Installation Guide
FUJITSU PCI GigabitEthernet 2.4
for Solaris ™ Operating System
This Product is designed, developed and manufactured as contemplated for general use, including without limitation,
general office use, personal use, household use, and ordinary industrial use, but is not designed, developed and
manufactured as contemplated for use accompanying fatal risks or dangers that, unless extremely high safety is
secured, could lead directly to death, personal injury, severe physical damage or other loss (hereinafter “High Safety
Required Use”), including without limitation, nuclear reaction control in nuclear facility, aircraft flight control, air
traffic control, mass transport control, medical life support system, missile launch control in weapon system. You
shall not use this Product without securing the sufficient safety required for the High Safety Required Use. If you
wish to use this Product for High Safety Required Use, please consult with our sales representatives in charge before
such use.
FUJITSU and the FUJITSU logo are trademarks of Fujitsu Limited.
UNIX is a registered trademark of The Open Group in the United States and other countries.
Sun, Sun Microsystems, the Sun Logo, Solaris and all Solaris based marks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and other countries, and are used under license.
Microsoft is a registered trademark of Microsoft Corporation in the U.S. and other countries.
Netscape, Netscape Navigator, Netscape Communications are trademarks or registered trademarks of Netscape
Communications Corporation in the U.S. and other countries.
All other products names mentioned herein are trademarks or registered trademarks of their respective owners.
All Rights Reserved, Copyright © FUJITSU LIMITED 2006
1 Program Components
This software is comprised of the following packages.
Solaris TM Operating System is written Solaris OS in this manual.
No. Directory Package Name Version Function Contents
FJSVgid.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2) Driver
1 2.6_7
FJSVgidx.us
2.0
GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2) 64bit Driver
Only for
Solaris 2.6 OS,
Solaris 7 OS
FJSVgid.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1),
PRIMEPOWER250/450 secondary LAN
port Driver
FJSVgidx.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1),
PRIMEPOWER250/450 secondary LAN
port 64bit Driver
2 8
FJSVgidr.us
2.0
GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1),
PRIMEPOWER250/450 secondary LAN
port etc files
Only for
Solaris 8 OS
1

No. Directory Package Name Version Function Contents
FJSVgidad.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1),
PRIMEPOWER250/450 secondary LAN
port addon files
FJSVgid.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1) Driver
FJSVgidx.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1) 64bit Driver
FJSVgidr.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1) etc files
3 9
FJSVgidad.us
2.1
GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1) addon files
Only for
Solaris 9 OS
FJSVgid.us GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1) Driver
4 10
FJSVgidad.us
2.2
GigabitEthernet card
(PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1) addon files
Only for
Solaris 10 OS
5 PRIMEPOWER
1_100 FJSVgid.u 2.0 GigabitEthernet card (PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2) Driver
For
PRIMEPOWER
1/100
2 Applicable Manuals
2.1 Online Manuals
The following online manual, in HTML format, is stored on the CD-ROM with the packages.
This online manual can be referred to either directly from the CD-ROM or copied to your hard disk.
No. Manual title
1 FUJITSU PCI GigabitEthernet 2.4 User's Guide
You can refer to the above listed online manuals on a servers or a PC by using a Web browser that supports
HTML3.2.
E.g. Microsoft ® Internet Explorer V3.0 or later, Netscape Navigator ® V3.0 or later, or Netscape ® Communicator
V4.0 or later.
The PDF manual can be available from below URL.
http://www.fujitsu.com/global/support/computing/server/unix/driver/
2.1.1 On a PC
1. Insert CD-ROM into the CD-ROM drive unit.
2. Open the following file using the Web browser.
CD-ROM_Drive_Name:/manual/english/index.htm
2.1.2 On a server
1. Insert CD-ROM into the CD-ROM drive unit on the server.
2. If the CD-ROM has not been mounted, mount it.
3. Open the following file using the Web browser.
/Mount_Point/manual/english/index.htm
2

2.2 Printed Documentation (Appended Papers)
Not supplied.
