Fujitsu PRIMERGY TX150 S2 User manual

U41057-J19-Z146-1-76 July 2004 02–TX150S2–1
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.ivz
PRIMERGY TX150 S2
Contents
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-5
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-6
Product designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-10
System allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-16
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-16
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-17
Installation and initial operation . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-19
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-19
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-19
Preparing the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-22
Connecting devices to the server . . . . . . . . . . . . . . . . . . . 02-TX150S2-24
Connecting the monitor to the line voltage . . . . . . . . . . . . 02-TX150S2-25
Connecting the server to the line voltage . . . . . . . . . . . . . 02-TX150S2-26
Initial operation and operating . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-28
Unlocking/locking the floorstand model . . . . . . . . . . . . . . 02-TX150S2-29
Controls and indicators on the front panel . . . . . . . . . . . . 02-TX150S2-31
Indicators on the rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-35
Switching the server on and off . . . . . . . . . . . . . . . . . . . . 02-TX150S2-37
Configuration of the server . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-39
– SCSI RAID controller configuration . . . . . . . . . . . . . . . 02-TX150S2-39
– SATA RAID controller configuration . . . . . . . . . . . . . . . 02-TX150S2-40
– Configuration with ServerStart . . . . . . . . . . . . . . . . . . 02-TX150S2-41
– Configuration without ServerStart . . . . . . . . . . . . . . . . 02-TX150S2-41
– Activate RemoteView . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-42
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-43
System board D1751 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-43
– Interfaces and connectors . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-43
– LAN connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-45
– Temperature/system monitoring . . . . . . . . . . . . . . . . . 02-TX150S2-46
– ISA bus resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-47
– PCI bus resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-47
– Screen resolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-50

02–TX150S2–2 July2004 U41057-J19-Z146-1-76
Contents
– Processor's clock speed . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-50
– Jumper and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-51
– Add-on modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-53
RemoteView-chipDISK . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-54
Operating panel board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-55
SCSI backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-56
SATA backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-57
Power backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-58
Internal cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-59
SCSI version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-59
– Cabling with onboard SCSI controller . . . . . . . . . . . . . 02-TX150S2-60
– Cabling with additional SCSI RAID controller . . . . . . . 02-TX150S2-61
– Cabling HDD extension box . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-62
– Addresses for SCSI devices . . . . . . . . . . . . . . . . . . . . 02-TX150S2-63
SATA version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-64
– Cabling with an additional SATA controller . . . . . . . . . . 02-TX150S2-64
Cable overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-65
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-67
Assignment of the components in ServerView . . . . . . . . . . . . 02-TX150S2-67
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-69
Removal/installation routines . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-75
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-75
Opening/closing the server . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-76
Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-76
– Removing/installing the drive covers . . . . . . . . . . . . . . 02-TX150S2-76
– Removing/installing the front cover . . . . . . . . . . . . . . . 02-TX150S2-80
Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-81
Hard disk subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-83
Components and indicators of the hard disk module . . . . 02-TX150S2-85
Installing/removing a hard disk module . . . . . . . . . . . . . . . 02-TX150S2-86
– Removing the dummy cover . . . . . . . . . . . . . . . . . . . . 02-TX150S2-86
– Installing the dummy cover . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-87
– Installing SCSI hard disk module . . . . . . . . . . . . . . . . . 02-TX150S2-87
– Removing hard disk module . . . . . . . . . . . . . . . . . . . . 02-TX150S2-88
– Replacing a hard disk module during
operation (hot-plug) . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-88
– Changing the hard disk drive in the hard disk carrier . . 02-TX150S2-89

