FWE P Series User manual

HEATED HOLDING CABINETS
“P” SERIES: Banquet Servers
“UHS” SERIES: Universal Servers
“TS” SERIES: Tray Servers
“PS” SERIES: Pan Servers
“TS PIZZA” SERIES:
16'' Pizzas Open/Boxed/Pan
TM
MOBILE HUMI-TEMP CABINETS
OPERATING
INSTRUCTIONS

FWE MOBILE HUMI-TEMP CABINETS
Heated Holding Cabinets:
Keep food hot, moist and “oven fresh” longer!
2
TS-1633-14L
with optional
see-thru door
P-200
Banquet Cabinet UHS-12
CONGRATULATIONS...
...and thank you for purchasing an FWE Mobile “HUMI-TEMP” serving
cabinet. Your unit has been designed and manufactured under rigid
controls to assure you the most efficient service. It is a full time unit,
and may be used continuously.
Please take a moment to read through this booklet of important
information pertaining to your cabinet. By following a routine of
proper use and care described on the following pages, your cabinet
will last for many years.
IMPORTANT: Your Manufacturer Registration Card must be
returned within 30 days after initial delivery to activate the warranty.

3
FWE MOBILE HUMI-TEMP HEATED HOLDING CABINETS
SERIAL AND MODEL NUMBER
INSTALLATION AND CLEANING
UNPACKING
These numbers are found on the nameplate (serial tag) affixed
near the electrical cord portal. Please record them in this
booklet, in the space provided on page 5. When ordering
parts and/or service, you will need to provide this information.
The voltage and amperage of the unit are also stamped
on the serial tag.
After uncrating your cabinet, remove all tape and padding
which held all doors, shelves, racks, cord, etc., in place during
shipment.
Keep your cabinet clean by simply wiping the interior and
exterior, as needed, with a damp cloth or sponge and a
mild soapy solution.
NEVER USE ABRASIVES, ACIDS, OR
STRONG CLEANERS.
Do not flood or allow electrical parts to become wet.
The interior tray slide assemblies and humidifier pans
are removable for easy cleaning. A stainless steel
cleaner/polish is recommended for the exterior to
maintain a "like-new" appearance.
DO NOT USE WAX OR STRONG CLEANERS ON
DOOR GASKETS OR VINYL TRIM.
CLEANING

4
FWE MOBILE HUMI-TEMP HEATED HOLDING CABINETS
WARNINGS AND CABINET CARE
FWE HUMI-TEMP models operate on 110/120 volt, 60 Hz, 1 ph,
A.C. (unless ordered otherwise), and are equipped with a three
prong grounding cord plug for your protection against possible
shock hazards. Be sure to plug only into a properly grounded
three prong wall receptacle. If you have any questions with
regard to adequate wiring or grounding in your building, a
qualified electrician should be contacted before using your
cabinet.The amperage of your cabinet is stamped on the
name plate attached to the unit.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR REMOVE
THE GROUNDING PRONG FROM THE CORD PLUG.
WARNING: ONLY A QUALIFIED ELECTRICIAN SHOULD
ATTEMPT TO REPAIR OR REPLACE ELECTRICAL
COMPONENTS OR WIRING.
BE SURE THAT MODEL IS UNPLUGGED FROM ELECTRICAL
SOURCE BEFORE REMOVING CONTROL PANEL.
ELECTRICAL REQUIREMENTS AND GROUNDING
WARNING:
THE WATER PAN, AIR TUNNEL AND HEATING ELEMENT ARE
HOT WHEN CABINET IS IN USE AND COULD CAUSE INJURY.
USE CAUTION WHEN LOADING AND UNLOADING -
PROTECTIVE GLOVES ARE STRONGLY RECOMMENDED.

