Operating Manual - English
PRIMERGY SX910 S1 Storage Blade
Operating Manual
Edition March 2011

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
email: [email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2011 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trade names and/or trademarks of their respective
manufacturers.
– The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
– No part of this manual may be reproduced in any form without the prior written permission
of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

SX910 S1 Operating Manual
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the product
is used in a hot environment. The customer shall bear the cost of replacing
replaceable components which have exceeded their operating life. Note that
these are only guidelines, and do not constitute a guarantee of trouble-free
operation during the maintenance support period.
High safety use
This product has been designed and manufactured for general uses such as
general office use, personal use, domestic use and normal industrial use. It has
not been designed or manufactured for uses which demand an extremely high
level of safety and carry a direct and serious risk to life or body if such safety
cannot be ensured.

Operating Manual SX910 S1
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance control
in weapons systems (hereafter, "high safety use"). Customers should not use
this product for high safety use unless measures are in place for ensuring the
level of safety demanded of such use. Please consult the sales staff of Fujitsu if
intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://primeserver.fujitsu.com/primergy/harddisk/

SX910 S1 Operating Manual
Only for the Japanese market:
IAlthough described in this manual, some sections do not apply to the
Japanese market. These options and routines include:
– USB Flash Module (UFM)
– CSS (Customer Self Service)
– Replacing the lithium battery

Operating Manual SX910 S1

SX910 S1 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups for this manual . . . . . . . . . 10
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10
1.3 Performance features . . . . . . . . . . . . . . . . . . . . . 11
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 12
1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 13
2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Electrostatic sensitive device label . . . . . . . . . . . . . . 17
2.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 FCC Class A Compliance Statement . . . . . . . . . . . . . 18
2.5 RFI suppression . . . . . . . . . . . . . . . . . . . . . . . . 19
2.6 Notes on transportation . . . . . . . . . . . . . . . . . . . . 19
2.7 Environmental protection . . . . . . . . . . . . . . . . . . . 20
3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1 Installation procedure . . . . . . . . . . . . . . . . . . . . . 24
3.2 Unpacking a Storage Blade . . . . . . . . . . . . . . . . . . 24
3.3 Installing/removing a Storage Blade . . . . . . . . . . . . . 25
3.3.1 Installing/removing in a PRIMERGY BX900 S1 . . . . . . . . . 25
3.3.2 Installing/removing in a PRIMERGY BX400 S1 . . . . . . . . . 30
4 Installation and operation . . . . . . . . . . . . . . . . . . . 37
4.1 Control and display elements . . . . . . . . . . . . . . . . . 37
4.1.1 Indicators on the Storage Blade . . . . . . . . . . . . . . . . . 37
4.1.2 Controls and indicators on the tape drive . . . . . . . . . . . . 39

Operating Manual SX910 S1
Contents
4.2 Putting the Storage Blade into operation . . . . . . . . . . . 41
5 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 43
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

SX910 S1 Operating Manual 9
1 Introduction
Figure 1: PRIMERGY SX910 S1 storage blade
The PRIMERGY SX910 S1 storage blade is used as a storage subsystem for
the PRIMERGY BX900 S1 blade server and the BX400 S1 blade server and
their successor models.
The PRIMERGY SX910 S1 storage blade allows an SAS tape drive to be
installed together with the corresponding controller and occupies one bay in the
PRIMERGY BX900 S1 and BX400 S1 system units.

10 Operating Manual SX910 S1
Concept and target groups for this manual Introduction
Up to six PRIMERGY SX910 S1 storage blades can be installed in the
BX900 S1 system unit. Up to four PRIMERGY SX910 S1 storage blades can be
installed in the BX400 S1 system unit.
1.1 Concept and target groups for this manual
This operating manual shows you how to install the storage blade in the basic
unit, how to start up the storage blade and how to operate it.
This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the
information you need to put your PRIMERGY SX910 S1 storage blade into
operation.
To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.
1.2 Documentation overview
More information on your PRIMERGY SX910 S1 storage blade can be found in
the following documents:
– "Safety notes and regulations" manual
"安全上のご注意 " for the Japanese market
– "Warranty" manual
"保証書 " for the Japanese market
– "Returning used devices" manual and "Service Desk" leaflet
"サポート＆サービス " for the Japanese market
– “LTO-3 Half-Height SAS Tape Drive” manual
"内蔵 LTO3 ユニット 取扱説明書 “ for the Japanese market
– “LTO-4 Half-Height SAS Tape Drive” manual
"内蔵 LTO4 ユニット 取扱説明書 “ for the Japanese market
– “LTO-5 Half-Height SAS Tape Drive” manual
"内蔵 LTO5 ユニット 取扱説明書 “ for the Japanese market