3 Operating Environment
To use this software, the following software and hardware requirements must be met.
3.1 Software Environment
1) Basic software prerequisites
Before you can use this software, one of the following Basic Software products must have been installed on the
system.
No. Name of Basic Software Remarks
1 Solaris 2.6 OS -
2 Solaris 7 OS -
3 Solaris 8 OS -
4 Solaris 9 OS -
5 Solaris 10 OS -
2) Software requirements
When you use the error notification function (addon function), please be sure to install Enhanced Support Facility
before installing this package.
3) Exclusive software
None.
4) Patch requirements
By the application of this patch, the new function of FUJITSU PCI GigabitEthernet 2.4 is validated.
No. Patch ID Remarks
1 912784-03 For Solaris 2.6 OS or Solaris 7 OS.
This patch is applied by automatic install at "6.2 Installing Software".
2 114536-12 For Solaris 8 OS.
This patch is applied by automatic install at "6.2 Installing Software"
3 114994-12 For Solaris 9 OS.
This patch is applied by automatic install at "6.2 Installing Software".
4 120462-05 For Solaris 10 OS.
This patch is applied by automatic install at "6.2 Installing Software".
5 913306-03 It must be required only this patch when the using machine is
PRIMEPOWER 1 or PRIMEPOWER 100. Also, above 1, 2, 3, 4
patches are not required.
This patch is applied by automatic install at "6.2 Installing Software".
When executing the DR(Dynamic Reconfiguration) function or PCI Hot Plug function with Quad
GigabitEthernet(PW008QG1), the following patches are needed.
No. Patch ID Remarks
1 912680-04 On Solaris 9 OS installed with ESF2.3 system, when DR(Dynamic
Reconfiguration) function is executed to the system board installing
Quad GigabitEthernet card (PW008QG1), this patch is needed.
2 913371-03 On Solaris 9 OS installed with ESF2.4 or ESF2.4.1 system, when
DR(Dynamic Reconfiguration) function is executed to the system
board installing Quad GigabitEthernet card (PW008QG1), this patch
is needed.
3 913732-02 On Solaris 9 OS installed with ESF2.5 or ESF2.5.1 system, when
DR(Dynamic Reconfiguration) function is executed to the system
3

board installing the Quad GigabitEthernet card (PW008QG1), this
patch is needed.
4 110900-12 On Solaris 8 OS, when PCI Hot Plug function is executed to the Quad
GigabitEthernet card (PW008QG1), this patch is needed.
5 112838-11 On Solaris 9 OS, when PCI Hot Plug function is executed to the Quad
GigabitEthernet card (PW008QG1), this patch is needed.
6 118822-11 On Solaris 10 OS, when PCI Hot Plug function is executed to the
Quad GigabitEthernet card (PW008QG1), this patch is needed.
5) Unified Installer
* Related Files
Below files are included. The file path is from CD-ROM root.
- ./.FJSVclis/Disk1/cdsetup : The script for information about Product CD.
- ./.FJSVclis/Product1/prodsetup : The script to install Product CD.
- ./.FJSVclis/Product1/admin : The file for package adding.
- ./.FJSVclis/Config1/I08FJSVgid.sh : The script to set the operating mode.
- ./.FJSVclis/Config1/FJSVgid_config_readme.txt : Readme file of the script to set the operating mode.
- ./.FJSVclis/Config1/config/fjgi.sh : The script for auto setting used by I08FJSVgid.sh.
* Precondition
The files cdsetup and prodsetup are created in order to be called from the Unified installer.
* Required Product
- Enhanced Support Facility
When you install this CD-ROM by Unified Installer, please carry out to the host in whom required product has
simultaneously or already been installed.
3.2 Hardware Environment
The following hardware environments are required to use this software.
1) Main memory
Main memory of 64M bytes or more is required.
