User Guide
LTO-5Half-Height
SAS Tape Drive
English

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected]ujitsu.com.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2010 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
© Copyright 2010 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP
products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Linear Tape-Open, LTO, LTO Logo, Ultrium and Ultrium Logo are trademarks of Quantum, HP
and IBM in the US, other countries or both.
Patented under one or more of U.S. Patents Nos. 5,003,307; 5,016,009; 5,463,390; 5,506,580;
held by Hi/fn, Inc.
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.
UNIX® is a registered trademark of The Open Group.
Parts © Copyright 2009 Fujitsu Technology Solutions

LTO-5 Half-Height SAS Tape Drives
Contents
Intended audience . . . . . . . . . . . . . . . . . . . . . . . . . 5
Document conventions and symbols . . . . . . . . . . . . . . . 5
1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Your LTO-5 tape drive . . . . . . . . . . . . . . . . . . . . . . 7
1.2 How do I connect the drive to my server? . . . . . . . . . . . 8
1.3 Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.1 Installing on Windows . . . . . . . . . . . . . . . . . . . . . . . 9
1.3.2 Installing on Red Hat Enterprise Linux . . . . . . . . . . . . . . 9
2 Verify installation . . . . . . . . . . . . . . . . . . . . . . . . 11
3 Operating your tape drive . . . . . . . . . . . . . . . . . . . 13
3.1 Loading a cartridge . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Unloading a cartridge . . . . . . . . . . . . . . . . . . . . . 14
3.3 Removing power from the drive . . . . . . . . . . . . . . . . 14
4 Cautions concerning backup . . . . . . . . . . . . . . . . . 15
4.1 Ejecting the data cartridge after backup . . . . . . . . . . . 15
4.2 Data compression rate . . . . . . . . . . . . . . . . . . . . . 15
4.3 Backup performance/capacity . . . . . . . . . . . . . . . . . 16
4.4 Points to note during system configuration . . . . . . . . . 16
5 Use the correct media . . . . . . . . . . . . . . . . . . . . . 17
5.1 Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1.1 Cleaning cartridges . . . . . . . . . . . . . . . . . . . . . . . 17
5.1.2 Data cartridges . . . . . . . . . . . . . . . . . . . . . . . . . 17

LTO-5 Half-Height SAS Tape Drives
5.2 Cartridge life . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.3 Write protecting cartridges . . . . . . . . . . . . . . . . . . . 19
5.4 WORM data cartridges . . . . . . . . . . . . . . . . . . . . . 20
5.5 LTO-5 tape drives and encryption . . . . . . . . . . . . . . . 20
5.5.1 When should I use encryption? . . . . . . . . . . . . . . . . . . 21
5.5.2 How do I enable encryption? . . . . . . . . . . . . . . . . . . . 21
5.5.3 What happens if I don't remember the key? . . . . . . . . . . . 21
5.5.4 Does encryption affect tape drive performance? . . . . . . . . . 21
5.5.5 Does the tape drive encrypt media in an earlier LTO format? . . 22
5.5.6 Where can I get more information? . . . . . . . . . . . . . . . . 22
5.6 Cleaning the tape drive . . . . . . . . . . . . . . . . . . . . . 23
5.7 Handling cartridges . . . . . . . . . . . . . . . . . . . . . . . 23
5.8 Storage environment . . . . . . . . . . . . . . . . . . . . . . 24
6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1 General Procedure . . . . . . . . . . . . . . . . . . . . . . . 25
6.2 Understanding LED sequences . . . . . . . . . . . . . . . . 27
6.2.1 Encryption LED . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.3 Problems with cartridges . . . . . . . . . . . . . . . . . . . . 32
6.3.1 The cartridge is jammed . . . . . . . . . . . . . . . . . . . . . 32
6.3.2 The drive will not accept the cartridge (or ejects it immediately) . 34

