Fujitsu ETERNUS DX S5 Series Installation guide

FUJITSU Storage
ETERNUS DX S5 series
Hybrid Storage Systems
Operation Guide (Basic)
Operation management/maintenance
P3AG-3992-02ENZ0

Table of Contents
1. Basic Operation .................................................................................................... 11
How to Open/Close the Rack Doors........................................................................................... 11
How to Open/Close the Front Door...................................................................................................................11
How to Open/Close the Rear Door....................................................................................................................12
Powering On and Off ................................................................................................................ 13
Switching On and Off the Main Line Switch on the Power Distribution Unit.....................................................13
Switching On and Off the PSU Switch on the Power Supply Unit ......................................................................14
Powering On ....................................................................................................................................................18
Powering Off....................................................................................................................................................21
Using the FUNCTION Button/Setting Change Switches.............................................................. 23
2. Storage System Monitoring.................................................................................. 25
Checking LED Status ................................................................................................................. 25
Displaying Status via ETERNUS Web GUI................................................................................... 25
Displaying Status via ETERNUS CLI............................................................................................ 26
Event Notification..................................................................................................................... 26
Audit Log.................................................................................................................................. 27
3. Process Time (Estimated)..................................................................................... 28
Volume Formatting Time.......................................................................................................... 28
Rebuild/Copyback Process Time................................................................................................ 28
4. Component Expansion/Function Enhancement ................................................... 30
License Registration ................................................................................................................. 30
Installing Additional Drives ...................................................................................................... 32
Installable Drives.............................................................................................................................................32
Drive Handling Instructions .............................................................................................................................32
Additional Drive Installation Procedure ...........................................................................................................34
Installing Additional Drive Enclosures ...................................................................................... 43
Installable Drive Enclosures.............................................................................................................................43
Drive Enclosure Handling Instructions .............................................................................................................43
Additional Drive Enclosure Installation Procedure ...........................................................................................44
Installing Long Wave SFP+ Modules (16Gbit/s) ........................................................................ 63
Installation Rules for Long Wave SFP+ Modules (16Gbit/s)..............................................................................63
2 Operation Guide (Basic)

Installable Long Wave SFP+ Modules (16Gbit/s)..............................................................................................63
SFP+ Module Handling Instructions .................................................................................................................63
Long Wave SFP+ Modules (16Gbit/s) Installation Procedure............................................................................64
Adding Servers ......................................................................................................................... 67
RAID Group Creation ........................................................................................................................................67
Volume Creation ..............................................................................................................................................68
Connection Setup.............................................................................................................................................68
5. Maintenance......................................................................................................... 72
Periodic Backup........................................................................................................................ 72
Maintenance Service ................................................................................................................ 72
Maintenance Support Period ...........................................................................................................................72
Replacing Batteries..........................................................................................................................................73
Related Service ................................................................................................................................................73
6. Troubleshooting ................................................................................................... 74
Check List ................................................................................................................................. 74
Required Information for Inquiries ........................................................................................... 82
A. Component Names............................................................................................... 83
Frontend Enclosures (ETERNUS DX900 S5) ............................................................................... 83
Front................................................................................................................................................................83
Rear .................................................................................................................................................................85
Component Names and LED Names.................................................................................................................86
Menu Operation Using the Panel Key ..............................................................................................................91
Controller Enclosure ................................................................................................................. 95
Front................................................................................................................................................................95
Rear .................................................................................................................................................................98
Component Names and LED Names...............................................................................................................105
Drive Enclosure....................................................................................................................... 122
Front..............................................................................................................................................................122
Rear ...............................................................................................................................................................125
Component Names and LED Names...............................................................................................................127
Power Distribution Unit .......................................................................................................... 133
Power Distribution Units (1U)........................................................................................................................133
Power Distribution Units (2U)........................................................................................................................133
Table of Contents
3 Operation Guide (Basic)

