Furniture of America CM7058D-M User manual

MODEL #
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
2 - People
Phillips
Screwdriver
(Not Included)
(Included)
Allen Wrench
Recommended
1 / 9
VERSION # 20-06-18
CM7058D-M

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX9

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXXXX9

4 / XXXXXXX9

Bolt Ø1/4 x 1-3/8"
Mirror Mirror Support
Dresser
Lock Washer Ø1/4" Allen Wrench M4
Flat Washer Ø1/4"
#1 1pc #2 1pc #3 2pcs
#A 6pcs
5 / 8
#B 6pcs #C 6pcs #D 1pc
#E 1Set
Anti Tip Kit
DRESSER & MIRROR
CM7058D-M

Carton Disignation Part Hardware
Dresser
CM7058D
#A 6pcs
#B 6pcs
#C 6pcs
#D 1pc
CM7058M Mirror
Back Rail
#1
#3
#2
6 / 8
#E 1 Set
#2 #3
#1
850mm
19mm
40mm
62mm
325mm
130mm
232mm
82mm
850mm
CM7058D-M is packed in 2 cases

#B #A
#C
#D
#2
#3
1
2
Part #1 x1pc
7 / 8
ASSEMBLY INSTRUCTIONS
Part #2 x1pc
Part #3 x2pcs
#1
#3
Hardware #A x6pcs
Hardware #B x6pcs
Hardware #C x6pcs
1. Prepare 6 bolt assemblies by first inserting
a lock washer (#B) onto the bolt (#A) then
a flat washer (#C) onto that same bolt
(#A).
2. Carefully place the mirror (#2) onto the
dresser (#1), then align the mirror supports
(#3) to the holes along the back. Insert a
bolt assembly into each hole and secure.
Adjust the leveler
according to the
ground level.

3
4
Hardware #E x 1 Set
8 / 8
ASSEMBLY INSTRUCTIONS
WALL
#E
