C141-E128-01EN
MAN3735MC/MP SERIES
MAN3367MC/MP SERIES
MAN3184MC/MP SERIES
DISK DRIVES
PRODUCT/MAINTENANCE MANUAL

C141-E128-01EN
FOR SAFE OPERATION
Handling of This manual
This manual contains important information for using this product. Read thoroughly before using the
product. Use this product only after thoroughly reading and understanding especially the section
“Important Alert Items” in this manual. Keep this manual handy, and keep it carefully.
FUJITSU makes every effort to prevent users and bystanders from being injured or from suffering damage
to their property. Use the product according to this manual.
IMPORTANT NOTE TO USERS
READ THE ENTIRE MANUAL CAREFULLY BEFORE USING THIS PRODUCT.
INCORRECT USE OF THE PRODUCT MAY RESULT IN INJURY OR DAMAGE
TO USERS, BYSTANDERS OR PROPERTY.
While FUJITSU has sought to ensure the accuracy of all information in this manual, FUJITSU assumes no
liability to any party for any damage caused by any error or omission contained in this manual, its updates
or supplements, whether such errors or omissions result from negligence, accident, or any other cause. In
addition, FUJITSU assumes no liability with respect to the application or use of any porduct or system in
accordance with the descriptions or instructions contained herein; including any liability for incidental or
consequential damages arising therefrom.
FUJTSU DISCLAIMS ALL WARRANTIES REGARDING THE INFORMATION CONTAINED
HEREIN, WHETHER EXPRESSED, IMPLIED, OR STATUTORY.
FUJITSU reserves the right to make changes to any products described herein without further notice and
without obligation.
This product is designed and manufactured for use in standard applications such as office work, personal
devices and household appliances. This product is not intended for special uses (atomic controls,
aeronautic or space systems, mass transport vehicle operating controls, medical devices for life support, or
weapons firing controls) where particularly high reliability requirements exist, where the pertinent levels of
safety are not guaranteed, or where a failure or operational error could threaten a life or cause a physical
injury (hereafter referred to as "mission-critical" use). Customers considering the use of these products for
mission-critical applications must have safety-assurance measures in place beforehand. Moreover, they are
requested to consult our sales representative before embarking on such specialized use.
The contents of this manual may be revised without prior notice.
The contents of this manual shall not be disclosed in any way or reproduced in any media without the
express written permission of Fujitsu Limited.
All Right Reserved, Copyright © FUJITSU LIMITED 2001

C141-E128-01EN i
REVISION RECORD
Edition Date published Revised contents
01 Jun., 2001
Specification No.: C141-E128-**EN

ii C141-E128-01EN
Related Standards
Specifications and functions of products covered by this manual comply with the following
standards.
Standard (Text) No. Name Enacting Organization
ANSI X3.131-1986 American National Standard for
Information Systems—Small Computer
System Interface (SCSI)
American National
Standards Institute
(ANSI)
ANSI X3.131-1994 American National Standard for
Information Systems—Small Computer
System Interface - 2(SCSI-2)
American National
Standards Institute
(ANSI)
X3T9.2/85-52 Rev 4.B COMMON COMMAND SET (CCS)
of the Small Computer
System Interface (SCSI)
American National
Standards Institute
(ANSI)
X3T9.2/855D Rev 12 WORKING DRAFT Information
Technology SCSI-3 Parallel Interface
American National
Standards Institute
(ANSI)
T10/1236-D Rev 12 WORKING DRAFT Information
technology SCSI Primary Commands-2
(SPC-2)
American National
Standards Institute
(ANSI)
ANSI NCITS 306-199x American National Standard for
Information Technology—SCSI-3 Block
Commands (SBC)
American National
Standards Institute
(ANSI)
X3T10/994D Rev 18 WORKING DRAFT Information
technology SCSI-3 Architecture Model
(SAM)
American National
Standards Institute
(ANSI)
T10/1302D Rev 11 WORKING DRAFT Information
technology SCSI Parallel Interface-3
(SPI-3)
American National
Standards Institute
(ANSI)

