Fujitsu SE500 User manual

Edition April 2017
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.vor
English
SE700 / SE500 / SE300
Basic Operating Manual
FUJITSU Server BS2000
Valid for:
SE700 / SE500 / SE300 (basic software V6.1A and higher)
SE700B / SE500B / SE300B (basic software V6.2A and higher)

Comments…Suggestions…Corrections…
The User Documentation Department would like to know your
opinion on this manual. Your feedback helps us to optimize our
documentation to suit your individual needs.
Feel free to send us your comments by e-mail to:
[e-mail]
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system which
complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
This manual is printed
on paper treated with
chlorine-free bleach.
Copyright © 2017 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
The Xen® mark is a trademark of Citrix Systems, Inc., which manages the mark on behalf of the Xen open source
community. The Xen® mark is registered with the U.S. Patent and Trademark Office, and may also be registered in
other countries.
Novell and SUSE are registered brands of Novell, Inc. in the USA and other countries.
Linux is a registered brand of Linus Torvalds.
Windows® is a registered trademark of Microsoft Corporation.
The Linux-based basic software M2000, X2000, and HNC which is installed on the Management Unit,
Server Unit x86, and HNC contains Open Source Software. The licenses for this can be found in the LICENSES
directory on the relevant installation DVD.

U41858-J-Z126-2-76
Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
12. April 2017 Stand 18:58.58 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.ivz
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Documentation for the SE servers . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.2 Objective and target groups of this manual . . . . . . . . . . . . . . . . . . . . . 11
1.3 Summary of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.5 Open Source Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1 Notes from the manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1.1 For safe operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1.2 About this product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.1.3 Trademark acknowledgments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2 Note regarding radio interference suppression . . . . . . . . . . . . . . . . . . 18
2.3 Note on safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.3.1 Important alert messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.3.2 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.4 Installation and operation precautions . . . . . . . . . . . . . . . . . . . . . . . 20
2.4.1 Installation precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.4.2 Operating precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3 System overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1.1 Rack of the SE server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.1.2 Expanded maintenance and operational functions . . . . . . . . . . . . . . . . . . . 27

Contents
U41858-J-Z126-2-76
4 Racks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.1 Basic rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2 Extension rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.3 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.3.1 Connection of the power cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1 Rack console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.2 Console switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.3 Control panel (on the SE700 and SE500) . . . . . . . . . . . . . . . . . . . . . . . 44
5.3.1 Function of the displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.3.2 Function of the keys and switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.3.2.1 UNIT EMERGENCY switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.3.2.2 POWER ON key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.3.2.3 STAND-BY key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6 Management Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.1 Front of the MU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6.2 Rear of the MU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7 Net Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.1 Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.1.1 Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.1.2 Network and management interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.1.3 LED indicators for ports, system and power status . . . . . . . . . . . . . . . . . . . 64
7.1.4 Threshold values for the operating temperature . . . . . . . . . . . . . . . . . . . . 67
7.2 Extension of the Net Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.2.1 Redundant Net Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.2.2 Port extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.2.3 HNC (High Speed Net Connect) on the SE700 / SE500 . . . . . . . . . . . . . . . . 68

Contents
U41858-J-Z126-2-76
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.ivz
8 Switching the server on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.1 Switching the SE300 on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.1.1 Switching off in an emergency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
8.1.2 Switching the SE server on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8.1.3 Switching the SE server off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8.2 Switching the SE700 / SE500 on and off . . . . . . . . . . . . . . . . . . . . . . 75
8.2.1 Switching off in an emergency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.2.2 Switching the SE server on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.2.3 Switching the SE server off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
9 Environmental protection and service . . . . . . . . . . . . . . . . . . . . . . . 83
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Contents
U41858-J-Z126-2-76

