INTERFACE UNIT
IF-2500
(TENI, 0307) PUB. No. OMC-43421-A1
IF-2500

i
SAFETY INSTRUCTIONS
CAUTION
The mounting location should satisfy
the following conditions:
Sparate from radio transmitter, radar,
direction finder (at least 3m).
Locate the equipment away from air
conditioner vents.
Keep the equipment out of direct
sunlight.
Vibration should be minimal.
The location should be free of water
spray.
CAUTION
Observe the following compass safe
distances to prevent deviation of a
magnetic compass:
Turn off the power switch at the
switchboard before beginning the
installation.
IF-2500
Standard
compass Steering
compass
1.40 m 0.95 m

ii
TABLE OF CONTENTS
Overview...............................................................................................................1
Installation materials...........................................................................................1
Spare parts ...........................................................................................................1
Cables...................................................................................................................2
Mounting...............................................................................................................2
Grounding ............................................................................................................2
Selection of output data format..........................................................................2
Cable fabrication ................................................................................................. 2
Maintenance.........................................................................................................5
SPECIFICATIONS
PACKING LIST
OUTLINE DRAWING
INTERCONNECTION DIAGRAM

1
Overview
The interface for the dual GPS navigator receives data from two GPS navigators and chooses
one to output in accordance with priority order. Output data is converted to NMEA current loop,
IEC 61162-1 or contact signal and output.
Outputs data in accordance
with priority order
Input 1
(GPS navigator)
Input 2
(GPS navigator)
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Receiving Error Alarm
Cross Track Error Alarm
12-24 VDC
Arrival Alarm

2
Mounting
This unit does not have power switch. If you
do not connect the IF-2500 to power
switchboard or circuit breaker, install an
external power switch (local supply), locating
it near the IF-2500.
•All dimensions in millimeters.
•For added support, use nuts, bolts and
washers instead of woodscrews.
•Leave sufficient space at the sides and rear
of the unit for maintenance and servicing.
Grounding
To prevent mutual interface, run a ground
wire between the earth terminal on the unit
and ship’s superstructure.
Selection of output data format
The output data format is selectable by
changing a jumper block; A for IEC61162-1
and B for NMEA. For example, to select
NMEA for J4, change the jumper block from A
to B on JP401 and JP402. Do the same on J5
thru J9.
Factory setting
Output Jumper IEC61162-1
(A)
Current
loop
(B)
J4 JP401/JP402 !
J5 JP501/JP502 !
J6 JP601/JP602 !
J7 JP701/JP702 !
J8 JP801/JP802 !
J9 JP901/JP902 !
Cable fabrication
Use the following cables (Japan Industrial
Standard cables) or the equivalents.
Conductor
S = 0.75 mm
φ= 1.11 mm
2
TTYCS-1 (Twisted pair cable)
Conductor
S = 0.2 mm
φ= 0.6 mm
2
CO-SPEVV-SB-C 0.2x2P
Armor
Armor
Vinyl sheath
Shield
Shield
Sheath
Sheath
Current loop or IEC 61162-1 signal
Current loop or IEC 61162-1 signal
φ = 10.1 mm
φ = 10.5 mm

3
Fabrication of CO-SPEVV-SB-C 0.2X2P
33 mm
Shield
Earth cable
Heat shrink tube
Heat shrink tube
Cut unused cores and solder them to shield.
Twist and solder
(Supplied)
28 mm
15 mm
15 mm
30 mm
35 mm
75 mm
Sheath
Armor
3 mm
3 mm
Fix the cable with
the cable clamp
at this location.
How to fabricate the signal cable

4
0.5A
J12
J11
JP802
CR10
14P0285
JP702JP602JP502JP402JP902
J10
J8
J7
J6
J5
J4
J9
J3
J2
J1 Power
10-35V
FUSE
JP801JP701JP601JP501JP901JP401
S1
CR9CR8CR7CR6CR4CR3CR2
Alarm output 3
Alarm output 2
Alarm output 1
Output port 5
Output port 4
Output port 3
Output port 2
Output port 1
Output port 6
Input port 2
Input port 1
Jumper A: IEC61162-1
B: Current loop
B
A
B
A
B
A
B
A
A
B
B
A
A
B
B
A
B
A
B
A
B
A
B
A
Parts location
Alarm output 1 ArrivalAlarm
Alarm output 2 Cross Track Error Alarm
Alarm output 3 Receiving Error Alarm
Alarm output normal closed type
Normal Relay contact is closed.
Abnormal Relay contact is open.
Turns the power
off Relay contact is open.
LEDs (Normal status)
CR6 Blinks every second.
CR7 Off.
CR8 Off.
CR9 Lights when Input port 1 has
priority.
CR10 Lights when Input port 2 has
priority.