C141-E128-01EN iii
PREFACE
This manual describes the MAN3735MC/MP, MAN3367MC/MP, MAN3184MC/MP (hereafter, MAN
series), 3.5 type fixed disk drives with an embedded SCSI controller.
This manual details the specifications and functions of the above disk drive, and gives the requirements and
procedures for installing it into a host computer system.
This manual is written for users who have a basic understanding of fixed disk drives and their use in
computer systems. The MANUAL ORGANIZATION section describes organization and scope of this
manual. The need arises, use the other manuals.
Chapter 1 GENERAL DESCRIPTION
This chapter introduces the MAN series disk drives and discusses their standard features, hardware, and
system configuration.
Chapter 2 SPECIFICATIONS
This chapter gives detailed specifications of the MAN series disk drives and their installation environment.
Chapter 3 DATA FORMAT
This chapter describes the data structure of the disk, the address method, and what to do about media
defects.
Chapter 4 INSTALLATION REQUIREMENTS
This chapter describes the basic physical and electrical requirements for installing MAN series disk drives.
Chapter 5 INSTALLATION
This chapter explains how to install MAN series disk drives. It includes the notice and procedures for
setting device number and operation modes, mounting the disk drive, connecting the cables, and
confirming drive operation.
Chapter 6 DIAGNOSIS and MAINTENANCE
This chapter describes the automatic diagnosis, and maintenance of MAN series disk drive. This chapter
also describes diagnostic methods for operation check and the basics of troubleshooting the disk drives.
Chapter 7 ERROR ANALYSIS
This chapter describes in details how collect the information for error analysis and how analyze collected
error information.
Chapter 8 PRINCIPLE OF OPERATION
This chapter explains disk drives configuration and operation of MAN series.

iv C141-E128-01EN
APPENDIX A to D
The appendixes give supplementary information, including the locations of mounting setting terminals and
connectors, a list of setting items, the signal assignments of interface connectors, lists of model names and
product numbers, and SCSI interface functions.
The model numbers have a suffix that describes the electrical requirements of the SCSI interface between
host system and disk drive, the data formatted at the factory and device type.
CONVENTIONS
This manual uses the following conventions for alerts to prevent physical or property damages to users or
by standards.
DANGER
DANGER indicates that personal injury will occur if the user does not perform the procedure correctly.
WARNING
WARNING indicates that personal injury could occur if the user does not perform the procedure
correctly.
CAUTION
CAUTION indicates that either minor or moderate personal injury may occur if the user does not
perform the procedure correctly.
NOTICE
NOTICE indicates that inconvenience to the user such as damages to the product, equipment, data, and/or
other property may occur if the user does not pay attention or perform the procedure correctly.
IMPORTANT
IMPORTANT indicates information that the helps the user use the product more effectively.
Indicates

C141-E128-01EN v
This manual indicates;
Decimal number: Indicates as it is.
Hexadecimal number: Indicates as X’17B9’, 17B9h, or 17B9H
Binary number: Indicates as “010”
DISCLAIMER
Failure of the MAN series intelligent disk drive is defined as a failure requiring adjustments, repairs, or
replacement. Fujitsu is not responsible for drive failures caused by misuse by the user, poor environmental
conditions, power trouble, host problems, cable failures, or any failure not caused by the drive itself.
The suffix of the model name of the disk drive varies depending on the electrical requirements, capacity,
and data format at factory shipment of the SCSI, i.e., the interface for connecting the three device types or
host system and the disk drives (Note 1). However, in this manual, the typical model names (Note 2) are
used unless otherwise noted. These disk drives may be called intelligent disk drives (IDD), drives, or
devices in this manual.
Note 1: Model names
M AN 3 735 MC
Interface types MC: LVD, 16-bit SCSI SCA2 connector 160MHz transfer
MP: LVD, 16-bit SCSI 68 pin connector 160MHz transfer
Formatted capacity (100 MB units)
Disk drive size 3: 3.5 type. Hand Disk Drive
Type AN: Number of rotations 10,025min-1 (10,025rpm)
Note 2: Type model name
Type model name Model name
MAN3735 MAN3735MC, MAN3735MP
MAN3367 MAN3367MC, MAN3367MP
MAN3184 MAN3184MC, MAN3184MP