LTO-5 Half-Height SAS Tape Drives 5
About this guide
This guide provides information about:
●Installing the LTO-5 SAS half-height tape drive
●Using the LTO-5 SAS half-height tape drive
●Troubleshooting the LTO-5 SAS half-height tape drive
Intended audience
This guide is intended for users who install, operate and maintain the LTO-5
half-height tape drive.
Document conventions and symbols
Convention Element
Blue text: table 1 on page 5 Cross-reference links and e-mail addresses
Bold text ●Keys that are pressed
●Text typed into a GUI element, such as a box
●GUI elements that are clicked or selected,
such as menu and list items, buttons, tabs,
and check boxes
Italic text Text emphasis
Monospace text ●File and directory names
●System output
●Code
●Commands, their arguments, and argument
values
Monospace, italic text ●Code variables
●Command variables
Monospace, bold text Emphasized monospace text
Table 1: Document conventions

6 LTO-5 Half-Height SAS Tape Drives
WWARNING! Indicates that failure to follow directions could result
in bodily harm or death.
VCAUTION: Indicates that failure to follow directions could result
in damage to equipment or data.
IIMPORTANT: Provides clarifying information or specific
instructions.
NOTE: Provides additional information.

LTO-5 Half-Height SAS Tape Drives 7
1 Getting started
In this chapter:
●"Your LTO-5 tape drive" on page 7
●"How do I connect the drive to my server?" on page 8
1.1 Your LTO-5 tape drive
Figure 1: Front view of LTO–5 SAS tape drive
1. Drive door 5. Drive LED
2. Encryption LED 6. Ready LED
3. Clean LED 7. Eject button
4. Tape LED

8 LTO-5 Half-Height SAS Tape Drives
How do I connect the drive to my server?
1.2 How do I connect the drive to my server?
The tape drive is installed into a 5¼-inch drive bay in your server and is attached
to the host server's internal SAS controller or SAS host bus adapter, as
illustrated below.
Connect a spare power cable from the server's internal power supply to the
power connector on the SAS data cable.
Figure 2: Connecting cables to the LTO—5 tape drive
1. Power connector on data cable 2. SAS connector to tape drive (SFF-8482
SAS cable with power)

LTO-5 Half-Height SAS Tape Drives 9
Drivers
1.3 Drivers
The driver can be obtained from the Fujitsu ServerView Suite DVD, for updates
please check http://support.ts.fujitsu.com. Refer also to the documentation of your
software application to ensure you are using the recommended driver.
1.3.1 Installing on Windows
Install as instructed in the readme file in the drivers directory.
1.3.2 Installing on Red Hat Enterprise Linux
Drivers are included with the operating system and should be loaded
automatically.

10 LTO-5 Half-Height SAS Tape Drives
Drivers

LTO-5 Half-Height SAS Tape Drives 11
2 Verify installation
Once you have installed the drive hardware, check that drivers have been
installed correctly and you have the correct version of backup software, and
verify that the tape drive is functioning properly before you store your valuable
data.
1. Switch on the server.
2. The tape drive will run its hardware self-test, which takes about 5 seconds.
If self-test passes, the green Ready LED flashes and then shows steady
green. If the test fails, the Drive and Tape LEDs flash, while the Ready and
Clean LEDs are off. This continues until the drive is reset. See
"Understanding LED sequences" on page 27 for more information about
front panel LEDs.
●If you installed drivers before connecting the tape drive (Windows
only)
The tape drive should be detected automatically and the correct drivers
used.
●Installing drivers after connecting the tape drive (Windows only)
If you have not already installed drivers, install the driver according to the
supplied documentation
in the driver's folder.
●Installing drivers (other operating systems)
Drivers are included with the operating system and should be loaded
automatically.
NOTE:
Certain backup applications require you to use their own Tape driver.
3. Verify that the tape drive installation was successful.
4. For all operating systems ensure that you have downloaded any upgrades
necessary for your backup application.