U41057-J19-Z146-1-76 July 2004 02–TX150S2–3
Contents
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.ivz
Replacing the SCSI backplane . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-90
Replacing the SATA backplane . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-91
Accessible drives and operating panel . . . . . . . . . . . . . . . . . . 02-TX150S2-92
Installing/removing an accessible 5.25" drive . . . . . . . . . . 02-TX150S2-92
– Removing dummy cover . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-93
– Installing dummy cover . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-93
– Installing an accessible 5.25" drive . . . . . . . . . . . . . . . 02-TX150S2-94
– Removing an accessible 5.25" drive . . . . . . . . . . . . . . 02-TX150S2-94
Installing/removing the HDD extension box . . . . . . . . . . . 02-TX150S2-95
Replacing the operating panel board . . . . . . . . . . . . . . . . 02-TX150S2-97
Replacing the floppy disk drive . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-98
RemoteView medium . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-100
Installing/removing the chipDISK . . . . . . . . . . . . . . . . . . 02-TX150S2-100
Configuring the chipDISK . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-101
RemoteView service board S2 . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-102
Boards in PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-103
Installing/removing a board . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-103
Removing the card guide . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-106
System board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-107
Air duct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-107
– Removing/installing the air duct . . . . . . . . . . . . . . . . 02-TX150S2-107
Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-108
– Installing/removing memory modules . . . . . . . . . . . . 02-TX150S2-109
Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-111
– Installing/removing processor . . . . . . . . . . . . . . . . . . 02-TX150S2-111
Lithium battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-116
– Replacing the lithium battery . . . . . . . . . . . . . . . . . . . 02-TX150S2-116
Changing the system board . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-117
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-120
Standard power supply . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-120
– Replacing standard power supply unit . . . . . . . . . . . 02-TX150S2-120
Redundant power supply . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-121
– Replacing power supply module . . . . . . . . . . . . . . . . 02-TX150S2-122
– Adding second power supply module . . . . . . . . . . . . 02-TX150S2-124
– Replacing power backplane . . . . . . . . . . . . . . . . . . . 02-TX150S2-125
Upgrading from standard PS to redundant PS . . . . . . . . 02-TX150S2-126
Replacing the system fan . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-130
Replacing the IDTEMP combo . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-131
Replacing intrusion detection switches . . . . . . . . . . . . . . . . 02-TX150S2-133

02–TX150S2–4 July2004 U41057-J19-Z146-1-76
Contents
Conversion of the housing model . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-135
From floorstand model to rack model . . . . . . . . . . . . . . . 02-TX150S2-135
Fit assembly kit and rack-mount the server . . . . . . . . . . . . . 02-TX150S2-141
Rack installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-141
Overviews, lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-157
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-157
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-157
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX150S2-161

U41057-J19-Z146-1-76 July 2004 02–TX150S2–5
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
02
TX150S2
General information
Description
The PRIMERGY TX150 S2 server is an Intel-based server for small and mid-
size networks. Itcan beused as afloorstand modelaswell as arack model. The
floorstand model can be converted to a rack model with an optional available
conversion kit.
The PRIMERGY TX150 S2 server offers a high level of data safety and avail-
ability through highlydeveloped hardware and software components. Hardware
components include hot-plugable hard disk modules, optional hot-plugable
power supply modules, ServerView server management, Prefailure Detection
and Analysing (PDA), and Automatic Server Reconfiguration and Restart
(ASR&R).
Security functions in the BIOS Setup and on the system board protect the data
ontheserveragainstmanipulation.Youfindthedetaileddescriptionof theBIOS
Setup utility in the BIOS Setup manual on the PRIMERGY ServerBooks CD.
As a floorstand model, the lockable drive cover offers additional protection. As
a rack model, the lockable front door of the rack offers additional security.

02–TX150S2–6July2004 U41057-J19-Z146-1-76
Description General information
Features
System board D1751
–Systemboard in (ATX + 3.4 x 6) format
–Intel® Pentium 4 processor (Northwood/Prescott)
–Intel® E7210/6300ESB chipset
–1 processor socket for Intel® Pentium 4 processor with 478 pin surface up
to 3.2 GHz and 800/533/400MHz front side bus
–Intel Celeron can also be connected (optional)
–1MB/512KB/128 L2 cache
–Dual-channel memory architecture:
4 x 184-pin DDR DIMM sockets for up to 4GB memory with
PC3200/2700/2100 DDR SDRAM memory,
supports PC3200/2700/2100 unbuffered ECC DDR DIMM or ECC DDR
DIMM modules for a data transfer rate of up to 6.4 B/s
–3 PCI slots with 32bit/33 MHz
–2 PCI slots with 64bit/66MHz
–Intel 82547GI Gigabit Ethernet controller with 10/100/1000 Mbit/s (Intel
Kenai II)
–Memory, supported by South Bridge (6300ESB ICH):
2 x UltraDMA100 connectors
–Video controller ATI Rage XL VGA onboard with 8 Mbyte SDRAM memory
–2 fast-IDE (ATA) controller onboard (2x ATA-100)
–LSI 1020 SCSI bus controller
–2 USB 1.0 UHCI ontroller
–1 USB 2.0 EHCI ontroller
–4Mbit BIOS Flash PROM
–Super I/O controller Winbond W83627THF-A
–2 x USB 2.0 connector
–Cover and system monitoring, sensor monitoring, power monitoring, fan
monitoring
–Server Management with system fan, CPU fan and PSU fan revolution
monitoring and controlling, intrusion detection, Wake on LAN, ASR&R
–2 external serial ports (COM1, COM2)
–2 external USB 2.0 ports
–1 RJ45 LAN connector (10/100/1000 MBit/s)
–2 external PS/2 ports for keyboard and mouse
–1 external USB port