vi C141-E128-01EN
Important Alert Items
Important Alert Messages
The important alert messages in this manual are as follows:
A hazardous situation could result in minor or moderate personal injury if the
user does not perform the procedure correctly. This alert signal also indicates
that damages to the product or other property may occur if the user does not
perform the procedure correctly.
Task Alert message Page
Mounting Installation Data loss
For MAN series, Reed Solomon codes are applied for their ECC.
The sector-data is divided into 6 interleaving sectors, and ECC is
performed in each sector where the maximum number of errors (up
to 5 byte) can be corrected. [Total maximum byte: 5 byte
×
6 (
interleave) = 30 byte]
If the error of read sector keeps allowable error byte number,
correction is performed.
However, if error byte exceeds its allowable number, correction
may not be performed properly.
Hot temperature
To prevent injury, do not handle the drive until after the device has
cooled sufficiently after turning off the power. The DE and LSI
become hot during operation and remain hot immediately after
turning off the power.
Data loss
1. The user must not change the setting of terminals not described
in this section. Do not change setting status set at factory
shipment.
2. Do not change the setting of terminals except following setting
pins during the power is turned on.
• Write protect: CN2 9-10 (MP model only)
3. To short the setting terminal, use the short plug attached when
the device is shipped from the factory.
Damage
1. Make sure that system power is off before connecting or
disconnecting cables.
2. Do not connect or disconnect cables when power is on.(except
MC model)
Damage
1. Be careful of the insertion orientation of the SCSI connectors.
With the system in which terminating resistor power is supplied
via the SCSI cable, if the power is turned on, the overcurrent
2-5
5-1
5-5
5-11
5-11

C141-E128-01EN vii
Task Alert message Page
Mounting Installation protection fuse of the terminating resistor power supplier may
be blown or the cable may be burnt if overcurrent protection is
not provided.
When the recommended parts listed in Table 4.2 are used,
inserting the cables in the wrong direction can be prevented.
2. To connect SCSI devices, be careful of the connection position
of the cable. Check that the SCSI device with the terminating
resistor is the last device connected to the cable.
Data loss
When the SEND DIAGNOSTIC command terminates with the
CHECK CONDITION status, the INIT must collect the error
information using the REQUEST SENSE command. The RECEIVE
DIAGNOSTIC RESULTS command cannot read out the error
information detected in the self-diagnostics.
Caution
1. To avoid shocks, turn off the power before connecting or
disconnecting a cable, connector, or plug.
2. To avoid injury, do not touch the mechanical assembly during
disk drive operation.
3. Do not use solvents to clean the disk drive.
Caution
1. Always ground yourself with a wrist strap connected to ground
before handling. ESD (Electrostatics Discharge) may cause
the damage to the device.
2. To prevent electrical damage to the disk drive, turn the power
off before connecting or disconnecting a cable, connector, or
plug.
3. Do not remove a PCA. This operation is required to prevent
unexpected or unpredictable operation.
4. Do not use a conductive cleaner to clean a disk drive assembly.
5. Ribbon cables are marked with a colored line. Connect the
ribbon cable to a cable connector with the colored wire
connected to pin 1.
Damage
Do not open the DE in the field because it is a completely sealed
room.
Data loss
Save data stored on the disk drive before requesting repair. Fujitsu
does not assume responsibility if data is destroyed during servicing
or repair.
Caution
Never open the disk enclosure in the field. Opening the disk
enclosure in the field may cause an irreparable fault.
6-4
6-5
6-6
6-6
6-7
6-15

viii C141-E128-01EN
MANUAL ORGANIZATION
PRODUCT/
MAINTENANCE
MANUAL
(This manual)
1. General Description
2. Specifications
3. Data Format
4. Installation Requirements
5. Installation
6. Diagnostics and Maintenance
7. Error Analysis
8. Principle of Operation
SCSI Physical
Interface
Specifications
1. SCSI Bus
2. SCSI Message
3. SCSI Bus Error Recovery Processing
SCSI Logical
Interface
Specifications
1. Command Processing
2. Data Buffer Management
3. Command Specification
4. Sense Data and error Recovery Procedure
5. Disk Medium Management

