaded from the Internet free of
charge: At http://manuals.fujitsu-siemens.com you will find an overview
page showing the online documentation available on the Internet. You
can go to the PRIMERGY Server documentation by clicking on industry
standard servers.

6 Service Supplement RX600 S3 SAS
Documentation overview Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k01
Information/Activity Manual
Features and technical data of the server Operating Manual
Installation and initial operation, such as:
– external connections to the server
– operation
– configuring the server
– installing the rack mounting kit
Troubleshooting
Installing/removing all hot-plug components:
– hot-plug power supply units
– hot-plug HDD modules
– hot-plug memory boards etc.
Extensions and conversions:
– expanding/replacing RAM modules
– installing additional processors/replacing
processors
– installing accessible drives
– installing controllers in non-hot-plug PCI
slots
– installing RemoteView components
Options Guide
Replacement routines:
– replacing the LocalView module
– replacing the BMC board
– replacing the control panel
– replacing the control panel board
– replacing a chassis ID board
– replacing the SAS backplane
– replacing RoMB components
– replacing the system board
– replacing the power backplane
Service Supplement
Settings
Cable connections
Table 1: Overview of the RX600 S3 SAS documentation (part 1 of 2)

Service Supplement RX600 S3 SAS 7
Preface Notational conventions
1.2 Notational conventions
The following notational conventions are used in this manual:
Information on the system board:
– features of the system board
– connector assignment
– jumper settings
– replacing the battery
Technical Manual
BIOS settings BIOS Setup Utility
Detailed safety information Manual “Safety notes and
other important information”
Italics indicate commands, menu items or software programs.
“quotation marks” indicate names of chapters and terms that need to be
emphasized.
Êindicates an activity that must be performed.
VATTENTION! indicates that, if you ignore the information given at this
point, your health, the correct functioning of your
system or the security of your data may be at risk.
Iindicates supplementary information, remarks and tips.
Table 2: Notational conventions
Information/Activity Manual
Table 1: Overview of the RX600 S3 SAS documentation (part 2 of 2)

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k01

Service Supplement RX600 S3 SAS 9
2Procedure
VATTENTION!
The activities described in this manual should only be performed by
engineers, service personnel or technical specialists.
ÊFirst of all please familiarize yourself with the safety instructions in the
chapter “Important notes” on page 11ff.
ÊMake sure that all the manuals you need (see service DVD) are available,
printing out the PDF files if necessary. You will definitely need the Operating
Manual for the server, the Options Guide for the server, and the Technical
Manual for the system board.
ÊShut down the server correctly, switch it off, pull out the power plugs, and
open the server as described in the chapter “Replacement routines” on
page 21ff.
ÊReplace the defective component as described in the relevant chapter.
ÊClose the server.
ÊConnect the cables to the server.1
ÊConnect the server to the mains.1
ÊStart the operating system.1
ÊIf necessary, configure the operating system as required.1
1These procedures are described in the Operating Manual.

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k02

Service Supplement RX600 S3 SAS 11
3 Important notes
This chapter provides safety instructions which you must observe when
handling your server.
3.1 Notes on safety
IThe following safety instructions can also be found in the manual entitled
“Safety”.
This device complies with the relevant safety regulations for data processing
equipment, including electronic office machines for use in an office
environment.
VATTENTION!
The activities described in this manual should only be performed by
specialist technical personnel. Equipment repairs must only be
performed by qualified staff. Any unauthorized opening or improper
repairs could endanger the user (through electric shock, energy hazard,
fire hazard) or damage the equipment. Please note that any unautho-
rized opening of the device will result in the invalidation of the warranty
and exclusion from all liability.

12 Service Supplement RX600 S3 SAS
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k03
Before setting up
VATTENTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see
operating manual).
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Before operating the device, wait until it is absolutely dry and has
reached approximately the same temperature as the installation site.
Failure to observe these guidelines can lead to material damage of
the device.
●Transport the device only in its original packaging or in packaging
which protects it from knocks and jolts.
Installation and operation
VATTENTION!
●If the rack model is integrated in an installation that receives power
from an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for the non-industrial (public) power supply networks for
the type A connector.
●The server automatically adjusts to a mains voltage from 200 V - 240 V.
Make sure that the local mains voltage is neither above nor below this
range.
●This device has safety-tested power cables and must only be
connected to properly grounded power outlets.
●Make sure that the power sockets on the device or the grounded
mains outlets are freely accessible.
●The power switch does not disconnect the device from the mains
voltage. To completely disconnect it from the mains voltage, you must
remove the power plugs from the power outlet.

