Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
1

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
2
Content
Introduction and safety ........................................................................................................................... 3
Intended use ........................................................................................................................................ 3
General safety instructions for power tools........................................................................................ 3
Workplace Safety ................................................................................................................................ 3
Electrical Safety ................................................................................................................................... 3
Safety of Persons ................................................................................................................................. 4
Use and treatment of the power tool ................................................................................................. 5
Use and handling of the cordless tool ................................................................................................. 5
Safety Instructions for Lawn Mowers ..................................................................................................... 6
General Safety Instructions ................................................................................................................. 6
Before Use ....................................................................................................................................... 6
During Operation ............................................................................................................................. 7
After use .......................................................................................................................................... 7
Safety instructions for the charger ...................................................................................................... 7
Safety Instructions for Li-Ion Batteries ................................................................................................ 8
Presentation ............................................................................................................................................ 9
Switching the device on/off .................................................................................................................. 14
Working Instructions ............................................................................................................................. 14
Lawn care tips .................................................................................................................................... 14
Disposal ................................................................................................................................................. 15
Technical Data ....................................................................................................................................... 16
Declaration of Conformity ..................................................................................................................... 17

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
3
Introduction and safety
Never allow children or persons unfamiliar with these instructions to use the garden device. Children
should be supervised to ensure that they do not play with the appliance.
Intended use
This device is intended exclusively for mowing lawns in private areas.
The device must be used following the descriptions
and safety instructions are given in this user manual. Any other use is not intended. Unauthorized
use will invalidate the warranty and override any responsibility on the part of the manufacturer. The
user is liable for all damages to third parties and their property. Operate the device only in the
technical condition prescribed and delivered by the manufacturer. Unauthorized modifications to the
device exclude the manufacturer's liability for any resulting damage.
General safety instructions for power tools
WARNING!
Read all safety notices and instructions. Failure to follow the safety instructions and instructions can
cause electric shock, fire, and/or severe injury.
Keep all safety notes and instructions for future reference.
The term power tool used in the safety instructions refers to mains operated power tools (with
power cord) and cordless power tools (without power cord).
Workplace Safety
- Keep your work area clean and well lit. Clutter or unlit work areas can lead to accidents.
- Do not work with the power tool in explosive environments containing flammable liquids, gases, or
dust. Power tools produce sparks that can ignite the dust or fumes.
- Keep children and other persons away while using the power tool. If distracted, you may lose
control of the device.
Electrical Safety
- The plug of the power tool must fit into the socket. The cap must not be changed in any way. Do
not use adapter plugs together with grounded power tools. Unchanged plugs and suitable sockets
reduce
the risk of electric shock.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
4
- Avoid physical contact with grounded surfaces such as pipes, heaters, stoves, and refrigerators.
There is an increased risk of electric shock if your body is grounded.
- Keep power tools away from rain or moisture. The penetration of water into a power tool increases
the risk of electric shock.
- Do not use the cable to carry or hang up the power tool or to pull the plug from the socket. Keep