U41057-J19-Z146-1-76 July 2004 02–TX150S2–7
General information Description
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
Hard disk subsystem
There are two versions of the hard disk subsystem:
–SCSIversion
–SATAversion
SCSI version
The hard disk subsystem consists of the hard disk cage with up to four ULTRA-
320 SCSI hard disk modules and the SCSI backplane. Each hard disk module
can accommodate a SCSI hard disk drive with a SCA (Single Connector
Attachment) interface and a maximum height of 1 inch. The module is
connected to the SCSI backplane without cables via the SCA interface. This
allows hard disk modules to be simply plugged in or pulled out.
The hard disk subsystem can be controlled by the onboard U320 controller, a
PCI standard SCSI controller or by a SCSI RAID controller.
In the SCSI version it is possible to install a HDD extension box in two bays of
the accessible drives. By this three additional ULTRA-320 SCSI hard disk
modules can be used.
Onlyifthe serverisequippedwithaRAIDcontroller,adefectiveharddisk
module can be replaced during operation (hot-plug).
SATA version
The hard disk subsystem consists of the hard disk cage with up to four SATA
hard disk modules and the SATA backplane. Each hard disk module can accom-
modate a SATA hard disk drive with a SATA interface and a maximum height of
1 inch. The module is connected to the SATA backplane without cables via the
SATA interface. This allows hard disk modules to be simply plugged in or pulled
out.
The hard disk subsystem can be controlled by a SATA controller or by a SATA
RAID controller.
Onlyifthe serverisequippedwithaRAIDcontroller,adefectiveharddisk
module can be replaced during operation (hot-plug).
!
!

02–TX150S2–8 July2004 U41057-J19-Z146-1-76
Description General information
Accessible drives
A 3.5-inch floppy disk drive (1.44 MB) and three bays for the installation of
accessible drives (CD-ROM, DVD-ROM, CD burner or tape drive) are available.
The accessible drives cannot be replaced during operation.
In the SCSI version it is possible to install a HDD extension box in two bays of
the accessible drives.
Power supply
In itsbasic configuration level theserver hasa fixed powersupply unit (standard
power supply) that adjusts automatically to a power voltage in the range from
100 V - 240 V.
As an option, this power supply unit can be replaced with a hot-plug power
supply unit (redundant power supply) which consists of two power supply
modules inthe maximum configuration. To achieve redundant power supply the
second power supply module must be added.
If one power supplymodule of the redundant power supply unit fails, the second
power supply module ensures unimpaired continued operation and the
defective power supply module can be replaced during operation (hot-plug).
High level of availability and failure protection
When accessing stored data, 1-bit-errors in the main memory are automatically
recognized and corrected by ECC mechanism (ECC = Error Detection Code).
ASR&R (Automatic Server Reconfiguration and Restart) tunes out defective
system components during an automatic system reboot.
The Prefailure Detection and Analysing Technology (PDA) analyzes and
monitors all components that are vital for the system's reliability.
Optional RAID controllers increase system availability and support the RAID
levels 0,1 and 5.
The hot-plugable hard disks provide additional protection.
Server management
Server management is implemented with aid of the supplied ServerView
softwareandPDA(PrefailureDetectionandAnalyzing)technology.PDAreports
the threat of system errors or problems to the system administrator so that
preventative measures can be taken.