U41858-J-Z126-2-76 7
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. April 2017 Stand 15:41.40 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k01
1 Introduction
The FUJITSU Server BS2000 SE Series unites the existing server lines S servers and SQ
servers in the server line SE servers.
Depending on requirements, the SE server contains all the system components needed for
operation as an overall application:
– SU /390 for BS2000 guest systems
– Server Unit x86 with BS2000, Linux or Windows guest systems
– Application Units x86 for operating Native or hypervisor systems (e.g. Linux, Windows,
VMware, OVM, etc.)
– Shareable tape and disk periphery
– A high-speed, server-internal infrastructure to connect the components with each other
and with the customer's IP or FC network.
The SE server is installed entirely and tested on the vendor’s premises in accordance with
customer specifications.
Many hardware components are redundant in design, thus ensuring that even if a fault
occurs with these components, operation can continue with the same performance.
You can easily upgrade the models on site.
Information on the hardware lifecycle of the FUJITSU Server BS2000 SE Series
(Changes since the last edition of the manual)
With the hardware lifecycle of the SE Series, the hardware basis for the Server Unit x86,
the Management Unit and the HNC has been renewed. These new generation versions are
called SU300 M2, MU M2 and HNC M2. They are supported from basic software V6.2A
onwards.
The FUJITSU BS2000 servers of the SE Series that are equipped with this hardware
generation are called SE300B, SE500B and SE700B.
The changes in the manuals are mainly due to these new hardware lifecycle generation
models. Any differences to the previous models regarding structure and operation are
described in detail.

Introduction
8 U41858-J-Z126-2-76
Names and abbreviations
Because the names are used frequently, for the sake of simplicity and clarity the following
abbreviations are employed:
●SE server for the FUJITSU Server BS2000 SE Series (Server Units /390 and x86) with
the following models:
●SE700 for FUJITSU Server BS2000 SE700 / SE700B
(with SU700, more than one SU300 and AU optional)
●SE500 for FUJITSU Server BS2000 SE500 / SE500B
(with SU500, more than one SU300 and AU optional)
●SE300 for FUJITSU Server BS2000 SE300 / SE300B
(with SU300, more than one SU300 and AU optional)
Based on the different models, a distinction is made between the following SUs:
●SU700 for the Server Unit of the unit type SU /390 in SE700 and SE700B
●SU500 for the Server Unit of the unit type SU /390 in SE500 and SE500B
●SU300 for the Server Unit of the unit type SU x86 in SE300, optionally in SE500 /
SE700
Both SU300 M1 and SU300 M2 are described in the operating manual.
●MU for the Management Unit. The MU enables centralized, user-friendly and cross-
system management on the SE server.
Both MU M1 and MU M2 are described in the operating manual.
●AU for the Application Unit (on a varying hardware base)
The names of the models are derived from the hardware bases. AU47 is, for example,
an Application Unit based on a PRIMERGY RX4770.

Introduction
U41858-J-Z126-2-76 9
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. April 2017 Stand 15:41.40 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k01
●HNC (High Speed Net Connect)
The HNC connects the Server Unit /390 to the LAN and as the net client enables the
BS2000 systems on the SU /390 to access the Net-Storage.
Both HNC M1 and HNC M2 are described in the operating manual.
HNC is also the name used for the basic HNC software.
For a description of the further features of the SE servers SE700, SE500 and SE300,
please refer to the chapter “System overview” on page 23.
Figure 1: SE Server SE700 and SE700B

