FUZRR ES1010 User manual

CONTENT
I.SafetyPrecautionsAndProcedures................................................................................3
IIIntroduction...........................................................................................................................4
IIIElectricalSymbols..............................................................................................................4
IVTechnicalSpecifications....................................................................................................5
VStructure...............................................................................................................................7
VI HostDisplayInterfaceDescription..................................................................................8
VIIOperation ...........................................................................................................................9
1. Switchofhigh voltagedetector.......................................................................................9
2. Switchofmain engine.....................................................................................................9
3. High-voltagecurrent , high-altitudecurrent , high -altitudeleakagecurrenttest....10
4. Lowvoltagecurrent, leakagecurrent test.....................................................................12
5. Phasevariation test........................................................................................................13
6. Datahold.......................................................................................................................15
7. Datastorage...................................................................................................................16
8. Dataaccess....................................................................................................................16
9. Datadeletion .................................................................................................................16
10. Dataupload.................................................................................................................16
VIII Battery.............................................................................................................................17
IXAccessories.......................................................................................................................17

I. SafetyPrecautionsAnd Procedures
Thankyou forbuying ourwireless highvoltage ratiotester. Inordertoavoid possible
electrical shockorpersonalinjury,pleasebesure:strictlyabide bythe safetyrules
and precautions listed inthismanual.
lCheckwhether theinstrumentisingood conditionbeforeuse,nobreakage,no
useofthebackcover beforecover,otherwisethereisadanger of electricshock
lUnder anycircumstances,usethisinstrumentshouldpayspecial attentionto
safety, especiallywhen measuringvoltage linesaboveAC100V andabove.
lIfthelinevoltage exceeds 600v, theinsulation rod must beconnectedtouse
lBecausehighvoltage linesare dangerous,operatorshavetobe trained strictly
and get relevant fromthecountry
lHigh pressureOperationAuthenticationcanbeusedtocarryoutField Testwith
thisinstrument
lItisstrictlyprohibited tousethisinstrumenttotestbareconductorsorbusbars
withvoltages exceeding 60kv.
lNotethestickersand symbolson thepanel andbackof thisinstrument
lDonotplaceandstore instrumentsfor long periodsoftimein hot,wet, dewy
places orunder direct sunlight
lWhenhighvoltage currentclampdisplayslowpower,pleasereplacebatteryin
timetoavoid affecting operation
lDisassemblyand maintenanceofthisinstrument must beoperatedbyauthorized
personnel
lCheckthehousingbeforeusingthemeter.Checkfor cracksor lackofplastic
parts.Iftheclamphead andother partsofthisinstrumentaredamaged,please
do not use
lAvoid impact clamphead,maintain thisinstrumentregularly,do notcleanwith
corrosivesor coarseproducts,usesoftcloth(suchasspectacle cloth),clean
antirustanddehumidificationlubricant, gentlywipe testinstrument
lIfitisdangeroustocontinueusingthisinstrument, itshouldbestopped
immediatelyand sealed immediately, and handledbyan authorizedorganization
lThe""hazard sign on the instrumentandmanual,theusermustfollowthe
instructionsforsafeoperation
lThe extremelydangerous""signintheinstrumentandmanualmustbe used
in strictaccordancewiththeinstructions.
lIt isrecommended thatthe instrumentconduct atleastone insulationstrength
test per year. (Ac60kv/rms between thetwoends oftheinsulation rod).