FWE MOBILE HUMI-TEMP HEATED HOLDING CABINETS
SERVICE RECORD
Model Number ______________________
Serial Number ______________________
Date of Purchase ____________________
Notes:
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
___________________________________________________
5

GENERAL OPERATING INSTRUCTIONS
PREPARING THE CABINET BEFORE LOADING FOOD
6
PLUG CABINET INTO OUTLET, MAKING SURE THAT IT
IS A PROPERLY GROUNDED POWER RECEPTACLE.
The red indicating light will come on and remain on until
the unit is unplugged.
FILL THE HUMIDIFIER PAN WITH HOT WATER. This pan
is located on the inside bottom of the unit, and pulls out
from the tunnel cover protecting the heating element.The
entire pan is removable for ease of cleaning and filling.
Fill this pan with HOT water prior to heating the cabinet.
This will allow the heating system to condition and add
humidity to the cabinet’s air and help prevent your food
from drying out and shrinking. NOTE: If dry heat is desired
(no humidity), simply drain the water out of the pan.
SELECT A TEMPERATURE SETTING. For most foods,
a holding temperature of 150°F - 160°F should be
adequate. By keeping the water pan filled and the
thermostat set at @ 150°F, a normal (40%) humidity
level will be achieved. PRESS POWER SWITCH TO
“ON” POSITION TO ACTIVATE HEAT.
PRE-HEAT CABINET FOR 15-30 MINUTES. When the
amber light goes off, the unit has reached the temperature
which you selected in step 3, and is ready to load with
your HOT foods. NOTE: the amber light goes on and off
as the heating element cycles on and off. Plates may be
heated in the cabinet before dish-up, but this will require
extra pre-heat time. AVOID PUTTING YOUR HOT FOODS
INTO A COLD CABINET! By pre-heating the unit 20-30
minutes before each use, you can be assured of
maintaining the temperature and obtaining the best
results from your cabinet.
1)
2)
3)
4)

7
LOAD THE CABINET. During the loading procedure,
keep the doors closed as much as possible. After
loading is completed, do not open doors again until
you are ready to serve.
TRANSPORTING HOT FOODS. Your cabinet is
equipped with a positive transportation latch to assure
safety during transportation. Before moving the cabinet,
keep it plugged in and wait until the amber cycling light
goes off.This recovery takes only a short time, and
allows the internal temperature to again reach the
setting you have selected. As soon as the cycling light
goes off, unplug the cabinet and wheel to serving area.
Plug the cabinet into an electrical outlet at the serving
location (if available), so that the thermostat will
re-activate and automatically hold your pre-selected
temperature.
CAUTION:
HOLDING FOOD AT TEMPERATURES OF
LESS THAN 140°F MAY BE DANGEROUS.
TEMPERATURES UNDER 140°F
PROMOTE THE GROWTH OF HARMFUL
BACTERIA ANDTOXINS IN SOME FOODS.
5)
6)
GENERAL OPERATING INSTRUCTIONS
LOAD HOT FOOD INTO A PRE-HEATED CABINET

TROUBLE-SHOOTING CHART
Check this list first before you call for service...
8
PROBLEM POSSIBLE CAUSE REMEDY
TEMP
TOO
HOT
TEMP
NOT
HOT
ENOUGH
NO HEAT
AT ALL
1 A] Adjustable thermostat
set too high
1B] Thermostat needs
re-calibrating**
2A] Opening door unnecessarily
2B] Thermostat set too low
2C] Cord plug pulled out from outlet
2D] Fuse blown - no power to outlet
2E] Thermostat out of calibration**
3A] Cabinet not plugged into outlet
3B] Thermostat knob at “ OFF ”
3C] Rocker switch at “ OFF ” position
3D] Fuse Blown - no power to outlet
3E] Thermostat needs replacing
3F] Heating element burned out*
1A] Set thermostat at a lower temperature
(no lower than 140°F).
1B] Loosen screw in thermostat knob and remove knob.
Adjust set screw in hollow stem with small blade
screwdriver by turning CLOCK-WISE.
1/4 turn lowers temperature approximately 10°F.
DO NOT REMOVE SET SCREW.
2A] Keep door closed and latched shut
as much as possible.
2B] Set thermostat at a higher temperature.
2C] Replug cord into proper outlet.
2D] Have a qualified electrician check power
and fuse box.
2E] Loosen set screw in thermostat knob
and remove knob. Adjust set screw in hollow stem
with small blade screwdriver by turning
COUNTER-CLOCKWISE.
1/4 turn raises temperature approximately
10°F. DO NOT REMOVE SET SCREW.
3A] Plug cabinet into properly grounded electrical outlet.
3B] Adjust thermostat knob to temperature
setting required.
3C] Turn switch to “ ON ” position.
3D] Have a qualified electrician check power
to fuse box.
3E] Unplug cabinet from electrical source.
Loosen set screw in thermostat knob and remove
knob. Remove control panel, disconnect wires from
terminals on thermostat, and remove 2 screws
holding thermostat to control panel. Replace
thermostat with new one, and re-install control
panel and thermostat knob.
3F] Unplug cart from electrical source. Remove screws
holding heating element in place. Gently pull
element away from back wall a few inches to
expose wire connections. Disconnect wires, and
replace element with new one. Reconnect wires,
secure element with screws.
* * NOTE: CALIBRATION IS EXCLUDED FROM FWE WARRANTY.Thermostats on all units are calibrated at the factory
* * prior to shipping. Due to conditions in transit, beyond our control, occasionally units will need to be re-calibrated prior
* * to use.This is a simple procedure for which instructions are given above. (1B, 2E)
* Heating element will either function or not function. Only a slight warmth indicates a problem with the thermostat,
* not the element.