List of Figures
Figure 1 ON Position of the Main Line Switches on a 1U Power Distribution Unit ..................................................13
Figure 2 ON Position of the Main Line Switches on a 2U Power Distribution Unit ..................................................13
Figure 3 OFF Position of the Main Line Switches on a 1U Power Distribution Unit .................................................14
Figure 4 OFF Position of the Main Line Switches on a 2U Power Distribution Unit .................................................14
Figure 5 ON Position (Marked "|") of the PSU Switch on a Power Supply Unit ........................................................15
Figure 6 OFF Position (Marked "¡") of the PSU Switch of a Power Supply Unit ......................................................17
Figure 7 ETERNUS Web GUI Screen (Example: ETERNUS DX500 S5)........................................................................25
Figure 8 Front View of a Frontend Enclosure (with a Front Cover)..........................................................................83
Figure 9 Front View of a Frontend Enclosure (without a Front Cover).....................................................................84
Figure 10 Rear View of a Frontend Enclosure ...........................................................................................................85
Figure 11 System Operation Panel...........................................................................................................................86
Figure 12 Message Format of the LCD Panel (during Startup)..................................................................................87
Figure 13 Message Format of the LCD Panel (While Running) .................................................................................88
Figure 14 Service Controller .....................................................................................................................................89
Figure 15 Power Supply Unit (Frontend Enclosure) ..................................................................................................90
Figure 16 Frontend Routers......................................................................................................................................90
Figure 17 Front View of a 2.5" Type Controller Enclosure (ETERNUS DX60 S5/DX100 S5/DX200 S5)..........................95
Figure 18 Front View of a 3.5" Type Controller Enclosure (ETERNUS DX60 S5/DX100 S5/DX200 S5)..........................95
Figure 19 Front View of a Controller Enclosure (for the ETERNUS DX500 S5/DX600 S5, with a Front Cover) .............96
Figure 20 Front View of a Controller Enclosure (for the ETERNUS DX500 S5/DX600 S5, without a Front Cover) ........96
Figure 21 Front View of a Controller Enclosure (for ETERNUS DX900 S5, with a Front Cover)....................................97
Figure 22 Front View of a Controller Enclosure (for ETERNUS DX900 S5, without a Front Cover) ..............................97
Figure 23 Rear View of a Controller Enclosure (When the ETERNUS DX60 S5 Is installed with Only One
Controller)................................................................................................................................................98
Figure 24 Rear View of a Controller Enclosure (When the ETERNUS DX60 S5 Is Installed with Two Controllers)........98
Figure 25 Rear View of a Controller Enclosure (When the ETERNUS DX100 S5/DX200 S5 Is Installed with
Only One Controller)...............................................................................................................................100
Figure 26 Rear View of a Controller Enclosure (When the ETERNUS DX100 S5/DX200 S5 Is Installed with
Two Controllers) .....................................................................................................................................101
Figure 27 Rear View of a Controller Enclosure (ETERNUS DX500 S5) ......................................................................102
Figure 28 Rear View of a Controller Enclosure (ETERNUS DX600 S5) ......................................................................103
Figure 29 Rear View of a Controller Enclosure (ETERNUS DX900 S5) ......................................................................104
Figure 30 Operation Panel (ETERNUS DX60 S5/DX100 S5/DX200 S5) .....................................................................105
Figure 31 Operation Panel (Controller Enclosure for the ETERNUS DX500 S5/DX600 S5)........................................106
Figure 32 Operation Panel (Controller Enclosure [ETERNUS DX900 S5]) ................................................................107
Figure 33 2.5" Drives and 3.5" Drives .....................................................................................................................108
Figure 34 Controller (for the ETERNUS DX60 S5, Pattern 1)....................................................................................109
Figure 35 Controller (for the ETERNUS DX60 S5, Pattern 2)....................................................................................109
Figure 36 Controller (for the ETERNUS DX100 S5/DX200 S5, Pattern 1)..................................................................110
Figure 37 Controller (for the ETERNUS DX100 S5/DX200 S5, Pattern 2)..................................................................110
Figure 38 Controller (ETERNUS DX500 S5)..............................................................................................................111
Figure 39 Controller (ETERNUS DX600 S5)..............................................................................................................112
Figure 40 Controller (ETERNUS DX900 S5)..............................................................................................................113
4 Operation Guide (Basic)