5
Maintenance
Self test 1
The unit performs an internal self-check in
the following sequence each time power is
turned on.
1. LEDs CR7 to CR10 blink twice every 2
seconds.
2. ROM and RAM are tested.
3. LED CR6 blinks every second for normal
operation. If an error is detected during
the test, the corresponding LED is turned
on.
•When CR7 is on, ROM is defective.
•When CR8 is on, RAM is defective.
Self test 2
The test requires an external loop to check
I/O. Follow the steps below to carry out the
test.
1. Set the DIP switch #4 of S1 to the ON
position.
2. Temporarily disconnect input and output
connectors J2 and J4.
3. Construct a pair of short connector
assemblies as below.
1
2
3
4
1
2
3
4
5
6
RS422_OUT_A
RS422_OUT_B
For J4, J5, J6 ,J7 and J8
For J9
J2
J2
XH4P
XH6P
NC NC
NC
NC
GND GND
RD_H
RD_C
1
2
3
4
5
1
2
3
4
5
6
RS422_OUT_A
RS422_OUT_B
XH5P
XH6P
NC
NC NC
NC
NC
GND GND
RD_H
RD_C
Short connector assy
4. Connect the XH6P-XH4P short connector
assy. between J2 and J4.
5. Confirm that each LED lights according
to equipment status as follows:
CR2 Lights when receiving NMEA data
from J2.
CR4 Lights when sending NMEAdata
to J4 thru J9.
CR6 Blinks every second.
CR7 Lights when ROM error is
detected.
CR8 Lights when RAM error is
detected.
CR9 Lights when SIO error is detected.
CR10 Normally off.
5. Remove the connector from J4 and plug
it into J5, J6, J7 and J8 successively,
confirming that CR2 and CR9 light as
below for each port. Then, remove the
XH6P-XH4P short connector assy., plug
in the XH6P-XH5P short connector assy.
between J2 and J9, and confirm that CR2
and CR9 light as below.
CR2 Lights when receiving NMEA data
at J2.
CR9 Lights when SIO error is detected.
6. Remove the XH6P-XH5P short
connector assy. Plug in the XH6P-XH4P
short connector assy. between J3 and J4,
J5, J6, J7 and J8 successively. Confirm
that LEDs light or blink as below.
Remove the XH6P-XH4P short
connector assy., plug in the XH6P-XH5P
short connector assy. between J3 and J9
and confirm that the LEDs light or blink
as below.
CR3 Lights when receiving NMEA data
at J3.
CR4 Lights when sending NMEAdata
to J4 thru J9.
CR6 Blinks every second.
CR9 Lights when SIO error is detected.
The relay contact signal output is turned on
and off alternately every second during the
test.
Fuse replacement
If the fuse blows, find the cause of the
problem before replacing it. Do no use a fuse
rated more than 0.5A, since it may cause
more serious damage to the equipment.

FURUNO
SP-1E4408S01C
SPECIFICATIONS OF INTERFACE UNIT
IF-2500
This equipment is used for distribution of navaids data from navigation equipment. It provides
six outputs each from two independent inputs. Alarm signal is also available to distribute three
outputs from two independent inputs.
1. Port Input: 2 ports (IEC61162-1)
Output: 6 ports (IEC61162-1 or Current loop)
Alarm signal Output: 3 ports (Relay contact)
2. Alarm signal Receiving Error Alarm, Cross Track Error Alarm, Arrival Alarm
3. Rated voltage/Current 12-24 VDC: 0.16-0.08 A
4. Coating Color 2.5GY 5/1.5 Newtone No.5
5. Ambient Temperature -15 to 55℃
6. Relative Humidity 95%RH(40℃)
7. Water proofing IPX0

NAME OUTLINE Q'TYDESCRIPTION/CODE№
ＰＡＣＫＩＮＧ ＬＩＳＴ
ＰＡＣＫＩＮＧ ＬＩＳＴＰＡＣＫＩＮＧ ＬＩＳＴ ＰＡＣＫＩＮＧ ＬＩＳＴ
14CL‑X‑9851‑1
IF‑2500
IF‑2500IF‑2500 IF‑2500
1/1
NAME OUTLINE Q'TY
DESCRIPTION/CODE№
ユニット
ユニットユニット ユニット UNIT
UNITUNIT UNIT
ｲﾝﾀ‑ﾌｪｲｽﾕﾆｯﾄ INTERFACEUNIT
IF‑2500
000‑000‑999
1
(*1)
予備品
予備品予備品 予備品 SPAREPARTS
SPAREPARTSSPAREPARTS SPAREPARTS SP14‑01100
SP14‑01100SP14‑01100 SP14‑01100
ﾋｭｰｽﾞ FUSE
FGMB0.5AAC125V
000‑114‑994
3
工事材料
工事材料工事材料 工事材料 INSTALLATIONMATERIALS
INSTALLATIONMATERIALSINSTALLATIONMATERIALS INSTALLATIONMATERIALS CP14‑06300
CP14‑06300CP14‑06300 CP14‑06300
ｹｰﾌﾞﾙ組品MJ CABLEASSY.
MJ‑A6SPF0012‑100 64S4071
000‑133‑817
1
+ﾄﾗｽﾀｯﾋﾟﾝﾈｼﾞ +TAPPINGSCREW
4X16SUS3041ｼｭ
000‑802‑080
4
XHｺﾈｸﾀ組品 XHCONNECTORASSY.
XH6P‑002
000‑000‑991
2
(*1)
XHｺﾈｸﾀ組品 XHCONNECTORASSY.
XH5P‑002
000‑000‑992
1
(*1)
XHｺﾈｸﾀ組品 XHCONNECTORASSY.
XH4P‑002
000‑000‑993
5
(*1)
XHｺﾈｸﾀ組品 XHCONNECTORASSY.
XH3P‑002
000‑000‑994
3
(*1)
電源ｹｰﾌﾞﾙ組品 POWERCABLEASSY.
VCTF1.25X2C*3M*/VH2P
000‑000‑995
1
(*1)
ｽﾐﾁｭｰﾌﾞF(Z) HEAT‑SHRINKTUBE
3X0.25ｸﾛ*1.00M*
000‑568‑172
1
ｽﾐﾁｭｰﾌﾞF HEAT‑SHRINKTUBE
10X0.25ｸﾛ*0.5M*
000‑123‑379
1
1.(*1)印のユニット及び部品コードは架空コードに付き注文用には使用できません。 (*1)Code numbers are not allowed to order as dummy code.
（略図の寸法は、参考値です。DIMENSIONSINDRAWINGFORREFERENCEONLY.）
（略図の寸法は、参考値です。DIMENSIONSINDRAWINGFORREFERENCEONLY.）（略図の寸法は、参考値です。DIMENSIONSINDRAWINGFORREFERENCEONLY.） （略図の寸法は、参考値です。DIMENSIONSINDRAWINGFORREFERENCEONLY.） 14CL‑X‑9851