2) Hardware requirements
The following table shows the I/O devices that can use this software.
No. Device Name Model Remarks
1 GigabitEthernet Card PW008GE4/PW0G8GE1/PW008GE5/
PW0G8GE2/PW008QG1 -
2 GigabitEthernet Port PRIMEPOWER250/450 secondary LAN port -
Make sure that the above-mentioned GigabitEthernet card is set up before installing this software and complete card
recognition by "boot -r" command.
3.3 Static Disk Resources
The disk space requirements for this software are shown below.
3.3.1 Disk space requirements
The following table lists the disk space requirements for installing this software. If necessary, expand the size of the
appropriate file systems.
No. Directory Disk Space Requirement (in megabytes) Remarks
1 / 0.4 -
2 /usr 0 -
3 /var 0.1 -
4

4 /opt 0.1 -
3.3.2 Work area requirements
None.
3.4 Dynamic Disk Resources
None.
3.5 Memory Requirements
The following table shows the memory required when you use this software for the following operations.
No. Memory required
(unit:megabytes) Operation
1 9 GigabitEthernet based communication
*This value shows required memory per a port.In Quad GigabitEthernet card(PW008QG1), about 36 megabytes
memory size is required for a card.
3.6 Swap Space
Swap space is not used.
4 Restrictions and Notes
4.1 Restrictions
A JumboFrame function or VLAN interface cannot be used for the private LAN of "SynfinityCluster" and the
cluster interconnect of "PRIMECLUSTER".
•
•VLAN interface cannot be used with "SynfinityLINK" and "PRIMECLUSTER GLS" (But, PRIMECLUSTER
GLS 4.1A30 or later only Fast switching mode or NIC switching mode can use VLAN interface.).
4.2 Notes
4.2.1 About packages
In case of using on PRIMEPOWER1 or PRIMEPOWER100, please be sure to install the package for
PRIMEPOWER1/100 (a procedure is referring to "6. Installation Procedures"). And on other machines, please be
sure to install the package for each Solaris OS of use (a procedure is referring to " 6.2 Installing Software "). In
addition, the packages for Solaris 8 OS are not able to be installed in Solaris 7 OS.
4.2.2 Using PRIMECLUSTER GLS 4.0 (Multipath Function)
When using PRIMECLUSTER GLS 4.0 (Multipath Function), it is needed 911872-03 or later patch.
4.2.3 Using PRIMECLUSTER GLS 4.1 (Multipath Function)
When using PRIMECLUSTER GLS 4.1 (Multipath Function), it is needed 912419-02 or later patch.
4.2.4 Static electrocity (PW008GE5/PW0G8GE2 and PW008QG1)
Twisted-pair cables may be charged with static electricity due to environment. If the electrified cables are
continuously used, system and/or LAN interface of system may be damaged, or may malfunction. When you newly
install or move the cables, it is necessary to remove static electricity from the cables. In Japan, you can order
tool(TS2002-001) in order to remove static electricity. In other countries, please consult with your local service.
4.2.5 About VLAN function and LinkAggregation function and Quad
GigabitEthernet support
VLAN(Virtual LAN) function can be used in Solaris 8 OS or later.
5

LinkAggregation function can be used in Solaris 8 OS or later 64bit mode.
The Quad GigabitEthernet card (PW008QG1) can be used only in Solaris 8 OS or later, and with PRIMEPOWER
250/450/650/850/900/1500/2500/HPC2500.
5 Procedure of Installation
(1) If the system is powered on, ask the system administrator to shut down the OS and power off the system.
(2) Disconnect the power supply cord or turn off the main line switch of the product that Gigabit Ethernet Card is
installed to reduce the electric hazard.
(3) Install the card according to the installation instruction of the products that the card is installed.
(4) Connect the power supply cord of the product to the supply or turn on the main line switch of the product.
(5) Power the system on after confirming the proper installing in accordance with the installation instruction of the
products.