Figure 41 Power Supply Unit (Controller Enclosure for the ETERNUS DX60 S5/DX100 S5/DX200 S5) (AC
Power Type) ...........................................................................................................................................114
Figure 42 Power Supply Unit (Controller Enclosure for the ETERNUS DX100 S5) (DC Power Type) ..........................114
Figure 43 Power Supply Unit (Controller Enclosure for the ETERNUS DX500 S5/DX600 S5/DX900 S5).....................115
Figure 44 Host Interface Ports (ETERNUS DX60 S5) ................................................................................................116
Figure 45 Host Interface Ports (ETERNUS DX100 S5/DX200 S5)..............................................................................117
Figure 46 Host Interface Ports (ETERNUS DX500 S5/DX600 S5)..............................................................................118
Figure 47 Host Interface (ETERNUS DX900 S5).......................................................................................................119
Figure 48 PFM........................................................................................................................................................120
Figure 49 Batteries ................................................................................................................................................121
Figure 50 Front View of a 2.5" Type Drive Enclosure...............................................................................................122
Figure 51 Front View of a 3.5" Type Drive Enclosure...............................................................................................122
Figure 52 Front View of a High-Density Drive Enclosure.........................................................................................123
Figure 53 Top View of a High-Density Drive Enclosure with the Cover Opened.......................................................124
Figure 54 Rear View of a 2.5"/3.5" Type Drive Enclosure (When Only One I/O Module Is Installed).........................125
Figure 55 Rear View of a 2.5"/3.5" Type Drive Enclosure (When Two I/O Modules Are Installed) ............................125
Figure 56 Rear View of a High-Density Drive Enclosure..........................................................................................126
Figure 57 Operation Panel (Drive Enclosure) .........................................................................................................127
Figure 58 Disk Activity Panel (DAP)........................................................................................................................128
Figure 59 2.5" Drives and 3.5" Drives .....................................................................................................................129
Figure 60 I/O Module (Drive Enclosure)..................................................................................................................130
Figure 61 Power Supply Unit (Drive Enclosure) (AC Power Type)............................................................................131
Figure 62 Power Supply Unit (Drive Enclosure) (DC Power Type) ...........................................................................131
Figure 63 Fan Expander Module ............................................................................................................................132
Figure 64 Power Distribution Units (1U) ................................................................................................................133
Figure 65 Power Distribution Units (2U) ................................................................................................................133
List of Figures
5 Operation Guide (Basic)