Service Supplement RX600 S3 SAS 13
Important notes Notes on safety
VATTENTION!
ÊAlways connect the device and the attached peripherals to the same
power circuit. Otherwise you run the risk of losing data if, for example,
a power outage occurs and the central processing unit is still running
but the peripheral device (e.g. a storage subsystem) has failed.
ÊData cables must be adequately shielded to avoid interference.
ÊFor the LAN wiring, the requirements according to standards
EN 50173 and EN 50174-1/2 apply. The minimum requirement is the
use of a protected LAN line of category 5 for 10/100 Mbps Ethernet,
and/or of category 5e for Gigabit Ethernet. The requirements of the
specification ISO/IEC 11801 must also be taken into account.
ÊRoute the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the Operating Manual.
ÊDo not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
ÊBe careful to ensure that no objects (e.g. jewelry, paper clips etc.) or
liquids get inside the device (electric shock, short circuit).
ÊIn emergencies (e.g. damaged casing, control elements or cable,
penetration of liquids or foreign bodies), switch off the device immedi-
ately, unplug it from the grounded power outlet, and contact your
customer service center.
ÊProper operation of the device (in accordance with IEC 60950-1/
EN 60950-1) is only ensured if the casing is completely assembled
and the rear covers for the installation openings are in place (electric
shock, cooling, fire protection, interference suppression).

14 Service Supplement RX600 S3 SAS
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k03
VATTENTION!
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and telecommunica-
tions terminal equipment.
If you install other extensions, you might damage the system or
violate these safety regulations.
Information on which system extensions are suitable can be obtained
from the customer service center or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
should only be opened, removed, or exchanged by authorized,
qualified personnel.
Exception: You may exchange hot-plug power supply units.
●If you cause a defect on the device by installing or exchanging system
extensions, the warranty will be invalidated.
●You should only set the resolutions and refresh rates specified in the
operating manual for your monitor.
Otherwise, you might damage the monitor. If you are in any doubt,
contact your sales outlet or customer service center.
Batteries
VATTENTION!
●Incorrect replacement of batteries can lead to risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer (see the Technical Manual for the
system board in the section “Documentation overview” on page 5).
●When replacing the lithium battery on the system board, always follow
the instructions in the Technical Manual for the system board (see
section “Documentation overview” on page 5).

Service Supplement RX600 S3 SAS 15
Important notes Notes on safety
Notes on handling CDs/DVDs and CD/DVD drives
VATTENTION!
●To prevent loss of data, damage to the device, or injuries, you should
only use CDs/DVDs in good condition in the CD/DVD drive of your
server.
●Therefore, check each CD/DVD for damage, cracks, breakage etc.
before inserting it in the drive.
Please note that any additional labels applied may change the
mechanical properties of a CD/DVD and cause imbalance.
Damaged and imbalanced CDs/DVDs can break at high drive speeds
(loss of data).
Under certain conditions, sharp-edged pieces of broken CDs/DVDs
can penetrate the cover of the drive (cause damage to the device)
and be thrown out of the device (therefore causing injury to
uncovered body parts, particularly the face or neck).
ITo protect the CD/DVD drive and prevent mechanical damage as well as
premature wearing of the CDs/DVDs, you should observe the following
advice:
– Only insert the CDs/DVDs in the drive when needed and remove
them after use.
– Store the CDs/DVDs in suitable sleeves.
– Protect the CDs/DVDs from exposure to heat and direct sunlight.
Note on the laser
The CD/DVD drive is classified as Laser Class 1, according to IEC 60825-1.
VATTENTION!
The CD/DVD drive contains a light-emitting diode (LED) which may
generate a stronger laser beam than Laser Class 1. It is dangerous to
look directly into the beam.
Never remove any parts of the housing of the CD/DVD drive!