12 LTO-5 Half-Height SAS Tape Drives

LTO-5 Half-Height SAS Tape Drives 13
3 Operating your tape drive
In this chapter:
●"Loading a cartridge" on page 13
●"Unloading a cartridge" on page 14
●"Removing power from the drive" on page 14
3.1 Loading a cartridge
1. Lift the drive door and insert the cartridge into the slot in the front of the drive
with the arrow uppermost and facing the drive slot.
Figure 3: Inserting a cartridge
2. Apply gentle pressure until the drive takes the cartridge and loads it.
3. The Ready LED flashes green while the drive performs its load sequence.
When the cartridge is loaded, the Ready LED shows steady green.
1. Arrow indicates leading direction 2. Label area
3. Drive door 4. Ready LED

14 LTO-5 Half-Height SAS Tape Drives
Unloading a cartridge
3.2 Unloading a cartridge
VCAUTION:
Never try to remove a cartridge before it is fully ejected.
1. Press the Eject button on the front panel.
Figure 4: Ejecting a cartridge
1. Eject button
2. The drive will complete its current task, rewind the tape to the beginning, and
eject the cartridge. The rewind process may take up to 10 minutes. The
Ready LED will flash to indicate that the unload is still in progress.
3.3 Removing power from the drive
To ensure reliable operation, do not remove power from the drive during read,
write, fast-search, load and unload activities.

LTO-5 Half-Height SAS Tape Drives 15
4 Cautions concerning backup
In this chapter:
●"Ejecting the data cartridge after backup" on page 15
●"Data compression rate" on page 15
●"Backup performance/capacity" on page 16
●"Points to note during system configuration" on page 16
4.1 Ejecting the data cartridge after backup
●Do not leave the data cartridge in this product.
Doing so makes the data cartridge wear faster, because the longer it is used,
the faster it wears. The tape recording surface of the data cartridge is
exposed when inserted in this product and if it is left in this state for a long
time it will easily be affected by suspended particles of dust. Insert the data
cartridge just before the backup operation, and remove it immediately after
the operation.
●Do not turn off the power with the data cartridge inserted.
If the power is turned off with the data cartridge inserted, it takes a while
before this product can be used after the next power-on.
4.2 Data compression rate
This product has a data compression function included in the hardware.
Although the data compression rate is approximately 200%, it varies depending
on the data content.
Data that has already been compressed by software is not effected by this
product.
Some backup software has a data compression function prior to transfer,
however, do not compress data by software if the hardware compression
function is on.

16 LTO-5 Half-Height SAS Tape Drives
Backup performance/capacity
4.3 Backup performance/capacity
The backup performance and backup capacity that can be used in one data
cartridge varies depending upon the following factors:
●The conditions (attrition, dust, etc.) of the recording surface of the data
cartridge to be used
●The dust and dirt condition of the product's magnetic head
●The data compression rate
●The workload on the server
4.4 Points to note during system configuration
When repeatedly using a single data cartridge, all the data can be lost if the
backup fails. Also, if a backup data cartridge becomes damaged, the data
cannot be recovered.
Damage in the event of a failure can be minimized if two or more data cartridges
are used for backup operation. For example, use different data cartridges for
each day of the week.

LTO-5 Half-Height SAS Tape Drives 17
5 Use the correct media
In this chapter:
●"Cartridges" on page 17
●"Cartridge life" on page 18
●"Write protecting cartridges" on page 19
●"WORM data cartridges" on page 20
●"LTO-5 tape drives and encryption" on page 20
●"Cleaning the tape drive" on page 23
●"Handling cartridges" on page 23
●"Storage environment" on page 24
5.1 Cartridges
5.1.1 Cleaning cartridges
Use the universal cleaning cartridge. It may be used for up to 50 cleans.
5.1.2 Data cartridges
LTO–5 tape drives use LTO Ultrium 5 tape cartridges. These are single-reel
cartridges that match your drive's format and are optimized for high capacity,
throughput and reliability. Compatible media can be recognized by the Ultrium
logo, which is the same as the logo on the front of your drive. Do not use other
format cartridges in your tape drive and do not use LTO Ultrium 5 cartridges in
other format tape drives.
To achieve best performance we recommend using only “Fujitsu — Preferred
Quality” LTO Media cartridges.
For optimum performance always use LTO Ultrium 5 data cartridges because
they match the specification of your tape drive. A lower specification will have a
lower transfer speed and may not support write activities; a higher specification
will not support read or write.