II Introduction
Wireless highand lowvoltage ratiotesterisalsocalledhigh and lowvoltage CT
wireless ratiotester.Itiscomposedofhigh voltage detector,lowvoltage current
clamp,mainengine,highvoltageinsulationrod,monitoringsoftware and
communicationline.Theinstrumentadoptsfast digitalcircuitprocessing technology.
Itcanconnect insulationrodstomeasure high-voltage current transformers,primary
transformers, high-voltage primarycurrent,low-voltage secondarycurrent,and can
be calculatedunderthecondition ofnotdisconnecting orpowering on site.Change
ratio, phase,polarity, and ratioerror below60kV
Whennotusingtheinsulationrod,itcanalsobeusedasahigh-precision
low-voltage clampammeter,leakage currentmeter,canaccuratelymeasure the
currentof0.1mA,it hasthecharacteristicsof easytouse, easytocarry.
Itswirelesstransmission functioncanreceivemeasureddatawithin 30meters
(withoutobstacles)in astraight line, ensuringhighprecision,highreliability,andhigh
stabilityforcontinuoustesting withoutinterruption.
The hostusesalarge-screenLCD display,featuringsmallsize,lightweight,and
portability. It can save500 groupsdata.
High-voltage currentmeasurementrange of0.0mA~1200A,low-voltage current
measurementrangeof0.0mA~20A.High-voltage detectorcurrentsignalusing
wireless transmission technology,connecting the insulation rod,through thepushor
pull backthe insulation rod caneasilyclampor evacuation ofthe measuredwire,
savetimeand fast.
Can be widelyused insubstations,power plants,industrial and mining
enterprisesandtestingstations,electricalmaintenancedepartmentsforcurrent
detectionand fieldelectrical work.Insulation rodsare light,moisture-proof,
high-temperatureresistant,impact-resistant,bend-resistant,andhighlyinsulating.
III Electrical Symbols
SymbolMeaning
Dangerousvoltage (shockhazard)
Warning attention safetysign
ComplywithEUCommunitySafetyStandards
Alternatingcurrent(AC)
Direct current(DC)
Battery, when indicated,indicates lowbattery

IVTechnical Specifications
Tester Highvoltagedetector Mainframe(current clamp)
Range 0.0mA 1200A（50/60Hz
Auto）0.0mA 20A
Resolution 0.1mA 0.1mA
Jawsize φ50mm φ7.5mm
Accuracy ±2%±5dgt ±0.5%±5dgt
Sampling
Rate 2times/second
Function
High-
lowvoltagecurrenttransformerprimaryandsecondary
loop current, transformation ratio,polarity,phase, and
on-
linetest;currentandvoltageratioonbothsidesof
transformer; on-line test; load current test
Transmission
type Wireless transmission, linear transmissiondistance 30m
Changegear
Fullyautomaticshift
Power DC6V7#alkalinebattery
（1.5VAAA×4）DC7.5V5#alkalinebattery（1.5VLR6×5）
Testmethod
ClampCT
Dimensions W/T/H87*37*262mm Host：W/T/H 100*35*204mm
Currentclamp：W/T/H42*20*137mm
Display
mode LCD：128dots×64dots Blue screenbacklight fordimplaces
LCD Size 62mm×44mm
Change
ratio
Threekindsoftransformationratio display:(Theprimaryand
secondarycircuitactuallymeasuredthecurrenttransformation
ratio; the conversionratioof thesecondarycircuit 5A;
10kV-
YYtransformerconversionratioof10kV/380V),the
maximumratioof1:1 million
Line voltage
Linetestwithinsulationsheathbelow60kVorbarewirecurrent
testbelow35kV (withinsulation rod operation)
Leadlength Currentclamplead2meters

Weight
Totalinstrument weight：3.1Kg（Insulatedrodand instrument package）
Highpressuredetector：370g（Including battery）
Host：409g（Including battery）
Currentclamp：180g
Data
interface USB transmission
Overflow
display Over-rangeoverflowfunction:"OLA"symbol display
Datastorage
500groups,press MENU tokeepdata, HOLD symbol display,press MENU
again to cancel
Data review
Long press the MENU
buttonto enter the datareference mode,
MR symbol display,press MENU againtoexit
Datais full Datafullfunction: "FULL"symbol display
Switch
display mode
Longpressthe POWER buttontoswitchbetweenthetestdisplaymodeand
theconversion ratio displaymode
No signal
indication
Whenthehostdoes notreceive thetransmitsignal, it prompts
"no signal"
Automatic
shut-down
About15 minutesafter power on, the meterwill automatically
shutdown
Battery
voltage
Whenthebatteryvoltage
dropsto3.5V,the
low-powerindicatorlights
to remind you toreplace
thebattery
Whenthebatteryvoltagedrops to 5.2V,the
batteryvoltageis low symbol to remind to
replace thebattery
Insulation
rod Fivesectioninsulationrod(5meters)
Insulation
strength AC60kV/rms
Line test Insulation sheathwiretestbelow60kVlinevoltage,bare wiretest below
60kV(with insulation rod operation)
Working
temperature
-10℃ 40℃
Storage
temperature
-10℃ 60℃
Relative
humidity 0℃ 31℃≦75%，31℃ 40℃≦50%
Suitablefor
safety
regulations
IEC1010-1 、IEC1010-2-032、Pollutiondegree2、CAT Ⅲ(600V)
IEC61326(EMC standard)

