Furniture of America Suzanne CM1028-Q Installation guide

CM1028-F/Q
For more information contact our team: [email protected]

Prepare 16 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#H,I). Align back/front
rail (#5,6) to the end of the left/right arm (#1,2), then align bracket (#A) to the holes of the rails (#5,6) and arms
(#1,2). Secure holes on the rails (#5,6) with bolts (#H) and secure holes on the arms (#1,2) with bolts (#I).
Prepare 4 bolts assembly by inserting washer (#F) onto bolts (#J). Align support rail (#8) to
the holes of the arms (#1,2). Secure with bolts (#J).

Prepare 2 bolts assembly by inserting washer (#F) onto bolts (#J). Align support
legs (#9) to the holes of the support rail (#8). Secure with bolts (#J).
Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#G).
Align back rest (#3) to the holes of the arms (#1,2). Secure with bolts (#G).

Align middle slat (#7) to the center of the daybed, then
align slats (#4) next to the middle slat (#7). Secure with
screws (#K).
Assembly Completed

For more information contact our team: [email protected]

Prepare 16 bolts assembly by inserting lock washer (#C),
then flat washer (#D) onto bolts (#B). Align trundle panels
(#1,2,3) to each other, then secure by using bolts (#B).

Align slats (#4,5) to the trundle.
Secure by using screws (#E).

ASSEMBLY COMPLETED
