Furniture of America CM-BK1039R User manual

EASY
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
Allen Wrench (Included)
Assembly Instructions
Tools Required for Assembly:
Rev.14-03-13
Page 1 of 9
DIFFICULT
ASSEMBLY RATING
CM-BK1039R
2 PERSONS RECOMMENDED

Page 2 of 9

Page 3 of 9
PARTS LIST
HARDWARE LIST
Due to the size of this product, it is highly recommended that
the assembly should be done near the area of its intended
location. Make sure you have enough space to move around
during the assembly.

Before you begin, please read Page 2
of “Assembly and Care Advice” AND
Page 9 of “Safety Warnings”.
And remember, do not tighten until
each step is completed or instructed.
Page 4 of 9
MD
Turn right (clockwise) to tighten
STEP 1: SIDE PANELAND BOTTOM TUBE ASSEMBLY
Note: Right and left is
determined by
standing in the FRONT
(ladder location) of the
completed bed.
STEP 2: GUARDRAIL ASSEMBLY
Enlarged
Turn right (clockwise) to tighten

Page 5 of 9
Turn right (clockwise) to tighten
Turn right (clockwise) to tighten
STEP 3: BASE FRAME ASSEMBLY
Enlarged
STEP 4: LADDER ASSEMBLY
Enlarged
Read and follow the information on the WARNINGS
shown on the end structure of the upper bunk and on
the carton. Do not remove warning label from the
bed. Keep these instructions for future reference.
Safety is ALWAYS the main
priority. Please take the time to
inspect the assembly and
FULLY tighten every bolts and
screws from Step 1 to Step 4.

Page 6 of 9
STEP 5: TENT POLE ASSEMBLY
STEP 6: TENT POLE ASSEMBLY
X 2

Page 7 of 9
STEP 7: TENT POLE ASSEMBLY
STEP 8: TENT COVER ASSEMBLY

Page 8 of 9
STEP 9: TENT COVER ASSEMBLY
ASSEMBLY IS COMPLETED
For extra safety measure and before using the
bunk bed, please take the time to inspect the
assembly again and make sure that ALL bolts
and screws are FULLY tighten.
Read and follow the information on the WARNINGS
shown on the end structure of the upper bunk and on
the carton. Do not remove warning label from the
bed. Keep these instructions for future reference.

Page 9 of 9
Safety Warnings for Bunk Beds
1. Read and follow the information on the WARNINGS shown on the end
structure of the upper bunk and on the carton. Do not remove warning label
from the bed. Keep these instructions for future reference.
2. Always use the recommended size mattress or mattress support, or both, to
help prevent the likelihood of entrapment or falls. Depending on whether
you have twin, full or both sizes, the proper mattress size for the UPPER
TWIN-SIZE bunk should be 74” to 75” long x 37½” to 38½” wide x 6” high
(no higher than 6”) OR for the UPPER FULL-SIZE bunk should be 75” long
x 54” wide x 6” high (no higher than 6”). The proper mattress size for the
LOWER TWIN-SIZE bunk should be 74” to 75” long x 37½” to 38½” wide x
6” to 8” high OR for the LOWER FULL-SIZE bunk should be 75” long x 54”
wide x 6” to 8” high.
3. Surface of mattress must be at least 5 inches (127 mm) below the upper
edge of guardrails.
4. Do not allow persons under 6 years of age to use the upper bunk.
5. Periodically check and ensure that the guardrails, ladder, handle and other
components are in their proper position, free from damage, and that all
connectors are tighten and secured.
6. For safety reasons, especially on the upper bunk bed, DO NOT allow rough
playing or jumping on the bed and do not allow playing or hiding under the
bed.
7. Always use the ladder for entering and leaving the upper bunk.
8. Do not use substitute parts. Contact the manufacturer or dealer for
replacement parts.
9. Use of a nightlight may provide added safety precaution for a person using
the upper bunk.
10. Always use the guardrails on both long sides of the upper bunk. If the bunk
bed will be placed next to the wall, the guardrail that runs the full length of
the bed should be placed against the wall to prevent entrapment between
the bed and the wall.
11. The use of water or sleep flotation mattresses is prohibited.
12. No more than one person is allowed on the upper bunk at all times.
13. The MAXIMUM weight capacity for the upper bunk is not to exceed 150 lbs.
.WARNING:
STRANGULATION HAZARD
Never attach or hang objects to any part of the bunk bed that are not
designed for use with the bed. Objects such as hanger, hook, belt,
bag, rope, string, etc. should not be used on or around the bunk bed.