U41057-J19-Z146-1-76 July 2004 02–TX150S2–9
General information Description
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
ServerView enables the management of all PRIMERGY servers in the network
via a central console. Here ServerView supports the following functions:
– Remote power-on (Wake On LAN)
– Intrusion Detection
– Temperature monitoring of the CPU and the surrounding area.
– Power monitoring
– Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event of failure of memory modules or processors.
– End-of-Life monitoring of the fans with timely notification before a failure
– Watchdog timer for operating system monitoring and application monitoring
Further information on the ServerView server management is provided in the
associated documentation.
ServerStart
You can configure the PRIMERGY server quickly and purposefully with the
ServerStart softwareprovided. User-guided menusare available for installing the
server operating systems.
Service and Support
PRIMERGY servers are service-friendly and modular, thus enabling quick and
simple maintenance. The flash EPROM program supplied with the FSC utilities
supports fast BIOS update BIOS update. With the optional Remote Test and
DiagnosisSystemRemoteView,long-distancemaintenanceandservice(remote)
can also be performed on the servers of the PRIMERGY series. A RemoteView
service board S2(RSBS2) can be used in conjunction with RemoteView. Due to
this remote diagnosis for system analysis, remote configuration and remote
restart (also when the operating system failed or hardware failures appear) are
made possible.

02–TX150S2–10 July2004 U41057-J19-Z146-1-76
Product designations General information
Product designations
The sales information contained in this service manual is provided for
service and may not be used as sales documentation. It is possible that
some products of the overview can not be ordered any more.
Product Base units
PRIMERGY TX150S2 with
1x Celeron/Pentium 4 processor
1 x onboard U320 SCSI controller
Intel LAN onboard 10/100/1000 Mbit
graphics onboard controller ATI Rage XL 8 MB
drive bay 3.5" occupied by one floppy disk 1.44 MB
standard power supply
ServerView, ServerStart on CD
SCSI version
S26361-K934-V105 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 256 MB memory
S26361-K934-V115 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 512 MB memory
S26361-K934-V125 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 1 GB memory
S26361-K934-V107 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V117 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V127 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-K934-V108 Floorstand model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V118 Floorstand model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V128 Floorstand model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-K934-V305 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 256 MB memory
S26361-K934-V315 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 512 MB memory
i

U41057-J19-Z146-1-76 July 2004 02–TX150S2–11
General information Product designations
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
S26361-K934-V325 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 1 GB memory
S26361-K934-V307 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V317 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V327 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-K934-V308 Rack model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V318 Rack model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V328 Rack model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 1 GB memory
SATA version (includes a 4 Port SATA controller Promise FastTrak S150-TX4)
S26361-K934-V231 Floorstand model with Celeron processor 2.8 GHz/400 MHz
/128 KB cache, 1x 256 MB memory
S26361-K934-V241 Floorstand model with Celeron processor 2.8 GHz/400 MHz
/128 KB cache, 1x 512 MB memory
S26361-K934-V251 Floorstand model with Celeron processor 2.8 GHz/400 MHz
/128 KB cache, 1x 1 GB memory
S26361-K934-V205 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 256 MB memory
S26361-K934-V215 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 512 MB memory
S26361-K934-V225 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 1 GB memory
S26361-K934-V207 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V217 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V227 Floorstand model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-K934-V208 Floorstand model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V218 Floorstand model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 512 MB memory
Product Base units

02–TX150S2–12 July2004 U41057-J19-Z146-1-76
Product designations General information
S26361-K934-V228 Floorstand model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-K934-V431 Rack model with Celeron processor 2.8 GHz/400 MHz
/128 KB cache, 1x 256 MB memory
S26361-K934-V441 Rack model with Celeron processor 2.8 GHz/400 MHz
/128 KB cache, 1x 512 MB memory
S26361-K934-V451 Rack model with Celeron processor 2.8 GHz/400 MHz
/128 KB cache, 1x 1 GB memory
S26361-K934-V405 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 256 MB memory
S26361-K934-V415 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 512 MB memory
S26361-K934-V425 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/512 KB cache, 2x 1 GB memory
S26361-K934-V407 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V417 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V427 Rack model with Pentium 4 processor 3.0 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-K934-V408 Rack model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 256 MB memory
S26361-K934-V418 Rack model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 512 MB memory
S26361-K934-V428 Rack model with Pentium 4 processor 3.2 GHz/800 MHz
/1 M cache, 2x 1 GB memory
S26361-F2618-L220 Conversion kit from floorstand to rack without installation kit
S26361-F2734-E31 /
S26361-F2734-L31 Rack mounting kit for rack server into: – 19" racks (DataCenter and PRIMECENTER rack)
– all server racks confirming to EIA standard EIA-310-D
incl. bracket DC/PC rack, cable management DC/PC rack
Note:
For older PRIMECENTER racks (Rev. 1B) it is necessary to
order an additional carrier angle D:GP70F-ZB211.
S26361-F1331-L7 Installation kit for rack model in 42/23U rack:
telescopic rails, cable management
Product Base units