16 Service Supplement RX600 S3 SAS
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k03
Modules with electrostatic-sensitive devices
Modules with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When you handle components fitted with ESDs, you must always observe the
following points:
●Pull out the power plug before installing or uninstalling components.
●You must always discharge static build-up (e.g. by touching a grounded
object) before working with such components.
●Any devices or tools that are used must be free of electrostatic charge.
●Wear a suitable grounding cable that connects you to the external chassis of
the system unit.
●Always hold components with ESDs at the edges or at the points marked
green (touch points).
●Do not touch any connectors or conduction paths on an ESD.
●Place all the components on a pad which is free of electrostatic charge.
IFor a detailed description of how to handle ESD components, see the
relevant European or international standards (EN 61340-5-1, ANSI/ESD
S20.20).

Service Supplement RX600 S3 SAS 17
Important notes Environmental protection
3.2 Environmental protection
Environmentally friendly product design and development
This product has been designed in accordance with the Fujitsu Siemens
Computers standard “Environmentally Friendly Product Design and Devel-
opment”. This means that the designers have taken into account crucial criteria
such as durability, selection and labeling of materials, emissions, packaging, the
ease with which the product can be dismantled, and the extent to which it can
be recycled.
This saves on resources and helps to protect the environment.
Notes on saving energy
Devices that do not have to be on permanently should not be switched on until
they are needed and should be switched off during long breaks and when work
is finished.
Notes on handling consumables
Please dispose of printer consumables and batteries in accordance with local
regulations.
Do not throw batteries into the trash can. They must be disposed of in accor-
dance with local regulations concerning special waste.
Note on labels on plastic housing parts
If possible, do not stick your own self-adhesive labels on plastic housing parts,
as this can hamper the recycling process.

18 Service Supplement RX600 S3 SAS
Environmental protection Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k03
Returning used electrical and electronic devices
●Separate disposal
Old electrical and electronic devices should be disposed of separately and
not with household refuse. Separate disposal allows this old equipment to
be reused or recycled, which helps conserve resources.
●Return and collection systems
It may be possible to return old electrical/electronic devices from private
households free of charge. Please use the country-specific return or
collection systems available to you (see “Local contacts” on page 19).
The return of used devices which pose a health or safety risk for human
beings due to soiling during use may be refused.
●Reuse and recycling
By actively using any return or collection systems offered, you will be contrib-
uting to the reuse and recycling of electrical/electronic devices.
●Effects on the environment and human health
Old electrical/electronic devices contain parts which must be handled selec-
tively according to EU directives. Separate disposal and selective treatment
are the basis for environment-friendly disposal and the protection of human
health.
●Meaning of the symbol “Crossed out trash can on wheels"
Electrical (electronic) devices which are marked with one of the following
symbols must not be disposed of with household refuse in accordance with
EU directives.
Figure 2: Symbols on electrical/electronic devices

Service Supplement RX600 S3 SAS 19
Important notes Environmental protection
Returning batteries
Batteries which are marked with one of the following symbols must not be
disposed of together with household refuse according to EU directives.
Figure 3: Symbols on batteries
With batteries containing harmful substances, the chemical symbol for the
heavy metal contained is indicated below the trash can.
Cd Cadmium
Hg Mercury
Pb Lead
The following applies to Germany:
– Private consumers can return batteries at the point of sale or in the
immediate vicinity thereof free of charge.
– The consumer is obligated to return defective or used batteries to the seller
or to the return points established for this purpose.
Local contacts
For details on take-back and reuse of devices and consumables within Europe,
contact your Fujitsu Siemens Computers branch office/subsidiary or our
recycling centre in Paderborn, Germany:
Fujitsu Siemens Computers
Recycling Center
33106 Paderborn, Germany
Tel. [phone]
Fax [phone]
Internet: http://www.fujitsu-siemens.com/recycling

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: D:\Aktuelles_Projekt\PRIMERGY\RX600S3-SAS\Supplement\EN\RX600S3-SAS_suppl_us.k03