List of Tables
Table 1 Time Required to Turn the Power On........................................................................................................18
Table 2 Time Required to Turn the Power Off........................................................................................................21
Table 3 General Status of ETERNUS Web GUI.........................................................................................................25
Table 4 General Status of ETERNUS CLI .................................................................................................................26
Table 5 Volume Formatting Time..........................................................................................................................28
Table 6 Rebuild Process Time................................................................................................................................28
Table 7 Copyback Process Time.............................................................................................................................29
Table 8 Time Required for the READY LED to Turns On after Turning the Power On ..............................................75
Table 9 Status and Meaning of Each LED (System Operation Panel) ....................................................................86
Table 10 Meaning of the Message on the LCD Panel (While Running) ...................................................................88
Table 11 Name and Function of the Panel Key .......................................................................................................89
Table 12 Status and Meaning of Each LED (Power Supply Unit)..............................................................................90
Table 13 Menu List for the LCD Panel .....................................................................................................................91
Table 14 Status and Meaning of Each LED (Operation Panel [Controller Enclosure for the ETERNUS DX60
S5/DX100 S5/DX200 S5])........................................................................................................................105
Table 15 Status and Meaning of Each LED (Operation Panel [Controller Enclosure for the ETERNUS
DX500 S5/DX600 S5]).............................................................................................................................106
Table 16 Status and Meaning of Each LED (Operation Panel [Controller Enclosure (ETERNUS DX900 S5)])..........108
Table 17 Status and Meaning of Each LED (Drive)................................................................................................108
Table 18 Status and Meaning of Each LED (Controller for the ETERNUS DX60 S5).................................................109
Table 19 Status and Meaning of Each LED (Controller for the ETERNUS DX100 S5/DX200 S5) ..............................110
Table 20 Status and Meaning of Each LED (Controller for the ETERNUS DX500 S5/DX600 S5) ..............................112
Table 21 Status and Meaning of Each LED (Controller for the ETERNUS DX900 S5)...............................................113
Table 22 Status and Meaning of Each LED (Power Supply Unit [Controller Enclosure for the ETERNUS
DX60 S5/DX100 S5/DX200 S5])...............................................................................................................115
Table 23 Status and Meaning of Each LED (Power Supply Unit for the ETERNUS DX500 S5/DX600 S5/
DX900 S5) ..............................................................................................................................................115
Table 24 Status and Meaning of Each LED (Host Interface for the ETERNUS DX60 S5)..........................................116
Table 25 Status and Meaning of Each LED (Host Interface for the ETERNUS DX100 S5/DX200 S5)........................117
Table 26 Status and Meaning of Each LED (Host Interface for the ETERNUS DX500 S5/DX600 S5)........................118
Table 27 Status and Meaning of Each LED (Host Interface for the ETERNUS DX900 S5)........................................119
Table 28 Status and Meaning of Each LED (PFM) .................................................................................................120
Table 29 Status and Meaning of Each LED (Battery).............................................................................................121
Table 30 Status and Meaning of Each LED (Operation Panel [Drive Enclosure])...................................................127
Table 31 Status and Meaning of Each LED (Disk Activity Panel [DAP]) .................................................................128
Table 32 Status and Meaning of Each LED (Drive)................................................................................................129
Table 33 Status and Meaning of Each LED (I/O Module [Drive Enclosure]) ...........................................................130
Table 34 Status and Meaning of Each LED (Power Supply Unit (Drive Enclosure))................................................131
Table 35 Status and Meaning of Each LED (Fan Expander Module)......................................................................132
6 Operation Guide (Basic)

Preface
Fujitsu would like to thank you for purchasing the FUJITSU Storage ETERNUS DX60 S5/DX100 S5/DX200 S5,
ETERNUS DX500 S5/DX600 S5/DX900 S5 Hybrid Storage Systems (hereinafter referred to as ETERNUS DX).
The ETERNUS DX is designed to be connected to Fujitsu servers (Fujitsu SPARC Servers, PRIMEQUEST, PRIMERGY,
and other servers) or non-Fujitsu servers.
This manual describes the operation management and maintenance of the ETERNUS DX.
This manual is intended for use of the ETERNUS DX in regions other than Japan.
Please carefully review the information outlined in this manual.
Copyright 2019 FUJITSU LIMITED
Second Edition
December 2019
7 Operation Guide (Basic)

Trademarks
Third-party trademark information related to this product is available at:
https://www.fujitsu.com/global/products/computing/storage/eternus/trademarks.html
About This Manual
Intended Audience
This manual is intended for storage system administrators or system administrators who manage and maintain
the ETERNUS DX.
Related Information and Documents
The latest information for your model is available at:
https://www.fujitsu.com/global/support/products/computing/storage/manuals-list.html
Refer to the following manuals of your model as necessary:
"Configuration Guide (Power Synchronized Unit)"
"Configuration Guide (Web GUI)"
"Configuration Guide (Basic)"
"Message List"
"Safety Notes and Regulations"
"Product List"
"Site Planning Guide"
"Design Guide"
"Configuration Guide -Server Connection-"
"ETERNUS Web GUI User's Guide"
Document Conventions
■Third-Party Product Names
•Oracle Solaris may be referred to as "Solaris", "Solaris Operating System", or "Solaris OS".
•Microsoft® Windows Server® may be referred to as "Windows Server".
■Notice Symbols
The following notice symbols are used in this manual:
Indicates information that you need to observe when using the ETERNUS storage system. Make
sure to read the information.
Indicates information and suggestions that supplement the descriptions included in this
manual.
Preface
8 Operation Guide (Basic)