U41057-J19-Z146-1-76 July 2004 02–TX150S2–13
General information Product designations
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
Product Upgradings
S26113-F483-E1 /
S26113-F483-L1 Upgrade option: Hot plug power supply: power supply cage, power backplane,
1x hot plug power supply module, 1x dummy cover
No redundancy!
S26113-F483-E11 /
S26113-F483-L11 2nd power supply module for redundancy
Product Main memory for
– There are 4 slots available.
– The slots accept 256 MB, 512 GB or 1 GB DDR RAM
modules.
– The maximum main memory capacity is 4 GB!
– Single channel and dual channel configuration are
possible.
Single channel
S26361-F3019-E512 Main memory 256 MB, DDR I 400, occupies one bank,
max. 2 or 3 per system
S26361-F3019-E513 Main memory 512 MB, DDR I 400, occupies one bank,
max. 2 or 3 per system
S26361-F3019-E514 Main memory 1 GB, DDR I 400, occupies one bank,
max. 2 or 3 per system
Dual channel
S26361-F3019-E522 2x main memory 256 MB, DDR I 400, occupies two banks,
max. 1 per system
S26361-F3019-E523 2x main memory 512 MB, DDR I 400, occupies two banks,
max. 1 per system
S26361-F3019-E524 2x main memory 1 GB, DDR I 400, occupies two banks,
max. 1 per system

02–TX150S2–14 July2004 U41057-J19-Z146-1-76
Product designations General information
Product Accessible drives
– The system unit has 4 bays (1x3.5"/3x5.25")
– The 3.5" bay is occupied by a floppy disk drive
– The three 5.25" bays:
- one bay is occupied by a DVD-/CD- or CD-RW drive
- the two remaining bays can be occupied by two
accessible drives or a HDD extension box (only SCSI
version)
SNP:SY-F2234E1-A DVD-ROM ATAPI; max. 2/system
SNP:SY-F2240E1-A CD-ROM ATAPI; max. 2/system
S26361-F3008-E1 CD-RW/DVD drive; maximum 2/system
S26361-F3080-E1 CD-RW/DVD drive; maximum 2/system
S26361-F2573-E3 Tape drive LTO Ultrium, 100 GB,
7.5 MB/s, U2W SCSI; maximum 2/system
S26361-F2849-E3 Tape drive VXA-2, 80 GB,
6 MB/s, U2W SCSI; maximum 2/system
S26361-F2238-E3 Tape drive SLR 100, 50 GB,
5 MB/s, U2W SCSI; max. 2/system
S26361-F2848-E3 Tape drive DDS4 Gen5, 36 GB,
3 MB/s, U2W SCSI; maximum 2/system
S26361-F2233-E3 Tape drive DAT DDS4, 20 GB,
2.8 MB/s, U2W SCSI; max. 2/system
S26361-F2233-E13 Tape drive DAT DDS4 Autoloader, 6x20 GB,
3 MB/s, U2W SCSI; max. 1/system
S26361-F2814-E6 SCSI cable with terminator, connection accessible drive to
separate SCSI controller
S26361-F2826-E1 HDD extension box; max. 1/system
released only with 1- or 2-channel RAID controller

U41057-J19-Z146-1-76 July 2004 02–TX150S2–15
General information Product designations
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
Product Hard disk drives
– The system unit has 4 bays
– There are a SCSI and a SATA version
– In the SCSI version HDD extension box possible
– Hot-plug is possible with RAID controller
SCSI version
S26361-F2764-E136 36 GB, 10000 rpm, U320 SCSI (320 MB/s),
max. 4 or 7/system
S26361-F2764-E173 73 GB, 10000 rpm, U320 SCSI (320 MB/s),
max. 4 or 7/system
S26361-F2764-E114 146 GB, 10000 rpm, U320 SCSI (320 MB/s),
max. 4 or 7/system
S26361-F2764-E518 18 GB, 15000 rpm, U320 SCSI (320 MB/s),
max. 4 or 7/system
S26361-F2764-E536 36 GB, 15000 rpm, U320 SCSI (320 MB/s),
max. 4 or 7/system
S26361-F2764-E573 73 GB, 15000 rpm, U320 SCSI (320 MB/s),
max. 4 or 7/system
SATA version
S26361-F3017-E80 80 GB, 7200 rpm, SATA max. 4/system
S26361-F3017-E160 160 GB, 7200 rpm, SATA max. 4/system
Product Description
S26361-F2425-E101 RemoteView service board S2
S26361-F2425-E201 RemoteView service board S2 accu board
S26361-F2116-E12 IDE chipDISK