C141-E128-01EN ix
CONTENTS
page
CHAPTER 1 GENERAL DESCRIPTION ............................................................................ 1-1
1.1 Standard Features ............................................................................................................. 1-2
1.2 Hardware Structure...........................................................................................................1-5
1.3 System Configuration ....................................................................................................... 1-8
CHAPTER 2 SPECIFICATIONS........................................................................................... 2-1
2.1 Hardware Specifications................................................................................................... 2-1
2.1.1 Model name and part number........................................................................................... 2-1
2.1.2 Function specifications ..................................................................................................... 2-2
2.1.3 Environmental specifications ........................................................................................... 2-4
2.1.4 Error rate........................................................................................................................... 2-5
2.1.5 Reliability ......................................................................................................................... 2-5
2.2 SCSI Function Specifications........................................................................................... 2-7
CHAPTER 3 DATA FORMAT................................................................................................... 3-1
3.1 Data Space ........................................................................................................................ 3-1
3.1.1 Cylinder configuration...................................................................................................... 3-1
3.1.2 Alternate spare area .......................................................................................................... 3-4
3.1.3 Track format ..................................................................................................................... 3-5
3.1.4 Sector format .................................................................................................................... 3-7
3.1.5 Format capacity ................................................................................................................ 3-9
3.2 Logical Data Block Addressing........................................................................................3-10
3.3 Defect Management.......................................................................................................... 3-11
3.3.1 Defect list.......................................................................................................................... 3-11
3.3.2 Alternate block allocation.................................................................................................3-11
CHAPTER 4 INSTALLATION REQUIREMENTS.................................................................4-1
4.1 Mounting Requirements ................................................................................................... 4-1
4.1.1 External dimensions ......................................................................................................... 4-1
4.1.2 Mounting .......................................................................................................................... 4-4
4.1.3 Notes on mounting ........................................................................................................... 4-4
4.2 Power Supply Requirements ............................................................................................ 4-8
4.3 Connection Requirements................................................................................................. 4-11

x C141-E128-01EN
4.3.1 68 pin connector 16-bit SCSI model (MP model) ............................................................ 4-11
4.3.2 SCA2 type SCSI model (MC model) ............................................................................... 4-19
4.3.3 Cable connector requirements .......................................................................................... 4-20
4.3.4 External operator panel (MP model) ................................................................................ 4-22
CHAPTER 5 INSTALLATION .................................................................................................. 5-1
5.1 Notes on Handling Drives ................................................................................................ 5-1
5.2 Connections ...................................................................................................................... 5-3
5.3 Setting Terminals.............................................................................................................. 5-5
5.3.1 SCSI ID setting (MP model only) .................................................................................... 5-6
5.3.2 Each mode setting (MP model only) ................................................................................5-7
5.3.3 Mode settings.................................................................................................................... 5-9
5.4 Mounting Drives............................................................................................................... 5-10
5.4.1 Check before mounting .................................................................................................... 5-10
5.4.2 Mounting procedures........................................................................................................5-10
5.5 Connecting Cables............................................................................................................5-11
5.6 Confirming Operations after Installation and Preparation for use.................................... 5-12
5.6.1 Confirming initial operations............................................................................................ 5-12
5.6.2 Checking SCSI connection............................................................................................... 5-13
5.6.3 Formatting ........................................................................................................................ 5-16
5.6.4 Setting parameters ............................................................................................................ 5-18
5.7 Dismounting Drives.......................................................................................................... 5-22
5.8 Spare Disk Drive .............................................................................................................. 5-22
CHAPTER 6 DIAGNOSTICS AND MAINTENANCE............................................................ 6-1
6.1 Diagnostics ....................................................................................................................... 6-1
6.1.1 Self-diagnostics ................................................................................................................ 6-1
6.1.2 Test programs ................................................................................................................... 6-4
6.2 Maintenance Information ................................................................................................. 6-5
6.2.1 Precautions ....................................................................................................................... 6-5
6.2.2 Maintenance requirements................................................................................................ 6-6
6.2.3 Maintenance levels ........................................................................................................... 6-8
6.2.4 Revision numbers ............................................................................................................. 6-9
6.2.5 Tools and test equipment .................................................................................................. 6-10
6.2.6 Tests.................................................................................................................................. 6-10
6.3 Operation Check............................................................................................................... 6-12

