Fusion 16908 User manual

Trouble Shooting Tips
If your solar light does not come on at dusk despite following all
instructions please try the following steps:
1. Make sure that the solar light is not affected by any other light
source.
2. Ensure the solar light does not stand in the shade all day.
3. Check to see if the batteries are installed correctly.
4. If there is a protective film on the solar panel carefully remove
this.
Care Information
1. Clean any dirt and debris from the solar panel. The panel
cannot recharge if the light is obstructed. Use a soft cloth to clean
the panel. Do not use abrasives or chemicals that might scratch or
damage the UV coating.
2. In a region where snow and ice are likely and the light
assembly is covered with snow for an extended period of time the
batteries will require a recharge for at least 8 hours.
Warranty Information
1-YEAR LIMITED PRODUCT WARRANTY
This product is covered under a one year limited warranty.
Fusion Products Ltd. warrants to the original purchaser that
this product is free from defects in materials and workmanship
for the period of one year warranty from date of purchase.
For Technical Support and/or Warranty inquiries
please contact:
Fusion Products Ltd.
Monday to Friday
8:30-5:00 PM EST
2905 Argentia Road, Unit 2,3
Mississauga, Ontario L5N 8G6
Tel: [phone] Fax: [phone]
Email: [e-mail]
SOLAR MOTION
ACTIVATED SECURITY
LIGHT
FUSION PRODUCTS LTD.
Model No. 16908

Contents
Overview ...........................................................................................see below
About Your Solar Light ...................................................................................1
Getting Started ...................................................................................................1
Important .............................................................................................................1
Parts and Hardware List ................................................................................2
Operation .............................................................................................................2
Installation...................................................................................................... 3-4
Battery Replacement ......................................................................................5
Trouble Shooting Tips ....................................................................................6
Care Information ..............................................................................................6
Warranty Information ....................................................................................6
Overview
This product is designed to the highest technical specifications and
standards. It will supply years of maintenance free use. Please read
these instructions thoroughly prior to installation, then store in a
safe place for future reference. If at any time you are unclear about
this product, or require further assistance please do not hesitate to
contact our trained professionals operating the customer support
line at 1-877-615-1378 Monday to Friday between the hours 8:30
AM to 5:00 PM Eastern Standard Time or email
[e-mail]
Battery Replacement (Remove Old)
STEP 1:
Turn the nut on the back of the light by hand in a counter clockwise
direction to remove.
STEP 2:
Carefully remove the back cover of the light.
STEP 3:
Locate the ON/OFF switch on the lower
right hand side. Move the switch to the left
(OFF position).
STEP 4:
Carefully remove the old batteries from the
battery compartment.
Battery Replacement (Install New)
STEP 1:
Replace the batteries with
equivalent new solar rechargeable
batteries, ensuring the correct
polarity is observed.
STEP 2:
Move the switch to the right (ON
position).
STEP 3:
Replace back cover.
STEP 4:
Turn the nut in clockwise direction until secure.
Allow the unit to charge for up to 2 days in the <OFF> position. Once fully
charged, move the switch to the right (ON position). The light will
automatically come on when motion is detected within the detection zone
of the sensor once it gets dark.
Caution: Rechargeable batteries contain Nickel-Cadmium or Nickel-
Metal Hydride and must be recycled or disposed of properly. Do not
mix old and new batteries. Do not mix alkaline, standard (carbon-
zinc), or rechargeable batteries. Do not dispose of batteries in fire.
Batteries may explode or leak.
5

Installation (Remote Solar Panel)
NOTE: If you choose, you can mount the solar
panel remotely from the light. Follow Steps 1-3
below, and then proceed to “Installation
(Mount Remote Solar Panel)”
STEP 1: Turn the nut on
the back of the light in a
counter clockwise direction
to remove.
STEP 2: Carefully remove
the back cover of the light.
STEP 3: Remove the
screws (2) on the back of
the light securing the solar
panel to the security light.
Installation (Mount Remote Solar Panel)
Carefully pull the wire through the top of security light to the desired
length. Before proceeding, ensure you will be able to mount both the
security light and solar panel in the desired locations (respectively).
STEP 1: Using the mounting bracket as a guide, select desired installation
location.
STEP 2: Mark the holes where you will need to pre-drill for screws or
wall anchors (if required).
STEPS 3 & 4: Pre-drill holes for screws and use wall anchors as necessary
(if required).
STEP 5: Secure
screws through
corresponding
holes in mounting
bracket.
STEP 6: Line up
mounting bracket
with the
underside of the
solar panel.
STEP 7: Secure
solar panel to
mounting bracket
with screws.
About Your Solar Light
During the day your solar panel will convert the sun's light and/or UV
rays into electrical power that will charge the rechargeable battery. When
it becomes dark, the solar light will turn on using the power stored on the
rechargeable battery as it will detect no day light. The units light output
strength and time depends on how many hours and how much sunlight
and/or UV rays your panel absorbs throughout the day.
For maximum output place the solar panel in an area where there is direct
sunlight for at least 8 hours in a given day. Do not install your solar light
in a shaded area. The selected location should not be near night time light
sources such as; porch lights, street lights or pool lights as these may
cause the solar light to turn off prematurely.
Getting Started
Please do not throw away any packing material until all parts are verified
as present.
Important
•Fully charge the battery before first use. Charge under direct sunlight
in the <OFF> position for 2 days.
•For best results, locate your solar lamp in a position where it can get
direct sunlight on the solar panel and generally free from cover and
shade.
•Keep your solar lights away from other night-time light sources, such
as streetlights.
•Make sure the solar panels are not covered by dust, snow and debris.
Clean it with a soft damp cloth or paper towel periodically. Avoid the
use of abrasive cleaning agents.
•Use only rechargeable batteries for your solar lights. Replace with a
new battery of the same size each year for optimum performance.
•The performance of the solar light will vary with the time of year. It
will deliver more light when it has had a full day in the sun rather
than a day in overcast weather.
4
1

Your Solar Light
You Will Need
Operation
For First Time Use:
Fully charge the battery before first use.
Charge under direct sunlight in the <OFF>
position for 2 days.
STEP 1: Turn the nut on the back of the
light in a counter clockwise direction to
remove.
STEP 2:
Carefully remove the back cover of the
light.
STEP 3:
With the back cover removed, locate the
ON/OFF switch on the lower right hand
side. Move the switch to the right (ON
position). When movement is detected,
the light will switch to full power for
about 25 seconds, before returning to
normal level once again.
Installation (Standard Wall Mount)
STEP 1: Using the wall mount bracket as a guide, select desired
installation location.
STEP 2: Mark the holes where you will need to pre-drill for screws or
wall anchors (if required).
STEPS 3 & 4: Pre-drill holes for screws and use wall anchors as
necessary (if required).
STEP 5: Secure screws through corresponding holes in wall mount
bracket.
STEP 6: Line up the hole at the end of the wall mount bracket with the
bottom of the security light.
STEP 7:
Tighten machine screw until secure.
Using the adjustment screw on the side of the
wall mount bracket, adjust the angle of the light
as required and tighten to secure in the desired
position.