02–TX150S2–16 July2004 U41057-J19-Z146-1-76
System allocation General information
System allocation
The following, and later, software- and firmware versions support the TX150 S2:
Operating systems
Service
The type label can be found at the rear side of the server.
The system serial number is written on the type label. You need it if there is a
HW error.
ServerView Version 3.5
RemoteView Version 3.1
ServerStart Version 5.405
ServerBooks Version 5.405
ServerSupport Version 5.405
Manufacturer Operating system
Microsoft Windows 2000 Server; SBS
Windows 2003 Standard; WEB Edition
Windows SBS 2003 Standard Edition
Novell NetWare 6 int’l; 6.5
Cluster Services 1.6
iSCSI Cluster Service 1.7
SuSE LINUX ES-7
LINUX ES-8
LINUX 8.1
LINUX 8.2
Red Hat LINUX EL 2.1
LINUX 8.0
LINUX 9.0

U41057-J19-Z146-1-76 July 2004 02–TX150S2–17
General information Technical data
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k01
Technical data
Electrical data (standard and redundant power supply
National and international standards
Rated voltage range 100 V - 240 V
Frequency 50 Hz - 60 Hz
Rated current in basic configuration 100 V - 240 V / 1.9 A - 0.8 A
Max. rated current 100 V - 240 V / 6 A - 3 A
Effective power 274 W
Apparent power 300 VA
Heat emission 986 kJ/h
Building fuse 16 A
Protection class I
Product safety IEC 60950 / EN 60950 / UL 60950 3rd. Ed.,
CAN/CSA 22.2 No. 60950 3rd. Ed.
Electromagnetic compatibility: FCC class A
VCCI class A
AS / NZS 3548 class A
CNS 13438
Interference emission
Harmonic current
Flicker
EN 55022 class A
EN 61000-3-2 JEIDA
EN 61000-3-3
Interference immunity EN 55024
CE certification to EU directives:
73/23/EEC (low voltage directive)
89/336/EEC (Electromagnetic compatibility,
product safety)

02–TX150S2–18 July2004 U41057-J19-Z146-1-76
Technical data General information
Dimensions
Weight
Approx. 21 - 28 kg (depending on the configuration)
Ventilation intervals
Approx. 200 mm to the front and rear
Maintenance area for the floorstand server
1.2 m on the left side. The maintenance area may also be used, but must be
quickly accessible.
Environmental conditions
Condensation in operating must be avoided!
Noise level
Dimensions Floorstand model Rack model
Width 205 mm 482 mm (front panel)
Depth 605 mm 642 mm (with handles)
Mounting depth -- 607 mm
Height 444 mm (with feet) 221 mm or 5 HU
Environment class 3K2
Environment class 2K2 DIN IEC 721 part 3-3 DIN IEC 721 part 3-2
Temperature:
–Operating(3K2)
– Transport (2K2) 10 °C .... 35 °C -25 °C .... 60 °C
Humidity 10%...85%
Sound power level LWAd (ISO 9296): ≤5,8 B (stand-by)
≤6 B (operation)
Sound pressure level at bystander position
LpAm (ISO 9296) for standard configuration ≤43 dB(A) (stand-by)
≤45 dB(A) (operation)

U41057-J19-Z146-1-76 July 2004 02–TX150S2–19
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX150S2\TX150S2-e\TX150S2-e.k02
02
TX150S2
Installation and initial operation
Installation
Preparation
Unpacking the server
Do not unpack the server until it is at its installation location.
Ask somebody for help with carrying the server.
Should you discover that the delivery has damages incurred during
transport or does not correspond to the delivery note, notify your supplier
immediately!
ÊUnpack all parts.
ÊCarry the server to its installation location.
!

02–TX150S2–20 July2004 U41057-J19-Z146-1-76
Installation Installation and initial operation
Mounting the anti-tilt bracket
For floorstand models with redundant power supply the supplied anti-tilt
bracket must be fitted at the rear of the server.
ÊPosition the server on the anti-tilt bracket so the rubber feet of the server fit
into the openings of the bracket (1).
!
1
1