C141-E128-01EN xi
6.3.1 Initial seek operation check ..............................................................................................6-12
6.3.2 Operation test.................................................................................................................... 6-12
6.3.3 Diagnostic test .................................................................................................................. 6-12
6.4 Troubleshooting Procedures ............................................................................................. 6-13
6.4.1 Outline of troubleshooting procedures ............................................................................. 6-13
6.4.2 Troubleshooting with disk drive replacement in the field ................................................ 6-13
6.4.3 Troubleshooting at the repair site ..................................................................................... 6-15
6.4.4 Troubleshooting with parts replacement in the factory .................................................... 6-16
6.4.5 Finding possibly faulty parts ............................................................................................ 6-16
CHAPTER 7 ERROR ANALYSIS ......................................................................................... 7-1
7.1 Error Analysis Information Collection ............................................................................. 7-1
7.1.1 Sense data ......................................................................................................................... 7-1
7.1.2 Sense key, sense code, and subsense code .......................................................................7-1
7.2 Sense Data Analysis ......................................................................................................... 7-3
7.2.1 Error information indicated with sense data..................................................................... 7-3
7.2.2 Sense data (3-0C-03), (4-40-xx), (4-44-xx), and (4-C4-xx).............................................7-4
7.2.3 Sense data (1-1x-xx), (3-1x-xx) and (E-1D-00): Disk read error....................................7-4
7.2.4 Sense data (5-2x-xx), (5-3D-00), (5-90-00), (B-47-xx), (B-49-00), (B-4D-xx) and
(B-4E-00): SCSI interface error ......................................................................................7-4
CHAPTER 8 PRINCIPLE OF OPERATION ....................................................................... 8-1
8.1 Outline .............................................................................................................................. 8-1
8.2 Disk Drive Configuration ................................................................................................. 8-1
8.2.1 Disks................................................................................................................................. 8-2
8.2.2 Heads ................................................................................................................................ 8-2
8.2.3 Spindle mechanism........................................................................................................... 8-2
8.2.4 Actuator ............................................................................................................................ 8-2
8.2.5 Air filters .......................................................................................................................... 8-2
8.3 Circuit Configuration........................................................................................................8-3
8.4 Power-On Sequence ......................................................................................................... 8-5
8.5 Factory-Calibration........................................................................................................... 8-6
8.6 Read/Write Circuit............................................................................................................ 8-7
8.6.1 Head IC............................................................................................................................. 8-7
8.6.2 Write circuit...................................................................................................................... 8-7
8.6.3 Read circuit....................................................................................................................... 8-9

xii C141-E128-01EN
8.7 Servo Control.................................................................................................................... 8-9
8.7.1 Servo control circuit ......................................................................................................... 8-9
8.7.2 Servo format ..................................................................................................................... 8-10
8.7.3 Servo frame format........................................................................................................... 8-12
8.7.4 Spindle motor control....................................................................................................... 8-12
8.7.5 Voice coil motor control...................................................................................................8-13
APPENDIX A LOCATIONS OF CONNECTORS AND SETTING TERMINALS ............ A-1
A.1 Locations of Connectors and Setting Terminals (MAH series MC model)...................... A-2
A.2 Locations of Connectors and Setting Terminals (MAN series MP model) ......................A-3
APPENDIX B SETTING TERMINALS ................................................................................. B-1
B.1 Setting Terminals (MP model only) ................................................................................. B-2
APPENDIX C CONNECTOR SIGNAL ALLOCATION....................................................... C-1
C.1 SCSI Connector Signal Allocation: SCA2 type LVD 16-bit SCSI.................................. C-2
C.2 SCSI Connector Signal Allocation: 68 pin type LVD 16-bit SCSI ................................. C-3
APPENDIX D MODEL NAMES AND PRODUCT NUMBERS ...........................................D-1
D.1 Model Names and Product Numbers................................................................................ D-2