VStructure
HighpressureHostLow voltage Insulation
Detectorsecondary rob
current
clamp
No. instruction
Clamphead
②LEDpower indication
③LEDlowbatteryindication（Lightswhenthepower supplyisbelow3.5V）
④POWERbutton
⑤Insulation rodconnector
⑥USB interface
⑦HostLCDdisplay
⑧HostLEFTbutton
⑨HostRIGHTbutton
⑩HostMENU button
HostPOWERbutton
⑫
Low-voltagecurrent inputinterface
⑬
Low voltage current clamp
⑭
Low voltage current clamp output plug
⑮
Insulation rod(5metersintotal)

VI HostDisplayInterface Description
StatussymbolInstructions
Whenthehighvoltagedetectorisofforthere is no signal, nosignal
is displayedintheprimarycurrentdisplayboxofthehost
Whenthehigh voltagedetectorisout ofrange, OLA willbe
displayedintheprimarycurrent displaybox ofthemain unit
Whenthehost detectsthecurrentexceedstherange,OLAdisplays
in thehost'ssecondarycurrent displaybox
PresstheMENU buttontolockthedisplaydata.Thedatais
automaticallystored.Tol:001indicatesthatatotalof01 setsofdata
are currentlystored.Thesavedprimarycurrentis25.0A,the
secondarycurrent is 1.00A, the5Aconvertedcurrentis125, andthe
phaseis thesameas ⊕
Whenthestoreddatais full of500 groups,the"FULL"symbol
flashesand canno longer bestored
Dataclear symbol,displayedduringclearing
Whenthenumber ofstoragegroups is 0,theNULLsymbol flashes
whentheMENU buttonis pressedforalongtimeto enter the
reference mode.
Inthelookupmode,thenumber after MRindicatesthenumber of
groupscurrentlyviewed,and thenumberafterTolindicatesthetotal
number ofgroups saved
Longpress POWERbutton toswitchtoconversion ratiodisplay
interface
Whenthepowersupplyvoltageislowerthan5.2V,whenthelow
voltagesignappearsin thelower leftcorner,pleasereplacethe
batterypromptly.

VII Operation
Beforeusingthetester,examine whether thereisanypartbroken;if
no, itcanbeput intouse.
Install thebatteryaccordingtothe manual.
1. Switchofhigh voltagedetector
Pressthe POWERbutton toturnon the POWERindicator light,the high
pressuredetectorstartsautomaticdetection,andthe testresults(thecurrent
level and pulseofthe high voltage side) aresenttothehostthrough wireless
transmission.Thehigh-voltage detector turnsoffautomaticallyafterabout15
minutes toreducebatteryconsumption.
Innormal testmode, press thePOWERbuttontoshutdown.
2. Switchofmainengine
PressthePOWERbuttontoturnon,LCD display, the hostentersthetest
receiving mode afternormalbooting (asshownin Figure 1),theprimarycurrent
isthetest dataofthehighvoltage side,thesecondarycurrent isthetest dataof
the lowvoltage side,Iftheprimaryand secondaryloopsbothdetect the signal,
the master will displaythe ratio ofthesecondaryloopat5Aconversionand
indicatethephasedifference.If themastercannotidentifythe phaseofthe
primaryand secondaryloops normally,the “Er”symbol will be displayed (as
shownin Figure2).
Figure1Figure2
About10minutesafterthemain unitisturnedon,theLCD will continue
flashing,indicatingthattheLCD will automaticallyshutdown.TheLCDwill
continuetoflashforapproximately30 secondsbeforeshuttingdownautomatically
toreducebatteryconsumption.IftheLCD continuestoflash,pressanykeyand
the hostcontinuestowork.
If theconversionratio coefficientislarge,the primaryloop currentislarge,
the secondaryloopcurrentissmall,andthe transformation ratiocoefficient
exceeds1000000,whichisdisplayed as “x.xxK6”(x.xx×106),the number of
pointsbehind Kisseveral timeson the10th,,ofcourse,normal runninglineswill
notshowthissituation
Inthe test mode, press thePOWERbuttonbrieflytoshut down.Long press