PARTS LIST
FWE PARTS DEPARTMENT: 815 459 7500
REPLACEMENT PARTS Part Number
Motor 115 volt MTR JK120 92
Motor 220 volt MTR JK220 93
Motor Mounting Bracket 4009
3'' fan blade BLD FAN AL
2.5'' fan blade BLD FAN 2.5B
Fan Guard GRD-FAN
Thermometer 100°F to 220°F / 40°C to 105°C T-METER H1
36'' Thermostat T-STAT-H1
Thermostat knob with black arrow KNB-H6 (With black arrow)
Indicator Light Amber/Green LT PLT A/G
Unlighted Rocker Switch SWH RCK E1
Terminal Block 3QC TRM3QC
Manual Control Panel with Components Z-600-1014
Cord and Plug for 15 amp Units CRDSET10/115
Strain Relief 7N-2 BSH STRN 3
Cord and Plug for 20 amp Units CRDSET20/115
Strain Relief 8P-2 BSH STRN 4
Edgemount Door Latch Non-Locking LTH-DR
Strike for Edgemount Door Latch STK LTH
Edgemount Door Hinge HNG 214
Edgemount Door Hinge Cover HNG COVER 214
Heated Door Gasket (Per Foot) GSKT DR
Sweep for dutch door units GSKT SWEEP
12.5'' Push/Pull Handle HDL 12.5 AL
21.5'' Push/Pull Handle HDL 21.5 AL
Push/Pull Handle Spacers SPCR125x330
Black Vinyl Bumper Insert Only BMPR INSERT
OPTIONAL ACCESSORIES
Digital Thermometer T-MTR DIG F
Food Sentry Control CNTRL HUMI-TEMP
Food Sentry Control Thermostat knob KNB-H7 (Without arrow)
CASTERS PART NUMBER
5" rigid CSTR 5 R-2
5" swivel with brake CSTR 5 SB-2
6" rigid CSTR 6R-5
6" swivel with brake CSTR 6SB-5
Other Replacement Parts are available.
Your Model Number and Serial Number are required when requesting Parts or Service.
These numbers are listed on your Serial Tag located by the power cord portal.
Heating Elements - Reference Electrical Data on Serial Tag
Model Serial Tag: Watts Volts Heating Element Part Number
Split Cavity - 2100 Watt 120v 1000 Watt EL 1000 / 115 HT
1250 Watt Standard 115v 1250 Watt EL 1250 / 115 HT
1250 Watt Standard 220v 1250 Watt EL 1250 / 220 HT
Upgrade 1500 Watt 115v 1500 Watt EL 1500 / 115 HT
Upgrade 1500 Watt 220v 1500 Watt EL 1500 / 220 HT
Upgrade 2000 Watt 115v 2000 Watt EL 2000 / 115 HT
Upgrade 2000 Watt 220v 2000 Watt EL 2000 / 220 HT
1500 Watt Standard 115v 1500 Watt EL 1500 / 115 A
1500 Watt Standard 220v 1500 Watt EL 1500 / 220 A
1600 Watt Standard 115v 1600 Watt EL 1600-115HT-XL-28
2000 Watt Standard 115v 2000 Watt EL 2000-115HT-XL-28
2000 Watt Standard 220v 2000 Watt EL 2000-220HT-XL-28
9

FWE MOBILE HUMI-TEMP HEATED HOLDING CABINETS
WIRING DIAGRAM
PILOT
LIGHT
T-STAT
BLACK
BLACK
POWER
CORD
SWH RCK
WHITE
WHITE
WHITE
ORANGE
BLACK
BLOWER
MOTOR
HEATER
TERMINAL BLOCK
WHITE
RED
RED
10