C141-E128-01EN xiii
FIGURES
page
Figure 1.1 MAN series MC outer view .....................................................................................................1-5
Figure 1.2 MAN series MP outer view......................................................................................................1-6
Figure 1.3 Disk/head configuration...........................................................................................................1-7
Figure 1.4 System configuration ...............................................................................................................1-8
Figure 3.1 Cylinder configuration .............................................................................................................3-2
Figure 3.2 Spare area in cell......................................................................................................................3-5
Figure 3.3 Alternate cylinder.....................................................................................................................3-5
Figure 3.4 Track format ............................................................................................................................3-6
Figure 3.5 Track skew/cylinder skew........................................................................................................3-7
Figure 3.6 Sector format............................................................................................................................3-8
Figure 3.7 Alternate block allocation by FORMAT UNIT command ....................................................3-13
Figure 3.8 Alternate block allocation by REASSIGN BLOCKS command ...........................................3-14
Figure 4.1 External dimensions (MAN series MC model)........................................................................4-2
Figure 4.2 External dimensions (MAN series MP model) ........................................................................4-3
Figure 4.3 IDD orientations.......................................................................................................................4-4
Figure 4.4 Mounting frame structure ........................................................................................................4-5
Figure 4.5 Limitation of side-mounting ....................................................................................................4-5
Figure 4.6 Surface temperature measurement points.................................................................................4-6
Figure 4.7 Service clearance area..............................................................................................................4-7
Figure 4.8 Current waveform (+12 VDC).................................................................................................4-8
Figure 4.9 Power on/off sequence (1) .......................................................................................................4-9
Figure 4.10 Power on/off sequence (2) ...................................................................................................4-9
Figure 4.11 Power on/off sequence (3) ...................................................................................................4-9
Figure 4.12 AC noise filter (recommended)..........................................................................................4-10
Figure 4.13 Connectors and terminals location (MP model).................................................................4-11
Figure 4.14 16-bit SCSI interface connector.........................................................................................4-11
Figure 4.15 Power supply connector (16-bit SCSI model) ...................................................................4-12
Figure 4.16 External operator panel connector (CN1) ..........................................................................4-13
Figure 4.17 External operator panel connector (CN2) ..........................................................................4-14
Figure 4.18 16-bit SCSI ID external input ............................................................................................4-15
Figure 4.19 Output signal for external LED..........................................................................................4-17
Figure 4.20 SCSI cables connection......................................................................................................4-18
Figure 4.21 Connectors location of MC model .....................................................................................4-19

xiv C141-E128-01EN
Figure 4.22 SCA2 type SCSI connector................................................................................................4-20
Figure 4.23 External operator panel circuit example ............................................................................4-22
Figure 5.1 SCSI bus connections (1 of 2)..................................................................................................5-4
Figure 5.1 SCSI bus connections (2 of 2)..................................................................................................5-4
Figure 5.2 IDD setting terminals position .................................................................................................5-5
Figure 5.3 Setting terminals (CN2 MP model only) .................................................................................5-6
Figure 5.4 Checking the SCSI connection (A)........................................................................................5-14
Figure 5.5 Checking the SCSI connection (B) ........................................................................................5-15
Figure 6.1 Revision label...........................................................................................................................6-9
Figure 6.2 Indicating revision numbers...................................................................................................6-10
Figure 6.3 Test flowchart ........................................................................................................................6-11
Figure 7.1 Format of extended sense data .................................................................................................7-2
Figure 8.1 Circuit configuration................................................................................................................8-4
Figure 8.2 IDD operation sequence at power-on.......................................................................................8-5
Figure 8.3 Block diagram of read-write circuit .........................................................................................8-8
Figure 8.4 Block diagram of servo control circuit ..................................................................................8-10
Figure 8.5 Position of servo track ...........................................................................................................8-12
Figure 8.6 Servo frame............................................................................................................................8-12
Figure A.1 Locations of connectors (MAN series MC model) .................................................................. A-2
Figure A.2 Locations of connectors and setting terminals (MAN series MP model)............................A-3