Warning Signs
Warning signs are shown throughout this manual in order to prevent injury to the user and/or material damage.
These signs are composed of a symbol and a message describing the recommended level of caution. The
following explains the symbol, its level of caution, and its meaning as used in this manual.
This symbol indicates the possibility of serious or fatal injury if the ETERNUS DX is not used
properly.
This symbol indicates the possibility of minor or moderate personal injury, as well as damage to
the ETERNUS DX and/or to other users and their property, if the ETERNUS DX is not used properly.
This symbol indicates IMPORTANT information for the user to note when using the ETERNUS DX.
The following symbols are used to indicate the type of warnings or cautions being described.
The triangle emphasizes the urgency of the WARNING and CAUTION contents. Inside the
triangle and above it are details concerning the symbol (e.g. Electrical Shock).
The barred "Do Not..." circle warns against certain actions. The action which must be avoided
is both illustrated inside the barred circle and written above it (e.g. No Disassembly).
The black "Must Do..." circle indicates actions that must be taken. The required action is both
illustrated inside the black disk and written above it (e.g. Unplug).
How Warnings are Presented in This Manual
A message is written beside the symbol indicating the caution level. This message is marked with a vertical
ribbon in the left margin, to distinguish this warning from ordinary descriptions.
An example is shown below.
Warning level indicator
Warning type indicator
Warning details
•To avoid damaging the ETERNUS storage system, pay attention to the
following points when cleaning the ETERNUS storage system:
Warning layout ribbon
Example warning
- Make sure to disconnect the power when cleaning.
- Be careful that no liquid seeps into the ETERNUS storage system
when using cleaners, etc.
- Do not use alcohol or other solvents to clean the ETERNUS storage system.
CAUTION Do
Preface
9 Operation Guide (Basic)

Setting Procedures in This Manual
Detailed information about the setup parameters (descriptions and input conditions in the procedure) and the
status displays is described in "ETERNUS Web GUI User's Guide".
Note that the screen shots in this manual may be different from the actual screens.
Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.
Preface
10 Operation Guide (Basic)

1. Basic Operation
This chapter explains how to open and close rack doors and how to turn the ETERNUS DX on and off.
How to Open/Close the Rack Doors
Each 19-inch rack has a front door and a rear door.
The following section explains how to open and close the front and rear doors.
How to Open/Close the Front Door
■How to Open the Front Door
1Insert the rack key and turn the key 180 degrees counterclockwise.
This will unlock the front door.
2Pull the door handle forward.
■How to Close the Front Door
Reverse the opening procedure to close the front door.
IMPORTANT
Close the front door with the door handle pulled forward.
11 Operation Guide (Basic)

How to Open/Close the Rear Door
■How to Open the Rear Door
1Insert the rack key and turn the key 180 degrees counterclockwise.
This will unlock the rear door.
2Pull the bottom of the door handle forward.
3Rotate the door handle counterclockwise and pull the door open.
1. Basic Operation
How to Open/Close the Rack Doors
12 Operation Guide (Basic)

■How to Close the Rear Door
Reverse the opening procedure to close the rear door.
IMPORTANT
Close the rear door with the door handle rotated.
Powering On and Off
This section explains how to turn on and off the ETERNUS DX.
Switching On and Off the Main Line Switch on the Power Distribution Unit
This section explains how to switch the main line switch of the power distribution unit to ON and OFF.
■To Switch to ON
Turn the main line switch of the power distribution unit to the ON position (marked "|").
IMPORTANT
When turning on the ETERNUS DX, be sure to turn all the main line switches to the ON position and then
follow the procedure in "Powering On" (page 18).
●For 1U
Figure 1 ON Position of the Main Line Switches on a 1U Power Distribution Unit
Main line switch
●For 2U
Figure 2 ON Position of the Main Line Switches on a 2U Power Distribution Unit
Main line switch
1. Basic Operation
Powering On and Off
13 Operation Guide (Basic)