the cord away from heat, oil, sharp edges, or moving parts. Damaged or tangled cables increase the
risk of electric shock.
- If you use a power tool outdoors, only use extension cables that are suitable for outdoor use. The
use of an extension cable
ideal for outdoor use reduces the risk of electric shock.
- If you use a power tool outdoors, only use extension cables that are suitable for outdoor use. The
use of an extension cable
ideal for outdoor use reduces the risk of electric shock.
Safety of Persons
- Be alert, pay attention to what you are doing, and use common sense when working with a power
tool. Do not use a power tool if you are tired or under the influence of drugs, alcohol, or medication.
A moment of inattention while utilizing the power tool can cause serious injury.
- Wear personal protective equipment and always protective goggles. Wearing personal protective
equipment, such as dust mask, non-slip safety shoes, safety helmet or hearing protection,
depending on the type and use of the power tool reduces the risk of injury.
- Avoid unintentional commissioning. Make sure that the power tool is switched off before
connecting it to the power supply and/or battery, picking it up or carrying it. If you have your finger
on the switch when carrying the power tool
or if you connect the device to the power supply while it is switched on, this can lead to accidents.
- Remove adjustment tools or wrenches before turning on the power tool. A tool or key that is in a
rotating part of the device
can cause injury.
- Avoid an abnormal posture. Make sure you have a secure
footing and keep your balance at all times. This allows you to better control the power tool in
unexpected situations.
- Wear suitable clothing. Do not wear loose clothing or jewelry. Keep hair, clothing, and gloves away
from moving parts. Loose clothing, jewelry, or long hair can be caught by moving parts.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
5
Use and treatment of the power tool
- Do not overload the device. Use the appropriate power tool for your work. With the right power
tool, you will work better and safer in the specified power range.
- Do not use a power tool with a defective switch. A power tool that can no longer be switched on or
off is dangerous and must be repaired.
- Unplug the power cord and/or remove the battery before making any adjustments to the device,
changing accessories, or putting the device away. This precaution prevents unintentional starting of
the power tool.
- Keep unused power tools out of the reach of children. Do not allow persons to use the device which
is not familiar with it or have not read
these instructions. Power tools are dangerous if they are used by inexperienced persons.
- Maintain power tools with care. Check that moving parts function correctly and do not jam, that
parts are not broken or damaged in such a way that the function
of the power tool is impaired. Have damaged parts repaired before using the device. Many accidents
are caused by poorly maintained power tools.
- Keep cutting tools sharp and clean. Carefully maintained cutting tools
with sharp cutting edges jam less and are easier
to guide.
- Use power tools, accessories, insertion tools, etc. according to these instructions. Take into account
the working conditions and the job to be performed. The use of power tools for applications other
than those intended can
lead to dangerous situations.
Use and handling of the cordless tool
- Charge the batteries only with chargers recommended by the manufacturer. A charger that is
suitable for a particular type of battery poses a fire hazard when used with other batteries.
- Only use the batteries provided in the power tools. Using other batteries may result in personal
injury and fire hazards.
- Keep the unused battery away from paper clips, coins, keys, nails, screws, or other small metal
objects that could cause the contacts to bridge. A short circuit between the battery contacts can
cause burns or fire.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
6
- The liquid may leak from the battery if misused. Avoid any contact with it. In case of accidental
contact, rinse with water. If the liquid gets into your eyes, seek additional medical attention. Leaking
battery fluid may cause skin
irritation or burns.
Safety Instructions for Lawn Mowers
General Safety Instructions
- For your safety and the safety of others, read this user manual and its safety instructions before
using the device. Please keep the user manual and
its safety instructions in a safe place for future reference and
keep them handy for any use.
- Pass on the operating instructions with the device if there is a change of ownership.
- Persons operating the device must not be under the influence of intoxicating substances (e.g.,
alcohol, drugs, or medicines).
- Operate the device only in the condition prescribed and delivered by
the manufacturer. Unauthorized modifications to the device exclude the manufacturer's liability for
any resulting damage.
- Only use the device in daylight or under good artificial lighting.
- Only use the device in dry weather conditions. Keep it away from rain or moisture. The penetration
of water into the device increases the risk of electric shock.
- Switch off the device and remove the battery in the following conditions:
 if the device is left unattended;
 before checking, cleaning or other work on the device;
 if the device starts to vibrate excessively.
Before Use
- Familiarize yourself with the device and its functions and controls before starting work.
- Check the device for signs of wear or damage before starting up and after a collision.
- Do not use a device whose switch is defective and can no longer be switched on or off.