C141-E128-01EN xv
TABLES
page
Table 2.1 Function specifications ............................................................................................................2-2
Table 2.2 Environmental/power requirements.........................................................................................2-4
Table 2.3 SCSI function specifications....................................................................................................2-7
Table 3.1 Zone layout and track capacity (MAN series) .........................................................................3-3
Table 3.4 Format capacity......................................................................................................................3-10
Table 4.1 Surface temperature check point..............................................................................................4-6
Table 4.2 Recommended components for connection ...........................................................................4-21
Table 5.1 SCSI ID setting (CN2 on MP model only) ..............................................................................5-7
Table 5.2 Setting SCSI terminal power supply (MP model only)............................................................5-7
Table 5.3 Motor start mode setting (MP model only)..............................................................................5-8
Table 5.4 Write protect setting (MP model only) ....................................................................................5-8
Table 5.5 Setting of the SCSI interface operation mode (MP model only) .............................................5-9
Table 5.6 Setting the bus width of the SCSI interface (MP model only).................................................5-9
Table 5.7 Default mode settings (by CHANGE DEFINITION command) .............................................5-9
Table 5.8 Setting check list (MP model only)........................................................................................5-10
Table 6.1 Self-diagnostic functions..........................................................................................................6-1
Table 6.2 System-level field troubleshooting ........................................................................................6-14
Table 6.3 Disk drive troubleshooting.....................................................................................................6-15
Table 7.1 Definition of sense data............................................................................................................7-3
Table B.1 Setting terminal: CN2 ............................................................................................................ B-2
Table C.1 SCSI connector (SCA2 type LVD 16-bit SCSI): CN1........................................................... C-2
Table C.2 SCSI connector (68 pin type LVD 16-bit SCSI): CN1 .......................................................... C-3
Table D.1 MAN series model names and product numbers .................................................................... D-2

This page is intentionally left blank.

C141-E128-01EN 1 - 1
CHAPTER 1 GENERAL DESCRIPTION
1.1 Standard Features
1.2 Hardware Structure
1.3 System Configuration
This chapter describes the feature and configuration of the intelligent disk drives (IDD).
IDDs are high performance large capacity 3.5 type fixed disk drives with an embedded SCSI controller.
The interface between the IDD and host system is based on SCSI (Small Computer System Interface)
standard [ANSI X3.131 - 1986: Small Computer System Interface (SCSI), ANSI X3.131-1994: Small
Computer System Interface - 2 (SCSI-2)].
The flexibility and expandability of the SCSI, as well as the powerful command set of the IDD, allow the
user to construct a high-performance reliable disk subsystem with large storage capacity. Refer to SCSI
Logical Interface Specifications for details.

C141-E128-01EN1 - 2
1.1 Standard Features
(1) Compactness
Since the SCSI controller circuit is embedded in the standard 3.5 type fixed disk drive form factor,
the IDD is extremely compact. The IDD can be connected directly to the SCSI bus of the host
system.
(2) SCSI/CCS standard
The IDD provides not only SCSI basic functions but also the following features:
•Arbitration
•Disconnection/Reconnection
•Data bus parity
•Command set which meets the logical specification of the SCSI CCS (Common Command
Set for Direct Access Device) requirements (Rev. 4.B)
The SCSI commands can manipulate data through logical block addressing regardless of the
physical characteristics of the disk drive. This allows software to accommodate future expansion
of system functions.
(3) 8-bit SCSI/16-bit SCSI
The IDD has 16-bit data bus width (16-bit SCSI), which have the wide transfer function suitable
for SCSI-2. This is also available as 8-bit data bus only MP model.
For the ultra SCSI model, number of connectable SCSI devices on the same SCSI bus is varied as
follows.
•8-bit SCSI: 8 drives max.
•16-bit SCSI: 16 drives max.
(4) High speed data transfer
Such a high data transfer rate on the SCSI bus can be useful with the large capacity buffer in the
IDD.
•8-bit SCSI: The data transfer rate on the SCSI bus is 40 MB/s maximum in
synchronous mode.
•16-bit SCSI: The data transfer rate on the SCSI bus is 160 MB/s maximum in
synchronous mode.