■To Switch to OFF
Turn the main line switch of the power distribution unit to the OFF position (marked "¡").
Note
This does not need to be turned off for normal operation. If the ETERNUS DX must be turned off, such as
before any inspections of power supply devices are performed, turn off the ETERNUS DX by using the
procedure described in "Powering Off" (page 21), turn all the PSU switches of the power supply unit to
the OFF position, and turn the main line switch of the power distribution unit to the OFF position.
●For 1U
Figure 3 OFF Position of the Main Line Switches on a 1U Power Distribution Unit
Main line switch
●For 2U
Figure 4 OFF Position of the Main Line Switches on a 2U Power Distribution Unit
Main line switch
IMPORTANT
When turning the main line switch to ON (marked "|") right after turning the main line switch to OFF
(marked "¡"), turn it back to ON (marked "|") after the POWER LED of the power supply unit has
turned off completely.
Switching On and Off the PSU Switch on the Power Supply Unit
This section explains how to move the PSU switch of the power supply unit of the controller enclosure and drive
enclosures to the ON and OFF positions in each enclosure. Note that power supply units for high-density drive
enclosures, frontend enclosures, and controller enclosures in the ETERNUS DX500 S5/DX600 S5/DX900 S5 do not
have PSU switches.
1. Basic Operation
Powering On and Off
14 Operation Guide (Basic)

■To Switch to ON
Turn the PSU switch of the power supply unit to the ON position (marked "|").
IMPORTANT
Make sure all of the PSU switches are in the ON position.
Figure 5 ON Position (Marked "|") of the PSU Switch on a Power Supply Unit
ETERNUS DX60 S5/DX100 S5/DX200 S5
ETERNUS DX500 S5/DX600 S5/DX900 S5
PSU#0 PSU#1
PSU#0 PSU#1
PSU#0 PSU#1
Drive enclosure
Controller enclosure
Drive enclosure
PSU#0 PSU#1
PSU#0 PSU#1
Drive enclosure
Controller enclosure
ETERNUS DX100 S5 (DC power type)
Power is supplied to an enclosure.
•For the controller enclosure, the POWER LED on the power supply unit blinks green.
1. Basic Operation
Powering On and Off
15 Operation Guide (Basic)

•For the drive enclosure, the POWER LED on the power supply unit emits green lights and the fan revolves at
high speed for 30 seconds.
Drive enclosure
Controller enclosure
PSU#0 PSU#1
PSU#0 PSU#1
PSU#0 PSU#1
Drive enclosure
ETERNUS DX60 S5/DX100 S5/DX200 S5
POWER LED
ETERNUS DX500 S5/DX600 S5/DX900 S5
Drive enclosure
Controller enclosure
POWER
LED
PSU#0 PSU#1
PSU#0 PSU#1
ETERNUS DX100 S5 (DC power type)
1. Basic Operation
Powering On and Off
16 Operation Guide (Basic)

■To Switch to OFF
Turn the PSU switch of the power supply unit to the OFF position (marked "¡").
Note
This does not need to be turned off for normal operation.
Figure 6 OFF Position (Marked "¡") of the PSU Switch of a Power Supply Unit
ETERNUS DX60 S5/DX100 S5/DX200 S5
ETERNUS DX500 S5/DX600 S5/DX900 S5
PSU#0 PSU#1
PSU#0 PSU#1
PSU#0 PSU#1
Drive enclosure
Controller enclosure
Drive enclosure
Check that the POWER LED of the power supply unit is off.
1. Basic Operation
Powering On and Off
17 Operation Guide (Basic)