Documentation for the SE servers Introduction
10 U41858-J-Z126-2-76
1.1 Documentation for the SE servers
A wide range of documentation is available for the SE servers. As the BS2000 OSD/XC
software package comprises the BS2000 OSD/BC operating system and additional
system-related software products, the documentation for BS2000 OSD/XC consists of the
following:
●The manuals on BS2000 OSD/BC, which provide the basic literature on BS2000
OSD/XC.
●The manuals for the system-related software products which belong to the BS2000
OSD/XC software package also apply.
Any additions to the manuals are described in the Readme files for the various product
versions. These Readme files are available at http://manuals.ts.fujitsu.com under the various
products.
Current information, version and hardware dependencies and instructions for installing and
using a product version are contained in the associated Release Notice. Release Notices,
in particular those relating to BS2000 OSD/XC, M2000, X2000, and HNC, are available at
http://manuals.ts.fujitsu.com.
The documentation for the SE servers consists of the following parts:
●Operating Manual SE700 / SE500 / SE300 (consisting of a number of modules):
●Basic Operating Manual SE700 / SE500 / SE300
●Server Unit /390 (SE700 / SE500)
●Server Unit x86 (SE700 / SE500 / SE300)
●Additive Components (SE700 / SE500 / SE300)
●Operation and Administration
●Security Manual
●Quick Guide
Further literature is listed in Related publications.

Introduction Objective and target groups of this manual
U41858-J-Z126-2-76 11
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. April 2017 Stand 15:41.40 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k01
1.2 Objective and target groups of this manual
The SE700 / SE500 / SE300 Operating Manual, which consists of a number of modules,
describes the features and hardware components of the FUJITSU Server BS2000 of the
SE Series. Users should read this manual carefully in order to obtain optimal performance
from the SE server.
Readers require a knowledge of BS2000 system operation and administration as well as
basic knowledge of Linux. In some places knowledge of X2000 is helpful. This can be
obtained from the “Operation and Administration” manual [5].
This manual is intended for people who operate an SE server:
●As administrator you manage the entire SE server with all its components and the
operating systems which run on it. You need a good knowledge of the BS2000, Linux
and Windows operating systems and of the network and peripherals.
As administrator you can also manage the integration of the optional Application Units
on which an open operating system runs in Native or virtualized mode (e.g. under
VMware).
●As operator you operate BS2000 on the Server Unit of the SE server. You need a good
knowledge of the BS2000 operating system and also of the connected peripherals.
●As XenVM administrator you operate the virtual machines and their devices for Linux
and Windows guest systems on the Server Unit x86 of the SE server. You need a good
knowledge of the Linux and Windows operating systems and also of the connected
peripherals.

Summary of contents Introduction
12 U41858-J-Z126-2-76
1.3 Summary of contents
This operating manual deals with the hardware-related display and operating functions of
the FUJITSU BS2000 servers of the SE Series.
Chapter 2 contains important information on the installation and operation of the SE server
and the components.
The content of the other chapters is based on the module of the existing operating manual.
Information on the modules of the operating manual can be found in section “Documen-
tation for the SE servers” on page 10.
The Glossary explains important terms used in this manual. The Abbreviations chapter
gives an overview of the abbreviations that have been employed in this manual.
References to publications are given in the text with shortened forms of the titles in quotes.
The Related publications chapter lists the full title of each document that is referred to.
The Index at the end of the manual lists the key terms and the page numbers telling you
where to find the information about these terms.

Introduction Notational conventions
U41858-J-Z126-2-76 13
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. April 2017 Stand 15:41.40 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k01
1.4 Notational conventions
The following notational conventions are used in this manual:
w WARNING! This indicates a hazardous situation
which could result in serious personal injury
if the user does not perform the procedure correctly.
vCAUTION! This indicates a hazardous situation
which could result in minor or moderate personal injury,
if the user does not perform the procedure correctly.
This signal also indicates that damage to the product or other
property may occur if the user does not perform the procedure
correctly.
This indicates also the tasks which are performed by Customer
Support.
iThis indicates information that could help the user to use the
product more effectively.
ÊThe prompt symbol indicates activities which need to be performed
(e.g. entries on the keyboard).
italics Texts from the SE Manager
monospace System inputs and outputs
monospace
semibold
Statements which are entered via the keyboard are displayed in
this font.
<abc> Variables which are replaced by values.
[Key symbols] Keys are displayed as they appear on the keyboard. When
uppercase letters need to be entered, the Shift key is specified,
e.g. [SHIFT] - [A] for A. If two keys need to be pressed at the same
time, this is indicated by a hyphen between the key symbols.
[number] The titles of related publications in the text are abbreviated. The
complete title of each publication which is referred to by a number
is listed in the Related Publications chapter after the associated
number.