FWE / Food Warming Equipment Company, Inc. (Seller) warrants to the original purchaser,
subject to the exceptions and conditions below, that FWE manufactured equipment shall be
free from defects in material or factory workmanship, under ordinary use for the purpose for
which it is designed.The effective warranty period is as follows:
PARTS: Seller will furnish without charge to the original purchaser, FOB Sellers’ factory,
replacement parts for repairs to all new standard catalog products and factory custom /
modified units, which in Seller’s sole judgement, prove defective in materials or workmanship
under normal and proper use with the reserved right to request the return of any part claimed
to be defective, prior to issuing replacement part or authorizing warranty service, for a period
of two (2) years from date of original shipment from Seller’s plant,
except for equipment used
in a Correctional Environment / Facilities, which is warranted for a period of one (1) year
from date of original shipment from Seller’s plant.
LABOR: Seller’s labor warranty shall be performed by a Seller-approved Service Agency who
must contact Seller to obtain a Warranty Service Authorization (WSA) number prior to
performing any repairs. If service is required during overtime periods, the difference between
overtime and standard labor rates shall be paid by the purchaser.Seller does not assume any
responsibility for any charges not expressly authorized, incidental to the repair or replacement
of equipment covered by this warranty, nor charges exceeding, in Sellers sole judgement,
normal and customary amounts. Only approved travel charges will be allowed. Seller’s labor
warranty shall be from the date of original shipment date from Seller’s plant for a period of one
(1) year,
except for equipment used in a Correctional Environment / Facilities which is
warranted for a period of six (6) months.
This warranty is for normal usage and does not apply to any product or parts thereof that have
been misused, altered, or where Seller’s operating instructions or specific voltage is not
observed; nor shall this warranty apply to defective products or parts resulting from accident
following date of original shipment, nor extend to or cover removal, installation, reinstallation or
calibration, or service calls or cost of repairs undertaken by a customer. This warranty is also
subject to the following:
1.] Customer returning the warranty registration card, accompanying Sellers original
shipment, to Seller within thirty (30) days of receipt;
2.] Giving immediate notice of any allegedly defective part or product to Seller; and
3.] Customer, at Sellers request, returning said defective parts or product to Seller.
This is the sole warranty applicable to the merchandise.It is expressly understood that Seller’s
liability hereunder is limited to the repair or replacement, at Seller’s option, of products or parts,
defective materials or workmanship as provided above.Seller’s judgement as to the cause and
nature of any defect will be final.Seller shall in no case be responsible for special or con-
sequential damages or any other obligation or liability with respect to products sold by Seller.
This warranty, as stated above, applies to equipment installed in the Continental United States.
FWE equipment installed outside the Continental United States shall carry parts coverage
only. All labor costs are approved on a discretionary basis, based on like repairs in the
Continental U.S.This warranty shall stand in whole or in part as allowed by law. Any exclusion
of a part of this warranty, as may be allowed by law, shall not void balance of warranty.
This is a limited warranty pursuant to the Consumer Product Warranties Act, 15 U.S. Code. section 2303.
©2003 Food Warming Equipment Co., Inc.
FWE MOBILE HUMI-TEMP HEATED HOLDING CABINETS
LIMITED TWO YEAR WARRANTY
11

OpsManual_Humi-Temp © 2008 Food Warming Equipment Co., Inc. Printed in USA
FWE Parts Department:
815 459 7500 FAX:
815 459 7989
Errors subject to correction. All specifications
subject to change without notice.
©08 Food Warming Equipment Company. Inc.
The best designed . . .
The best built . . .
The best performing units on the market!
◊
◊
◊
◊
◊
◊
◊
◊
◊
Retherm Cabinets
Self-Propelled Transports
Heated Banquet Cabinets
Universal Bulk Food
Cabinets
Utility Carts
Refrigerators, Freezers and
Convertibles
Prisoner & Correctional
Tray Delivery
Hospital Tray Delivery Carts
Portable Bars and Back-ups
WE OFFER SALES AND SERVICE WORLDWIDE
Food Warming Equipment Company, Inc.
P.O. Box 1001
Crystal Lake, IL 60039-1001
Manufacturing Facilities:
7900 S. Route 31
Crystal Lake, IL 60014