Powering On
This section explains how to turn on the ETERNUS DX.
To turn on the ETERNUS DX, perform the following procedure.
•Via the power switch
Press the Power switch to turn on the ETERNUS DX.
The following methods can be used to turn the power on by linking with the server.
•Power Synchronized Unit
Use the power synchronized unit to turn on the ETERNUS DX.
•Wake On LAN
Use the Wake On LAN function to turn on the power.
Note
Before turning on the ETERNUS DX, make sure that the main line switches of the power distribution units
and the PSU switches on the power supply units of the ETERNUS DX are "ON". Do not turn the main line
switches of the power distribution units and the PSU switches on the ETERNUS DX to the OFF position.
IMPORTANT
•The following table shows the time required for the ETERNUS DX to reach the READY state (the READY
LED turns on) after turning the power on. This should be taken into consideration for scheduled
operations.
Table 1 Time Required to Turn the Power On
Model
Deduplication/
Compression function
is disabled
Deduplication/
Compression function
is enabled
Unified configuration (*1) VLAN/Bonding maximum
configuration
Normal Error Normal Error Normal Error Normal Error
DX60 S5 Approx. 5
minutes
Max. 18
minutes
— — — — — —
DX100 S5 Approx. 5
minutes
Max. 18
minutes
— — Approx. 10
minutes
Max. 40
minutes
Approx. 20
minutes
Max. 50
minutes
DX200 S5 Approx. 5
minutes
Max. 18
minutes
Approx. 9
minutes
Max. 22
minutes
Approx. 10
minutes
Max. 40
minutes
Approx. 20
minutes
Max. 50
minutes
DX500 S5 Approx. 5
minutes
Max. 18
minutes
Approx. 12
minutes
Max. 25
minutes
Approx. 10
minutes
Max. 42
minutes
Approx. 22
minutes
Max. 53
minutes
DX600 S5 Approx. 7
minutes
Max. 20
minutes
Approx. 15
minutes
Max. 28
minutes
Approx. 12
minutes
Max. 44
minutes
Approx. 24
minutes
Max. 55
minutes
DX900 S5
(*2)
Approx. 10
minutes
Max. 20
minutes
Approx. 14
minutes
Max. 24
minutes
————
*1: The time required to turn the power on for the Unified configuration depends on the NAS configuration (or the number of
shared folders and the number of VLAN/Bonding configurations).
*2: The ETERNUS DX900 S5 supports the Compression function only.
•Before turning the server on, check that the ETERNUS DX and the network devices that connect the
ETERNUS DX and the server are all in READY status.
If the server is turned on while any of these devices are not in READY status, the server may not be able
to recognize the ETERNUS DX.
1. Basic Operation
Powering On and Off
18 Operation Guide (Basic)

•To turn on the ETERNUS DX by linking with the server, the server must wait until the ETERNUS DX is in
the READY state.
•If the Auto Power function is enabled via ETERNUS Web GUI or ETERNUS CLI, the ETERNUS DX is
automatically turned on when power is supplied to the ETERNUS DX.
•If the Power Resume function is enabled via ETERNUS Web GUI or ETERNUS CLI, the ETERNUS DX is
automatically turned on after the power is restored.
•If the REMOTE LED of the ETERNUS DX500 S5/DX600 S5 is green, turn on the ETERNUS DX500 S5/DX600
S5 via a power synchronized unit.
•After power-off, wait for about one minute before turning power on again.
•If the ETERNUS DX turns off abnormally due to problems such as a power failure, it takes approximately
10 minutes (max.) longer for the ETERNUS DX60 S5/DX100 S5/DX200 S5 and the ETERNUS DX500 S5,
approximately 15 minutes (max.) longer for the ETERNUS DX600 S5, or approximately 20 minutes
(max.) longer for the ETERNUS DX900 S5 to reach the READY state the next time the ETERNUS DX is
turned on.
•If the ETERNUS DX is not connected to a power source for long periods, it takes up to four hours before
the built-in battery is fully charged. If the ETERNUS DX is used before the battery is fully charged, the
operational state of the cache is changed to the Write Through mode and performance of the ETERNUS
DX degrades.
This section explains how to use the Power switch to turn on the ETERNUS DX.
For other procedures, refer to the related manuals.
1Press the Power switch of the controller enclosure or the frontend enclosure.
ETERNUS DX60 S5/DX100 S5/DX200 S5 ETERNUS DX500 S5/DX600 S5
Controller enclosure
Frontend enclosure
ETERNUS DX900 S5
Power switch
Power switch
Power switch
The POWER LED on each enclosure turns on.
1. Basic Operation
Powering On and Off
19 Operation Guide (Basic)

2Check that the READY LED of the controller enclosure or the frontend enclosure is lit up. For details about
the time required until the READY LED is turned on, refer to the table described in "IMPORTANT" of
"Powering On" (page 18).
ETERNUS DX60 S5/DX100 S5/DX200 S5 ETERNUS DX500 S5/DX600 S5
Controller enclosure
Drive enclosure
Frontend enclosure
ETERNUS DX900 S5
Controller enclosure
Drive enclosure
1. Basic Operation
Powering On and Off
20 Operation Guide (Basic)