thePOWERkeytoswitchbetween the test interfaceand theconversion ratio
displayinterface.
Intheconversionratiodisplayinterface, longpresstheMENU buttontoset
the conversion ratiovalue,setbythe LEFTbutton and the RIGHTbutton,long
presstheMENU buttontoexitthesetting ratio.
Intestmode,shortpressMENU tolockandsavedata.PresstheMENU
buttonforalongtimetoenterthereferencemode.PresstheLEFTbuttonor the
RIGHTbutton toviewthe data.Pressand hold theMENU button toexitthe
referencemode.
Inthetestmode,press thePOWERbuttonshortlytoenterthedelete
interface,selectYesorNobypressingtheLEFTbuttonortheRIGHTbutton,and
pressthePOWER buttontoconfirmtheselection.
PressPOWER tostartthe engine,andLCD displays. After the normal startup,the
main enginewill entertestreceiving mode (seethepictureabove).Theprimary
currentisthetestingdataofhigh-voltage terminalwhile thesecondarycurrentthe
low-voltage.Incasethatsignals aredetectedinbothprimaryand secondarycircuits,
the mainenginewill showthetransformation ratiosonthebasisofsecondarycircuit
bearing current5A,and indicatephase.If in phase，itshows"⊕"symbol；ifoutof
phase,itshows"Θ"symbol,ifthephasecantbeproperlyidentified,itshows"Er"
symbol.
Iftransformationratioistoohigh,whichmeansthatthe currentvalue inthe
primarycircuitislarge while itinthesecondaryissmall,theratiosurpasses
1000,000,i.e. “x.xxxK6”(x.xxx×106)isdisplayed,thenumeral value behind “K”
meansthe power of10.Ofcourse,thisphenomenon will notoccur in the normal
operational circuit.
Intest mode,press POWERkeytoshutdown.Andlongpress POWERkeyto
the ratiomode.
3. High -voltagecurrent, high -altitudecurrent,high -altitudeleakage
currenttest
High voltage,verydangerous！Nobodybutaqualifiedpersonnel
aftertraining could conduct operation on it.Theoperatorshould
obeysafetyregulations;otherwisetherewill bethedangerof
electricshock resulting inpersonalinjuryor casualty.
Dangerous!Itisnotallowabletotestbarewiresor busbarswhose
voltageexceeds60kV;otherwise therewill bedangerofelectric
shock resulting inpersonalinjuryorcasualty.
Dangerous!Itisnotallowabletodetect thehigh currentwire
above1200A.Otherwise therewill bethedangerofelectricshock
resulting inpersonalinjuryor casualty.

Priortothedetection, havetheinsulationbarsconnected
properly,finallyhavethedetectorconnected,and take careto
avoidanyground impacton theinstrument.
Nothing butthespecial-madeinsulation barscouldbeconnected
totheinstrument.
Afterthedetection,collecttheinsulation rod inslantdirection,
firsttake apartthedetector,thentheinsulation bars,and take care
toavoidground impact on detector.
The high-voltagedetectorisconnectedtotheinsulating rod.Afterthe
normal power on,letthe wire bein themiddle ofthe guide area oftheclamphead.
The instrumentguide areaisperpendiculartothewire.Pushthemetertoclamp
thehighvoltagetesterofthemeasured wire tostartthetest andsendthetest
resulttothehost.The host automaticallyentersthedetection receiving stateafter
the normal power on.Ifthehostreceivesthe signalsentbythe high voltage
detector,thecurrentvalue oftheprimaryloop ofthehighvoltage sideis
displayed in real time.Ifthe hostdoesnotreceivethe signal sentbythe
high-voltage detector,theprimarycurrentis “nosignal”.If thehostdisplaysa
currentvalue of “OL”,itindicatesthatthecurrentmeasured exceedstheupper
limitofthehigh-voltagedetector.Afterpullingback,the instrumentcanbe
evacuated fromthetestedwire.When evacuating,theinstrumentguidearea
shouldbekeptperpendiculartothewire (asshownin Figure 3).
wire
PushPull
Figure3