- Check that all nuts, bolts, and screws are tight to ensure that the device is operated safely.
- Never use a device with damaged or missing parts. Have them repaired or replaced if necessary by a
qualified specialist or workshop.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
7
- When working with or on the device, always wear sturdy shoes, long trousers, and the appropriate
personal protective equipment (safety goggles, hearing protection, non-slip work gloves, etc.). The
wearing of personal protective equipment reduces the risk of injury.
During Operation
Do not switch on the device if persons (especially children) or animals are in the immediate vicinity.
Make sure that children do not play with the device.
Interrupt work if you notice that people (especially children) or pets are nearby.
Working on steep slopes can be dangerous. Make sure that you have a firm stand and mow slowly.
Always mow across the slope and not up and down. Be especially careful when changing directions.
There is a danger of tipping over!
Do not mow on steep slopes. Be especially careful if you move backward when mowing and pull the
mower onto yourself.
Do not tilt the mower when starting the motor.
Keep a safe distance, as indicated by the handle frame.
Do not start the motor until your feet are at a safe distance from the cutter bar. Be careful not to
reach into the rotating cutter bar. Switch off the mower before tipping or transporting it, e.g.,
from/to lawn or over paths. Never drive over gravel while the motor is running. There is the danger
of being hit by stones!
Before lifting or transporting the mower, turn off the motor, remove the safety key and service
until the cutting bar has come to a standstill. Do not adjust the cutting height until the motor is
switched off, and the cutter bar has come to a standstill. Never open the discharge hatch while the
motor is running. Before removing the grass catcher, switch off the motor and wait until the cutter
bar has come to a standstill. After emptying the grass catcher, carefully re-attach it and ensure that
the grass catcher is securely attached to the mower. If possible, do not mow wet grass. Do not work
with the garden device in a potentially explosive environment where there are flammable liquids,
gases, or dust. If you interrupt work, never leave the device unattended and store it in a safe place.
After use
Switch off the device and remove the battery from the mower. Then place the unit in a safe place.
Do not store the device within reach of children. Make sure that the ventilation slots in the device
are clean.
Keep all nuts, bolts, and screws tightened to ensure that the mower is in safe working condition.
Check the grass catcher frequently for wear or damage.
Only use the cutter bar designed for this mower.
Please follow the provided installation instructions and remove the battery before.
Have repairs carried out only by a qualified technician or service center.
Safety instructions for the charger
- Keep the charger away from rain or moisture. The penetration of water into a charger increases the
risk of electric shock.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
8
- Keep the charger clean. There is a risk of electric shock from soiling.
- Check the charger, cable, and plug before each use. Do not use the charger if you notice any
damage. Do not open the charger yourself and have it repaired only by qualified personnel and only
with original spare parts.
Damaged chargers, cables, and connectors increase the risk of electric shock.
- Do not place objects on the charger or place them on soft surfaces. There is a risk of fire.
- Always check that the mains voltage corresponds to the voltage indicated on the charger's
nameplate.
- Never use the charger if the cable, plug, or the device itself is damaged by external influences. Take
the charger to the nearest specialist workshop.
- Never open the charger under any circumstances. Take it to a specialist workshop in the event of a
fault.
Safety Instructions for Li-Ion Batteries
- Do not open the battery. There is a danger of a short circuit.
- Protect the battery from heat, including continuous exposure to sunlight, fire, water, and moisture.
There is a danger of explosion.
- Vapors may escape if the battery is damaged or misused. Supply fresh air and consult a doctor if
you have any complaints. The vapors may irritate the respiratory tract.
- The liquid may leak from the battery if misused. Avoid any contact with it. In case of accidental
contact, rinse with water. If the liquid gets into your eyes, seek additional medical attention. Leaking
battery fluid may cause skin
irritation or burns.
- Only use original rechargeable batteries with the voltage specified on the rating plate of
your power tool. When using other batteries, e.g., imitation reconditioned batteries or batteries
from different manufacturers, there is a risk of injury and material damage due to exploding
batteries.
- The battery voltage must match the battery charging voltage of the charger. Otherwise, there is a
risk of fire and explosion.
- Charge the batteries only with chargers recommended by the manufacturer. A charger that is
suitable for a particular type of battery poses a fire hazard when used with other batteries.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
9
- The battery can be damaged by pointed objects such as nails or screwdrivers or by an external
force. An internal short circuit may occur, and the battery may burn, smoke, explode or overheat.
Presentation
Figure 1: Lawn Mower
1. On/off switch or handle
2. Upper linkage
3. Lower linkage
4. Grass catcher basket
5. Height adjustment lever
6. Battery cover
7. Grass catcher box cover
8. Safety button