Notational conventions Introduction
14 U41858-J-Z126-2-76
Names and abbreviations
Because the names are used frequently, for the sake of simplicity and clarity the following
abbreviations are employed:
●SE server for the FUJITSU Server BS2000 SE Series (Server Units /390 and x86) with
the following models:
●SE300 for FUJITSU Server BS2000 SE300 (with SU300, optionally AUs)
●SE500 for FUJITSU Server BS2000 SE500 (with SU500, optionally SU300 and
AUs)
●SE700 for FUJITSU Server BS2000 SE700 (with SU700, optionally SU300 and
AUs)
●SU for the Server Unit irrespective of the unit type
A distinction is made between SUs depending on the unit type:
●SU /390 for Server Unit /390 (type of Server Unit with one or more /390 processors)
●SU x86 for Server Unit x86 (type of Server Unit with one or more x86 processors)
A distinction is made between the following SUs according to models:
●SU300 for the Server Unit of the unit type SU x86 in SE300, optionally in SE500 /
SE700
●SU500 for the Server Unit of the unit type SU /390 in SE500
●SU700 for the Server Unit of the unit type SU /390 in SE700
●MU for the Management Unit. The MU permits central, user-friendly and cross-system
management on the SE server.
●AU for the Application Unit (on a varying hardware base)
A distinction is made between the models according to the hardware base. AU47 is, for
example, an Application Unit based on a PRIMERGY RX4770.
●HNC (High Speed Net Connect)
The HNC connects the Server Unit /390 to the LAN and as the net client enables the
BS2000 systems on the SU /390 to access the Net-Storage. HNC is also the name used
for the HNC software.
●SKP (service console processor)
The MU and SE Manager contain the SKP functionality for an SU /390.
●SVP (service processor)

Introduction Open Source Software
U41858-J-Z126-2-76 15
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
19. April 2017 Stand 15:41.40 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k01
●BS2000 server as the generic term for SE server, S and SQ server. BS2000 servers
are operated with the relevant BS2000 operating system.
●S server for the Business Servers of the S Series (/390 architecture)
●SQ server for the business servers of the SQ Series (x86 architecture)
●BS2000 for the BS2000 OSD/BC operating system in compound nouns, e.g. BS2000
system.
1.5 Open Source Software
The Linux-based operating systems X2000 and HNC which are installed on the Server Unit
x86, Management Unit and HNC contain Open Source Software. The licenses for this can
be found in the LICENSES directory on the relevant installation DVD.

Open Source Software Introduction
16 U41858-J-Z126-2-76

U41858-J-Z126-2-76 17
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
12. April 2017 Stand 18:58.58 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k02
2 Important notes
2.1 Notes from the manufacturer
The system fulfills the requirements of the EU directives 2004/108/EC "Electromagnetic
Compatibility" and 2006/95/EC "Low Voltage Directive", 2009/125/EC (Ecodesign) and the
directive regarding the restriction of the use of particular hazardous substances in electrical
and electronic equipment 2014/30/EU. Each individual component bears the CE Marking
to confirm this (CE = Communauté Européenne).
2.1.1 For safe operation
This manual contains important information regarding the use and handling of this product.
Read this manual thoroughly. Pay special attention to the section “Note on safety” on
page 19 Use the product according to the instructions and information available in this
manual. Keep this manual handy for further reference.
The manufacturer makes every effort to prevent users and bystanders from being injured
or from suffering damage to their property. Use the product according to this manual.
2.1.2 About this product
The FUJITSU Server BS2000 of the SE Series is designed and manufactured for use in
standard applications such as computing center work, office work, and general industrial
applications. This product is not intended for use in nuclear-reactor control systems,
aeronautical and space systems, air traffic control systems, mass transportation control
systems, medical devices for life support, missile launch control systems or other
specialized uses in which extremely high levels of reliability are required, the required levels
of safety cannot be guaranteed, or a failure or operational error could be life-threatening or
could cause physical injury.
iThese safety-critical areas of application are hereafter referred to as “Areas of appli-
cation with high safety requirements”.