The testmethod forhighand lowvoltage currentsis shownin Figure 4.
Notice:Forthesake ofsafety,please take theinstrumentaway
fromthewireafterthedetection isfinished.
High current,high currentleakagecanalsobetestedwiththis
instrument.
4. Lowvoltagecurrent,leakagecurrenttest
High voltage,verydangerous！Nobodybutaqualifiedpersonnel
aftertraining canconduct operationon it.Theoperatorshould
strictlyfollowthesafetyregulations;otherwisetherewill bethe
danger ofelectricshock resulting inpersonalinjuryorcasualty.
Lowvoltagecurrentpliersarenotallowabletodetecthigh voltage
wireabove600Vor10A;Otherwise,thereisadangerofelectric
shock that maycause personalinjuryor equipmentdamage.
1）Connectlowvoltage currentpliersand mainset, turnthemainseton,enterthe
detectionmode.
2）Havelowvoltage currentpliersclampthe wire(notice:itworkholdingjawsis
fullyclosed),examine thecurrentnumericalreading,iftheinstrumenthas
secondarycurrentindicationof “OL”,the secondarycurrentexceedsinstrument
upper currentlimit.
3）Refertothe legend (Figure5, Figure 6)
Theliveandneutralwires areclampedtogethertomeasurethe
leakagecurrentoftheelectricalequipment. (payattention to2)
Clamptheground wiretomeasuretheleakagecurrentofthe
grounding wireoftheelectrical equipment. (note:singlewire)
Clampthemainline,totalcurrentamountcouldbemeasured.
(note:singlewire)
Whereitsnumeralreading isnoteasilyaccessible,use high
voltagedetector toexaminethecurrenton lowvoltagewire.

5. Phasevariationtest
【Primarycurrent】:The currentcollected withhigh voltage current
pliersis mutual inductor sfirstcurrent
【Secondarycurrent】:The currentcollectedwithlowvoltagecurrent
pliersis mutual inductor ssecondarycurrent.
【Rationbased onsecondarycurrent5A】:The measured secondary
currentvalue isconverted tobe 5A,and thenconvertthe firstcurrent
basedonthatmultiple,whichis samewithtransformationratio.Display
【XXX/5A】
【Ratio】:The ratiobetween thefirst currentandsecondarycurrentby
actual measurement.
【10kV-YYconversion ratio】:highvoltage detectorcollectsthe
secondarybuscurrent,theratiobetween transformer sfirst current
and mutualinductorsecondarycurrentcould becalculated by

transformer10kV/380V
【】Phasedifferenceisabout0°to30°or 330°to360°,
whichispositivepolarityin phase
【】Phasedifferenceofabout150 °~210 °;isthe same
negativepolarity,thatis,the currentclampreversed ofthe firstor the
second ,thesamephasepolarityisopposite(highvoltage detector's
bootfrontand lowvoltage currentclampred markingpointisthe
currentinputendofthesamedirection)
【异】Thephasedifferenceisabout ±120°or ±60°outofphase.
The first andthesecondarycurrentclampdonotclampthesame
phasecurrent line.
【Er】Can notbeidentified normally,thehostmaynotreceivethe
high-lowvoltage signal normally,mayinterfere withthe samefrequency
signal,thesignal amplitudemaybe toosmall,etc.
The high-voltage detector and the low-voltage currentclampare respectively
clamped onthe firstandthesecondarycircuitoftheCT.The hostdisplaysthe
currentofthefirstandthe secondarycircuit(asshownin Fig.7),and
simultaneouslydisplaystheconvertedratioof5A,ifthe primarycurrentis
25.0A.thesecondarycurrentis1.00A,the actual currentratio is25,the
conversionratioofthesecondaryloopcurrentis5Ais125/5A,(ie:5÷1×25),
accordingtothe transformer 10kV/380V tocalculatethetransformerprimary
currentand transformer secondarycurrentratio is:0.95,((25 ÷(10kV ÷
380V)).
Figure7,test displaymodeFigure8,conversion ratiodisplaymodee
Inthetestmode,press andholdthePOWERbuttonforabout3secondsto
entertheconversionratiodisplaymode(asshownin Figure 8):Thecurrentvalue
oftheprimaryand secondaryloopsisautomaticallydefaulted totheconversion
ratioofthesecondaryloop 5A;themeasuredratioandphasedifferenceofthe
primaryand secondaryloop currents,and the phasedifferenceisabout0°to
30°or330°to360°.whichisconsideredtobe the positivepolarityofthe
samephase;10kV-YYisthe conversionratio.PressthePOWERbutton againfor
about3secondstoexittheconversion ratio displaymode andreturn tothe
power-on testmode.
Inthe conversion ratio displaymode,pressand hold the MENU button for