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
10
Figure 2: Charger and rechargeable battery (dual charger as shown on the
the right is included)
9. Battery
10. Battery level indicator
11. Push button to display the charging capacity
12. Locking button (locks in place when inserted into charger or mower)
13. Control lights (in the right picture point 4)
14. Charger

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
11
Figure 3: Lawn Mower
15. Locking lever for the lower linkage
16. Holding device for the lower linkage
Figure 4: Lawn Mower
17. Screw for connecting the upper linkage with the lower linkage
18. Locking lever for connecting the two linkages

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
12
Figure 5: Grass catcher basket
19. Grass catcher basket
20. Rail for attachment to lawnmower
Figure 6: Battery compartment including batteries
21. Ensure that the safety key is correctly seated
(circuit breaker)

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
13
Figure 7: Close up of the height adjustment lever
Figure 8: Close-up of the safety button and the on/off switch
or handle.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
14
Figure 9: Close up of the bottom of the lawnmower
23. Screw for fixing the blade to the lawnmower
24. Blade
25 Holes on the blade (ensure correct positioning)
Switching the device on/off
Insert the batteries in the rails provided. Then insert the security key (Figure 6, No. 21). Only then can
you operate the safety button and the on/off switch (Figure 8, points 8+1). The device now turns on.
When you
release the on/off switch, the device stops working. Attention: Cutting tools can still run on
minimally.
Working Instructions
Lawn care tips
Here are some tips to help you keep your lawn healthy and ensure even growth:
A lawn consists of different types of grass. Frequent mowing promotes the growth of grass,

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
15
this leads to strong roots and a firm grass leaf. If you rarely cut the grass, strongly growing grass
species and other weeds (such as clover, daisies) will develop.
The average height of a lawn is about 4-5 cm. Only a third of the total height should be mowed;
therefore, cut 7-8 cm of grass to the average height.
Disposal
WARNING!
Make used power tools unusable before disposal:
 mains-operated power tools by removing the connecting plug,
 cordless power tools by removing the battery.
For EU countries only
Do not throw power tools in household waste! According to the European Directive 2012/19/EC on
waste electrical and electronic equipment and its implementation in national law, used electrical
equipment must be collected separately and sent for environmentally sound recycling. Recovery of
raw materials instead of waste disposal. The device, accessories, and packaging should be recycled in
an environmentally friendly manner. Plastic parts are marked for recycling according to type.
WARNING!
Do not throw batteries in the household waste, fire, or water. Do not open worn-out batteries.
Batteries should be collected, recycled, or disposed of in an environmentally friendly manner.
For EU countries only: According to Directive 2006/66/EC, defective or exhausted batteries must be
recycled.
NOTE:
Please contact your local authority/city for information on disposal options,
Recycling raw materials instead of waste disposal.

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
16
Technical Data
Lawn Mower
Idling speed 3,900 min-1
Nominal voltage 2× 20 V
Working width 330 mm
Cutting heights 25–65 mm
Setting options 5
Grass catcher box volume 35l
Granted sound power level (LWA) 88.5 dB (A)
2.39 dB (A)
Measured sound pressure
(LPA) 77.9 dB (A) 3 dB (A)
Vibration 2.1 m/s²
(K = 1,5 m/s²)
Weight (without battery) 14 kg
Charger
Nominal voltage 230 V~, 50 Hz
Nominal power 140W
Charging voltage 20.9 V
Charging current 2.4A
Protection class II
Battery Pack
Battery type Li-Ion
Nominal voltage 20 V
Capacity 2Ah
Charging time
60min

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
17
Declaration of Conformity
Producer FUXTEC GmbH
Kappstraße 69, 71083 Herrenberg Germany
Phone.: [phone]
Fax: [phone]
Email: [email protected] Web: www.fuxtec.de
Name E1 2 x 20V Cordless Lawn Mower
Model D03004500
EC directive MD Directive: 2006 / 42 /EC
Applicable standards
EN 60335-1:2012+A11:2014+A13:2017
EN 60335-2-77:2010
EN 62233:2008
We hereby declare that the device mentioned above, due to its design, in the version marketed
by us, complies with the necessary safety and health requirements of the listed EC directive.
Any manipulation or change of the device not being explicitly authorized by us in advance
renders this document null and void.
Storage of the technical documentation: FUXTEC GmbH ● Kappstraße 69 ● 71083 Herrenberg
● Germany, T. Gumprecht, Management
Herrenberg, 7 January 2020
Tim Gumprecht FUXTEC GmbH
KAPPSTRASSE 69
71083 HERRENBERG GERMANY

Original User Manual FUXTEC 20V Cordless Lawnmower FX-E1RM20
18
