Furniture of America CM-BK967T User manual

MODEL #
CM-BK967T
1 / 12
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
VERSION # 20-01-14
2 - People
(Included)
Phillips
Screwdriver
(Not Included)
Allen Wrench
Recommended

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ 12

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ X12

4 / XXXXX12

BED
CM-BK967T
#1 1pc
#5 2pcs #6 2pcs
5 / 12
#10 1set #11 1pc
#13 3pcs
Front Guardrail
Front Right Foot
Headboard
Ladder Rail(L)
Ladder Rung
Slat(13pcs)
#2 1pc
Front Left Foot
#3 1pc
Back Right Foot
#4 1pc
Back Left Foot
#12 1pc
Ladder Rail(R)
#14 2pcs
Back
Guardrail Support
#7 2pcs #8 1pc
#9 2pcs
Back Siderail
Front
Guardrail Support
Back Guardrail
#15 1pc #16 1pc
Bottom Back Rail Front Siderail

#G 26pcs #H 2pcs
#I 1set #K 1pc #L 4pcs #M 6pcs
#N 6pcs
Screw #4x40mm
Screw #4x35mm
Hook (2PCS) Allen Key 4mm Bolt Ø1/4" x 1-5/8" Bolt Ø1/4" x 1-1/4"
Screw #3.5 x 16mm
#14
#7
#1
#5
#10
#2
#5
#8
#9
#16
#6
#15
#3
#4
6 / 12
#A 8pcs #B 10pcs #C 6pcs #D 18pcs
#E 8pcs #F 8pcs
Screw Ø1/4" x 4"
Washer Ø1/4"
Bolt Ø1/4" x 3-1/8" Bolt Ø1/4" x 2"
Bolt Ø1/4" x 3-1/8"
Wood Dowel
Ø10 x 40mm
#11
#12
#13

ASSEMBLY INSTRUCTIONS
7 / 12
#D
#7
#15
Part #7 x2pcs
Hardware #D x6pcs
Part #15 x1pc
1
2
#D
#5
#5
Part #5 x2pcs
Hardware #D x8pcs
Insert dowels (#D) to panels (#7,15).
Insert dowels (#D) onto panels (#5).

ASSEMBLY INSTRUCTIONS
8 / 12
#6
Part #6 x2pcs
Hardware #D x4pcs
3
4
#D
#5
#2
#4
#A #K
Part #2 x1pc
Part #4 x1pc
Hardware #A x4pcs
Part #5 x1pc
Insert dowels (#D) onto panels (#6).
Align headboard (#5) to HB legs (#2,4),
then secure by using screws (#A).

ASSEMBLY INSTRUCTIONS
#5
#1
#7
#F
#B
#F
#E
#K
9 / 12
#B
#K
#16
#15
#8
#K
Part #1 x1pc
Part #3 x1pc
Hardware #A x4pcs
Part #5 x1pc
Part #7 x2pcs
Part #15 x1pc
Part #16 x1pc
Hardware #B x6pcs
Hardware #E x8pcs
Part #8 x1pc
Hardware #F x8pcs
5
6
#A #K
#3
#E
Align headboard (#5) to HB legs
(#1,3), then secure by using screws
(#A).
Align panels (#7,15) to the
headboards, then secure
by using bolts (#B).
Align panels (#8,16) to headboard, then
secure by using bolts (#F) onto washers (#E).

#K
#K
#M
#L
ASSEMBLY INSTRUCTIONS
10 / 12
#B
#6
#9
#14
#2
#K
Part #6 x2pcs
Part #9 x2pcs
Hardware #B x4pcs
Hardware #K x1pc
Part #14 x2pcs
Hardware #L x4pcs
Hardware #M x6pcs
7
8
#9
#7
#16
#8
#9
Align support (#9) to the
guardrail (#6), then secure by
using screws (#B).
Align supports (#14) to the back guardrails, then
secure by using bolts (#M).
Align front guardrail (#9) to the side rail
(#8), then secure by using bolts (#L).

11 / 12
ASSEMBLY INSTRUCTIONS
#G
Part #10 x1set
Hardware #G x26pcs
9
10
#10
#13
#K
#C
#C
#I
#11
#K
#12
#N
Hardware #I x2pcs
Part #11 x1pc
Part #12 x1pc
Part #13 x3pcs
Hardware #N x4pcs
Hardware #C x6pcs
Align slats (#10) to the bed, then
secure by using screws (#G).
Align hooks (#I) to ladder, then secure by using
screws (#N). Align ladder rails (#11,12) to ladder
rungs (#13), then secure by using screws (#C).

ASSEMBLY INSTRUCTIONS
12 / 12
11
12
#11 #12
#N
#H
Hardware #H x2pcs
Hardware #N x2pcs
Align ladder to the bed, then secure by
using screws (#N,H) as shown in the
diagram.

SAFETY WARNING
To help prevent serious or fatal injuries from entrapment or falls
.Follow the information on the warnings appearing on the upper bunk bed structure and on thi
carton. Do not remove warning label from the bed.
. Always use the recommended type and size mattress or mattress support, or both, to help prevent
the likehood of entrapment or falls.
. Periodically check and ersure that the guardrail, ladder, and other components are in their proper
position, free from damage, and that all connectors are tight.
. Never allow a child under 6 years of age to use the upper bunk.
. Use only mattress which is 74”-75” long and 38-1/2” wide on upper bunk.
. Ensure thickness of mattress for upper bunk does not exceed 6” . Thicknes of mattress for lower
bunk is from 6”.
. Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
. Prohibit horseplay on or under bed (s)
. Prohibit more than one person on upper bunk.
. Prohibit humping on the bed.
. Always use the ladder for entering and leaving the upper bunk.
. Do not use substitute parts. Contact the dealer for replacement parts.
. Use of a night light may provide added safety precaution for a child using the upper bunk.
. Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed next to
the wall. The guardrail that runs the full length of the bed shuold be placed against the wall to prevent
entrapment between the bed and wall.
. The use of water or sleep flotation mattresses is prohibited.
. Do not exceed 175 lbs on upper bunk.
.Weight limitation: 175lbs.
STRANGUILATION HAZARD –Never attach or hang items to any part of the
bunk bed that are not desinged for use with the bed for exarnple, but not limited to hooks, belts and
jump ropes
Keep these instructions for future reference
