Furniture of America CM3824T User manual

1 / 10
MODEL #
CM3824T
Questions?
GIVE US A CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PT)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
2 - People
(Included)
Allen Wrench
Recommended
VERSION # 21-6-17

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific Time and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PT)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed are all acccounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2 / 10

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent to prevent
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3 / 10
scratches and damages.

4 / XXXXX10

TABLE
5 / 10
CM3824T
#1 1pc #2 2pcs #3 1pc
Table Top
#4 2pcs
Side Panel Stretcher Connection Panel
#A 8pcs
Bolt Ø5/16" x 1-1/4"
Allen Wrench M5
#H 1pc
#F 8pcs
#B 4pcs #C 8pcs #D 12pcs
Flat Washer Ø5/16"
#E 12pcs
Lock Washer Ø5/16" Flat Washer Ø1/4" Lock Washer Ø1/4"
#J 8pcs
Allen Wrench M4
#I 1pc
L Metal Plate
#J 4pcs
Bolt Ø5/16" x 2" Bolt Ø1/4" x 7/8"

6 / 10
CM3824T is packed in 2 cases
Carton Disignation Part Hardware
CM3824T-1 Table Top #1
#A x8pcs
#D x12pcs
#E x12pcs
#C x8pcs
#B x4pcs
#F x8pcs
#G x8pcs
Left Side Panel
#H x1pc
#I x1pc
#J x4pcs
CM3824T-2 Stretcher
Connection Panel
#2
#4
#3

7 / 10
Exploded View
#2
#4
#3
#1

ASSEMBLY INSTRUCTIONS
8 / 10
1
2
#3 x1pc
Hardware #C x4pcs
Hardware #G x4pcs
Hardware #F x4pcs
#2 x2pcs
Part
Part
Hardware #J x4pcs
#3 x1pc
Hardware #C x4pcs
Hardware #F x4pcs
Hardware #G x4pcs
#2 x2pcs
Part
Part
#J
#C
#G
#F
#I
#J
#2
#2
#3
#2
#2
#3
#I
#C
#G
#F
#J
Align and hook the stretcher (#3) to the side panels (#2),
then secure metal plates (#J) to stretcher (#3) and side
panels (#2) by using bolts (#C) with washers (#G,F).
Secure metal plates (#J) to stretcher (#3) by using
bolts (#C) with washers (#G,F).

ASSEMBLY INSTRUCTIONS
9 / 10
3
Hardware #B x4pcs
Hardware #D x4pcs
Hardware #E x4pcs
#2 x2pcs
Part
4
#3 x1pc
Part
#4 x2pcs
Part
Hardware #A x8pcs
Hardware #D x8pcs
Hardware #E x8pcs
#1 x1pc
Part
#2
#2
#4
#4
#H
#B
#E
#D
#2
#2
#1
#H
#A
#E
#D
Align mounting plates (#4) to the side
panels (#2), then secure by using
bolts (#B) with washers (#E,D).
Align side panels (#2) to the top (#1),
then secure by using bolts (#A) with
washers (#E,D).

10 / 10
ASSEMBLY INSTRUCTIONS
5