* When the card is installed in the PCI HOT-SWAP System product, install it in the card slot which carried out the
power supply cut according to installation instruction of the product.
6 Installation Procedures
To install this software, use the procedures described below.
6.1 Preparing for Installation
6.1.1 Checking the system environment
Check there is sufficient disk space to install this software. For more detailed information on the disk space
requirements, see "3.3 Static Disk Resources". If the disk space, for installing this software, is insufficient,
reconfigure the disk partition.
6.1.2 Installation time
It takes about 2 minutes to install this software (rebooting time not included).
6.2 Installing Software
1. Log in to your system as superuser.
# su <Return>
2. Insert CD-ROM into the CD-ROM drive unit and type the following command.
# mkdir -p /cdrom/cdrom0 <Return> (*1)
# /usr/sbin/mount -F hsfs -o ro /dev/dsk/c0t4d0s2 /cdrom/cdrom0 <Return> (*2)
(*1) required if "/cdrom/cdrom0" does not exist.
(*2) /dev/dsk/c0t4d0s2 is the example of the name to specify. This name changes with systems.
3. Install the package and required patch.
By below automatic installation, considering a machine, a Solaris OS version and a patch level, the packages
and a required patch are applied automatically.
# cd /cdrom/cdrom0 <Return>
# ./install <Return>
6.3 Environment Setting after Installation
1. When you install to the machine using
system-console(SMC)"PW800/PW900/PW1000/PW2000/PW1500/PW2500..", with the command below
after installation, please insert a CD-ROM in the CD-ROM equipment of SMC, and copy "fjgi_s.dat",
"fjgi_t.dat" and "fjgi_q.dat" files in CD-ROM to /opt/FJSVcsl/etc/scsidata/of SMC.
6

If using PW008GE4/PW0G8GE1/PW008GE5/PW0G8GE2 and using SCS2.3 or later, this operation is not
required. And, if using PW008QG1 and using SCS2.5.1 or later, this operation is not required.
# cp /cdrom/cdrom0/FJSVgid_2.4/fjgi_s.dat /opt/FJSVcsl/etc/scsidata/fjgi_s.dat
# cp /cdrom/cdrom0/FJSVgid_2.4/fjgi_t.dat /opt/FJSVcsl/etc/scsidata/fjgi_t.dat
# cp /cdrom/cdrom0/FJSVgid_2.4/fjgi_q.dat /opt/FJSVcsl/etc/scsidata/fjgi_q.dat
2. When you use GigabitEthernet on "SynfinityCluster" or "PRIMECLUSTER", please refer to "Appendix C.3
Note" in "FUJITSU PCI GigabitEthernet 2.4 User's Guide" for detailed information about the setting and
notes.
3. When the installation program is finished, the system must be rebooted.
4. After you reboot the system, environment setting is needed. Refer to "FUJITSU PCI GigabitEthernet 2.4
User's Guide" for detailed information about the setting.
6.4 Removing the Software
1. Log in to your system as superuser.
# su <Return>
2. Type pkgrm(1M) command.
(1) In case of using on PRIMEPOWER1 or PRIMEPOWER100
# pkgrm FJSVgid <Return>
(2) In case of using on other machines
*Solaris 2.6 OS :
# pkgrm FJSVgid <Return>
*Solaris 7 OS :
# pkgrm FJSVgid <Return>
# pkgrm FJSVgidx <Return>
*Solaris 8 OS :
# pkgrm FJSVgid <Return>
# pkgrm FJSVgidx <Return>
# pkgrm FJSVgidr <Return>
# pkgrm FJSVgidad <Return>
*Solaris 9 OS :
# pkgrm FJSVgid <Return>
# pkgrm FJSVgidx <Return>
# pkgrm FJSVgidr <Return>
# pkgrm FJSVgidad <Return>
*Solaris 10 OS:
# pkgrm FJSVgid <Return>
# pkgrm FJSVgidad <Return>
7