18 LTO-5 Half-Height SAS Tape Drives
Cartridge life
The drive supports the following LTO data cartridges:
5.2 Cartridge life
To avoid a backup failure due to worn media, replace the media (data cartridge)
before either of the following occur:
●After one year of use
●After being used 1000 times
The lifespan of media varies depending on the environment (temperature,
humidity, dust, etc.) and operating conditions of this product.
IIMPORTANT:
The data cartridge is a replaceable part. Worn media can cause
problems such as magnetic tape surface damage, dirty magnetic head,
many media errors, and so on. See also "Problems with cartridges" on
page 32.
LTO Ultrium 5 data cartridges 1500 GB (3000 GB at 2:1
compression)
Read/Write
LTO Ultrium 4 data cartridges 800 GB (1600 GB at 2:1
compression)
Read/Write
LTO Ultrium 3 data cartridges 400 GB (800 GB at 2:1
compression)
Read only
LTO Ultrium 2 data cartridges are not supported
LTO Ultrium 1 data cartridges are not supported
Table 2: Supported data cartridges

LTO-5 Half-Height SAS Tape Drives 19
Write protecting cartridges
5.3 Write protecting cartridges
WWARNING!
Always remove the cartridge from the tape drive before you change the
write protection.
If you want to protect the data on a cartridge from being altered or overwritten,
you can write protect the cartridge.
●To write protect a cartridge, push the switch to the right to prevent any data
recording on the cartridge. Note the padlock on the tab that indicates that the
cartridge is protected.
●To write enable a cartridge, push the switch to the left to allow data recording
on the cartridge. Figure 5 on page 19 illustrates the location of the write-
protect tab.
Figure 5: Write protecting a cartridge
1. Write-protect tab

20 LTO-5 Half-Height SAS Tape Drives
WORM data cartridges
VCAUTION:
Write-protection will not protect your cartridges against magnets. Write-
protection will not prevent a cartridge being erased by bulk-erasure or
degaussing. Do not bulk erase LTO format cartridges. This will destroy
pre-recorded servo information and make the cartridge unusable.
5.4 WORM data cartridges
The LTO–5 tape drive includes support for both re-writable and Write-Once,
Read-Many, WORM, data cartridges. WORM cartridges provide an enhanced
level of data security against accidental or malicious alteration of data on the
tape cartridge. The WORM data cartridge can be appended to maximize the full
capacity of the tape cartridge, but the user will be unable to erase or overwrite
data on the cartridge. Any attempt to modify a WORM cartridge to enable
writing over existing data will result in the media becoming permanently write
protected. It should still be readable in a WORM drive, depending upon the
severity of the tampering, but no further appended backups will be possible.
WORM data cartridges are clearly identified by their distinctive, two-tone
cartridge color. They can only be used with LTO tape drives that support the
WORM feature.
To check whether your backup or archive software application supports WORM
cartridges, refer to the software manual.
5.5 LTO-5 tape drives and encryption
The LTO–5 tape drive includes hardware capable of performing data encryption
at full speed while writing data, and decrypting when reading.
Encryption is the process of changing data into a form that cannot be read until
it is deciphered, protecting the data from unauthorized access and use. LTO–5
tape drives use the strongest version of the industry-standard AES encrypting
algorithm to protect your data.
To make use of this feature you need:
●A backup application that supports hardware encryption
●LTO Ultrium 5 media (recommended) or LTO Ultrium 4 media; no encryption
will be performed when writing earlier generations of tape