C
B
123
D
A
DWG.No.
SCALE
CHECKED
APPROVED
DRAWN
MASS kg
名称
NAME
TITLE
INTERCONNECTION DIAGRAM
相互結線図
IF‑2500
インターフェイスユニット
INTERFACE UNIT
NOTE
*1. SHIPYARD SUPPLY.
注記
＊１）造船所手配。
＊２）内部の設定で切替え。
P
RD‑H
RD‑C
1
2
3
4
5
6
NC
NC
NC
GND
J3(XH6P)
P
RD‑H
RD‑C
1
2
3
4
5
6
NC
NC
NC
GND
J2(XH6P)
1
2
P
DC+
DC‑
NC
GND
1
2
3
4
TD‑H/TD‑B
TD‑C/TD‑A
CO‑0.2x2P OR
P
J5(XH4P) 出力
CURRENT LOOP
NC
GND
1
2
3
4
TD‑H/TD‑B
TD‑C/TD‑A
CO‑0.2x2P OR
P
出力
CURRENT LOOP
J4(XH4P) OUTPUT
OUTPUT
IEC61162‑1/
IEC61162‑1/
NC
GND
1
2
3
4
TD‑H/TD‑B
TD‑C/TD‑A
CO‑0.2x2P OR
P
出力
CURRENT LOOP
OUTPUT
IEC61162‑1/
J6(XH4P)
NC
GND
1
2
3
4
TD‑H/TD‑B
TD‑C/TD‑A
CO‑0.2x2P OR
P
出力
CURRENT LOOP
OUTPUT
IEC61162‑1/
NC
GND
1
2
3
4
TD‑H/TD‑B
TD‑C/TD‑A
CO‑0.2x2P OR
P
出力
CURRENT LOOP
OUTPUT
IEC61162‑1/
J7(XH4P)
J8(XH4P)
NC
1
2
3
TD‑H/TD‑B
TD‑C/TD‑A
CO‑0.2x2P OR
P
出力
CURRENT LOOP
OUTPUT
IEC61162‑1/
1
2
3
CO‑0.2x2P OR
P
GND 4
5
NC
J9(XH5P)
J10(XH3P)
ALARM OUTPUT (ARRIVAL)
アラーム出力（接近警報）
ALARM‑OUT1‑H
ALARM‑OUT1‑C
GND
1
2
3
CO‑0.2x2P OR
P
GND
1
2
3
CO‑0.2x2P OR
P
GND
J11(XH3P) アラーム出力（オフトラック）
ALARM OUTPUT (OFF TRACK)
アラーム出力（受信不良）
ALARM OUTPUT (RECEIVING ERROR)
ALARM‑OUT3‑H
ALARM‑OUT3‑C
J12(XH3P)
*2
*2
*2
*2
*2
*2
CO‑0.2x2P OR
CO‑0.2x2P OR
データ入力
IEC61162‑1 DATA INPUT
航法装置
NAVIGATOR
航法装置
NAVIGATOR
*2. SELECT CURRENT LOOP OR IEC61162‑1 BY INNER SETTING.
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
TTYCS‑1 *1
C4342‑C02‑ A
31 July '03
H.MAKI
優先順位 (Priority): J2 > J3
TTYCS‑1 *1
TTYCS‑1 *1
ALARM‑OUT2‑H
ALARM‑OUT2‑C
インターフェイスユニット
INTERFACE UNIT
IF‑2500
J1(VH2P)
アース銅板 *1
COPPER STRAP
VCTF1.25x2C/VH2P,3m,φ7.4
12‑24VDC
CO‑0.2x2P: CO‑SPEVV‑SB‑C 0.2x2P,φ10.5
Takahashi T.
Takahashi T.