about3secondstoentertheinterfaceforsettingthe secondaryconversion
currentbase.PresstheLEFTbuttonand RIGHTbuttontoadjustthe basevalue
of theconvertedcurrent. Press andholdtheMENU buttonforabout 3seconds to
exittheconversionratiodisplaymodeandreturntothepower-ontestmode.
Eachtimetheinstrumentispoweredon,thesecondarycurrentisconverted to5A
bydefault.
Referencelegendforcomparisonratiotests, asshowninFigure9and
Figure 10
Figure9
Figure10
6. Dataholdand delete
Inthe normaltest mode,afterpressingtheMENUkeyforashorttime,the
LCD displaycan bemaintained.The “HOLD”symbol indicatesthattheMEM
flashesonceandthe measured currentdataismaintained.Press theMENU
buttonagaintoreleasethe datalock and return tothe test mode. The “HOLD”
symbol disappears.
7. Datastorage
Inthenormaltestmode,when the MENU keyispressedbrieflytohold the

data,themeter automaticallynumbersandstoresthe currentlyheld data.The
“MEM”symbol blinksonceduringthestorage process.Theinstrumentcan
store 500setsofdata.Ifthememory isfull,the “FULL”symbol will continueto
flash,andthememorymust beclearedbefore itcanbestoredagain.
8. Dataaccess
Innormaltest mode,pressandholdthe MENUbuttonforabout3secondsto
enterthedatareviewmode.Ifthenumber ofstoragegroupsis0,thescreen
flashes"NULL"andreturnstothe testinterface.If the number ofstorage groupsis
not0,the"MR" symbol isdisplayed onthescreenandthestored01stgroupdata
is automaticallydisplayed.The stored datacan be scrolledup or downbypressing
theLEFTbuttonortheRIGHTbutton,and thefirst setofdataisautomatically
returnedwhen thestored lastset ofdataisscrolled.
Scrollingoperationsinclude:long pressthe LEFTbutton (-10),long pressthe
RIGHTbutton(+10),shortpresstheLEFTbutton(-1),shortpressthe RIGHT
button(+1).
Inthe datareferencemode,pressandhold the MENU buttonfor about3
seconds toexitthedatareferencemodeandreturn tothetestmode
9. Datadeletion
Inthedatareferencemode,press thePOWERbuttonbrieflytoenterthe
deleteinterface.SelectYesor NobypressingtheLEFTbutton ortheRIGHT
button. Press the POWERbuttonshortlytoconfirmthe selection andreturntothe
test mode.
10. Dataupload
ConnecttheRS232communicationcable between thecomputerand thehost
computer,turn onthe detectorandrun themonitoring software.Ifthe software
showsthattheserial portisopenandtheconnectionissuccessful,thestored
historical datacanbe read,uploadedtothecomputer andsaved.
The monitoring software hason-line real-timemonitoring and historicalquery
functions,dynamicdisplay,withthemaximum,minimum,average indication,
alarmvalue settingandalarmindicationfunction,withhistoricaldatareading,
viewing, saving, printingand otherfunctions.

VIII.Battery
Caution! Nodetection could beconducted when thebatterycover isnot
properlyclosed,otherwisethereisdanger.
Payattentiontobatteryelectrode,otherwiseitwill doharmtothe
instrument.
Can notmixold andnewbatteries.
1.When the batteryvoltage ofthereceiving instrumentislower than 5.2V,the “”
symbol isdisplayed in thelower leftcorner of the instrument,indicating that the
batterypower is insufficient. Pleasereplacethebatteryin time.
2.Power off,confirmthattheinstrumentisshutdown.Open the batterycover and
replacewithnewqualifiedbatteries.Paying specialattention tothesizeand
electrode,closethebatterycover,coverthebatterycover.
3.PressthePOWERbutton tocheckwhether the meter can bootnormally.If it
cannot bestarted,pleasefollowthe secondsteptorestart..
IXAccessories
High voltage detector 1 PC
Main set 1PC
Lowvoltage currentpliers 1PC
Insulationbar 5PC(5 meter
Instrumentbag 1PC
High voltage detector (battery)DC6V 7
alkalinebattery 4section
Host(battery)DC7.5V5alkaline
battery 5section
Manual/warrantycard/certification 1set

The contentsofthisusermanualcannot be used asareason tousethe product for specialpurposes.
The companyisnot responsiblefor other losses caused byuse.
The companyreserves therighttomodifythe contentsofthe usermanual.Ifthereisanychange,itwillnotbe
notified.
GuangZhou ZhengNeng ElectronicsTechnologyCo.
Address:2F, No.15 Baoshu Road, Taihe, Baiyun District,Guangzhou, Guangdong, China
Toll-free call：4000-1515-38
Tel：[phone]
Fax：[phone]
Post：510540
WebSite：www.znele.com