Note regarding radio interference suppression Important notes
18 U41858-J-Z126-2-76
You may not use the product in areas with high safety requirements without ensuring the
required level of safety. If you wish to use this product in an area of application with high
safety requirements please consult the responsible sales representatives before use.
2.1.3 Trademark acknowledgments
●Linux is a free multiplatform multiuser operating system.
●Ethernet is a registered trademark of Xerox Corporation in the United States and in
certain other countries.
●All other product names mentioned herein are the trademarks or registered trademarks
of their respective owners.
●System and product names in this manual are not always noted with trademark (™) or
registered trademark symbols (®).
The contents of this manual may be revised without prior notice.
Copyright © 2017 Fujitsu Technology Solutions GmbH.
All rights reserved
Delivery subject to availability; right of technical modifications reserved.
2.2 Note regarding radio interference suppression
wWARNING!
This is a product which meets Class A of EN55022. In a domestic environment this
product may cause radio interference in which case the user may be required to
take adequate measures.

Important notes Note on safety
U41858-J-Z126-2-76 19
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
Dokuschablonen 19x24 Version 7.4us für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010
12. April 2017 Stand 18:58.58 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303913_BA_Basis_update_2\prod_e\ba_basis.k02
2.3 Note on safety
2.3.1 Important alert messages
vCAUTION!
This alert signal indicates a hazardous situation that could result in minor or
moderate personal injury if the user does not perform the procedure correctly. This
signal also indicates that damage to the product or other property may occur if the
user does not perform the procedure correctly.
Warning
Possible damage to the system if used incorrectly
Be sure to follow the precautions below when installing the equipment. Otherwise, the business
server may be damaged.
Possible damage to the system if used incorrectly
In the factory all the power cables are connected to the power distribution units which are integrated
into the rack. Attach the connection cables of the multiple socket outlets to the in-house installation
so that they are easy to access.
Do not connect any additional consumer loads to the power distribution units - this could cause the
nominal load capacity of the multiple socket outlet or feed cables / fuses to be exceeded! If you want
to connect additional equipment, please contact Customer Support.
Possible data loss if used incorrectly
Before shutting down power, you should ensure that the following events occur; otherwise data may
be destroyed.
All applications have finished processing.
No user is using the components.
When a unit of the SE server (MU, SU, HNC or AU) is turned off, the operating status indicator lights
up orange. Check this before shutting down the main power (to UPS, power cable, and power distri-
bution box).
If necessary, back up files before shutting down.

Installation and operation precautions Important notes
20 U41858-J-Z126-2-76
2.3.2 Maintenance
wWARNING!
All maintenance measures which are described in this manual may only be
performed by the Customer Support. Incorrect performance of these tasks may
cause electric shock, injury, or fire.
– Installation and reinstallation of all components, and initial settings
– Removal of front, rear, or side covers
– Mounting/de-mounting of optional internal devices
– Plugging or unplugging of external interface cables
– Maintenance and inspections (repairing, and regular diagnostics and mainte-
nance)
vCAUTION!
All maintenance measures for this product and the optional products of the
manufacturer may only be performed by Customer Support. Users must not
perform these tasks. Incorrect operation of these tasks may cause malfunction.
2.4 Installation and operation precautions
vCAUTION!
Equipment damage:
Be sure to follow the precautions below when installing or operating the equipment.
Otherwise, the SE server may be damaged.
